Page 977 of 1501

MITSUBISHI MONTERO 1998 Service Manual MIRRORS - POWER
1998 Mitsubishi Montero
1998 ACCESSORIES & EQUIPMENT
Mitsubishi - Power Mirrors
Eclipse, Galant, Mirage, Montero, Montero Sport, 3000GT
DESCRIPTI

Page 1001 of 1501

MITSUBISHI MONTERO 1998 Service Manual PARASITIC LOAD EXPLANATION & TEST PROCEDURES
1998 Mitsubishi Montero
GENERAL INFORMATION
Parasitic Load Explanation & Test Procedures
* PLEASE READ THIS FIRST *
T

PARASITIC LOAD EXPLANATION & TEST PROCEDURES
1998 Mitsubishi Montero
GENERAL INFORMATION
Parasitic Load Explanation & Test Procedures
* PLEASE READ THIS FIRST *
This article is provided for general information only. Not
all procedures apply to all makes and models.
GENERAL INFORMATION
The term Parasitic Load refers to electrical devices that
continue to use or draw current after the ignition switch is turned to
OFF position. This small amount of continuous battery draw is
expressed in milliamps (mA). On Ford Motor Co. and General Motors
vehicles produced after 1980, a typical Parasitic Load should be no
more than 50 milliamps (0.050 amps).
Vehicles produced since 1980 have memory devices that draw
current with ignition off for as long as 20 minutes before shutting
down the Parasitic Drain. When Parasitic Load exceeds normal
specifications, the vehicle may exhibit dead battery and no-start
condition.
Follow test procedure for checking Parasitic Loads to
completion. A brief overview of a suggested test procedure is included
along with some typical Parasitic Load specifications. Refer to the
GENERAL MOTORS PARASITIC LOAD TABLE chart.
TESTING FOR PARASITIC LOAD
INTRODUCTION
CAUTION: Always turn ignition off when connecting or disconnecting
battery cables, battery chargers or jumper cables. DO NOT
turn test switch to OFF position (which causes current to run
through ammeter or vehicle electrical system).
NOTE: Memory functions of various accessories must be reset after
the battery is reconnected.
The battery circuit must be opened to connect test switch
(shunt) and ammeter into the circuit. When a battery cable is removed,\
timer circuits within the vehicle computer are interrupted and
immediately begin to discharge. If in doubt about the condition of the
ammeter fuse, test it with an ohmmeter prior to beginning test. An
open fuse will show the same reading (00.00) as no parasitic drain.
Begin test sequence with the meter installed and on the 10-amp scale.
Select lower scale to read parasitic draw.
TEST PROCEDURE USING TEST SWITCH
1) Turn ignition off. Remove negative battery terminal cable.
Install Disconnect Tool (J-38758) test switch male end to negative
battery cable. Turn test switch knob to OFF position (current through
meter). Install negative battery cable to the female end of test
switch.
2) Turn test switch knob to ON position (current through
switch). Road test vehicle with vehicle accessories on (radio, air
conditioner, etc.). After road test, turn ignition switch to LOCKED
position and remove key. Connect ammeter terminals to test switch

Page 1374 of 1501

$MITSUBISHI MONTERO 1998 Service Manual Fires With Key Flywheel runout contributes released. Engine to the intermittent nature Fires and Cranks Normally ��\ ��\ ��\ ��\$

Fires With Key Flywheel runout contributes
released. Engine to the intermittent nature
Fires and Cranks
Normally
\
\
\
\
\
\
\

AIR CONDITIONING & HEAT
AIR CONDITIONING TROUBLE SHOOTING
WARNING: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.
BASIC AIR CONDITIONING TROUBLE SHOOTING CHART
\
\
\
\
\
\
\

CONDITION POSSIBLE CAUSE\
\
\
\
\
\
\

Compressor Not Working
Compressor clutch circuit open.

Compressor clutch coil inoperative.

Poor clutch ground connection.

Fan belts loose.

Thermostatic switch inoperative.

Thermostatic switch not adjusted.

Ambient temperature switch open.

Superheat fuse blown.\
\
\
\
\
\
\

Excessive Noise or Vibration
Missing or loose mounting bolts.

Bad idler pulley bearings.

Fan belts not tightened correctly.

Compressor clutch contacting body.

Excessive system pressure.

Compressor oil level low.

Damaged clutch bearings.

Damaged reed valves.

Damaged compressor.\
\
\
\
\
\
\

Insufficient or No Cooling;
Compressor Working
Expansion valve inoperative.

Heater control valve stuck open.

Low system pressure.

Blocked condenser fins.

Blocked evaporator fins.

Vacuum system leak.

Vacuum motors inoperative.

Control cables improperly adjusted.

Restricted air inlet.

Mode doors binding.

Blower motor inoperative.

Temperature above system capacity.\
\
\
\
\
\
\

HEATER SYSTEM TROUBLE SHOOTING
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to

Page 1375 of 1501

MITSUBISHI MONTERO 1998 Service Manual problem symptoms. For model-specific Trouble Shooting,
refer to DIAGNOSTIC, or TESTING articles available in the
section(s) you are accessing.
BASIC HEATER SYSTEM TROUBLE S

problem symptoms. For model-specific Trouble Shooting,
refer to DIAGNOSTIC, or TESTING articles available in the
section(s) you are accessing.
BASIC HEATER SYSTEM TROUBLE SHOOTING CHART
\
\
\
\
\
\
\

CONDITION POSSIBLE CAUSE\
\
\
\
\
\
\

Insufficient, Erratic,
or No Heat
Low Coolant Level

Incorrect thermostat.

Restricted coolant flow through
heater core.

Heater hoses plugged.

Misadjusted control cable.

Sticking heater control valve.

Vacuum hose leaking.

Vacuum hose blocked.

Vacuum motors inoperative.

Blocked air inlet.

Inoperative heater blower motor.

Oil residue on heater core fins.

Dirt on heater core fins.\
\
\
\
\
\
\

Too Much Heat
Improperly adjusted cables.

Sticking heater control valve.

No vacuum to heater control valve.

Temperature door stuck open.\
\
\
\
\
\
\

Air Flow Changes During
Acceleration
Vacuum system leak.

Bad check valve or reservoir.\
\
\
\
\
\
\

Air From Defroster At All
Times
Vacuum system leak.

Improperly adjusted control cables.

Inoperative vacuum motor.\
\
\
\
\
\
\

Blower Does Not Operate
Correctly
Blown fuse.

Blower motor windings open.

Resistors burned out.

Motor ground connection loose.

Wiring harness connections loose.

Blower motor switch inoperative.

Blower relay inoperative.

Fan binding or foreign object
in housing.

Fan blades broken or bent.\
\
\
\
\
\
\

BRAKES
BRAKE SYSTEM TROUBLE SHOOTING
NOTE: This is GENERAL information. This article is not intended
to be specific to any unique situation or individual vehicle
configuration. The purpose of this Trouble Shooting
information is to provide a list of common causes to
problem symptoms. For model-specific Trouble Shooting,
refer to SUBJECT, DIAGNOSTIC, or TESTING articles available
in the section(s) you are accessing.

Page 1399 of 1501

MITSUBISHI MONTERO 1998 Service Manual Excessive cylinder wear Rebore or replace
block
Excessive valve guide Worn or loose bearing

Excessive cylinder wear Rebore or replace
block
Excessive valve guide Worn or loose bearing
clearance
\
\
\
\
\
\
\

Gap Bridged Deposits in combustion Clean combustion
chamber becoming fused chamber of deposits
to electrode
\
\
\
\
\
\
\

Blistered Engine overheating Check cooling system
Electrode
Wrong type of fuel Replace with correct
fuel
Loose spark plugs Retighten spark plugs
Over-advanced ignition Reset ignition timing
timing see ENGINE PERFORMANCE
\
\
\
\
\
\
\

Pre-Ignition or Incorrect type of fuel Replace with correct
Melted Electrodes fuel
Incorrect ignition timing Reset ignition timing
see ENGINE PERFORMANCE
Burned valves Replace valves
Engine Overheating Check cooling system
Wrong type of spark plug, Replace with correct
too hot spark plug, see
ENGINE PERFORMANCE
\
\
\
\
\
\
\

Chipped Severe detonation Check for over-
Insulators advanced timing or
combustion
Improper gapping Re-gap spark plugs
procedure
\
\
\
\
\
\
\

Rust Colored Additives in unleaded Try different fuel
Deposits fuel brand
\
\
\
\
\
\
\

Water In Combus- Blown head gasket or Repair or replace
tion Chamber cracked head head or head gasket
\
\
\
\
\
\
\

NOTE: Before diagnosing an electronic ignition system, ensure that
all wiring is connected properly between distributor, wiring
connector and spark plugs. Ignition problem will show up
either as: Engine Will Not Start or Engine Runs Rough.
BASIC ELECTRONIC IGNITION TROUBLE SHOOTING CHARTS
\
\
\
\
\
\
\

CONDITION POSSIBLE CAUSE CORRECTION\
\
\
\
\
\
\

Engine Won't Open circuit between Repair circuit
Start distributor and bulkhead
connector
Open circuit between Repair circuit
bulkhead connector and
