![MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
\
ABBREVIATION DEFINITION](/img/19/57333/w960_57333-25.png "MITSUBISHI MONTERO 1998 Service Manual \
\
\
\
\
\
\
ABBREVIATION DEFINITION")
\
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
B/P Backpressure
BAC By-Pass Air Control
BAP Barometric Absolute Pressure Sensor
BARO Barometric
BBDC Before Bottom Dead Center
BCM Body Control Module
BDC Bottom Dead Center
BHP Brake Horsepower
BLK Black
BLU Blue
BMAP Barometric & Manifold Absolute Pressure Sensor
BOO Brake On-Off Switch
BP Barometric Pressure sensor
BPS Barometric Pressure Sensor
BPT Backpressure Transducer
BRN Brown
BTDC Before Top Dead Center
BTU British Thermal Unit
BVSV Bimetallic Vacuum Switching Valve
Baro. Barometric
Batt. Battery
Bbl. Barrel (Example: 4-Bbl.)
Blst. Ballast
Blwr. Blower
Brkr. Breaker
\
\
\
\
\
\
\
\f
"C" ABBREVIATION TABLE
"C" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
C Celsius (Degrees)
C(3) I Computer Controlled Coil Ignition
C(4) Computer Controlled Catalytic Converter
CANP Canister Purge solenoid
CARB California Air Resources Board
CAT Catalytic Converter
CB Circuit Breaker
CBD Closed Bowl Distributor
CBVV Carburetor Bowl Vent Valve
cc Cubic Centimeter
CCC Computer Command Control
CCD Computer Controlled Dwell
CCM Central Control Module
CCO Converter Clutch Override
CCOT Cycling Clutch Orifice Tube
CCW Counterclockwise
CDI Capacitor Discharge Ignition
CEC Computerized Engine Control
CFI Central Fuel Injection
CID Cubic Inch Displacement
CID Cylinder Identification sensor
CIS Continuous Injection System
CIS-E Continuous Injection System-Electronic
CKT Circuit
CLR Clear
CNG Compressed Natural Gas
Page 27 of 1501
CO Carbon Monoxide
CO2 Carbon Dioxide
CONV Convertible
CP Canister Purge
CPA Connector Position Assurance
CPS Crank Position Sensor
CTS Coolant Temperature Sensor
CV Check Valve or Constant Velocity
CVC Constant Vacuum Control
CW Clockwise
CYL or Cyl. Cylinder
Calif. California
Carb. Carburetor
Chrg. Charging
Circ. Circuit
Cntrl. Control
Comp. Compressor or Compartment
Conn. Connector
Cont. Continued
Conv. Convertible or Converter
Cu. In. Cubic Inch
Cyl. Cylinder
\
\
\
\
\
\
\
\f
"D" ABBREVIATION TABLE
"D" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
"D" Drive
DBC Dual Bed Catalyst
DC Direct Current or Discharge
DDD Dual Diaphragm Distributor
DERM Diagnostic Energy Reserve Module
DFI Digital Fuel Injection
DIC Driver Information Center
DIS Direct Ignition System
DIS Distributorless Ignition System
DIST Distribution
DISTR Distributor
DK BLU Dark Blue
DK GRN Dark Green
DME Digital Motor Electronics (Motronic System)
DOHC Double Overhead Cam
DOT Department of Transportation
DP Dashpot
DRB-II Diagnostic Readout Box
DVOM Digital Volt/Ohm Meter (see VOM)
Def. Defogger or Defroster
Def. Defrost
Defog. Defogger
Diag. Diagnostic
Dist. Distributor or Distribution
Dr. Door
\
\
\
\
\
\
\
\f
"E" ABBREVIATION TABLE
"E" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
Page 85 of 1501
A/C SWITCH
When turned on, the A/C system will operate if blower motor
control lever is in a position other than OFF. When activated, A/C
switch allows A/C compressor clutch to engage and operate the
compressor.
A/C ENGINE COOLANT TEMPERATURE SWITCH
The A/C engine coolant temperature switch, located on
thermostat housing, is wired in series with compressor clutch. When
coolant temperature is greater than switch control temperature, power
to compressor is cut and compressor is turned off until temperature
returns to operating range. Switch will turn on at 226
F (108C) and
off at 235-243F (112-118C).
AIR SELECTOR LEVER
The lever moves horizontally to select source of air used
inside passenger compartment. Lever moves from position on left
(outside air mode) to position on right (recirculated air mode). Lev\
er
should be set in recirculated air mode for maximum A/C cooling.
BLOWER MOTOR CONTROL SWITCH
Blower motor control switch rotates to select blower motor
speeds. As switch is rotated from left or OFF position, increasing
speeds of blower operation are selected. In order for A/C system to
operate, blower motor control switch must be in a position other than
OFF.
MODE SELECTOR KNOB
Mode selector knob has six modes available to achieve desired
distribution of air from various outlets. When knob is rotated fully
to left (counterclockwise), airflow is directed to upper passenger
area. In second position (clockwise), airflow is directed to upper
passenger area and slightly to leg area. Position 3, directs air
mostly to leg area and slightly to upper passenger area. Position 4,
directs air exclusively to leg area. Position 5, directs air to leg
area and to windshield and door windows. Position 6, directs air
exclusively to windshield and door windows.
TEMPERATURE CONTROL KNOB
Temperature control knob operates blend-air door in
heater/air conditioning unit, mixing cooled and heated air so that
selected air temperature can be obtained. The system will provide
cooled air when A/C switch is in ON position and blower motor is in
any position other than OFF. Temperature control knob should be on far
left (maximum cooling) side of temperature selection scale when
maximum A/C cooling is desired.
DUAL-PRESSURE SWITCH
The dual-pressure switch, mounted on receiver-drier, is wired
in series with compressor clutch. Whenever system pressures drop below
or increase above control points of switch, power supplied to
compressor will be cut and compressor function will cease until
pressures are back to normal operating ranges.
Page 107 of 1501
AIR BAG RESTRAINT SYSTEM
1998 Mitsubishi Montero
1998 AIR BAG RESTRAINT SYSTEMS
Mitsubishi
Montero
DESCRIPTION & OPERATION
WARNING: To avoid injury from accidental air bag deployment, read and
carefully follow all WARNINGS and SERVICE PRECAUTIONS.
Supplemental Restraint System (SRS) consists of an SRS
warning light, driver-side and passenger-side air bag module,
clockspring, right and left front impact sensors, and SRS Air Bag
Control Unit (ECU). The SRS-ECU contains an analog and a safing impact\
sensor. See Fig. 1.
Air bags are designed to deploy in a frontal or near frontal
impact of moderate to severe force. For air bags to deploy, ignition
must be on and safing impact sensor and at least one front impact
sensor must activate simultaneously.
Fig. 1: Locating SRS Components
Courtesy of Mitsubishi Motor Sales of America.
SRS WARNING LIGHT
Page 108 of 1501
When ignition switch is turned to ON or START position, SRS
warning light on instrument panel should come on for about 7 seconds
and then go off. This indicates SRS-ECU has determined SRS is
functioning properly. If SRS warning light flashes, stays on all the
time, or does not come on, a fault exists in SRS. See
DIAGNOSIS & TESTING.
FRONT IMPACT SENSORS
Sensors are inertia switches that verify direction and
severity of impact. If impact is great enough, switch contacts close,
completing an electrical circuit. Front impact sensors are located
under front fenders. See Fig. 1.
AIR BAG MODULE(S)
An inflator assembly in the air bag module produces nitrogen
gas to fill air bag. See Fig. 1. When a small amount of current from
SRS-ECU is applied, ignitor starts a thermal reaction, which spreads
to a pellet-filled canister that produces nitrogen gas. Gas pressure
builds and discharges from inflator through a diffuser and screen
assembly, forcing trim cover to burst along its seams until air bag is
fully inflated. When air bag is fully inflated, gas escapes through
vents on sides of air bag.
SRS AIR BAG CONTROL UNIT (ECU)
SRS-ECU (with integral safing and analog impact sensor) is
located behind front floor console assembly. See Fig. 1. If a system
fault occurs, SRS-ECU memory stores a diagnostic trouble code (DTC).
DATA LINK CONNECTOR (DLC)
DLC is located under left side of dash. See Fig. 1. DLC is
used to access SRS self-diagnostics through Mitsubishi Multi-Use
Tester II (MUT-II) (MB991502).
CLOCKSPRING
Clockspring connects driver-side air bag module to steering
column wiring, forming SRS circuit. See Fig. 1. Clockspring is a flat,
ribbon-like cable that winds and unwinds when steering wheel is
turned. Because of clockspring's constant movement, it is the most
fragile part in the system.
SYSTEM OPERATION CHECK
WARNING: After servicing, always turn ignition on from passenger-side
of vehicle in case of accidental air bag deployment.
Turn ignition switch to ON position. SRS warning light on
instrument panel should come on for about 7 seconds and then turn off.
This indicates SRS is functioning properly. If SRS warning light does
not come on, stays on, or comes on while driving, SRS is
malfunctioning and needs repair. See DIAGNOSIS & TESTING.
SERVICE PRECAUTIONS
Observe the following precautions when working with SRS:
* Disable SRS before servicing any SRS or steering column
Page 109 of 1501
component. Failure to do this may result in accidental air
bag deployment and possible personal injury. Refer to
DISABLING & ACTIVATING AIR BAG SYSTEM .
* For about 60 seconds after air bag system is disabled, it
retains enough voltage to deploy air bags. After disabling
system, wait at least 60 seconds before servicing.
* After servicing, always turn ignition on from passenger-side
of vehicle in case of accidental air bag deployment.
* After servicing, check SRS warning light to verify system
operation. See SYSTEM OPERATION CHECK.
* Always wear safety glasses when servicing or handling an
air bag.
* The SRS-ECU must be stored in its original special container
until used for service. It must be stored in a clean, dry
place, away from sources of extreme heat, sparks and high
electrical energy.
* DO NOT expose air bag module and clockspring to temperatures
greater than 200
F (93 C).
* When placing a live air bag module on a bench or other
surface, always face air bag module and trim cover up, away
from surface. This will reduce motion of module if air bag
accidentally deploys.
* After air bag deploys, air bag surface may contain deposits
of sodium hydroxide, which irritates skin. Always wear
safety glasses, rubber gloves and long-sleeved shirt during
clean-up. Wash hands using mild soap and water. Follow
correct clean-up and disposal procedures. Refer to
DISPOSAL PROCEDURES .
* Because of critical system operating requirements, DO NOT
service any SRS components. Repairs are only made by
replacing defective part(s).
* DO NOT allow any electrical source near inflator on the back
of air bag module.
* When carrying a live (undeployed) air bag module, trim cover
must be pointed away from body to minimize injury in case of
accidental air bag deployment.
* DO NOT probe wire harness connector terminals. Instead, use
SRS Check Harness (MB991530).
* DO NOT probe a wire through insulator, as this will damage
it and eventually cause failure due to corrosion.
* When performing electrical tests, prevent accidental
shorting of terminals. Such shorts can damage fuses or
components and may cause a second fault code to set, making
diagnosis of original problem more difficult.
* Never use an analog volt/ohm meter or test light in place of
a Digital Volt/Ohm Meter (DVOM). Use only a DVOM with a
maximum test current of 2 mA (milliamps) at minimum range of
resistance measurement. Also see SPECIAL TOOLS.
* If SRS is not fully functional for any reason, DO NOT drive
vehicle until system is repaired and is fully functional. DO
NOT remove bulbs, modules, sensors or other components, or
in any way disable system from operating normally. If SRS is
not functional, park vehicle until repairs are made.
SPECIAL TOOLS
To avoid air bag deployment when working on SRS, DO NOT use
electrical test equipment such as test lights, battery or A/C-powered
volt/ohmmeter, or any type of electrical equipment other than those
specified by manufacturer. See SRS RECOMMENDED TOOLS table.
SRS RECOMMENDED TOOLS TABLE
\
\
\
\
\
\
Page 111 of 1501
![MITSUBISHI MONTERO 1998 Service Manual least 60 seconds before continuing. Remove steering column lower
cover. Disconnect clockspring 2-pin Red connector.
3) Make a harness with two 20-foot (or longer) wires. Connec\
t
wires at on](/img/19/57333/w960_57333-110.png "MITSUBISHI MONTERO 1998 Service Manual least 60 seconds before continuing. Remove steering column lower
cover. Disconnect clockspring 2-pin Red connector.
3) Make a harness with two 20-foot (or longer) wires. Connec\
t
wires at on")
least 60 seconds before continuing. Remove steering column lower
cover. Disconnect clockspring 2-pin Red connector.
3) Make a harness with two 20-foot (or longer) wires. Connec\
t
wires at one end of this harness to SRS Air Bag Adapter Harness "A"
(MB686560). Wrap connections with insulating tape. See Fig. 2.
4) Temporarily connect other end of harness wires together to
prevent unexpected air bag deployment. Connect SRS air bag adapter
harness "A" to clockspring 2-pin Red connector. Run 20-foot wires
outside of vehicle as far away as possible from vehicle.
5) Ensure there are no loose parts in passenger compartment
and no one is within 20 feet of vehicle.
6) Deploy air bag by connecting ends of 20-foot wires to
terminals of a 12-volt battery. If air bags fail to deploy, go to
PROCEDURE 2 below. After deployment, allow air bag modules to cool and
dust to settle for at least 30 minutes before approaching vehicle.
Fig. 2: Connecting Wires To Air Bag Adapter Harness
Courtesy of Mitsubishi Motor Sales of America.
Procedure 2 (Off-Vehicle Deployment)
1) Before proceeding, follow air bag service precautions. See
Page 112 of 1501
SERVICE PRECAUTIONS. Turn ignition switch to LOCK position. Disconnect
negative battery cable. Shield cable end. Disconnect positive battery
cable. Remove battery. Wait at least 60 seconds before continuing.
2) Remove air bag module. Place air bag module on ground at
least 20 feet away from people or objects. Air bag module face (trim
cover) must face upward to prevent movement of air bag module when it
is deployed.
3) Make a harness with two 20-foot (or longer) wires. Connec\
t
wires at one end of this harness to stripped wires of SRS Air Bag
Adapter Harness "B" (MB628919) for driver-side air bag, or SRS Air Bag\
Adapter Harness "A" (MB686560) for passenger-side air bag. See Fig. 2.
4) Wrap connections with insulating tape. Temporarily connect
other end of harness wires together to prevent unexpected air bag
deployment. Connect appropriate adapter harness to air bag module
connector. Place a tire without a rim over the air bag module so rim
hole surrounds air bag module. Stack 3 more tires on top of first
tire. Connect ends of 20-foot wires to terminals of a 12-volt battery.
5) After air bag module deploys, let it cool off and allow
dust to settle for at least 30 minutes before approaching. Tightly
seal deployed air bag module in a strong vinyl bag and dispose of air
bag as you would any other part.
DEPLOYED AIR BAG CLEAN-UP
WARNING: Vehicle interior will contain sodium hydroxide powder, a
by-product of air bag deployment. Since this powder can
irritate skin, eyes, nose and throat, wear safety glasses,
rubber gloves and long-sleeved shirt during clean-up.
1) Avoid breathing powder from air bag deployment. Begin
clean-up by putting tape over air bag exhaust vent to prevent
additional powder from escaping into vehicle interior. Use a vacuum
cleaner to remove any residual powder from A/C-heater outlets and
vehicle interior.
2) Turn blower motor to low for a few minutes and exit
vehicle. Turn blower motor off. Vacuum any other powder expelled from
plenum. Vacuum interior a second time to recover all powder. Avoid
kneeling or sitting on unclean areas. Wrap deployed air bag in heavy
vinyl plastic and dispose of it as you would any other part.
POST-COLLISION INSPECTION
When a vehicle has been involved in a collision, certain
components of the passive restraint system must be inspected or
replaced. See PASSIVE RESTRAINT SYSTEM INSPECTION article in the
GENERAL INFORMATION section for post-collision inspection information.
REMOVAL & INSTALLATION
WARNING: Follow air bag service precautions to prevent accidental air
bag deployment and personal injury. See SERVICE PRECAUTIONS.
Replace faulty SRS components; DO NOT repair or disassemble.
Handle all SRS components carefully.
DRIVER-SIDE AIR BAG MODULE & CLOCKSPRING
Removal
1) Before proceeding, see SERVICE PRECAUTIONS. Reactivate
SRS. See DISABLING & ACTIVATING AIR BAG SYSTEM .
2) Ensure front wheels are in straight-ahead position. Remove
lower covers from air bag module. Remove air bag module mounting nut
Page 113 of 1501
and screws. See Fig. 3. Lift air bag module for access to clockspring
connector at air bag module and disconnect clockspring connector. See
Fig. 4 . Remove air bag module.
3) Place air bag module on flat surface with trim cover
facing up. Remove steering wheel with Steering Wheel Puller
(MB990803). Remove lower column cover. Disconnect clockspring lower
connectors. Remove clockspring mounting screws. Remove clockspring.
See Fig. 3 .
Fig. 3: Removing Driver-Side Air Bag & Clockspring
Courtesy of Mitsubishi Motor Sales of America.
Fig. 4: Disconnecting Clockspring Connector From Air Bag Module
Courtesy of Mitsubishi Motor Sales of America.
WARNING: If front wheels are not in straight-ahead position or
clockspring mating marks are not aligned before installing
Page 114 of 1501
clockspring, the steering wheel may not turn completely, or
flat cable inside clockspring may be severed, disabling SRS
system and possibly causing serious injury to driver.
Installation
1) Ensure front wheels are in straight-ahead position. Align
mating marks on clockspring. See CLOCKSPRING CENTERING under
ADJUSTMENTS. Install clockspring. To install remaining components,
reverse removal procedure. Before installing air bag module, ensure
horn switch wiring is positioned so that it will not be pinched.
2) Tighten fasteners to spec. See TORQUE SPECIFICATIONS.
Activate SRS. See DISABLING & ACTIVATING AIR BAG SYSTEM . Check AIR BAG
warning light for proper system function. SYSTEM OPERATION CHECK.
PASSENGER-SIDE AIR BAG MODULE
Removal & Installation
1) Before proceeding, see SERVICE PRECAUTIONS. Deactivate
SRS. See DISABLING & ACTIVATING AIR BAG SYSTEM .
2) Remove right-side foot shower duct and two stoppers on
either side. Remove and lower glove box. Disconnect air bag module
connector. Remove retaining bolts and passenger-side air bag module.
See Fig. 5 .
3) To install, reverse removal procedure. Tighten bolts to
specification. See TORQUE SPECIFICATIONS . Activate SRS. See procedures
under DISABLING & ACTIVATING AIR BAG SYSTEM . Check AIR BAG warning
light for proper system function. SYSTEM OPERATION CHECK.
Fig. 5: Removing Passenger-Side Air Bag Module
Courtesy of Mitsubishi Motor Sales of America.
SRS AIR BAG CONTROL UNIT (ECU)
