Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
 The Electric parking brake is not automatically applied because there is a fa
ult in the Electric park-
ing brake system.
 When the ignition switch is
turned off or the opera-
tion mode is put in OFF, place the selector lever in the “P” (PARK) position and depress the brake pedal more firmly than usual with the right foot. Then, operate the ignition
switch or the engine
switch.  We recommend you to have the brake auto hold sys- tem inspected by a MITSUBISHI MOTORS Autho-rized Service Point. Refer to “Brake auto hold” on page 5-93.
 The brake auto hold system does not turn on because the driver’s seat belt is not fastened.
 Press the brake auto hold switch after fastening the driver’s seat belt. Refer to “Brake auto hold” on page 5-93.
 The brake auto hold system does not turn off because the brake pedal is not pressed.
 Depress the brake pedal more firmly than usual with the right foot. Then, press
the brake auto hold switch.
Refer to “Brake auto hold” on page 5-93.
 There is a fault in the engi
ne oil circulation system.
Park your vehicle in a safe place as soon as possible and contact an authorized
Mitsubishi Motors dealer
or a repair facility of your
choice to have the system
checked.Refer to “Oil pressure wa
rning display” on page
5-220.
Screen
Cause
Do this (Reference)
BK0239700US.book 200 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-201
5
 There is a fault in the charging system.
Park your vehicle in a safe
place as soon as possible
and contact an authorized
Mitsubishi Motors dealer
or a repair facility of your
choice for assistance.
Refer to “Charging system
warning display” on page
5-220.
 There is a fault in the SRS airbag or the pre-tensioner system.
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked, immediately.Refer to “SRS airbag/Pre-t
ensioner system warning”
on page 4-40.
 There is a fault in the Active stability control (ASC).
Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked.Refer to “Active stability control (ASC)” on page 5-100.
 There is a fault in the Hill start assist.
Have the vehicle checked at
an authorized Mitsubi-
shi Motors dealer or a repa
ir facility of your choice.
Refer to “Hill start
assist” on page 5-95.
 There is a fault in the electronically controlled 4WD system.
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked.Refer to “Electronically
controlled 4WD system” on
page 5-82.
 There is a fault in the S-AWC system.
Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked. Refer to “S-AWC (Super-All Wheel Control)” on page 5-85.
Screen
Cause
Do this (Reference)
BK0239700US.book 201 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
 There is a fault in the automatic transaxle or CVT.
Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked. Refer to “Automatic tr
ansaxle” on page 5-67.
Refer to “Continuously
variable transmission
(CVT)” on page 5-75.
 The electronically controlled 4WD
system is hot. Refer to “Electr
onically controlled
4WD system” on
page 5-82.
 The S-AWC system is hot. Refer to “S-A
WC (Super-All Wheel Control)” on page
5-85.
 The fuel is running low.
Refuel as soon as possible. Refer to “Fuel remaining
display screen” on page
5-172.
 The outside temperature is
37 °F (3 °C) or less.
Be careful driving on frozen ground.  The ground may be frozen even when this warning is not displayed, so drive carefully.
 The Adaptive Cruise Control System (ACC) has detected the approach of
the vehicles in front.
 Increase the following di
stance by depressing the
brake pedal or marking ot
her decelerating control.
Refer to “Adaptive Cruise
Control System (ACC):
Approach alarm” on page 5-111.
 The Forward Collision Mitigation System (FCM) has detected the da
nger of collision.
 Take appropriate action such
as depressing the brake
to avoid collision.Refer to “Forward colli
sion warning function” on
page 5-119.
Screen
Cause
Do this (Reference)
BK0239700US.book 202 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-203
5
 The Adaptive Cruise Control System (ACC) detected a stop of the ve
hicle in front and stopped
your vehicle, but the brak
e will be re
leased soon.
 Depress the brake pedal
as soon as your vehicle
comes to a stop.Refer to “When ACC dete
cts a vehicle in front
within the set dist
ance” on page 5-110.
 The Electric parking brak
e cannot be applied auto-
matically.
 Depress the brake pedal as soon as possible. Refer to “Brake auto hold” on page 5-93.
Screen
Cause
Do this (Reference)
BK0239700US.book 203 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
 The Adaptive Cruise Control System (ACC) control is automatically canceled and the system is placed in the ‘standby’ state.
Refer to “How to use ACC” on page 5-108.
 Conditions for the start of control are not met, the Adaptive Cruise Control
System (ACC) cannot start
the control.  The Adaptive Cruise Control System (ACC) cannot start the control because th
e speed is out of speed
range.  The Adaptive Cruise Control System (ACC) cannot start the control because not
detected the approach of
the vehicles in front.  The Adaptive Cruise Control System (ACC) is tem- porarily unavailable due to conditions such as the adhesion of contaminants to the sensor. This is not a malfunction.  There is a fault in the Adaptive Cruise Control Sys- tem (ACC).
 Contact an authorized Mits
ubishi Motors dealer or a
repair facility of your c
hoice to have the system
checked. Refer to “When ACC dete
cts a vehicle in front
within the set distance” on page 5-110.
Screen
Cause
Do this (Reference)
BK0239700US.book 204 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-205
5
 There is a fault in the Forward Collision Mitigation System (FCM).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked. Refer to “FCM and Ultras
onic misacceleration Miti-
gation System ON/OFF swit
ch: When a problem is
detected” on page 5-123.
 FCM braking function of the Forward Collision Mit- igation System (FCM) has been activated.
Refer to “FCM braking
function” on page 5-119.
 The Forward Collision Mitig
ation System (FCM) is
temporarily unavailable for some reason. This is not a malfunction.  The Lane Departure Warning system (LDW) has detected that your vehicle is
about to leave or has left
the lane.
Refer to “Lane Departure
Warning system (LDW)” on
page 5-139.
 There is a fault in the La
ne Departure Warning sys-
tem (LDW).
 Contact an authorized Mitsubishi Motors dealer or a repair facility of your choi
ce to have the system
checked.Refer to “Lane Departure
Warning system (LDW)”
on page 5-139.
Screen
Cause
Do this (Reference)
BK0239700US.book 205 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
 The Ultrasonic misacceler
ation Mitiga
tion System
sensor is temporarily not available for some reason such as the environmental
condition or increase of
the sensor temperature.
 When the warning display does not disappear after waiting for a while, contac
t an authorized Mitsubishi
Motors dealer to have the system checked. Refer to “Ultrasonic misacc
eleration Mitigation Sys-
tem: Warning display” on page 5-131.
 The Ultrasonic misacceler
ation Mitiga
tion System
does not operate normally because there are some malfunctions in the se
nsor or the system.
 Immediately have your ve
hicle inspected at an
authorized Mitsubishi Motors dealer. Refer to “Ultrasonic misacc
eleration Mitigation Sys-
tem: Warning display” on page 5-131.
Screen
Cause
Do this (Reference)
BK0239700US.book 206 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-207
5
 The Ultrasonic misacceleration Mitigation System is activated.
Refer to “Ultrasonic misacceleration Mitigation Sys- tem” on page 5-127.
 The Blind Spot Warning (BSW) sensor is temporar- ily not available for some
reason such as the environ-
mental condition or incr
ease of the sensor
temperature.
 When the warning display does not disappear after waiting for a while, contact an authorized Mitsubishi Motors dealer.Refer to “Blind Spot Warning (BSW): When the sen- sor is temporarily not available” on page 5-135.
 The Blind Spot Warning (BSW) does not operate normally because there are
some malfunctions in the
sensor or the system.
 Immediately have your ve
hicle inspected at an
authorized Mitsubishi Motors dealer. Refer to “Blind Spot Warni
ng (BSW): When there is
a malfunction in the system
or the sensor” on page
5-135.
 Foreign objects, such as dirt
, snow or ice, adhere to
the bumper surface around the sensor.
 Remove a foreign object on the bumper surface around the sensor. When the warning display does not disappear after having cleaned the bumper
surface around the sen-
sor, contact an authorized
Mitsubishi Motors dealer.
Refer to “Blind Spot Warni
ng (BSW): When there is
a foreign objects on the
sensor” on page 5-135.
Screen
Cause
Do this (Reference)
BK0239700US.book 207 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
5
 The Rear Cross Traffic Alert (RCTA) is detected the vehicle approaching your vehicle.
 Pay special attention to the rear of your vehicle. Refer to “Rear Cross Traffic Alert (RCTA)” on page 5-136.
 There is a fault in the sensor.
Contact an authorized Mitsubishi Motors dealer. Refer to “Forward Coll
ision Mitigation System
(FCM): When a problem is detected” on page 5-123.Refer to “Lane Departure Warning System (LDW): System problem warning” on page 5-141. Refer to “Automatic high
beam system: System
problem warning” on page 5-227.
 The Forward Collision Mi
tigation System (FCM),
Lane Departure Warning system (LDW) and auto- matic high beam system is
temporarily unavailable
due to the high or low temperature of the sensor.
 After the temperature of the sensor has been in range, the system will automatically return to opera- tion. Refer to “Forward Coll
ision Mitigation System
(FCM): When a problem is detected” on page 5-123. Refer to “Lane Departure Warning System (LDW): System problem warning” on page 5-141.Refer to “Automatic high
beam system: System
problem warning” on page 5-227.
 The sensor is temporarily
unavailable due to condi-
tions such as the adhesion of contaminants to the sensor or windshield.This is not a malfunction.
Refer to “Lane Departure Wa
rning System (LDW): Sys-
tem problem warning”
on page 5-141.
Refer to “Automatic high be
am system: System problem
warning” on page 5-227.
Screen
Cause
Do this (Reference)
BK0239700US.book 208 ページ ２０１６年６月１６日　木曜日　午前１０時５８分

Indicator light, warning light, and information screen display list (multi information display - Type 1)
Features and controls 5-209
5
N00579100026
On vehicles equipped with Mitsubishi Multi- Communication System, the following infor- mation on navigation will be displayed whenguidance location such
as junction and desti-
nation is approached after you set the destina- tion and started the route guidance.
 There is a fault in the system of automatic high beam.
 Contact an authorized Mitsubishi Motors dealer. Refer to “Automatic hi
gh beam system: System
problem warning” on page 5-227.
Screen
Cause
Do this (Reference)
(if
so equipped)1- Guidance display
Shows the direction of vehicle travel and the guidance location.
2- Remaining di
stance display
Shows the distance to the location where the guidance is displayed.
Direction of vehicle travel (Example) Destination Ferry terminal Tollbooth Intermediate destination (Example)
NOTE
 Please read this section and also the separate owner’s manual for Mi
tsubishi Multi-Com-
munication System.
