MITSUBISHI MONTERO 1991 Service Manual

Remove free wheeling hub. Measure caster with
camber/caster/kingpin gauge and turning radius gauge. See WHEEL
ALIGNMENT SPECIFICATIONS table. If caster is not within specification,
remove upper arm from crossmember. Adjust caster by turning upper arm
shaft. See Fig. 4.
Fig. 4: Adjusting Caster (Montero)
Courtesy of Mitsubishi Motor Sales of America.
Pickup & Ram-50
1) Check tire inflation. Place front wheel on turning radius
gauge, and level vehicle (unladed). On 2WD models, remove hub cap and
cotter pin. On 4WD models, remove free wheeling hub assembly.
2) On all models, measure caster with camber/caster/kingpin
gauge attached. See WHEEL ALIGNMENT SPECIFICATIONS table. If caster is
not within specification, remove shock absorber mounting nut and lock
nut.
3) Compress shock absorber and loosen upper arm mounting
bolts and nuts. Adjust caster by increasing or decreasing shims
between upper arm shaft and crossmember. See Fig. 1.
CAUTION: Difference in shim thickness between front and rear must be
.16" (4 mm) or less. DO NOT use more than 3 shims at one
location.
All Other Models
Check caster using a camber/caster/kingpin gauge and turning
radius gauge. See WHEEL ALIGNMENT SPECIFICATIONS table. If caster is
not to specification, replace damaged or bent parts.
TOE-IN ADJUSTMENT
Check toe-in. See WHEEL ALIGNMENT SPECIFICATIONS table. If

toe-in is not within specification, remove clips. Turn tie rods or
turnbuckles the same amount, but in opposite directions. Recheck toe-
in.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS TABLE








\









\









\









\









\









\

Application Ft. Lbs. (N.m)
Shock Absorber-To-Crossmember Nut
Montero, Pickup & Ram-50 ............ 10-13 (14-18)
Shock Absorber-To-Lower Arm Bolt
Montero ............................. 11-16 (15-22)
Pickup & Ram-50 ........................... 10 (14)
Upper Arm Shaft To Crossmember
Montero, Pickup & Ram-50 ........... 72-87 (98-118)
Wheel Lug Nut
Colt Vista
Aluminum Wheels ................... 65-80 (88-108)
Steel Wheels ....................... 50-57 (68-77)
Eclipse, Pickup, Ram-50,
Stealth & 3000GT ................ 87-101 (118-137)
Montero ............................ 72-87 (98-118)
All Others ......................... 65-80 (88-108)









\









\









\









\









\









\

WHEEL ALIGNMENT SPECIFICATIONS
WHEEL ALIGNMENT SPECIFICATIONS TABLE (COLT, COLT 200, MIRAGE, SUMMIT)








\









\









\









\









\









\









\







Application Preferred Range
Camber (Degrees)
Front ....................... 0 .................... -1/2 to 1/2
Rear ..................... -11/16 .............. -13/16 to -3/16
Caster (Degrees) ........... 2 5/16 ........... 1 13/16 to 2 13/16\
Toe-In (In. (mm))
Front .................... 0 (0) ........ -1/8 to 1/8 (-3 to 3\
)
Rear ..................... 0 (0) ...... -3/16 to 3/16 (-5 to 5\
)
Toe-In (Degrees)
Front ...................... 0 .................... -1/4 to 1/4
Rear ....................... 0 .................... -3/8 to 3/8









\









\









\









\









\









\









\







WHEEL ALIGNMENT SPECIFICATIONS TABLE (COLT VISTA)








\









\









\









\









\









\









\







Application Preferred Range
Two Wheel Drive
Camber (Degrees)
Front ..................... 7/16 .............. -1/16 to 15/16.
Rear ..................... -9/16 .................. -1 1/8 to 0
Caster (Degrees) .......... 13/16 ................ 5/16 to 15/16\
Toe-In (In. (mm))
Front & Rear ............. 0 (0) ........ -1/8 to 1/8 (-3 to 3\
)
Toe-In (Degrees)
Front & Rear ............... 0 .................... -1/4 to 1/4
Toe-Out on Turns (Degrees)
Inner .................... 37 3/4 ....................... .....
Outer ................... 30 11/16 ...................... .....
Four Wheel Drive

Camber (Degrees)
Front .................... 13/16 ................ 5/16 to 15/16
Rear ....................... 0 .................... -1/2 to 1/2
Caster (Degrees) .......... 13/16 ................ 5/16 to 15/16\
Toe-In (In. (mm))
Front & Rear ............. 0 (0) ........ -1/8 to 1/8 (-3 to 3\
)
Toe-In (Degrees)
Front & Rear ............... 0 .................... -1/4 to 1/4
Toe-Out on Turns (Degrees)
Inner ................... 37 3/4 ........................ .....
Outer .................. 30 11/16 ....................... .....









\









\









\









\









\









\









\







WHEEL ALIGNMENT SPECIFICATIONS TABLE (ECLIPSE)








\









\









\









\









\









\









\







Application Preferred Range
1.8L Engine
Camber (Degrees)
Front ..................... 1/4 ................... -1/4 to 3/4
Rear ..................... -3/4 ................ -1 1/4 to -1/4
Caster (Degrees) ......... 2 5/16 ........... 1 13/16 to 2 13/16\
Toe-In (In. (mm))
Front & Rear ............. 0 (0) ........ -1/8 to 1/8 (-3 to 3\
)
Toe-In (Degrees)
Front & Rear ............... 0 .................... -1/4 to 1/4
2.0L Engine (2WD)
Camber (Degrees)
Front .................... 1/16 ................. -7/16 to 9/16
Rear ..................... -3/4 ................ -1 1/4 to -1/4
Caster (Degrees) ......... 2 3/8 ................ 1 7/8 to 2 7/8\
Toe-In (In. (mm))
Front & Rear ............. 0 (0) ........ -1/8 to 1/8 (-3 to 3\
)
Toe-In (Degrees)
Front & Rear ............... 0 .................... -1/4 to 1/4
2.0L Engine (4WD)
Camber (Degrees)
Front .................... 3/16 ................ -5/16 to 11/16
Rear ................... -1 9/16 ........... -2 1/16 to -1 1/16
Caster (Degrees) ......... 2 5/16 ........... 1 13/16 to 2 13/16\
Toe-In (In. (mm))
Front .................... 0 (0) ........ -1/8 to 1/8 (-3 to 3\
)
Rear .................. 9/64 (3.6) .. -1/32 to 1/4 (-.6 to 6.6\
)
Toe-In (Degrees)
Front ...................... 0 .................... -1/4 to 1/4
Rear ..................... 9/32 ................... 1/16 to 1/2









\









\









\









\









\









\









\







WHEEL ALIGNMENT SPECIFICATIONS TABLE (GALANT)








\









\









\









\









\









\









\







Application Preferred Range
Two Wheel Drive
Camber (Degrees)
Front ..................... 3/8 ................... -1/8 to 7/8
Rear ..................... -3/4 ................ -1 1/4 to -1/4
Caster (Degrees) ............ 2 ................. 1 1/2 to 2 1/2\
Toe-In (In. (mm))
Front & Rear ............. 0 (0) ........ -1/8 to 1/8 (-3 to 3\
)
Toe-In (Degrees)
Front & Rear ............... 0 .................... -1/4 to 1/4
Four Wheel Drive
Camber (Degrees)

Front ..................... 1/2 ........................ 0 to 1
Rear ...................... -1 ................. -1 1/2 to -1/2
Caster (Degrees) ........ 1 15/16 ............. 1 7/16 to 2 7/16\
Toe-In (In. (mm))
Front .................... 0 (0) ........ -1/8 to 1/8 (-3 to 3\
)
Rear .................... 1/8 (3) ......... 0 to 1/4 (0 to 6.4\
)
Toe-In (Degrees)
Front ...................... 0 .................... -1/4 to 1/4
Rear ...................... 1/4 ...................... 0 to 1/2









\









\









\









\









\









\









\







WHEEL ALIGNMENT SPECIFICATIONS TABLE (MONTERO)








\









\









\









\









\









\









\







Application Preferred Range
Camber (Front) (1) ............. 1 .................. 1/2 to 1 1/2
Caster (1) .................. 2 15/16 ......... 1 15/16 to 3 15/16
Toe-In (Front) (2) ....... 7/32 (5.5) .. 3/32 to 11/32 (2.5-8.5)
Toe-In (Front) (1) ......... 7/16 ................ 3/16 to 11/16
Toe-Out on Turns (1)
Inner ..................... 32 1/2 ...................... .....
Outer ....................... 29 ........................ .....
(1) - Measurement in degrees.
(2) - Measurement in inches (mm).









\









\









\









\









\









\









\







WHEEL ALIGNMENT SPECIFICATIONS TABLE (RAM-50 & PICKUP)








\









\









\









\









\









\









\







Application Preferred Range
Two Wheel Drive
Camber (Front) (1) ......... 11/16 .............. 3/16 to 1 3/16
Caster (1) ................. 2 1/2 .............. 1 1/2 to 3 1/2
Toe-In (Front) (2) ...... 7/32 (5.5) .. 3/32 to 11/32 (2.5-8.5)
Toe-In (Front) (1) ......... 7/16 ................ 3/16 to 11/16
Toe-Out on Turns (1)
Inner ...................... 37 ......................... .....
Outer .................... 30 3/8 ....................... .....
Four Wheel Drive
Camber (Front) (1) ........... 1 .................. 1/2 to 1 1/2
Caster (1) ................... 2 ........................ 1 to 3
Toe-In (Front) (2) ....... 7/32 (5.5) .. 3/32 to 11/32 (2.5-8.5)
Toe-In (Front) (1) ......... 7/16 ................ 3/16 to 11/16
Toe-Out on Turns (1)
Inner ...................... 30 ......................... .....
Outer ...................... 27 ......................... .....
(1) - Measurement in degrees.
(2) - Measurement in inches (mm).









\









\









\









\









\









\









\







WHEEL ALIGNMENT SPECIFICATIONS TABLE (PRECIS)








\









\









\









\









\









\









\







Application Preferred Range
Camber (Degrees)
Front ........................ 0 ................... -1/2 to 1/2
Rear ...................... -11/16 ................. -1 to -3/16
Caster (Degrees)
With P/S .................. 1 11/16 ........... 1 3/16 to 2 3/16
Without P/S .................. 1 .................. 1/2 to 1 1/2
Toe-In (In. (mm))

Front .................... 1/32 (1) .... -1/16 to 5/32 (-2 to 4\
)
Rear ....................... 0 (0) ....................... .....\
Toe-In (Degrees)
Front ...................... 1/16 ................. -1/8 to 5/16
Rear ......................... 0 ......................... .....
Toe-Out on Turns (Degrees)
Inner ..................... 37 3/8 ....................... .....
Outer ..................... 31 1/2 ....................... .....









\









\









\









\









\









\









\







WHEEL ALIGNMENT SPECIFICATIONS TABLE (STEALTH & 3000GT)








\









\









\









\









\









\









\







Application Preferred Range
Front Wheel Drive
Camber (Degrees)
Front & Rear ............... 0 ................... -1/2 to 1/2
Caster (Degrees) .......... 3 29/32 ......... 3 13/32 to 4 29/32\
Toe-In (In. (mm))
Front .................... 0 (0) ....... -1/8 to 1/8 (-3 to 3\
)
Rear ..................... 0 (0) ..... -3/32 to 3/32 (-2 to 2\
)
Toe-In (Degrees)
Front ...................... 0 ................... -1/4 to 1/4
Rear ....................... 0 ................. -3/16 to 3/16
Toe-Out on Turns (Degrees)
Inner ................... 33 3/4 ....................... .....
Outer .................. 28 11/32 ...................... .....
All Wheel Drive
Camber (Degrees)
Front ...................... 0 ................... -1/2 to 1/2
Rear ..................... -5/32 ............. -21/32 to 11/32
Caster (Degrees) .......... 3 29/32 ......... 3 13/32 to 4 29/32\
Toe-In (In. (mm))
Front .................... 0 (0) ....... -1/8 to 1/8 (-3 to 3\
)
Rear ..................... 0 (0) ..... -3/32 to 3/32 (-2 to 2\
)
Toe-In (Degrees)
Front ..................... 0 ................... -1/4 to 1/4
Rear ...................... 0 ................. -3/16 to 3/16
Toe-Out on Turns (Degrees)
Inner .................. 33 3/4 ....................... .....
Outer ................. 28 11/32 ...................... .....









\









\









\









\









\









\









\

\003
WHEEL A LIG NM EN T T H EO RY/O PER ATIO N
1991 M it s u bis h i M onte ro
GENERAL INFORMATION
Wheel Alignment Theory & Operation
ALL MODELS
* PLEASE READ THIS FIRST *
NOTE: This article is intended for general information purposes
only. This information may not apply to all makes and models.
PRE-ALIGNMENT INSTRUCTIONS
GENERAL ALIGNMENT CHECKS
Before adjusting wheel alignment, check the following:
* Each axle uses tires of same construction and tread style,
equal in tread wear and overall diameter. Verify that radial
and axial runout is not excessive. Inflation should be at
manufacturer's specifications.
* Steering linkage and suspension must not have excessive play.
Check for wear in tie rod ends and ball joints. Springs must
not be sagging. Control arm and strut rod bushings must not
have excessive play. See Fig. 1.
Fig. 1: Checking Steering Linkage
* Vehicle must be on level floor with full fuel tank, no
passenger load, spare tire in place and no load in trunk.
Bounce front and rear end of vehicle several times. Confirm

vehicle is at normal riding height.
* Steering wheel must be centered with wheels in straight ahead
position. If required, shorten one tie rod adjusting sleeve
and lengthen opposite sleeve (equal amount of turns). See
Fig. 2.
* Wheel bearings should have the correct preload and lug nuts
must be tightened to manufacturer's specifications. Adjust
camber, caster and toe-in using this sequence. Follow
instructions of the alignment equipment manufacturer.
CAUTION: Do not attempt to correct alignment by straightening parts.
Damaged parts must be replaced.
Fig. 2: Adjusting Tie Rod Sleeves (Top View)
CAMBER
1) Camber is the tilting of the wheel, outward at either top
or bottom, as viewed from front of vehicle. See Fig. 3.
2) When wheels tilts outward at the top (from centerline of
vehicle), camber is positive. When wheels tilt inward at top, camber
is negative. Amount of tilt is measured in degrees from vertical.

Fig. 3: Determining Camber Angle
CASTER
1) Caster is tilting of front steering axis either forward or
backward from vertical, as viewed from side of vehicle. See Fig. 4.
2) When axis is tilted backward from vertical, caster is
positive. This creates a trailing action on front wheels. When axis is
tilted forward, caster is negative, causing a leading action on front
wheels.
Fig. 4: Determining Caster Angle
TOE-IN ADJUSTMENT
Toe-in is the width measured at the rear of the tires

subtracted by the width measured at the front of the tires at about
spindle height. A positive figure would indicate toe-in and a negative
figure would indicate toe-out. If the distance between the front and
rear of the tires is the same, toe measurement would be zero. To
adjust:
1) Measure toe-in with front wheels in straight ahead
position and steering wheel centered. To adjust toe-in, loosen clamps
and turn adjusting sleeve or adjustable end on right and left tie
rods. See Figs. 2 and 5.
2) Turn equally and in opposite directions to maintain
steering wheel in centered position. Face of tie rod end must be
parallel with machined surface of steering rod end to prevent binding.
3) When tightening clamps, make certain that clamp bolts are
positioned so there will be no interference with other parts
throughout the entire travel of linkage.
Fig. 5: Wheel Toe-In (Dimension A Less Dimension B)
TOE-OUT ON TURNS
1) Toe-out on turns (turning radius) is a check for bent or
damaged parts, and not a service adjustment. With caster, camber, and
toe-in properly adjusted, check toe-out with weight of vehicle on
wheels.
2) Use a full floating turntable under each wheel, repeating
test with each wheel positioned for right and left turns. Incorrect
toe-out generally indicates a bent steering arm. Replace arm, if
necessary, and recheck wheel alignment.

STEERING AXIS INCLINATION
1) Steering axis inclination is a check for bent or damaged
parts, and not a service adjustment. Vehicle must be level and camber
should be properly adjusted. See Fig. 6.
2) If camber cannot be brought within limits and steering
axis inclination is correct, steering knuckle is bent. If camber and
steering axis inclination are both incorrect by approximately the same
amount, the upper and lower control arms are bent.
Fig. 6: Checking Steering Axis Inclination
