MITSUBISHI MONTERO 1998 Workshop Manual

Fig. 2: Exploded View Of Compressor (Typical)
Courtesy of Mitsubishi Motor Sales of America.
SANDEN SCROLL
CLUTCH COIL & SHAFT SEAL
Removal
1) Remove drive belt pulley (if equipped). Hold clutch plate\
using Pliers (MB991367) and Bolts (MB991386). Use a ratchet and sock\
et
to remove clutch hub nut.
2) Remove clutch plate. See Fig. 3 or 4. Remove snap ring
with internal snap ring pliers. Remove clutch hub (rotor). Remove snap\
ring and clutch coil.
3) Using an awl, remove bearing cover and retainer. Using
Bearing Remover (MB991456), engage bearing grooves. Place base of
bearing remover over remover arms and tighten nut.
4) Tighten bearing remover bolt to withdraw bearing from
compressor. Engage grooves of Shaft Seal Remover/Installer (MB991458)
and pull straight up on shaft seal.
Installation
1) To install shaft seal, ensure front housing is free of
foreign objects. Lubricate Shaft Seal Protector (MB991459) and place
over compressor shaft. Lubricate shaft seal and install using shaft
seal remover/installer. Remove shaft seal protector.
2) Using a 21-mm socket or Drift (MB991301), carefully press\
bearing onto compressor shaft. Install clutch coil so that alignment
pin is engaged. Install clutch coil snap ring with tapered side facing
out.
3) Align armature plate with crankshaft spline. Tighten shaft
nut to 12 ft. lbs. (16 N.m). Using feeler gauge, ensure air gap
between pressure plate and pulley is 0.02-0.03" (0.5-0.8 mm) on
Diamante and 0.016-0.024" (0.4-0.6 mm) on all other models. If air gap\
is incorrect, add or remove shim(s) as necessary.

Fig. 3: Exploded View Of Compressor (Sanden Scroll MSC105 Shown;
MSC90C Is Similar)
Courtesy of Mitsubishi Motor Sales Of America.

Fig. 4: Exploded View Of Compressor (Sanden Scroll)
Courtesy of Mitsubishi Motor Sales Of America.
