Page 15 of 1501
![MITSUBISHI MONTERO 1998 Service Manual Water Pump Bolt (Diamante)
8 mm Bolt .............................................. 18 (24)\
10 mm Bolt ............................................. 30 (41)\](/img/19/57333/w960_57333-14.png "MITSUBISHI MONTERO 1998 Service Manual Water Pump Bolt (Diamante)
8 mm Bolt .............................................. 18 (24)\
10 mm Bolt ............................................. 30 (41)\")
Water Pump Bolt (Diamante)
8 mm Bolt .............................................. 18 (24)\
10 mm Bolt ............................................. 30 (41)\
INCH Lbs. (N.m)
Crankshaft & Drive Plate
Bell Housing ............................................ 79.7 (9)\
Oil Seal Case .......................................... 97.3 (11)\
Rear Plate (Montero) ................................... 97.3 (11\
)
Exhaust Manifold
Heat Shield ........................................... 123.9 (14)\
Oil Level Gauge Guide Bolt ............................ 123.9 (14)\
Generator & Drive Belt
Cooling Fan Bolt (Montero) ............................. 97.3 (11\
)
Cooling Fan Nut (Montero) .............................. 97.3 (11\
)
Timing Indicator Bolt (Montero) ........................ 97.3 (11\
)
Intake Manifold & Fuel
ECT Gauge Sender ....................................... 97.4 (11)\
Fuel Pressure Regulator Bolt ............................ 79.6 (9)\
Fuel Pipe Banjo Bolt .................................... 79.6 (9)\
Injector & Fuel Rail Bolt ............................. 106.2 (12)\
Water Outlet Pipe ..................................... 123.9 (14)\
Intake Plenum & Throttle Body
Ignition Coil Bolt (Montero) ............................ 115 (13\
)
Manifold Differential Pressure (MDP) Sensor ............. 44 (4.9\
)
Throttle Body Bolt ...................................... 106 (12)\
Vacuum Hose Assembly (Diamante) ......................... 88 (9.8\
)
Oil Pan & Oil Pump
Baffle Plate (Montero) ................................. 97.3 (11\
)
Baffle Plate (Diamante) ................................ 97.3 (11\
)
6 mm Bolt ............................................... 53.1 (6)\
8 mm Bolt ............................................... 79.6 (9)\
Oil Pump Cover Bolt (Diamante) ......................... 88.5 (10\
)
Oil Pump Cover Bolt (Montero)
6 mm x 10 mm Bolt .................................... 97.3 (11)\
6 mm x 18 mm Bolt ..................................... 53.1 (6)\
Oil Pressure Gauge Sender .............................. 88.5 (10)\
Oil Pan (Upper) ......................................... 53.1 (6\
)
Oil Pan (Lower) ........................................ 97.3 (11\
)
Oil Pump Case ......................................... 123.9 (14)\
Oil Screen (Montero)
6 mm Bolt ............................................. 53.1 (9)\
Rocker Arms & Camshafts
Rocker Cover Bolt ....................................... 31 (3.5)\
Thrust Case Bolt ...................................... 115.1 (13)\
Timing Belt
Camshaft Position (CMP) Sensor (Montero) ................ 79.6 (\
9)
Crankshaft Position (CKP) Sensor ........................ 79.6 (9\
)
( 1) - Tighten cylinder head bolts in 2 or 3 steps with engine cold.
\
\
\
\
\
\
\
ENGINE SPECIFICATIONS
GENERAL SPECIFICATIONS
GENERAL SPECIFICATIONS\
\
\
\
\
\
\
Application Specification
Displacement .................................. 213.4 Cu. In. (3.5L)\
Bore ............................................... 3.6614" (93 mm)\
Page 135 of 1501
Fig. 8: Identifying Data Link Connector Terminals
Courtesy of Mitsubishi Motor Sales of America.
CLEARING DTCs
To clear DTCs using scan tool, follow scan tool
manufacturer's instructions. To clear DTCs without scan tool,
disconnect negative battery cable for at least 10 seconds. Reconnect
battery cable and repeat RETRIEVING DTCs to confirm that malfunction
has been corrected.
DTC DEFINITION
\
\
\
\
\
\
\
DTC ( 1) System Affected
11 ..................... Right Front Wheel Speed Sensor (Open/Short)\
12 ...................... Left Front Wheel Speed Sensor (Open/Short)\
13 ...................... Right Rear Wheel Speed Sensor (Open/Short)\
14 ....................... Left Rear Wheel Speed Sensor (Open/Short)\
15 ..................... Wheel Speed Sensor Output Signal (Abnormal)\
16 ................................................ ECU Power Supply
21 ....................... Right Front Wheel Speed Sensor (Abnormal)\
22 .............................. Left Front Wheel Sensor (Abnormal)\
23 ........................ Right Rear Wheel Speed Sensor (Abnormal)\
24 ......................... Left Rear Wheel Speed Sensor (Abnormal)\
25 ........................................ Free Wheel Engage Switch
26 ....................... Center Differential Lock Detection Switch
27 ..................... ( 2) Rear Differential Lock Detection Switch
Page 136 of 1501
27 ..................... (3) Rear Differential Lock Detection Switch
32 ............................................... "G" Sensor System
33 ......................................... Stoplight Switch System
41 ....................................... RF Solenoid Valve Circuit
42 ....................................... LF Solenoid Valve Circuit
43 ..................................... Rear Solenoid Valve Circuit
51 ..................................................... Valve Relay
53 ..................................................... Motor Relay
63 Or 64 ............................................ ( 4) Faulty ECU
( 1) - See appropriate DTC under DIAGNOSTIC TESTS.
( 2) - Vehicles with differential lock.
( 3) - Vehicles without differential lock.
( 4) - Replace ECU.
\
\
\
\
\
\
\
DIAGNOSTIC TESTS
DTC 11, 12, 13 OR 14: WHEEL SPEED SENSOR (OPEN/SHORT
CIRCUIT)
NOTE: DTC will set if ECU detects a wheel speed sensor open or
short circuit.
1) Ensure sensor is properly installed. See WHEEL SPEED
SENSOR (WSS) under REMOVAL & INSTALLATION . Correct installation if
needed. If installation is okay, go to next step.
2) Disconnect ECU 26-pin connector. Check resistance between
specified ECU connector terminals. See
WHEEL SPEED SENSOR OUTPUT CIRCUIT IDENTIFICATION table. See Figs. 5-6.
Resistance for front sensors should be 1170-1350 ohms. Resistance for
rear sensors should be 1300-1500 ohms. If resistance is as specified,
go to next step. If resistance is not as specified, check and repair
connectors and related wiring between ECU and suspect sensor. See
WIRING DIAGRAMS .
WHEEL SPEED SENSOR OUTPUT CIRCUIT IDENTIFICATION
\
\
\
\
\
\
\
Application Terminals No.
Left Front .................................................. 7 & 20
Left Rear ................................................... 9 & 22
Right Front ................................................ 10 & 23
Right Rear .................................................. 8 & 21
\
\
\
\
\
\
\
3) Raise and support vehicle. Disconnect ECU connectors.
Using DVOM, backprobe specified ECU connector terminals. See
WHEEL SPEED SENSOR OUTPUT CIRCUIT IDENTIFICATION table. See Figs. 5-6.
Check voltage between each harness connector terminal while rotating
wheel at 1/2 to one rotation per second. If pulse voltage is 70 mV or
more, go to step 8). If voltage is not as specified, go to next step.
4) Inspect condition of suspect speed sensor. Ensure tip of
speed sensor is clean. If speed sensor is okay, go to next step.
5) Disconnect sensor connector. Using DVOM, check resistance
across sensor terminals. Resistance for front sensors should be 1170-
1350 ohms. Resistance for rear sensors should be 1300-1500 ohms. If
resistance is as specified, go to next step. If resistance is not as
specified, replace sensor.
6) Remove sensor. Check resistance between each sensor
terminal and sensor body. If resistance is 100,000 ohms or more, go to
next step. If resistance is not as specified, replace sensor.
Page 138 of 1501
2) Disconnect ECU 26-pin connector. Check resistance between
specified ECU connector terminals. See
WHEEL SPEED SENSOR OUTPUT CIRCUIT IDENTIFICATION table. See Figs. 5-6.
Resistance for front sensors should be 1170-1350 ohms. Resistance for
rear sensors should be 1300-1500 ohms. If resistance is as specified,
go to next step. If resistance is not as specified, check and repair
connectors and related wiring between ECU and suspect sensor. See
WIRING DIAGRAMS .
3) Raise and support vehicle. Disconnect ECU connectors.
Using DVOM, backprobe specified ECU connector terminals. See
WHEEL SPEED SENSOR OUTPUT CIRCUIT IDENTIFICATION table. See Figs. 5-6.
Check voltage between each harness connector terminal while rotating
wheel at 1/2 to one rotation per second. If pulse voltage is 70 mV or
more, go to step 8). If voltage is not as specified, go to next step.
4) Inspect condition of suspect speed sensor. Ensure tip of
speed sensor is clean. If speed sensor is okay, go to next step.
5) Disconnect sensor connector. Using DVOM, check resistance
across sensor terminals. Resistance for front sensors should be 1170-
1350 ohms. Resistance for rear sensors should be 1300-1500 ohms. If
resistance is as specified, go to next step. If resistance is not as
specified, replace sensor.
6) Remove sensor. Check resistance between each sensor
terminal and sensor body. If resistance is 100,000 ohms or more, go to
next step. If resistance is not as specified, replace sensor.
7) Inspect condition of toothed rotor. Check for broken or
deformed teeth. If toothed rotor is okay, go to next step.
8) Check ECU connectors. Repair connectors as needed. If
connectors are okay, replace ECU.
DTC 25: FREE WHEEL ENGAGE SWITCH
NOTE: DTC sets if ECU detects an open circuit in free wheel engage
switch.
1) Start engine. Ensure 4WD indicator light operates
correctly when transfer shift lever is moved to desired 4WD positions.
If indicator light operates correctly, go to step 3). If indicator
light does not operate correctly, go to next step.
2) Turn engine off. Check wiring harness between 4WD
indicator control unit (located behind radio) and free wheel engage
switch (located on right side of front differential housing, near
carrier assembly). If circuit is okay, replace 4WD indicator control
unit.
3) Disconnect ECU 22-pin connector. Turn ignition on. Using
DVOM, check voltage between ECU 22-pin connector terminal No. 45 and
ground. See Figs. 5-6. In 2WD, battery voltage should exist. Battery
voltage should not exist in 4WD. If voltage is as specified, go to
next step. If voltage is not as specified, check and repair connectors
and wiring harness between free wheel engage switch and ECU. See
WIRING DIAGRAMS .
4) Check and repair ECU 22-pin connector. If connector is
okay, replace ECU.
DTC 26: CENTER DIFFERENTIAL LOCK DETECTION SWITCH
NOTE: DTC sets if ECU detects an open circuit in center
differential lock detection switch system.
1) Start engine. Ensure 4WD indicator light operates
correctly when transfer shift lever is moved to desired 4WD positions.
If indicator light does not operate correctly, go to step 4). If
indicator light operates correctly, go to next step.
2) Disconnect ECU 22-pin connector. Turn ignition on. Using
Page 139 of 1501
DVOM, check voltage between ECU 22-pin connector terminal No. 35 and
ground. See Figs. 5-6. Battery voltage should exist in 4WD. Go to next
step.
3) If voltage is not as specified, check and repair
connectors and wiring harness between center differential lock
detection switch and ECU. See WIRING DIAGRAMS. Center differential
lock detection switch is located on side of transfer case. See Fig. 9.
If voltage is as specified, check and repair ECU 22-pin connector. If
connector is okay, replace ECU.
Fig. 9: Identifying 4WD Indicator Switch Location
Courtesy of Mitsubishi Motor Sales of America.
NOTE: When checking for short in ECU circuit, remove ECU connector
and ensure 4WD indicator light operates correctly. If 4WD
indicator light operates correctly, replace faulty ECU. If
4WD indicator light does not operate correctly, replace
faulty 4WD indicator control unit.
4) If no indicator lights come on, repair 4WD indicator power
circuit, or check for faulty 4WD indicator control unit. See 4WD
CONTROL UNIT under COMPONENT TESTS. If center differential light comes
on, regardless of position of transfer shift lever, check the
following:
Page 140 of 1501
* Check for short in center differential lock switch circuit.
* Check for faulty center differential lock switch.
* Check for short in ECU circuit or faulty ECU.
* Check for short in indicator control unit circuit or faulty
4WD indicator control unit.
Repair wiring harness or replace component as necessary. See
WIRING DIAGRAMS .
5) If 4WD indicator light does not come on with transfer
shift lever in "4H" position, repair wiring harness between 4WD
indicator control unit and center differential lock switch. Check for
faulty 4WD indicator control unit.
6) If 4WD indicator light does not come on with transfer
shift lever in "4H" position, repair wiring harness between 4WD
indicator control unit and free wheel engage switch. See
WIRING DIAGRAMS . Check ground wire at engage switch. Check for faulty
free wheel engage switch.
DTC 27: REAR DIFFERENTIAL LOCK DETECTION SWITCH (WITH
DIFFERENTIAL LOCK)
NOTE: DTC is set if ECU detects an open circuit in rear
differential lock detection switch system.
1) Start engine. Ensure rear differential indicator light
comes on when top of rear differential lock switch (located below
radio) is pushed. If indicator light comes on, go to step 3). If
indicator light does not come on, go to next step.
2) Turn engine off. Check wiring harness between rear
differential lock control unit and rear differential lock switch. See
WIRING DIAGRAMS . Check rear differential lock control unit power
circuit. See REAR DIFFERENTIAL CONTROL UNIT under COMPONENT TESTS. If
circuit is okay, replace rear differential lock control unit.
3) Disconnect ECU 22-pin connector. Turn ignition on. Using
DVOM, check voltage between terminal No. 46 and ground. See Figs. 5-6.
When rear differential is locked, battery voltage should not be
present. When rear differential is unlocked, battery voltage should be
present. If voltage is as specified, go to next step. If voltage is
not as specified, repair connectors and related wiring harness between
ECU and rear differential lock switch. See WIRING DIAGRAMS.
4) Check and repair ECU 22-pin connector. If connector is
okay, replace ECU.
DTC 27: REAR DIFFERENTIAL LOCK DETECTION SWITCH (WITHOUT
DIFFERENTIAL LOCK)
NOTE: DTC is set if ECU detects an interruption of battery voltage
at ECU terminal No. 46.
1) Check fuse No. 18 in main fuse block. If fuse is blown,
correct cause of blown fuse, and replace fuse. If fuse is okay, go to
next step.
2) Disconnect ECU 22-pin connector. Turn ignition on. Using
DVOM, check voltage between terminal No. 46 and ground. See Figs. 5-6.
If battery voltage is present, go to next step. If battery voltage is
not present, check and repair connectors and related wiring harness
between ECU and fuse No. 18. See WIRING DIAGRAMS.
3) Check and repair ECU 22-pin connector. If connector is
okay, replace ECU.
DTC 32: "G" SENSOR SYSTEM
NOTE: DTC is set if ECU detects "G" sensor output voltage less
Page 145 of 1501
All switches are mounted to transfer case. See Fig. 9.
Switches use single harness lead and ground to transfer case. See 4WD
INDICATOR SWITCH CONTINUITY CHECK table. Ensure all appropriate
grounding straps are connected to vehicle body or frame.
4WD INDICATOR SWITCH CONTINUITY CHECK
\
\
\
\
\
\
\
Switch Transfer Control Lever Position Specification
Center Differential Lock
Detection Switch .............. 4H ................. No Continuity
Detection Switch ............. 4HLc ................... Continuity
Center Differential Lock
Operation Detection Switch .. 4H .................. No Continuity
" ........................... 4HLc .................... Continuity
4WD Operation
Detection Switch .............. 2H ................. No Continuity
Detection Switch .............. 4H .................... Continuity
HI/LO Detection Switch ...... 4HLc .................... Continuity
" ............................. N .................. No Continuity
" ........................... 4LLc .................... Continuity
2WD/4WD
Detection Switch ............ 2H .................... Continuity
" ........................... 4H ................. No Continuity
\
\
\
\
\
\
\
REAR DIFFERENTIAL CONTROL UNIT
Remove rear seat and remove rear differential control unit.
Do not disconnect control unit harness connector. Backprobe harness
connector. Check voltage between each individual terminal and ground
terminal No. 6 (Black wire). See Figs. 14 and 15. If after all tests
have been completed system is not operating properly, substitute rear
differential control unit with known good-unit and retest.
Fig. 14: Identifying Rear Differential Control Unit Connector
Courtesy of Mitsubishi Motor Sales of America.
Page 146 of 1501
Fig. 15: Rear Differential Control Unit Pin Voltage Chart
Courtesy of Mitsubishi Motor Sales of America.
WHEEL SPEED SENSOR (WSS)
WSS Resistance Test
1) Before testing WSS resistance, ensure pole piece-to-WSS
tip is clean. Check WSS pole piece for damage. If pole piece is
damaged, replace WSS.
2) Disconnect WSS connector. Inspect WSS wiring harness for
broken and pinched wires. See WIRING DIAGRAMS. Repair harness as
necessary. If harness is okay, go to next step.
3) Using ohmmeter, check resistance across WSS terminals.
Resistance for front WSS should be 1170-1350 ohms. Resistance for rear
WSS should be 1300-1500 ohms. If resistance is as specified, go to
GROUND CIRCUIT TEST. If resistance is not as specified, replace WSS.
Ground Circuit Test
Disconnect WSS wiring harness connector. Check resistance
between each WSS terminal and WSS housing. Resistance should be more
than 100,000 ohms. If resistance is not as specified, replace WSS.
REMOVAL & INSTALLATION
ELECTRONIC CONTROL UNIT (ECU)
Removal & Installation
1) ECU is located behind right rear quarter panel trim. See
Fig. 16 . Disconnect negative battery cable. Remove quarter panel
mounti ng screws and trim clip.
2) Carefully remove quarter panel trim. Disconnect ECU wiring
harness connector. Remove ECU mounting bolts/nuts and ECU. To install,
reverse removal procedure.
Page 184 of 1501
* BRAKE SYSTEM UNIFORM INSPECTION GUIDELINES *
1998 Mitsubishi Montero
GENERAL INFORMATION
Brake Systems - Motorist Assurance Program
Standards For Automotive Repair
All Makes & Models
CONTENTS
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
OVERVIEW OF SERVICE REQUIREMENTS AND SUGGESTIONS
ACCELEROMETERS (G SENSOR OR LATERAL)
ACCUMULATORS
ANCHOR PINS
ANTI-LOCK BRAKE SYSTEMS
BACKING PLATES
BRAKE FLUID
BRAKE FRICTION MATERIAL
BRAKE PADS
BRAKE PEDALS
BRAKE SHOES
BRAKE SHOE HARDWARE
BRAKE STOPLIGHT SWITCHES
BULB SOCKETS
BULBS AND LEDS
CALIPER HARDWARE
CALIPERS
CONTROLLERS
DIGITAL RATIO AXLE CONTROLLERS AND BUFFERS (DRAC AND DRAB)
DISABLE SWITCHES
DRUMS
ELECTRICAL PUMPS AND MOTORS
ELECTRONIC CONTROLLERS
FLUID
FLUID LEVEL SENSOR SWITCHES
FOUR WHEEL DRIVE SWITCHES
FRICTION MATERIAL
G SENSORS
HOSES
HYDRAULIC MODULATORS
HYDRO-BOOSTERS
HYDRO-ELECTRIC BOOSTERS (POWERMASTER)
IGNITION DISABLE SWITCHES
LATERAL ACCELERATION SWITCHES
LEDS
LENSES
MASTER CYLINDERS
MODULATORS
MOTORS
PARKING BRAKE SWITCHES
PARKING BRAKE SYSTEMS
PADS
PEDAL TRAVEL SWITCHES
PEDALS
POWERMASTER
PUMPS
PRESSURE DIFFERENTIAL SWITCHES
PRESSURE SWITCHES
RELAYS
ROTORS
SELF-ADJUSTING SYSTEMS
Page 205 of 1501
missing ................ C .. Require replacement of missing
parts.
Threads damaged ......... A .. Require repair or replacement.
Threads stripped (threads
missing) ............... A ............ Require replacement.
(1) - Inoperative includes intermittent operation.
\
\
\
\
\
\
\
PADS
See FRICTION MATERIAL .
PEDAL TRAVEL SWITCHES
See SWITCHES.
PEDALS
See BRAKE PEDALS.
POWERMASTER
See HYDRO-BOOSTERS .
PUMPS
See ELECTRICAL PUMPS AND MOTORS .
PRESSURE DIFFERENTIAL SWITCHES
See SWITCHES.
PRESSURE SWITCHES
See SWITCHES.
RELAYS
NOTE: Copied from Electrical UIGs
RELAY INSPECTION
\
\
\
\
\
\
\
Condition Code Procedure
Attaching hardware
broken ................. A ... Require repair or replacement
of hardware.
Attaching hardware
missing ................ C .......... Require replacement of
hardware.
Attaching hardware not
functioning ............ A ... Require repair or replacement
of hardware.
Housing broken .......... A ............ Require replacement.
Housing cracked ......... 2 ............ Suggest replacement.
Inoperative ( 1) ......... A ............ Require replacement.
Missing ................. C ............ Require replacement.
Terminal broken ......... A .. Require repair or replacement.
Terminal burned,
affecting performance .. A ........... ( 2) Require repair or
replacement.
