MITSUBISHI MONTERO 1991 Service Manual

meter long with force of one Newton applied). Some conversions are:
* A meter kilogram is about 7.2 foot pounds.
* A foot pound is about 1.4 Newton-meters.
* A centimeter kilogram (cmkg) is equal to .9 inch pounds.
PRESSURE
Pressure is another complicated measurement. Pressure is
described as a force or weight applied to a given area. Our common
unit is pounds per square inch. Metric units can be expressed in
several ways. One is the kilogram per square centimeter (kg/cm
).
Another unit of pressure is the Pascal (force of one Newton on an area
of one square meter), which equals about 4 ounces on a square yard.
Since this is a very small amount of pressure, we usually see the
kiloPascal, or kPa (1000 Pascals). Another common automotive term for
pressure is the bar (used by German manufacturers), which equals 10
Pascals. Thoroughly confused? Try the examples below:
* Atmospheric pressure at sea level is about 14.7 psi.
* Atmospheric pressure at sea level is about 1 bar.
* Atmospheric pressure at sea level is about 1 kg/cm
.
* One pound per square inch is about 7 kPa.
CONVERSION FACTORS
CONVERSION FACTORS
\
\
\
\
\
\
\

TO CONVERT TO  MULTIPLY BY
\b
\
\
\
\
\
 \
\



LENGTH


Millimeters (mm) Inches  .03937

Inches Millimeters  25.4

Meters (M) Feet  3.28084

Feet Meters  .3048

Kilometers(Km) Miles  .62137
\b
\
\
\
\
\
 \
\



AREA


Square Centimeters (cm) Square Inches  .155

Square Inches Square Centimeters  6.45159
\b
\
\
\
\
\
 \
\



VOLUME


Cubic Centimeters Cubic Inches  .06103

Cubic Inches Cubic Centimeters  16.38703

Liters Cubic Inches  61.025

Cubic Inches Liters  .01639

Liters Quarts  1.05672

Quarts Liters  .94633

Liters Pints  2.11344

Pints Liters  .47317

Liters Ounces  33.81497

Ounces Liters  .02957
\b
\
\
\
\
\
 \
\



WEIGHT


Grams Ounces  .03527

Ounces Grams  28.34953

Kilograms Pounds  2.20462

Pounds Kilograms  .45359
\b
\
\
\
\
\
 \
\



WORK


Centimeter Kilograms Inch Pounds  .8676

Pounds/Sq. Inch Kilograms/Sq.Centimeter .07031

Bar Pounds/Sq. Inch  14.504

Pounds/Sq. Inch Bar  .06895

Atmosphere Pounds/Sq. Inch  14.696

Pounds/Sq. Inch Atmosphere  .06805
\b
\
\
\
\
\
 \
\



TEMPERATURE


Centigrade Degrees Fahrenheit Degrees (Cx(9)/5)+32

Fahrenheit Degrees Centigrade Degrees (F-32)x(5)/9
\f
\
\
\

\
\

\
\

CONVERSION FACTORS (Cont.)
\
\
\
\
\
\
\

INCHES DECIMALS mm

\b
\
\
\
\
\
\
\





1/64 ...................... .016 ........................ .397

1/32 ...................... .031 ........................ .794

3/64 ...................... .047 ....................... 1.191

1/16 ...................... .063 ....................... 1.588

5/64 ...................... .078 ....................... 1.984

3/32 ...................... .094 ....................... 2.381

7/64 ...................... .109 ....................... 2.778

1/8 ....................... .125 ....................... 3.175

9/64 ...................... .141 ....................... 3.572

5/32 ...................... .156 ....................... 3.969

11/64 ..................... .172 ....................... 4.366

3/16 ...................... .188 ....................... 4.763

13/64 ..................... .203 ....................... 5.159

7/32 ...................... .219 ....................... 5.556

15/64 ..................... .234 ....................... 5.953

1/4 ....................... .250 ....................... 6.350

17/64 ..................... .266 ....................... 6.747

9/32 ...................... .281 ....................... 7.144

19/64 ..................... .297 ....................... 7.541

5/16 ...................... .313 ....................... 7.938

21/64 ..................... .328 ....................... 8.334

11/32 ..................... .344 ....................... 8.731

23/64 ..................... .359 ....................... 9.128

3/8 ....................... .375 ....................... 9.525

25/64 ..................... .391 ....................... 9.992

13/32 ..................... .406 ...................... 10.319

27/64 ..................... .422 ...................... 10.716

7/16 ...................... .438 ...................... 11.113

29/64 ..................... .453 ...................... 11.509

15/32 ..................... .469 ...................... 11.906

31/64 ..................... .484 ...................... 12.303

1/2 ....................... .500 ...................... 12.700

33/64 ..................... .516 ...................... 13.097

17/32 ..................... .531 ...................... 13.494

35/64 ..................... .547 ...................... 13.891

9/16 ...................... .563 ...................... 14.288

37/64 ..................... .578 ...................... 14.684

19/32 ..................... .594 ...................... 15.081

39/64 ..................... .609 ...................... 15.478

5/8 ....................... .625 ...................... 15.875

41/64 ..................... .641 ...................... 16.272

21/32 ..................... .656 ...................... 16.669

43/64 ..................... .672 ...................... 17.066

11/16 ..................... .687 ...................... 17.463

45/64 ..................... .703 ...................... 17.859

23/32 ..................... .719 ...................... 18.256

47/64 ..................... .734 ...................... 18.653

3/4 ....................... .750 ...................... 19.050

49/64 ..................... .766 ...................... 19.447

25/32 ..................... .781 ...................... 19.844

51/64 ..................... .797 ...................... 20.241

13/16 ..................... .813 ...................... 20.638

53/64 ..................... .828 ...................... 21.034

27/32 ..................... .844 ...................... 21.431

55/64 ..................... .859 ...................... 21.828

7/8 ....................... .875 ...................... 22.225

57/64 ..................... .891 ...................... 22.622

29/32 ..................... .906 ...................... 23.019

59/64 ..................... .922 ...................... 23.416

15/16 ..................... .938 ...................... 23.813

61/64 ..................... .953 ...................... 24.209

31/32 ..................... .969 ...................... 24.606

63/64 ..................... .984 ...................... 25.003

1 ......................... 1.000 ..................... 25.400
\f
\
\
\
\
\
\
\


\003
PR E-A LIG NM EN T C HEC KS

1991 M it s u bis h i M onte ro
Wheel Alignment
PRE-ALIGNMENT INSPECTION PROCEDURES
PRE-ALIGNMENT CHECKS
Before making wheel alignment adjustment, perform the
following checks:
1) Tires should be equal in size and runout must not be
excessive. Tires and wheels should be in balance, and inflated to
manufacturer's specifications.
2) Wheel bearings must be properly adjusted. Steering linkage
and suspension must not have excessive looseness. Check for wear in
tie rod ends and ball joints.
3) Steering gear box must not have excessive play. Check and
adjust to manufacturer's specifications.
4) Vehicle must be at curb height with full fuel load and
spare tire in vehicle. No extra load should be on vehicle.
5) Vehicle must be level with floor and with suspension
settled. Jounce front and rear of vehicle several times and allow it
to settle to normal curb height.
6) If steering wheel is not centered with front wheels in
straight-ahead position, correct by shortening one tie rod adjusting
sleeve and lengthening opposite sleeve equal amounts.
7) Ensure wheel lug nuts are tightened to torque
specifications.

\003
N - R EM OVE/IN STA LL/O VER HAU L
1991 Mitsubishi Montero
1991 ENGINE PERFORMANCE
Removal, Overhaul & Installation
Dodge; Colt, Colt 200, Colt Vista, Ram-50, Stealth
Eagle; Summit
Mitsubishi; Eclipse, Galant, Mirage, Montero, Pickup, 3000GT
Plymouth; Colt, Colt 200, Colt Vista
INTRODUCTION
Removal, overhaul and installation procedures (when given by
manufacturer) are covered in this article. If component removal and
installation is primarily an unbolt and bolt-on procedure, only a
torque specification may be furnished.
IGNITION SYSTEM
DISTRIBUTOR
Fig. 1: Exploded View of Distributor (Colt Vista)
Courtesy of Mitsubishi Motor Sales of America.

Fig. 2: Exploded View of Distributor (Colt, Colt 200, Mirage &
Summit 1.5L)
Courtesy of Mitsubishi Motor Sales of America.
Fig. 3: Exploded View of Distributor (Galant 2.0L SOHC)
Courtesy of Mitsubishi Motor Sales of America.

Fig. 4: Exploded View of Distributor (Eclipse 1.8L)
Courtesy of Mitsubishi Motor Sales of America.
Fig. 5: Exploded View of Distributor (Montero & Ram-50 3.0L)
