Page 29 of 1501
![MITSUBISHI MONTERO 1998 Service Manual \
\b\
\
\
\
\
\
g grams](/img/19/57333/w960_57333-28.png "MITSUBISHI MONTERO 1998 Service Manual \
\b\
\
\
\
\
\
g grams")
\
\b\
\
\
\
\
\
g grams
GND or GRND Ground
GRN Green
GRY Gray
Ga. Gauge
Gals. gallons
Gov. Governor
\
\
\
\
\
\
\
\f
"H" ABBREVIATION TABLE
"H" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
H/D Heavy Duty
HAC High Altitude Compensation
HC Hydrocarbons
HEDF High Speed Electro Drive Fan relay or circuit
HEGO Heated Exhaust Gas Oxygen Sensor
HEGOG HEGO Ground circuit
HEI High Energy Ignition
HLDT Headlight
HO High Output
HP High Performance
HSC High Swirl Combustion
HSO High Specific Output
HTR Heater
HVAC Heating
Headlt. Headlight
Hg Mercury
Hgt. Height
Htr. Heater
Hz Hertz (Cycles Per Second)
\
\
\
\
\
\
\
\f
"I" ABBREVIATION TABLE
"I" ABBREVIATION TABLE \
\
\
\
\
\
\
ABBREVIATION DEFINITION
\
\b\
\
\
\
\
\
I.D. Inside Diameter
IAC Idle Air Control
IACV Idle Air Control Valve
IC Integrated Circuit
ID Identification
IDM Ignition Diagnostic Monitor
IGN Ignition system or circuit
ILC Idle Load Compensator
In. Hg Inches of Mercury
INCH Lbs. Inch Pounds
INFL REST Inflatable Restraint
INJ Injector or Injection
IP Instrument Panel
IPC Instrument Panel Cluster
ISA Idle Speed Actuator
ISC Idle Speed Control
ISS Idle Stop Solenoid
ITS Idle Tracking Switch
IVSV Idle Vacuum Switching Valve
Page 44 of 1501
* A/C-HEATER SYSTEM UNIFORM INSPECTION GUIDELINES *
1998 Mitsubishi Montero
GENERAL INFORMATION
A/C-Heater System Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
Motorist Assurance Program (MAP)
OVERVIEW
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
Heating, Ventilation and Air Conditioning
ACCUMULATORS
ACTUATORS (ELECTRICAL)
ACTUATORS (VACUUM)
AIR CONDITIONING FITTINGS
AIR CONDITIONING HOSES
AIR CONDITIONING METAL LINES, HOSES AND FITTING ASSEMBLIES
AIR CONTROL DOORS
AIR DAMS (EXTERNAL)
AIR DISTRIBUTION SYSTEM
BELTS
BLEND DOORS
BLOWER FANS (BLOWER WHEEL OR SQUIRREL CAGE)
BLOWER MOTORS
BLOWER RESISTORS
BLOWER SWITCHES
CABIN AIR FILTERS
CIRCUIT BREAKERS
COMPRESSOR CLUTCH ASSEMBLIES
COMPRESSORS
CONDENSER AIR SEALS
CONDENSER FAN MOTORS
CONDENSERS
CONNECTORS
CONTROL CABLES
CONTROL HEADS (FUNCTION SELECTORS)
CONTROL LINKAGES
CONTROL MODULES
COOLANT
COOLING FAN BLADES
COOLING FAN CLUTCHES
COOLING FAN MOTORS
EVAPORATOR DRAIN TUBES
EVAPORATOR PRESSURE REGULATORS (EPRS)
EVAPORATORS
EXPANSION VALVES
FUNCTION SELECTORS
FUSES, FUSIBLE LINKS AND CIRCUIT BREAKERS
FUSIBLE LINKS
GASKETS
HEATER CASES
HEATER CONTROL VALVES
HEATER CORES
Page 49 of 1501
![MITSUBISHI MONTERO 1998 Service Manual (1) - Inspect system to determine effects of dessicant bag
deterioration.
\
\
\
\
\
\](/img/19/57333/w960_57333-48.png "MITSUBISHI MONTERO 1998 Service Manual (1) - Inspect system to determine effects of dessicant bag
deterioration.
\
\
\
\
\
\")
(1) - Inspect system to determine effects of dessicant bag
deterioration.
\
\
\
\
\
\
\
ACTUATORS (ELECTRICAL)
ACTUATOR (ELECTRICAL) INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Connector broken ........ A .. Require repair or replacement.
Connector (Weatherpack
type) leaking .......... A .. Require repair or replacement.
Connector melted,
affecting performance .. A ........... ( 1) Require repair or
replacement.
Connector melted, not
affecting performance .. 2 ........... ( 1) Suggest repair or
replacement.
Connector missing ....... C ............ Require replacement.
Inoperative ............. A ........ ( 2) Require replacement.
Missing ................. C ............ Require replacement.
Noisy ................... 2 .. Suggest repair or replacement.
Out of adjustment ....... B .. Require repair or replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned, affecting
performance ............ A ........... ( 1) Require repair or
replacement.
Terminal burned, not
affecting performance .. 1 ........... ( 1) Suggest repair or
replacement.
Terminal corroded,
affecting performance .. A .. Require repair or replacement.
Terminal corroded, not
affecting performance .. 1 .. Suggest repair or replacement.
Terminal loose, affecting
performance ............ B .. Require repair or replacement.
Terminal loose, not
affecting performance .. 1 .. Suggest repair or replacement.
\
\
\
\
\
\
\
ACTUATORS (VACUUM)
ACTUATOR (VACUUM) INSPECTION \
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
Page 143 of 1501
NOTE: DTC is set if valve relay is removed or if no power is
supplied to relay.
1) Inspect ABS relay box. See Fig. 3. Replace ABS relay box
if needed. If ABS relay box is okay, go to next step.
2) Disconnect ABS relay box 8-pin connector. Turn ignition
on. Using a DVOM, check voltage between ABS relay box 8-pin harness
connector terminal No. 6 and ground. See Fig. 4. If battery voltage
exists, go to next step. If battery voltage does not exist, check and
repair wiring harness between ABS valve relay and fusible link No. 1.
See WIRING DIAGRAMS .
3) Disconnect ECU connectors. Check resistance between ECU
22-pin connector terminal No. 37 and ECU 26-pin connector terminal No.
26. Resistance should be 60-120 ohms. If resistance is as specified,
go to next step. If resistance is not as specified, check and repair
connectors and related wiring harness between ABS valve relay and ECU.
See WIRING DIAGRAMS .
4) Check continuity between ECU 22-pin connector terminal No.
48 and ground. If continuity exists, go to next step. If continuity
does not exist, check and repair wiring harness between ABS valve
relay and ECU. See WIRING DIAGRAMS.
5) Check and repair ECU 22-pin connector. If connector is
okay, replace ECU.
DTC 53: MOTOR RELAY
NOTE: DTC is set when ECU detects motor relay on but motor does
not run, motor relay off but motor does not stop, or when
motor relay is faulty.
1) Using scan tool, perform hydraulic unit actuator test. If
motor is not operating, go to next step. If motor is still operating,
repair wiring harness between hydraulic unit and ECU. See
WIRING DIAGRAMS .
2) Inspect ABS relay box. See Fig. 3. Replace ABS relay box
if needed. If ABS relay box is okay, go to next step.
3) Disconnect ABS relay box 2-pin connector. Using DVOM,
check voltage between 2-pin connector terminal No. 11 and ground. See
Fig. 4 . If battery voltage is present, go to next step. If battery
volt age is not present, check and repair wiring harness between ABS
motor relay and fusible link No. 1. See WIRING DIAGRAMS.
4) Turn ignition off. Disconnect ECU connectors. Check
resistance between ECU 22-pin connector terminal No. 38 and 26-pin
connector terminal No. 26. Resistance should be 26-38 ohms. If
resistance is as specified, go to next step. If resistance is not as
specified, check and repair connectors and related wiring harness
between ABS motor and ECU. See WIRING DIAGRAMS.
5) Check resistance between ECU 22-pin connector terminal No.
49 and ground. Resistance should be 0.1-0.3 ohm. If resistance is as
specified, go to next step. If resistance is not as specified, check
and repair hydraulic unit motor ground connection or wiring harness
between ECU and hydraulic unit. See WIRING DIAGRAMS.
6) Check motor operation. Momentarily apply battery voltage
to hydraulic unit connector terminal No. 11. See Fig. 11. If motor
operates, go to next step. If motor does not operate, replace
hydraulic unit.
7) Check and repair ECU 22-pin connector. If connector is
okay, replace ECU.
COMPONENT TESTS
4WD CONTROL UNIT
Page 297 of 1501
CRUISE CONTROL SYSTEM
1998 Mitsubishi Montero
1998 ACCESSORIES & EQUIPMENT
Mitsubishi - Cruise Control Systems
Montero
DESCRIPTION & OPERATION
WARNING: Deactivate air bag system before performing any service
operation. See AIR BAG RESTRAINT SYSTEMS article. Do not
apply electrical power to any component on steering column
without first deactivating air bag system. Air bag may
deploy.
Cruise control system is electronically and vacuum
controlled. System components include a control unit, actuator, vacuum
pump, cruise control switch, clutch pedal position switch (M/T),
cruise indicator light, diode, Park/Neutral (P/N) switch (A/T),
stoplight switch, vehicle speed sensor and A/T control unit (if
equipped).
System has self-diagnostic capability. When self-diagnostic
mode is activated, each switch and sensor is checked for defects. When
cruise control system has been canceled without using a normal cancel
method, a trouble code will be set and stored in control unit. Trouble
codes can be retrieved to help determine which circuit is
malfunctioning.
COMPONENT LOCATIONS
COMPONENT LOCATIONS TABLE \
\
\
\
\
\
Component Location
Cruise Control ECU .............. Behind Dash, On Steering
Column Bracket
Data Link Connector (DLC) ....... Under Left Side Of Dash,
Near Steering Column
Vehicle Speed Sensor ........... On Speedometer Assembly &
On Transmission
Throttle Position Sensor ........ Mounted On Throttle Body
\
\
\
\
\
\
ADJUSTMENTS
CRUISE CONTROL CABLE
Remove link protector. Loosen lock nut. Hold link "A" so that
it touches link "B". Adjust free play by turning adjusting nut until
free play is.04-.08" (1-2 mm). Tighten lock nut. See Fig. 1 or 2.
Page 299 of 1501
* PLEASE READ THIS FIRST *
NOTE: For further trouble shooting information, see INPUT
INSPECTION CHART. See Fig. 3. See
INSPECTION CHART FOR TROUBLE SYMPTOMS table under SYMPTOM
TESTS.
PRELIMINARY CHECKS
Inspect vacuum pump, linkage assembly, actuator, cables and
vacuum hoses. Ensure linkage and cables move smoothly. Ensure cables
do not have excessive slack or tension.
CRUISE CONTROL SWITCH FUNCTION TEST
NOTE: If vehicle speed decreases about 9 MPH less than the set
speed, set speed will be canceled. Speed will not set beyond
system limit of 124 MPH.
1) Cruise control switch is part of multifunction switch
mounted on steering column. To operate cruise control system, turn
ignition on. Turn cruise control switch to ON position. Ensure switch
indicator light comes on.
2) With cruise control switch in ON position, drive vehicle
at least 25 MPH. Press and release SET button. Vehicle speed should
stay at set speed. Instrument cluster cruise indicator light should
come on. To increase set speed, turn control switch to RESUME position
and hold until new set speed is reached.
3) To lower set speed, press SET button and hold until new
set speed is reached. To return to set speed after cancellation, move
resume switch to ON position. Vehicle speed should return to previous
setting before cancellation. Set speed should cancel when any of the
following occurs:
* Brake pedal is depressed.
* Cruise control main switch is turned to OFF position.
* Ignition switch is turned to OFF position.
* Transmission is shifted to Neutral.
SYSTEM CANCELS OR WILL NOT RESET AFTER CANCELLATION
1) Check for trouble codes. See RETRIEVING CODES under SELF-
DIAGNOSTIC SYSTEM. If no trouble codes are stored, ensure cruise
control can be set.
2) If cruise control can be set, system may have canceled due
to driving on steep hills, or a loose wiring connection. If cruise
control still cannot be set, perform SYSTEM INPUT TESTS under SYMPTOMS
TESTS.
3) If SYSTEM INPUT TESTS check okay, check vacuum pump
circuit. See CODE 11 under DIAGNOSTIC TESTS. If SYSTEM INPUT TESTS do
not check okay, see INPUT INSPECTION CHART. See Fig. 3.
SYMPTOM TESTS
SYSTEM INPUT TESTS
1) System input tests should be performed if no trouble codes
are stored when performing RETRIEVING CODES under SELF-DIAGNOSTIC
SYSTEM. System input tests cycle each cruise control switch and
sensor.
Page 301 of 1501
![MITSUBISHI MONTERO 1998 Service Manual Does Not Illuminate
(Cruise Control Operation Normal) .................. 12
\
\
\
\
\](/img/19/57333/w960_57333-300.png "MITSUBISHI MONTERO 1998 Service Manual Does Not Illuminate
(Cruise Control Operation Normal) .................. 12
\
\
\
\
\")
Does Not Illuminate
(Cruise Control Operation Normal) .................. 12
\
\
\
\
\
\
Fig. 4: Identifying Cruise Control Circuit Connector Terminals:
IOD Or Storage Connector (A-09X)
Courtesy of Mitsubishi Motor Sales of America
Fig. 5: Identifying Cruise Control Circuit Connector Terminals:
Cruise Control Actuator Connector (A-57 Or A-95)
Courtesy of Mitsubishi Motor Sales of America
Page 318 of 1501
13. If input switch Code 26 is still displayed, go to TEST NO. 14. If
codes are no longer displayed, replace cruise control ECU.
Test No. 9
A malfunction of Vehicle Speed Sensor (VSS) or incorrect
vacuum in cruise control vacuum pump or actuator may be present.
Probable causes are:
* Malfunction of VSS.
* Malfunction of cruise control vacuum pump.
* Malfunction of actuator.
* Malfunction of cruise control ECU.
1) Check vehicle speed sensor. See VEHICLE SPEED SENSOR TEST
under COMPONENT TESTS. If speed sensor is okay, go to next step. If
speed sensor is defective, replace VSS.
2) Check cruise control vacuum pump. See VACUUM PUMP TEST
under COMPONENT TESTS. If pump is defective, replace pump. If pump is
okay, go to next step.
3) Check actuator. See ACTUATOR TEST under COMPONENT TESTS.
If actuator is defective, replace actuator. If actuator is okay,
replace cruise control ECU.
Test No. 10
A blown bulb in cruise control main switch or malfunction of
cruise control main switch is probable cause of malfunction. Replace
cruise control main switch.
Test No. 11
A malfunction of cruise control main switch, harness or
connector may exist. Probable causes are:
* Malfunction of cruise control main switch.
* Malfunction of connector.
* Malfunction of harness.
1) Check cruise control main switch. See
CRUISE CONTROL SWITCH TESTS under COMPONENT TESTS. If switch is okay,
go to next step. If switch is defective, replace cruise control main
switch.
2) Disconnect cruise control main switch connector C-01. At
harness side of connector, measure voltage between terminal No. 2 and
ground. If battery voltage is present, go to next step. If battery
voltage is not present, check joint connector C-130 and junction block
connector C-80. Repair as necessary. See Figs. 16, 18, 26 and 28. If
connectors are okay and malfunction remains, check harness between
cruise control main switch and power supply. Repair as necessary.
3) Check cruise control main switch connector C-01,
combination meter connector C-04, and joint connector C-130. Repair as
necessary. See Figs. 8, 9, 16 and 28. If connectors are okay and
malfunction remains, check harness between cruise control main switch
and dash lights rheostat. Repair as necessary.
Test No. 12
A malfunction of bulb, connector or harness may exist.
Probable causes are:
* Malfunction of bulb.
* Malfunction of connector.
* Malfunction of harness.
* Malfunction of cruise control ECU.
1) Perform cruise control indicator test. See
Page 319 of 1501
CRUISE CONTROL INDICATOR TEST under COMPONENT TESTS. If cruise control
indicator is defective, replace indicator. If indicator checks okay,
go to next step.
2) If cruise control indicator illuminates when cruise
control connector C-50 terminal No. 23 is grounded at harness side,
replace cruise control ECU. If indicator does not illuminate, check
combination meter connector C-12 and cruise control ECU connector C-
50. Repair as necessary. If connectors are okay and malfunction
remains, check harness between combination meter and cruise control
ECU. Repair as necessary.
Test No. 13
1) Perform stoplight switch test. See
BRAKELIGHT/STOPLIGHT SWITCH TEST under COMPONENT TESTS. If switch is
okay, go to next step. If switch is defective, replace brakelight
switch.
2) Check cruise control ECU connector C-50, stoplight switch
connector C-55 and joint connector C-131. Repair as necessary. See
Figs. 13 , 14, 16 and 29. If connectors are okay and malfunction
remains, check harness between joint connector C-131 and cruise
control ECU.
Test No. 14 (A/T)
1) Perform park/neutral switch test. See
PARK/NEUTRAL SWITCH TEST under COMPONENT TESTS. If switch is okay, go
to next step. If switch is defective, replace switch.
2) Check starter relay. Replace if defective. If relay is
okay, check cruise control ECU connector C-50 and joint connector C-
130. Repair as necessary. See Figs. 13, 16 and 28. If connectors are
okay and malfunction remains, check harness between cruise control ECU
and power supply.
COMPONENT TESTS
ACTUATOR TEST
Remove actuator. Apply vacuum to actuator. Actuator linkage
holder should move more than 1.38" (35 mm). Actuator diaphragm should
hold vacuum. Replace actuator if actuator does not test as specified.
BRAKELIGHT/STOPLIGHT SWITCH TEST
Disconnect stoplight switch connector C-55. When brake pedal
is pressed, continuity should be present between terminals No. 2 and
3. See Fig. 14. When brake pedal is released, continuity should be
present between terminals No. 1 and 4. Replace switch if it does not
test as specified.
CLOCKSPRING TEST
WARNING: Deactivate air bag system before performing any service
operation. See AIR BAG RESTRAINT SYSTEMS article. Do not
apply electrical power to any component on steering column
without first deactivating air bag system. Air bag may
deploy.
If clockspring fails any check, replace with a NEW
clockspring.
1) Check connectors and protective tube for damage and
deformities.
2) Visually check case for damage or deformities.
Page 325 of 1501
1) To clear trouble codes, disconnect battery cable, or use
alternative method to prevent memory loss.
2) Turn ignition on. Turn main cruise control switch and SET
switch to ON position, and within one second, turn RES switch to ON
position. Hold stoplight switch and cruise control switch in ON
position for greater than 5 seconds. Verify codes are cleared.
DIAGNOSTIC TESTS
CODE 11: VACUUM PUMP DRIVE SYSTEM
Code 11 is displayed if release valve, control valve and
motor drive signals from vacuum pump are not input to cruise control
ECU. Probable causes are:
* Malfunction of vacuum pump.
* Malfunction of stoplight switch.
* Malfunction of connector.
* Malfunction of harness.
* Malfunction of cruise control ECU.
1) Check vacuum pump. See VACUUM PUMP TEST under COMPONENT
TESTS. If vacuum pump is defective, replace vacuum pump. If vacuum
pump is okay, go to next step.
2) Disconnect cruise control actuator harness connector A-57
or A-95. See Fig. 5. At harness side of connector, check voltage
between terminal No. 1 and ground. If battery voltage is present, go
to next step. If battery voltage is not present, check stoplight
switch. See BRAKELIGHT/STOPLIGHT SWITCH TEST under COMPONENT TESTS.
Replace switch if defective. Check cruise control main switch harness
connector C-01 and stoplight switch harness connector C-55. Repair as
necessary. If malfunction remains, check harness between cruise
control main switch and vacuum pump. Repair as necessary.
3) Disconnect cruise control ECU connector C-50. See Fig. 13.
At harness side of connector, check voltage between ground and
terminals No. 12 (driving release valve), No. 13 (driving control
valve), and No. 26 (driving motor). If battery voltage is present, go\
to next step. If battery voltage is not present, check and repair
connectors A-57 or A-95 and C-111 as necessary. See Figs. 5 and 24. If
malfunction remains, check and repair harness between vacuum pump and
cruise control ECU as necessary.
4) Check cruise control ECU connector C-50. Repair as
necessary. If malfunction remains, replace cruise control ECU.
CODE 12: VEHICLE SPEED SENSOR SIGNAL
Code 12 is displayed if vehicle speed signals from vehicle
speed sensor are not input to cruise control ECU when vehicle speed is
25 MPH or more. Probable causes are:
* Malfunction of VSS.
* Malfunction of connector.
* Malfunction of harness.
* Malfunction of cruise control ECU.
1) Check vehicle speed sensor. See VEHICLE SPEED SENSOR TEST
under COMPONENT TESTS. If speed sensor is okay, go to next step. If
speed sensor is defective, repair or replace as necessary.
2) Disconnect combination meter connector C-06. See Fig. 10.
At harness side of connector, with ignition switch in ON position,
measure voltage between terminal No. 1 and ground. If voltage is 4.5
volts or more, go to next step. If voltage is less than 4.5 volts,
