starter mounting bolt MITSUBISHI MONTERO 1998 Service Manual

release bearing with solvent. Apply a light coat of multipurpose
grease to release bearing sliding surface. Apply a very light coating
of grease to input shaft splines. DO NOT allow grease or dirt on
clutch disc or pressure plate surfaces.
3) To install remaining components, reverse removal
procedure. Refill all fluids to proper levels. Adjust all control
cables, clutch pedal height and free play. See CLUTCH PEDAL HEIGHT and
CLUTCH PEDAL FREE PLAY under ADJUSTMENTS. See Fig. 1.
Removal (4WD Models)
1) Remove switch panel from rear console. Remove suspension
control switch or hole cover. Disconnect rear console harness
connector. Remove side panel. Remove rear console assembly. Remove
shift lever knob(s). Remove floor console harness connector. Remove
front console assembly.
2) Move transmission lever to Neutral position and transfer
lever to 4H (4WD high range) position. Remove control lever boot
retainer and boot. Remove transmission and transfer control lever
assemblies. Remove control lever bushing (transmission), gaskets and
stopper plates.
3) Raise and support vehicle. Remove skid plate and front
exhaust pipe. Drain transmission and transfer case fluid. Index mark
front and rear drive shaft flanges. Remove front and rear drive
shafts.
4) Remove drive shaft dust seals. Disconnect HI/LO and
2WD/4WD detection switch connectors. Disconnect back-up light switch
connector. Disconnect center differential lock detection switch
connector. Disconnect center differential lock operation switch
connector. Disconnect 4WD operation detection switch.
5) Disconnect speedometer cable. Remove clutch slave cylinder
heat shield. Remove clutch slave cylinder (without disconnecting
hydraulic line) and wire aside. Remove starter and starter cover.
Remove heat shield, both transmission stays and bellhousing lower
cover.
6) Support transmission with transmission jack. Remove
transfer case roll stopper and bracket. Remove crossmember and engine
mounting rear insulator. Remove transfer case protector bracket and
mass damper. Remove remaining bellhousing bolts. Pull toward rear of
vehicle to free transmission input shaft from clutch. Lower
transmission/transfer assembly from vehicle.
7) If reusing pressure plate, mark pressure plate to flywheel
for installation reference. Insert a clutch alignment tool to prevent
pressure plate and clutch disc from dropping. Loosen pressure plate
bolts gradually in a crisscross pattern to avoid warping pressure
plate flange during removal. Remove pressure plate and clutch disc.
See Fig. 3 .
Fig. 3: Removing & Installing Clutch On Flywheel (Typical)
Courtesy of Mitsubishi Motor Sales of America.
Inspection
1) Check release bearing and release fork for damage or wear.

Clutch Pedal Mounting Nut .................................. 21 (29)\
Flywheel Bolt
Montero .................................................. 54 (74)\
Montero Sport ........................................... 98 (132)\
Fulcrum Ball ............................................... 26 (35)\
Hydraulic Line Flare Nut ................................... 11 (15)\
Push Rod Jam Nut ........................................... 10 (13)\
Release Cylinder Mounting Bolt ............................. 27 (36)\
Starter Mounting Bolt ...................................... 23 (31)\
Transfer Case Roll Stopper Bolt ............................ 33 (44)\
Transmission Crossmember Mounting Bolt ..................... 47 (64)\
Transmission Support Bolt
Front (Crossmember) ...................................... 29 (39\
)
Rear ..................................................... 26 (35)\









\









\









\









\









\









\









\

ARMATURE TEST
Ensure armature is not grounded. Place armature in growler.
Hold a thin steel blade parallel and just above armature while slowly
rotating armature in growler. A shorted armature will cause blade to
vibrate and be attracted to core. Using an ohmmeter, check continuity
between armature coil cores and commutator segments (small diameter
end of armature). Continuity should not exist. Check for continuity
between segments. Continuity should exist. Replace armature as
necessary.
BRUSH HOLDER TEST
Using an ohmmeter, check continuity between brush holder
plate and brush holder. Continuity should not exist. Replace brush
holder as necessary.
REMOVAL & INSTALLATION
NOTE: On Montero with A/T, it may be necessary to disconnect
transmission oil cooler line for starter removal.
Removal & Installation
Disconnect negative battery cable. If necessary, raise
vehicle on hoist. Remove starter mounting bolts and starter. To
install, reverse removal procedure.
OVERHAUL
Check commutator for out-of-round and proper amount of
undercut. Replace or repair armature if not within specification. See
STARTER SPECIFICATIONS table. Ensure brushes are not worn beyond wear
line (outer line closest to commutator contact surface). Check pinion
gap. See PINION GAP MEASUREMENT under BENCH TESTING. See Figs. 5 and
6.
Fig. 5: Exploded View Of Direct Drive Starter (Typical)
Courtesy of Mitsubishi Motor Sales of America

TRANSMISSION REMOVAL & INSTALLATION - A/T
1998 Mitsubishi Montero
1997-98 TRANSMISSION SERVICING
Mitsubishi Transmission Removal & Installation
Diamante, Eclipse, Galant, Mirage, Montero, 3000GT
REMOVAL & INSTALLATION
AWD & FWD MODELS
Removal
1) On all models except Galant, remove battery and battery
tray. On 3000GT, remove washer tank. On all models, remove air cleaner
cover with air inlet hose assembly. Raise and support vehicle. Remove
wheels. Remove undercover(s) (if equipped). Disconnect control cable\
s
at transaxle. Drain transaxle fluid.
2) On AWD models, remove front exhaust pipe. On all models,
disconnect neutral safety switch connector, oil cooler hoses and
electrical connectors from transaxle. Disconnect speedometer cable and
throttle control cable (if equipped). Remove starter motor.
3) Separate tie rod end. Separate lower ball joint. Separate
stabilizer bar connection (if necessary). Remove axle shafts. See
appropriate AXLE SHAFTS article in DRIVE AXLES. Remove center
crossmember assembly.
4) On AWD models, separate transfer assembly from transaxle.
Reference mark transfer assembly-to-drive shaft and remove transfer
assembly.
5) On all models, remove transmission inspection (dust)
cover. Place index mark on torque converter and drive plate for
reassembly reference. Remove torque converter-to-drive plate bolts.
Push torque converter away from engine into transaxle.
6) On all 4-cylinder models, support engine. On all models,
support transaxle with jack. Remove bolts from transaxle mounts.
Remove mounting brackets and remaining transaxle-to-engine bolts.
Slide transaxle assembly to right and lower to remove.
CAUTION: Ensure torque converter is fully seated in transaxle before
installation. Always install new snap rings on inner
constant velocity joints.
Installation
1) To install, reverse removal procedure. Tighten transaxle-
to-engine bolts and torque converter-to-drive plate bolts to
specification. See TORQUE SPECIFICATIONS .
2) Ensure reference marks on torque converter-to-drive plate
and transfer assembly-to-drive shaft align. Tighten mounting bolts
with weight of engine and transaxle on mounts. Refill transaxle fluid
to specified level. See LUBRICATION in TRANSMISSION SERVICING - A/T
article. Adjust all control cables. See ADJUSTMENTS in
TRANSMISSION SERVICING - A/T article.
RWD & 4WD MODELS
Removal
1) Disconnect negative battery cable. On Montero 4WD, remove
transfer case shift lever knob, dust boot and retainer plate or
console. Remove transfer case gearshift assembly.
2) On all models, raise and support vehicle. Remove
undercarriage cover and/or skid plate(s). Drain transmission and
transfer case (if applicable). Place reference mark on drive shaft(s)\

and remove. Disconnect all external solenoid and switch connections.
3) On Montero 4WD, remove catalytic converter and front
exhaust pipe. On all models, disconnect speedometer cable and control
cables at transmission. Remove starter and bellhousing cover. Place
reference mark on torque converter and drive plate for reassembly
reference. Remove torque converter bolts. Push torque converter back
and away from drive plate.
4) Disconnect transmission cooler lines. Remove oil filler
tube. Secure transmission on a jack. Raise transmission slightly to
take weight off mount. Remove crossmember-to-mount bolts and
crossmember.
5) Remove transfer case mounting bracket and mount (if
equipped). Remove transmission-to-engine mounting bolts. Carefully
lower transmission from vehicle.
CAUTION: Ensure torque converter is fully seated in transmission
before installation.
Installation
1) To install, reverse removal procedure. Tighten
transmission-to-engine bolts and torque converter-to-drive plate bolts
to specification. See TORQUE SPECIFICATIONS. Tighten mount bolts with
weight of engine and transmission on mounts. Ensure reference marks on
drive shaft(s) and torque converter-to-drive plate are matched.
2) Apply sealant to transfer case gearshift assembly gasket
before installation. Coat transmission oil filler tube "O" ring with
transmission fluid before installation. Refill transmission fluid to
specified level. See LUBRICATION in TRANSMISSION SERVICING - A/T
article. Adjust all control cables. See ADJUSTMENTS in
TRANSMISSION SERVICING - A/T article.
TORQUE SPECIFICATIONS
TORQUE SPECIFICATIONS - FWD MODELS








\









\









\









\









\









\









\







Applications Ft. Lbs. (N.m)\
Ball Joint Nut ............................................ 74 (100)\
Center Crossmember Assembly Front Bolt ..................... 69 (93)\
Center Crossmember Assembly Rear Bolt ...................... 52 (70)\
Starter Bolts .............................................. 22 (30)\
Tie Rod End Nut ............................................ 21 (28)\
Torque Converter-To-Drive Plate Bolt ................. 33-38 (45-52)\
Transaxle-To-Engine Block Bolt
8-mm Bolt .................................................... ( 1)
10-mm Bolt ......................................... 22-25 (30-34)\
12-mm Bolt ......................................... 31-40 (42-54)\
Upper Coupling Bolts
2.4L ..................................................... 35 (48)\
3.0L ..................................................... 54 (73)\
Lower Coupling Bolts
2.4L ..................................................... 35 (48)\
3.0L ..................................................... 65 (88)\
( 1) - Tighten to 84-108 INCH lbs. (10-12 N.m).









\









\









\









\









\









\









\







TORQUE SPECIFICATIONS - RWD MODELS








\









\









\









\









\









\









\







Applications Ft. Lbs. (N.m)\
Engine-To-Transmission Bolt ................................ 65 (88)\

\









\









\









\









\









\









\







Starter Drive Starter motor loose on Tighten starter
Will Not mountings attach bolts
Disengage
Worn drive end bushing See STARTER article
Damaged engine flywheel Replace flywheel and
teeth starter pinion gear for
damage
Drive yolk return spring Replace return spring
broken or missing
Faulty ignition switch Replace ignition switch
Insufficient clearance Replace starter
between winding leads to solenoid
solenoid terminal and main
contact in solenoid
Starter clutch not Replace starter clutch
disengaging
Ignition starter switch Replace ignition switch
contacts sticking









\









\









\









\









\









\









\







Starter Relay Faulty solenoid switch, Check all wiring
Operates but switch connections or between relay and
Solenoid Does Not solenoid or replace
relay or solenoid as
necessary
Broken lead or loose Repair wire or wire
soldered connections connections as
necessary









\









\









\









\









\









\









\







Solenoid Plunger Weak battery Charge or replace
Vibrates When battery as necessary
Switch is Engaged
Solenoid contacts Clean contacts or
corroded replace solenoid
Faulty wiring Check all wiring
leading to solenoid
Broken connections inside Repair connections or
switch cover replace solenoid
Open hold-in wire Replace solenoid









\









\









\









\









\









\









\







Low Current Draw Worn brushes or weak Replace brushes or
brush springs as
necessary









\









\









\









\









\









\









\







High Pitched Whine Distance too great Align starter or check
During Cranking between starter that correct starter
Before Engine pinion and flywheel and flywheel are being
Fires but Engine used
Fires and Cranks
Normally









\









\









\









\









\









\









\







High Pitched Distance too small between
Whine After Engine starter pinion and flywheel

Does Not Close battery as necessary
Faulty wiring Check all wiring and
connections leading to
relay
Neutral safety switch Replace neutral safety
faulty switch
Starter relay faulty Replace starter relay









\









\









\









\









\









\









\







Starter Drive Starter motor loose on Tighten starter
Will Not mountings attach bolts
Disengage
Worn drive end bushing See STARTER article
Damaged engine flywheel Replace flywheel and
teeth starter pinion gear for
damage
Drive yolk return spring Replace return spring
broken or missing
Faulty ignition switch Replace ignition switch
Insufficient clearance Replace starter
between winding leads to solenoid
solenoid terminal and main
contact in solenoid
Starter clutch not Replace starter clutch
disengaging
Ignition starter switch Replace ignition switch
contacts sticking









\









\









\









\









\









\









\







Starter Relay Faulty solenoid switch, Check all wiring
Operates but switch connections or between relay and
Solenoid Does Not solenoid or replace
relay or solenoid as
necessary
Broken lead or loose Repair wire or wire
soldered connections connections as
necessary









\









\









\









\









\









\









\







Solenoid Plunger Weak battery Charge or replace
Vibrates When battery as necessary
Switch is Engaged
Solenoid contacts Clean contacts or
corroded replace solenoid
Faulty wiring Check all wiring
leading to solenoid
Broken connections inside Repair connections or
switch cover replace solenoid
Open hold-in wire Replace solenoid









\









\









\









\









\









\









\







Low Current Draw Worn brushes or weak Replace brushes or
brush springs as
necessary
