Page 432 of 443

Tires and wheels
Specifications 11-7
11
N01147901890
PCD: Pitch Circle
Diameter (ins
tallation holes)
N01148002361
Tires and wheels Tire P215/70R16 99H P225/55R18 97HWheel
Size 16 x 6 1/2J 18 x 7JPCD 4.5 in (114.3 mm)Offset (Inset) 1.5 in (38 mm)
NOTE
Contact an authorized Mitsubishi
Motors dealer for de
tails on the combinati
on used on your vehicle.
These tires satisfy vehicle loading condi
tions described in
this owner’s manual.
Capacity
Item
Capacity
Lubricants
Fuel (approximate)
Front-wheel drive ve
hicles 16.6 gal (63 L)
Refer to “Fuel selection” on page 3-2
All-wheel drive vehicles 15.8 gal (60 L)
Engine oil
2.4 liter models
Oil pan 4.5 qt (4.3 L)
Engine oils displayi
ng the ILSAC certification mark (“star-
burst” symbol) on the container. If these oils are not available,
and API classification SN can be
used.
Oil filter .32 qt (0.3 L)
3.0 liter models
Oil pan 4.2 qt (4.0 L)Oil filter .32 qt (0.3 L)
Automatic transaxle 8.7 qt (8.2 L) Refer to
“Automatic transaxle fluid” on page 9-12.
Continuously variable transm
ission (CVT) 7.2 qt (6.9 L)
Refer to “Continuously variable
transmission (CVT) fluid” on
page 9-12.
BK0278200US.book 7 ページ 2019年4月10日 水曜日 午前10時59分
Page 436 of 443

Alphabetical index
12-3
12
Fuel
Filling the fuel tank
...........................
3-3
Fuel economy
...................................
6-2
Fuel hoses
......................................
9-25
Fuel selection
...................................
3-2
Tank capacity
.................................
11-7
Fuel Pump Shut-off System
.................
8-20
Fuses
.................................................
9-27
Fusible links
.......................................
9-27
G
General maintenance
...........................
9-25
General vehicle data
............................
11-4
Genuine parts
.......................................
3-7
Glove compartment
...........................
5-232
Glove compartment light
Bulb capacity
.................................
9-35
H
Hazard warning
flasher switch
...........
5-209
Hazard warning lights
.......................
5-195
Head restraints
....................................
4-11
Headlights
Bulb capacity
.................................
9-34
Dimmer
.......................................
5-202
Headlight flasher
..........................
5-203
Replacement
.........................
9-36
, 9-37
Switch
.........................................
5-199
Heated steering wheel switch
..............
5-217
High beam indicator
..........................
5-195
High-mounted stop light
Bulb capacity
.................................
9-34
Hill start assist
...................................
5-96
HomeLink® Wireless
Control System
.5-223
Hood lock release me
chanism and safety
catch
...............................................
9-26
Horn switch
......................................
5-218
I
If the vehicle breaks down
.....................
8-2
Ignition switch
...................................
5-66
Important facts to know in
case of an accident
10-4 Indicators
..............................
5-176
, 5-195
Information screen display
.................
5-177
Inside rearview mirror
.........................
5-60
Inspection and maintena
nce following rough
road operation
..................................
5-91
Instrument cluster
..............................
5-156
Interior lights
....................................
5-228
J
Jack
....................................................
8-5
Storage
............................................
8-5
Jump-starting the engine
.......................
8-2
K
Keyless entry system
....................
5-7
, 5-31
Keys
....................................................
5-3
L
Labeling
.............................................
11-2
Lane Departure Warning System (LDW)
.....
5-137 License plate light
Bulb capacity
.................................
9-34
Replacement
...................................
9-41
Liftgate
..............................................
5-40
Link System
.....................................
5-218
Loading information
..............................
6-6
Lubricants
..........................................
11-7
Luggage floor box
.............................
5-233
Luggage hooks
.................................
5-239
M
MIVEC engine
..........................
5-27
, 5-70
Modification of your vehicle
..................
3-5
Multi Around Monitor
.......................
5-147
Multi information display
..................
5-157
BK0278200US.book 3 ページ 2019年4月10日 水曜日 午前10時59分
Page 438 of 443

Alphabetical index
12-5
12
5-60 Wheel lock
............................
5-25
, 5-68
Stop lights
Bulb capacity
.................................
9-34
Storage spaces
..................................
5-231
Sun visors
........................................
5-220
Sunglasses holder
.............................
5-235
Sunroof
..............................................
5-54
Super-all wheel control (S-AWC)
S-AWC drive mode display
.............
5-87
S-AWC drive mode-selector
............
5-87
S-AWC operation display
................
5-88
Supplemental Re
straint System
............
4-35
How the Supplemental Restraint System works
..........................................
4-38
Maintenance service
........................
4-50
T
Tail light
Bulb capacity
.................................
9-34
Tank capacity
.....................................
11-7
Theft-alarm system
.............................
5-49
Ticket holder
....................................
5-221
Timing belt
........................................
9-26
Tire
...................................................
9-16
Inflation pressure
............................
9-20
Maintenance
...................................
9-21
Quality grading
...............................
10-2
Replacing tires and wheels
..............
9-21
Rotation
........................................
9-22
Size (tire and wheel)
.......................
11-7
Snow tires
.....................................
9-22
Tire and loading information placard 11-3Tire chains
.....................................
9-23
To change a tire
..............................
8-11
Tread wear indicator
.......................
9-21
Tire pressure monitoring system
.........
5-140
Tire repair kit
.......................................
8-6
Tools
...................................................
8-6
Storage
............................................
8-5
Towing
..............................................
8-18
Trailer towing
....................................
6-11
Transfer oil
................................
9-13
, 11-7
Turn signal light
Indicators
.....................................
5-195
Lever
...........................................
5-208
U
USB input terminal
............................
5-218
How to connect a USB memory device
....
5-219 How to connect an iPod
.................
5-220
USB port
..........................................
5-222
V
Vanity mirror
....................................
5-220
Vanity mirror lights
Bulb capacity
.................................
9-35
Vehicle care precautions
......................
9-42
Vehicle dimensions
.............................
11-4
Vehicle labeling
..................................
11-2
Vehicle preparation before driving
..........
6-4
Vehicle weights
..................................
11-5
Vents
...................................................
7-2
W
Warning lights
..................................
5-196
Washer
Fluid
.....................................
9-13
, 11-7
Rear window washer
.....................
5-214
Switch
.........................................
5-214
Washing
.............................................
9-44
Waxing
..............................................
9-45
Weights
.............................................
11-5
Wheel
Specification
..................................
11-7
Wiper
Rear window wiper
.......................
5-214
Switch
.........................................
5-210
Wiper blades
..................................
9-24
Wiper deicer switch
..........................
5-215
