Calibration Test
Adjust tire pressure to standard value. Using a calibrated,
reliable speedometer tester, compare reading of vehicle speedometer to
speedometer tester. See SPEEDOMETER ALLOWABLE VARIATION table. Replace
speedometer if necessary.
SPEEDOMETER ALLOWABLE VARIATION TABLE
\
\
\
\
\
MPH (km/h) Allowable Variation MPH (km/h)
20 (32) .......................... 19-22 (31-35)
40 (64) .......................... 38-44 (61-71)
60 (97) ......................... 57-66 (92-106)
80 (129) ....................... 76-88 (122-142)
100 (161) ..................... 94-110 (151-177)
\
\
\
\
\
TACHOMETER
NOTE: DO NOT reverse polarity when installing tachometer, as diode
and transistor may be damaged.
Calibration Test
Connect a calibrated, reliable tach-dwell meter to vehicle
ignition system. Operate engine at various speeds (RPM). See
TACHOMETER ALLOWABLE VARIATION table. If comparison between tach-dwell
meter and vehicle tachometer readings do not fall in the standard
range of permissible variation, replace vehicle tachometer.
TACHOMETER ALLOWABLE VARIATION TABLE
\
\
\
\
\
Engine Speed (RPM) Allowable Variation (RPM)
1000 .................................. 900-1100
3000 ................................. 2850-3150
5000 ................................. 4750-5250
6000 ................................. 5700-6300
\
\
\
\
\
TEMPERATURE GAUGE
CAUTION: DO NOT connect sender wire directly to ground during test.
Circuit Test
Disconnect temperature sender wire from sending unit. Connect
a 12-volt, 3.4-watt test bulb between connector terminal and ground.
Turn ignition switch to ON position. If test bulb flashes and
temperature gauge needle moves, go to SENSOR RESISTANCE TEST. If test
light does not flash and gauge needle does not move, repair wiring to
sending unit.
Sensor Resistance Test
Remove thermosensor (sending unit) from engine block. Place
sending unit in hot water of 158
F (70C) temperature. Check sensor
resistance with an ohmmeter. Thermosensor resistance should be 90-117
ohms at 158
F (70C). If thermosensor resistance in okay, go to GAUGE
RESISTANCE TEST. Replace thermosensor if resistance is not as
specified.
Gauge Resistance Test
Remove instrument cluster from instrument panel. See
INSTRUMENT CLUSTER under REMOVAL & INSTALLATION. Measure resistance
between temperature gauge terminals at rear of cluster or combination
Page 670 of 1333
2.6L Engine ........................................... 45
2.6L Optional ......................................... 45
3.0L V6 ........................................... (1) 24
3.5L V6 ........................................... ( 1) 24
( 1) - Check hood clearance on 1986 and newer models.
\
\
\
\
\
\
CAUTIONS & WARNINGS
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM
NOTE: See the AIR BAG RESTRAINT SYSTEM article in the
ACCESSORIES/SAFETY EQUIPMENT Section.
The SRS has no user-servicable parts. Always have servicing
done by an authorized dealer.
When performing maintenance on air bag equipped vehicles
always observe proper safety precautions.
WARNING: To avoid injury from accidental air bag deployment, read and
carefully follow all warnings and service precautions. See
appropriate AIR BAG RESTRAINT SYSTEM article in the
ACCESSORIES/SAFETY EQUIPMENT section.
CAUTION: Disconnect negative battery cable before servicing any air
bag system, steering column or passenger side dash
component. After any repair, turn ignition key to the ON
position from passenger's side of vehicle in case of
accidental air bag inflation
ANTI-LOCK BRAKE SYSTEM (ABS)
CAUTION: Never mix different diameter tires. On loose or uneven
surfaces, the ABS system may require longer stopping
distances than conventional brake systems. Exercise caution
when removing mud or snow from the wheels so as not to
damage the ABS wiring or speed sensors.
BATTERY WARNING
WARNING: When battery is disconnected, vehicles equipped with
computers may lose memory data. When battery power is
restored, driveability problems may exist on some vehicles.
These vehicles may require a relearn procedure. See
appropriate COMPUTER RELEARN PROCEDURES article in the
GENERAL INFORMATION section below.
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off
all lights and accessories to avoid damaging the electrical system. Be
sure to use fuse with the correct indicated amperage rating. The use
of an incorrect amperage rating fuse may result in a dangerous
electrical system overload.
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning
that brake pads need replacement.
Page 676 of 1333
MAIN TE N AN CE R EM IN DER L IG HT R ESET P R O CED URES
1991 M it s u bis h i M onte ro
1983-96 MAINTENANCE
Chrysler Motors/Mitsubishi Maintenance Reminder Lights
Dodge; Challenger, Colt, Colt Vista, Conquest, Raider,
Ram-50
Eagle; Summit, Summit Wagon
Plymouth; Colt, Colt Vista, Sapporo
Mitsubishi; 3000GT, Cordia, Diamante, Eclipse,
Expo/Expo LRV, Galant, Mirage, Montero, Pickup, Precis,
Sigma, Starion, Tredia, Van/Wagon
EGR/MAINTENANCE REQUIRED WARNING LIGHT
1) On some models, an EGR or MAINTENANCE REQUIRED warning
light in dash will come on as a reminder to have EGR system serviced
(each 50,000 miles), oxygen sensor replaced (each 80,000 miles) or
evaporative carbon canister replaced (100,000 miles).
2) After servicing or replacing components, reset mileage
counter. On all models except 1987-95 Pickup and 1987-93 Ram-50, reset
switch is located on back of instrument cluster.
3) On 1987-95 Pickup and 1987-93 Ram-50, reset switch is on
lower right corner of instrument cluster, behind instrument cluster
face trim. Slide switch to other side to reset indicator light.
4) Remove warning light bulb after 150,000 mile servicing on
Colt Vista and Wagon. Remove bulb after 120,000 mile servicing on Ram-
50.
Fig. 1: Locating Warning Light Reset Switch (Colt Vista; Colt
Wagon is Similar)
Courtesy of Chrysler Motors.
Page 689 of 1333
FUEL SYSTEM PRESSURE RELEASE
WARNING: ALWAYS relieve fuel pressure before disconnecting any fuel
injection-related component. DO NOT allow fuel to contact
engine or electrical components.
1) On Colt and Mirage, remove rear seat cushion. On all
models, disconnect fuel pump harness connector at fuel tank.
2) Start engine. Let engine run until it stops. Turn ignition
off. Disconnect negative battery terminal. Connect fuel pump harness
connector.
FUEL PUMP
Removal & Installation
1) Fuel pump assembly is located inside fuel tank. Release
fuel pressure from system. See FUEL SYSTEM PRESSURE RELEASE. Raise
vehicle on hoist. Drain fuel into suitable container. Disconnect
electrical connectors and fuel hoses at fuel tank.
2) Remove fuel filler hose from fuel tank. Remove nuts
securing fuel tank. Remove fuel tank from vehicle and remove fuel pump
assembly. To install, reverse removal procedure. Tighten nuts to
specification. See TORQUE SPECIFICATION table.
FUEL RAILS & INJECTORS (PFI)
Use a rag to cover fuel hose connection before disconnecting
high pressure fuel hose at fuel rail. Some residual fuel pressure may
still be in system.
Removal (Except Pickup & Ram-50 2.4L)
1) On all models, relieve fuel pressure. See
FUEL SYSTEM PRESSURE RELEASE . Disconnect negative battery cable. On
Montero, Pickup, Ram-50, Stealth and 3000GT 3.0L, disconnect air
intake plenum. On Eclipse, disconnect PCV valve hose.
2) On Colt Vista, disconnect coolant temperature sensor
connector, idle speed control servo connector and brake booster vacuum
hose. On all models, disconnect high pressure fuel hose at fuel rail.
3) Disconnect fuel return hose. Disconnect vacuum hoses. On
Eclipse, Colt and Colt 200, disconnect throttle cable clamp. Remove
center cover. On all models, disconnect injector electrical
connectors. Remove fuel rail bolts and lift fuel rail and injectors
from engine.
Installation
To install, reverse removal procedure. Tighten bolts to
specifications. See TORQUE SPECIFICATIONS table.
Removal (Pickup & Ram-50 2.4L)
1) Relieve fuel pressure. See FUEL SYSTEM PRESSURE RELEASE.
Disconnect negative battery cable. Drain coolant. On all models,
disconnect air intake hose. Disconnect breather hose (if applicable)
and vacuum hoses.
2) Disconnect coolant lines as necessary for clearance.
Disconnect injector electrical connectors. Position all lines, hoses
and electrical connectors out of way. Disconnect throttle and/or
kickdown cables. Remove throttle body assembly and position it out of
the way.
3) Disconnect high pressure fuel hose at fuel rail.
Disconnect fuel return line and vacuum line connection at fuel rail.
Remove fuel rail bolts and lift fuel rail and injectors from engine.
Page 690 of 1333
Installation
1) To install, reverse removal procedure. Injectors may be
removed after fuel rail is removed from intake manifold. Use new
insulators and "O" rings when installing injectors.
2) Use spindle oil or gasoline on "O" ring. Install injectors
into fuel rail with a twisting motion. Adjust throttle and kickdown
cable (if applicable). Do not drop injectors while removing or
installing fuel rail.
OXYGEN (O2) SENSOR
Removal & Installation
1) O2 Sensor is mounted in exhaust pipe below exhaust header.
It is equipped with a permanent pigtail which must be protected from
damage when sensor is removed. Ensure sensor is free of contaminants,
avoid using cleaning solvents of any type. Sensor may be difficult to
remove when engine temperature is less than 120
F (48 C).
2) Always use anti-seize compound on threads before
installation. On non-turbo models, remove sensor using Remover
(MD998703). On turbo models, use Remover (MD998748) on Eclipse and
Galant, or Remover (MD998770) on Stealth and 3000GT. Tighten oxygen
sensor to specification. See TORQUE SPECIFICATIONS table.
THROTTLE BODY
Removal
Disconnect air intake hose. Remove accelerator and automatic
speed control cables (if equipped). Disconnect fuel vapor hose,
electrical harness connector, vacuum hose and coolant hoses. Remove
throttle body retaining bolts.
Disassembly
Remove throttle position sensor. Remove idle speed control
motor. Remove throttle bracket and connector bracket (if equipped).
Remove idle position switch and adjusting nut.
NOTE: DO NOT remove throttle valve. DO NOT use cleaning solvents
on throttle position sensor, idle speed control motor or
idle position switch.
Cleaning
Clean all parts except those noted in solvent. Check vacuum
port and passage for clogging. Clean vacuum, vapor and fuel passages
with compressed air.
Reassembly
To reassemble, reverse disassembly procedure.
Installation
To install, reverse removal procedure.
THROTTLE POSITION SENSOR/SWITCH
Removal & Installation
Throttle position sensor/switch is located on throttle body.
Disconnect TPS electrical connector. Remove bolts holding TPS and
remove TPS. To install, reverse removal procedure. Tighten throttle
position sensor/switch to specification. See TORQUE SPECIFICATIONS
table. For adjustment procedure, see ON-VEHICLE ADJUSTMENTS article.
TURBOCHARGERS
Page 691 of 1333
NOTE: Removal of turbocharger exhaust housing and water pipes at
turbocharger is not necessary when removing turbocharger
assembly. Stealth and 3000GT models have 2 (front and rear)
turbochargers.
Removal (Eclipse & Galant)
1) Disconnect negative battery cable. Drain engine coolant
and oil. On models with A/C, remove condenser fan motor assembly. On
all models, remove oxygen sensor. Remove oil dipstick guide and "O"
ring. See Figs. 8 and 9.
Fig. 8: Removing Turbocharger (Eclipse & Galant 2.0L)
Courtesy of Mitsubishi Motor Sales of America.
Fig. 9: Exploded View of Turbocharger Assembly (Eclipse & Galant
2.0L Shown; Stealth & 3000GT Similar)
Page 692 of 1333
Courtesy of Mitsubishi Motor Sales of America.
2) Disconnect air intake hose and vacuum hoses. Remove air
hose and air outlet housing. Remove heat protectors. Disconnect
exhaust pipe. Remove power steering oil pump and bracket. Remove
engine hanger bracket. Disconnect oil inlet pipe.
3) Disconnect coolant hose and tubes. Remove nuts and bolts
securing exhaust manifold. Remove exhaust manifold and gaskets.
Disconnect oil return pipe. Remove turbocharger assembly.
Removal (Stealth & 3000GT Front)
1) Disconnect negative battery cable. Drain engine oil and
coolant. Remove radiator. Disconnect exhaust pipe. Remove air intake
hose, air hoses and air pipe. Remove alternator and belt. Remove oil
dipstick guide.
2) Remove heat protector. Disconnect oxygen sensor electrical
connector. Remove oil return pipe. Remove turbocharger support bracket
and remove turbocharger from exhaust manifold. See Fig. 10.
Fig. 10: Removing Front Turbocharger (Stealth & 3000GT)
Courtesy of Mitsubishi Motor Sales of America.
Removal (Stealth & 3000GT Rear)
1) Disconnect battery cables and remove battery. Drain engine
oil and coolant. Remove accelerator cable. Remove air hose, air pipe
and heat protectors. Disconnect clutch booster vacuum hose. Remove air
Page 693 of 1333
intake hoses and EGR pipe. Disconnect oxygen sensor electrical
connector.
2) Remove oil pipe and EGR valve. Disconnect exhaust fitting
and remove rear heat protector. Remove oil return pipe. Remove
turbocharger assembly. See Fig. 11.
Fig. 11: Removing Rear Turbocharger (Stealth & 3000GT)
Courtesy of Mitsubishi Motor Sales of America.
Inspection
Check turbine and compressor wheels for cracking and other
damage. Make sure turbine and compressor wheels turn smoothly. Check
for oil leakage from turbocharger assembly. Check for proper wastegate
valve operation. See SYSTEM & COMPONENT TESTING article.
Installation
1) To install, reverse removal procedure. Before oil pipe
flare nut (above turbocharger) is installed, pour clean engine oil
into turbocharger. Ensure oil and air hoses are properly installed and
securely clamped.
2) Use new gaskets. Adjust accelerator cable (if necessary).\
Refill engine oil and coolant. Check for oil and coolant leaks.
Tighten all bolts to specification. See TORQUE SPECIFICATIONS table.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE\
\
\
\
\
\
Applications Ft. Lbs. (N.m)
Fuel Tank Nuts ............................. 15-22 (20-30)
