Head restraints
Seat and restraint systems 4-7
4
N00404300584
Padded head restraints for the seats can reduce the risk of a whiplash injury if your vehicle is hit from the rear. The head restraints are equipped in the illus-trated position. To maximize the effectiveness of your head restraint, adjust the front seatback to theupright position, the rear seatback to the nor- mal seating position, a
nd the head restraint to
the proper position. Sit back against the seat-back with your head close to the head restraint.
To reduce the risk of injury in an accident, adjust the head restraint height so that thecenter of the restraint is at your ear level when seated. Any person too tall for the restraint to reach their ear level when seatedshould raise the restrain
t to the highest locked
position.  To raise the restraint,
pull it straight up.
 To lower the restraint, push down on it while pressing the lock knob (A) in the direction shown by the arrow. After adjusting the height, push down on the restraint to make sure it is locked in position.
WA R N I N G After returning the seatbacks to their upright positions, make sure that the seat-backs are locked in place and firmly.Also check to be sure that the rear seat belts are in front of
the seatbacks, and not
caught behind the seatbacks.CAUTION Do not grab the seat be
lt guide to raise the
seatback; doing so can
cause damage of the
seat belt guide
and the seatback.
Head restraints
WA R N I N GDriving without the
head restraints in
place can cause you and your passengersserious injury or deat
h in an accident. To
reduce the risk of in
jury in an accident,
always make sure the head restraints areinstalled and proper
ly positioned when
the seat is occupied. In order to minimize
the risk of a neck
injury due to a rear impact, the front seat- back must be adjusted to the upright posi-tion, the rear seatback to the normal seating position, and
the head restraint to
the proper position
before vehicle opera-
tion. The driver shou
ld never adjust the
seat while the vehicle is in motion. Never place a cushion
or similar device on
the seatback. This can adversely affect head restraint performance by increasingthe distance betwee
n your head and the
restraint.
Adjustment of the head restraint height
BK0212400US.book 7 ページ ２０１４年４月１日　火曜日　午後２時２１分

Steering wheel height adjustment 5-32 Features and controls
5
When parking on a hill, set the parking brake, and turn the front wheels toward the curb on a downhill, or away from
the curb on an uphill.
N00511501254
To adjust the steering wheel to the desired position, move the lever upward or down-ward while moving the steering wheel to the desired level.
N00511600317
Adjust the inside rearview mirror only after making any seat adjustme
nts so as to have a
clear view to the rear of the vehicle.
To deactivate 1- Pull the lever up slightly. 2- Press and hold the button at the end of
the hand grip.
3- Push the lever downward.
CAUTION Before driving, be sure that the parking brake is fully released and brake warninglight is off.If you drive without the parking brake fully released, the warning lamp will illuminate and a buzzer sounds when the vehicle speedexceeds 5 mph (8 km/h). If a vehicle is driven without releasing the parking brake, the brak
es will be overheated,
resulting in ineffective braking and possible brake failure.
Steering wheel height adjustment
A- Wheel lock B- ReleaseWA R N I N G After adjusting, make sure the lever is secured in the locked (A) position. Do not attempt to adjust the steering wheel while driving. This can be danger-ous. When releasing the leve
r (moving it to the
position (B), be sure to hold the steering wheel firmly. Otherwise, the steering wheel may slip down too suddenly.
Inside rearview mirror
BK0212400US.book 32 ページ ２０１４年４月１日　火曜日　午後２時２１分

Alphabetical index 12-2
12
D
Daytime running lights
Bulb capacity
.................................
9-26
Defogger (rear window)
......................
5-80
Defrosting or defogging (windshield, door windows)
................................
7-10
, 7-16
Dimensions
........................................
11-3
Dimmer (high/lo
w beam change)
.........
5-76
Disc brake pads
..................................
9-20
Dome light
Bulb capacity
.................................
9-27
Door-ajar warning buzzer
....................
5-74
Door-ajar warning light
.......................
5-74
Doors
Lock
..............................................
5-24
Power door locks
............................
5-26
Driving during cold weather
..................
6-4
Driving, alcohol and drugs
.....................
6-2
E
Electric power steering system (EPS)
...
5-48
Electric rear win
dow defogger switch
...
5-80
Electronic immobilizer (Anti-theft starting system)
.....................................
5-3
, 5-20
Emission-control sy
stem maintenance
..9-19
Engine
Compartment
...................................
9-5
Coolant
...................................
9-7
, 11-5
High coolant temperature warning light
....
5-73 Hood
...............................................
9-4
Oil and oil filter
.......................
9-5
, 11-5
Overheating
.....................................
8-4
Serial number
.................................
11-2
Specification
...................................
11-4
Engine hood
........................................
9-4
Engine switch
.....................................
5-13
Error codes
.........................................
7-38
Exhaust system
...................................
9-21
F
Floor mat
.............................................
6-2
Fluid
Brake fluid
.....................................
11-5
Continuously variable
transmission (CVT)
fluid
......................................
9-9
, 11-5
Engine coolant
.........................
9-7
, 11-5
Manual transaxle
.............................
11-5
Washer fluid
............................
9-9
, 11-5
Fluid capacities and lubricants
..............
11-5
Free-hand advanced security transmitter (F.A.S.T.-key)
...................................
5-9
Front fog lights
Bulb capacity
..................................
9-26
Indicators
.......................................
5-71
Replacement
..................................
9-29
Switch
...........................................
5-77
Front seat adjustment
............................
4-3
Front side-marker lights
Bulb capacity
.................................
9-26
Replacement
..................................
9-28
Front turn signal light
Bulb capacity
.................................
9-26
Replacement
..................................
9-28
Fuel
Filling the fuel tank
...........................
3-3
Fuel economy
...................................
6-2
Fuel hoses
......................................
9-20
Fuel remaining warning display
.......
5-66
Fuel selection
...................................
3-2
Tank capacity
.................................
11-5
Fuel Pump Shut-off System
.................
8-20
Fuel remaining display
........................
5-66
Fuses
.................................................
9-22
Fusible links
.......................................
9-22
G
General maintenance
Maintenance
...................................
9-20
General vehicle data
............................
11-3
Genuine parts
.......................................
3-6
Glove compartment
...........................
5-108
BK0212400US.book 2 ページ ２０１４年４月１日　火曜日　午後２時２１分

Alphabetical index 12-4
12
Parking brake lever stroke
...............
9-18
Parking brake
............................
5-31
, 9-18
Parking lights
Bulb capacity
.................................
9-26
Replacement
..................................
9-29
Polishing
............................................
9-34
Power brakes
......................................
5-44
Power outlet
.....................................
5-106
Power windows
..................................
5-29
Puncture (Tire changing)
.....................
8-11
R
Radio
AM/FM electronically tuned radio with CD player
....................................
7-18
General information about your radio 7-42
Rear combination lights
Bulb capacity
.................................
9-26
Replacement
..................................
9-30
Rear seats
............................................
4-5
Rear shelf panel
................................
5-109
Rear side-marker lights
Bulb capacity
.................................
9-26
Replacement
..................................
9-30
Rear turn signal light
Bulb capacity
.................................
9-26
Replacement
..................................
9-30
Rear-view camera
...............................
5-60
Rearview mirror
Inside rearview mirror
.....................
5-32
Outside rearview mirrors
.................
5-33
Replacement of light bulbs
...................
9-26
Replacing tires and wheels
...................
9-15
Reporting Safety Defects
.....................
10-2
S
Safe driving techniques
.........................
6-4
Seat belts
.............................................
4-8
Adjustable seat be
lt shoulder anchor
.4-12
Child restraint systems
.....................
4-14
Front passenger seat belt warning light
.....
4-11 Maintenance and inspection
.............
4-20
Seat belt extender
............................
4-12
Seat belt force limitter system
..........
4-14
Seat belt instructions
........................
4-9
Seat belt pre-tensioners
....................
4-13
Seat belt use
during pregnancy
.........
4-12
Seats
...................................................
4-2
Front seats
.......................................
4-3
Head restraints
.................................
4-7
Heated seats
.....................................
4-4
Seats and restraint systems
................
4-2
Service brake
......................................
5-44
Service precautions
..............................
9-2
Side turn signal light
Bulb capacity
..................................
9-26
Snow tires
..........................................
9-17
Spark plugs
........................................
9-19
Starting the engine
..............................
5-36
Steering
Electric power steeri
ng system (EPS) 5-48
Steering wheel he
ight adjustment
.....
5-32
Stop lights
Bulb capacity
.................................
9-26
Replacement
..................................
9-30
Storage spaces
..................................
5-107
Sun visors
........................................
5-105
Supplemental Restraint System
............
4-21
How the Supplementa
l Restraint System
works
..........................................
4-23
Maintenance service
.......................
4-35
T
Tail light
Bulb capacity
.................................
9-26
Replacement
..................................
9-30
Tank capacity
.....................................
11-5
Tire
Inflation pressures
..........................
9-14
Maintenance
...................................
9-16
Quality grading
..............................
10-2
Replacing tires and wheels
..............
9-15
Rotation
.........................................
9-16
Size (tire and wheel)
.......................
11-5
Snow tires
......................................
9-17
