Page 189 of 1333
FRICTION MATERIAL
NOTE: Original Equipment Manufacturer (OEM) specifications
designate replacement at different thicknesses.
CAUTION: It is required that friction material be matched in axle
sets for consistent braking characteristics.
FRICTION MATERIAL INSPECTION
\
\
\
\
\
\
\
Condition Code Procedure
Contaminated, for example,
fluid that leaked from
caliper, wheel cylinder,
or axle seal ........... A ........ ( 1) Require replacement.
Cracked through ......... B Require replacement.
Flaking or chunking ..... B Require replacement.
Glazed (shiny) .......... .. ........ No service suggested or
required.
Grooves or ridges ....... .. .... ( 2) No service suggested or
required.
Permanently attached
hardware bent .......... A ............ Require replacement.
Permanently attached
hardware broken ........ A ............ Require replacement.
Permanently attached
hardware loose ......... A ............ Require replacement.
Permanently attached
hardware missing ....... C ............ Require replacement.
Permanently attached
hardware seized ........ A .. Require repair or replacement.
Rivets loose ............ B ............ Require replacement.
Separating from backing . B ............ Require replacement.
Shoe table or web bent .. B ............ Require replacement.
Shoe table or web
cracked ................ A ............ Require replacement.
Shoe table or web worn,
affecting performance .. A ............ Require replacement.
Surface cracking ........ .. ........ No service suggested or
required. Further inspection
may be necessary to determine
cause.
Tapered wear ............ B ........ ( 3) Suggest replacement.
Thickness of one pad is
greater than opposite pad
in the same caliper
(uneven wear) .......... .. .... ( 4) Replacement of friction
material not suggested or
required. Further inspection
required. See CALIPERS
and CALIPER HARDWARE.
Wear indicator device
(electronic) contacts
rotor .................. B ...... ( 5) Require replacement of
appropriate parts.
Wear indicator device
(mechanical) bent ....... .. .......... ( 6) Further inspection
required.
Wear indicator device
(mechanical) broken .... .. ......... ( 6) Further inspection
required.
Page 289 of 1333
\003
* D RIV ETR AIN S YSTE M S U NIF O RM IN SPEC TIO N G UID ELIN ES *
1 991 M it s u bis h i M onte ro
GENERAL INFORMATION
Drivetrain/Transmission Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
Drive/Power Train Assemblies
AUTOMATIC TRANSMISSION/TRANSAXLE ASSEMBLIES
DIFFERENTIAL AND FINAL DRIVE ASSEMBLIES
MANUAL TRANSMISSION/TRANSAXLE ASSEMBLIES
TRANSFER CASE ASSEMBLIES
Drive/Power Train Components
ACTUATORS (ELECTRICAL)
ACTUATORS (VACUUM)
AXLES
BEARINGS AND RACES
BELL CRANKS
BELL HOUSINGS
BUSHINGS (EXTERNAL)
CABLES (SPEEDOMETER)
CABLES (TV, DETENT AND SHIFT)
CARRIER BEARINGS
CLUTCH CABLES AND CABLE HOUSINGS
CLUTCH DISCS (MANUAL TRANSMISSION)
CLUTCH FORKS
CLUTCH LINKAGES (MECHANICAL)
CLUTCH MASTER CYLINDERS
CLUTCH PEDALS
CLUTCH PIVOTS
CLUTCH PRESSURE PLATES
CLUTCH RELEASE BEARINGS
CLUTCH SLAVE CYLINDERS (CONCENTRIC)
CLUTCH SLAVE CYLINDERS (CONVENTIONAL OR EXTERNAL)
COMPANION FLANGES
CONNECTORS
COOLER BYPASS VALVES
COOLER LINES
COOLERS
CV JOINTS
DIP STICK TUBES
DIP STICKS (FLUID LEVEL INDICATORS)
DOWEL PINS, GUIDES AND PILOT HOLES
DRIVE SHAFT FLANGES
DRIVE SHAFTS AND HALF SHAFTS
DUST BOOTS
ENGINE MOUNTS
EXCITER RINGS
FILLER TUBES
FILTERS AND SCREENS
Page 310 of 1333
![MITSUBISHI MONTERO 1991 Service Manual performs its intended
function ............... A ............ Require replacement.
Weights missing ......... A ............ Require replacement.
\
\](/img/19/57332/w960_57332-309.png "MITSUBISHI MONTERO 1991 Service Manual performs its intended
function ............... A ............ Require replacement.
Weights missing ......... A ............ Require replacement.
\
\")
performs its intended
function ............... A ............ Require replacement.
Weights missing ......... A ............ Require replacement.
\
\
\
\
\
\
\
FLUID LEVEL INDICATORS
See DIP STICKS (FLUID LEVEL INDICATORS) .
FLUIDS AND LUBRICANTS
FLUID AND LUBRICANT INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Application incorrect ... B ........ ( 1) Require replacement.
At service interval ..... 3 ............ Suggest replacement.
Beyond service interval . 3 ............ Suggest replacement.
Burned .................. .. ......... ( 2) Further inspection
required.
Contaminated, for example,
fluid other than hydraulic
fluid present .......... A or B .... ( 3)( 4) Require service.
Exceeding service
interval ............... 3 ............ Suggest replacement.
Hydraulic fluid
incorrect .............. B ............ ( 5) Require service.
Level incorrect ......... B ..... Require correction of fluid
level.
Near service interval ... 3 ............ Suggest replacement.
Rubber master cylinder
cover gasket distorted
and gummy .............. A ............ ( 3) Require service.
Varnished ............... .. ......... ( 6) Further inspection
required.
( 1) - Determine and correct cause.
( 2) - Fluid that is burned indicates a serious problem.
Determine and correct the cause.
( 3) - If a fluid other than hydraulic fluid is present in the
hydraulic system which DOES affect the rubber parts, the
required service is to: 1) remove all components having
rubber parts from the system, 2) flush lines with
denatured alcohol or hydraulic cleaner, 3) repair or
replace all components having rubber parts, and 4) bleed
and flush with correct hydraulic fluid. (Code A)
( 4) - If a fluid other than hydraulic fluid is present in the
hydraulic system which DOES NOT affect the rubber parts,
the required service is to flush and fill with the
correct hydraulic fluid. (Code B)
( 5) - If a fluid other than specification hydraulic fluid is
present in the hydraulic system, the required service
is to flush and fill with the correct hydraulic fluid.
( 6) - Fluid that is varnished may indicate a serious problem.
Determine and correct the cause.
\
\
\
\
\
\
\
FLYWHEELS
NOTE: Clutch disc replacement does not necessitate flywheel
reconditioning, unless other conditions justify the
reason to do so.
Page 325 of 1333
performance ............ A .. Require repair or replacement.
Fins damaged, not
affecting performance .. .. ........ No service suggested or
required.
Internal restrictions ... B .. Require repair or replacement.
Leaking ................. A .. Require repair or replacement.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A .. Require repair or replacement.
Tubes damaged, affecting
performance ............ A .. Require repair or replacement.
Tubes damaged, not
affecting performance .. .. ........ No service suggested or
required.
\
\
\
\
\
\
\
TRANSMISSION MOUNTS
See MOUNTS (ENGINE, TRANSAXLE AND TRANSMISSION) .
TRANSMISSION PANS
TRANSMISSION PAN INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Bent, interfering with
filter or other internal
components ............. A .. Require repair or replacement.
Leaking ................. A .. Require repair or replacement.
\
\
\
\
\
\
\
TRANSMISSION RANGE INDICATORS (PRNDL)
TRANSMISSION RANGE INDICATOR (PRNDL) INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Binding ................. A .. Require repair or replacement.
Broken .................. A .. Require repair or replacement.
Components missing ...... C .. Require replacement of missing
components.
Loose, affecting
performance ............ A .. Require repair or replacement.
Out of adjustment ....... A ................. Require repair.
Worn, affecting
performance ............ A .. Require repair or replacement.
\
\
\
\
\
\
\
TUBES
See HOSES, LINES AND TUBES .
UNIVERSAL JOINTS (CARDON OR CROSS TYPE)
UNIVERSAL JOINT (CARDON OR CROSS TYPE) INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Page 423 of 1333
If equipped, the EMR light (some models may use a reminder
flag) reminds vehicle operator that an emission system maintenance is
required. This indicator is activated after a predetermined
time/mileage.
When performing a smog check inspection, ensure EMR indicator
is not activated. On models using an EMR light, light should glow when
ignition switch is turned to ON position and should turn off when
engine is running.
If an EMR flag is present or an EMR light stays on with
engine running, fail vehicle and service or replace applicable
emission-related components. To reset an EMR indicator, refer to
appropriate MAINTENANCE REMINDER LIGHTS in the MAINTENANCE section.
MALFUNCTION INDICATOR LIGHT (MIL)
The Malfunction Indicator Light (MIL) is used to alert
vehicle operator that the computerized engine control system has
detected a malfunction (when it stays on all the time with engine
running). On some models, the MIL may also be used to display trouble
codes.
As a bulb and system check, malfunction indicator light will
glow when ignition switch is turned to ON position and engine is not
running. When engine is started, light should go out.
Page 670 of 1333
2.6L Engine ........................................... 45
2.6L Optional ......................................... 45
3.0L V6 ........................................... (1) 24
3.5L V6 ........................................... ( 1) 24
( 1) - Check hood clearance on 1986 and newer models.
\
\
\
\
\
\
CAUTIONS & WARNINGS
SUPPLEMENTAL RESTRAINT SYSTEM (SRS) AIR BAG SYSTEM
NOTE: See the AIR BAG RESTRAINT SYSTEM article in the
ACCESSORIES/SAFETY EQUIPMENT Section.
The SRS has no user-servicable parts. Always have servicing
done by an authorized dealer.
When performing maintenance on air bag equipped vehicles
always observe proper safety precautions.
WARNING: To avoid injury from accidental air bag deployment, read and
carefully follow all warnings and service precautions. See
appropriate AIR BAG RESTRAINT SYSTEM article in the
ACCESSORIES/SAFETY EQUIPMENT section.
CAUTION: Disconnect negative battery cable before servicing any air
bag system, steering column or passenger side dash
component. After any repair, turn ignition key to the ON
position from passenger's side of vehicle in case of
accidental air bag inflation
ANTI-LOCK BRAKE SYSTEM (ABS)
CAUTION: Never mix different diameter tires. On loose or uneven
surfaces, the ABS system may require longer stopping
distances than conventional brake systems. Exercise caution
when removing mud or snow from the wheels so as not to
damage the ABS wiring or speed sensors.
BATTERY WARNING
WARNING: When battery is disconnected, vehicles equipped with
computers may lose memory data. When battery power is
restored, driveability problems may exist on some vehicles.
These vehicles may require a relearn procedure. See
appropriate COMPUTER RELEARN PROCEDURES article in the
GENERAL INFORMATION section below.
REPLACING BLOWN FUSES
Before replacing a blown fuse, remove ignition key, turn off
all lights and accessories to avoid damaging the electrical system. Be
sure to use fuse with the correct indicated amperage rating. The use
of an incorrect amperage rating fuse may result in a dangerous
electrical system overload.
BRAKE PAD WEAR INDICATOR
Indicator will cause a squealing or scraping noise, warning
that brake pads need replacement.
Page 676 of 1333
MAIN TE N AN CE R EM IN DER L IG HT R ESET P R O CED URES
1991 M it s u bis h i M onte ro
1983-96 MAINTENANCE
Chrysler Motors/Mitsubishi Maintenance Reminder Lights
Dodge; Challenger, Colt, Colt Vista, Conquest, Raider,
Ram-50
Eagle; Summit, Summit Wagon
Plymouth; Colt, Colt Vista, Sapporo
Mitsubishi; 3000GT, Cordia, Diamante, Eclipse,
Expo/Expo LRV, Galant, Mirage, Montero, Pickup, Precis,
Sigma, Starion, Tredia, Van/Wagon
EGR/MAINTENANCE REQUIRED WARNING LIGHT
1) On some models, an EGR or MAINTENANCE REQUIRED warning
light in dash will come on as a reminder to have EGR system serviced
(each 50,000 miles), oxygen sensor replaced (each 80,000 miles) or
evaporative carbon canister replaced (100,000 miles).
2) After servicing or replacing components, reset mileage
counter. On all models except 1987-95 Pickup and 1987-93 Ram-50, reset
switch is located on back of instrument cluster.
3) On 1987-95 Pickup and 1987-93 Ram-50, reset switch is on
lower right corner of instrument cluster, behind instrument cluster
face trim. Slide switch to other side to reset indicator light.
4) Remove warning light bulb after 150,000 mile servicing on
Colt Vista and Wagon. Remove bulb after 120,000 mile servicing on Ram-
50.
Fig. 1: Locating Warning Light Reset Switch (Colt Vista; Colt
Wagon is Similar)
Courtesy of Chrysler Motors.
Page 730 of 1333
SER VIC E IN DIC ATO R & W AR NIN G L IG HTS
1991 M it s u bis h i M onte ro
1983-92 MAINTENANCE
Mitsubishi Service Indicator & Warning Lights
Montero
SERVICE INDICATOR & WARNING LIGHTS
Fig. 1: 1983-88 Dash Gauges & Warning Lights
Courtesy of Mitsubishi Motor Sales of America, Inc.
Page 732 of 1333
Light comes on with the ignition switch in the "ON" position
as a bulb check, but should go out shortly after engine is started. If
light remains on or comes on while driving, it indicates low oil
pressure and possible system malfunction. Have the system checked and
serviced immediately. Do not operate vehicle until cause is located
and corrected.
ALTERNATOR WARNING LIGHT
Light comes on with the ignition switch in the "ON" position
as a bulb check and goes out after engine is started. If light remains
on or comes on while driving, it indicates possible fault in the
electrical charging system. The alternator belt may be loose or
broken. Have the system checked and serviced promptly. Do not drive
vehicle if alternator belt is loose or broken.
"BRAKE" WARNING LIGHT
Light comes on with the ignition switch in the "ON" position
as a bulb check and goes out after engine is started. Light will also
come on with the parking brake fully or partially engaged. If light
remains on or comes on at any other time, it indicates low brake fluid
level in the master cylinder reservoir or the parking brake switch may
be damaged. Have the system checked and serviced immediately if brake
fluid level is low. Do not continue driving if further trouble is
experienced.
"CHECK ENGINE" WARNING LIGHT (IF EQUIPPED)
Light is designed to come on briefly with the ignition switch
in the "ON" position as a bulb check. If light remains on or comes on
while driving, it indicates fault in an exhaust gas related component
and the system is not functioning properly. Have the system checked
and serviced as soon as possible.
"MAINTENANCE REQUIRED" WARNING LIGHT (IF EQUIPPED)
Light comes on at 50,000 miles, 80,000 miles, 100,000 miles
and 120,000 miles (150,000 miles on 1990-91 models) as a service
reminder that it is time for the periodic maintenance of the emission
control system. Have the system inspected and serviced as necessary
when light comes on. Continued operation of vehicle without having
system serviced after warning light comes on may adversely affect
proper performance of the emission control system. Reset warning
light, after the system has been checked, by pushing the reset switch
in front of the combination meter. Remove the warning light bulb after
the last maintenance service at 120,000 miles (150,000 miles on 1990-
91 models).
"A/T TEMPERATURE" WARNING LIGHT (IF EQUIPPED)
Light comes on when the automatic transmission fluid
temperature becomes abnormally high. If light comes on, reduce engine
speed, stop car and put it in "P" (Park) position. Leave engine
running until light goes out. Normal vehicle operation may be resumed
after light has gone out. If light does not go out, have the system
checked and serviced as necessary.
WHEEL LOCK INDICATOR LIGHT (IF EQUIPPED)
Light comes on when automatic free-wheeling hubs are locked.
If ignition is turned off, indicator light will not come on when
Page 824 of 1333
(chunking),
exposing cord .......... A ............ Require replacement.
Tread missing pieces
(chunking), not
exposing cord .......... 1 ............ Suggest replacement.
Tread separations A ............ Require replacement.
Tube in tubeless tire 3 .... (4) Suggest removal of tube.
Weather-checking ........ .. ......... No service required or
suggested.
Worn to tread wear
indicators ............. B ............ Require replacement.
( 1) - Determine and correct cause of irregular tire wear.
( 2) - If radials and bias or bias-belted ply tires are on the
same vehicle, the radials must be on the rear axle,
except for high-pressure temporary spares.
( 3) - Excessive is defined as enough to contribute to
performance problems. Match mounting may correct
run-out. If not, require replacement of appropriate
part. Refer to manufacturer's specifications.
( 4) - Most manufacturers do not recommend tubes in tubeless
tires. Inspect tire and wheel assembly to determine
the reason for a tube in tubeless tire. Recommendation
for repair or replacement should be based upon condition
of tires and/or wheel listed in these guidelines.
\
\
\
\
\
\
\
VALVE STEMS
VALVE STEM INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Bent .................... 1 ........... Suggest replacement.
Broken .................. A ........... Require replacement.
Cut, but not leaking .... 1 ........... Suggest replacement.
Deteriorated
(cracking, dry rot) .... 1 ........... Suggest replacement.
Leaking ................. A . Require repair or replacement.
Missing ................. C ........... Require replacement.
Threads damaged ......... A . Require repair or replacement.
Threads stripped ........ A ........... Require replacement.
Valve cap missing ....... C .... Require replacement of cap.
Weather-checking ........ 1 ........... Suggest replacement.
Won't take air .......... A . Require repair or replacement.
\
\
\
\
\
\
\
WHEEL ATTACHMENT HARDWARE
For conditions noted below, also check conditions of wheel
stud holes.
CAUTION: Proper lug nut torque is essential. Follow recommended
torque specifications and tightening sequence. DO NOT
lubricate threads unless specified by the vehicle
manufacturer.
WHEEL ATTACHMENT HARDWARE INSPECTION
\
\
\
\
\
\
\
Condition Code Procedure
Bent .................... A ............ Require replacement.
Broken .................. A ........ ( 1) Require replacement.
