MITSUBISHI OUTLANDER 2020 (in English) User Guide

Outside (Front) 1-7 Overview
1
N00100602968
Outside (Front)
Sunroof (if so equipped) P.5-54
Windshield wipers P.5-210
Engine hood P.9-3
Front fog lights (if so equipped) P.5-209, 9-34, 9-39
Outside rearview mirrors P.5-63 Side turn-signal lights (if so equipped) P.5-208, 9-34, 9-39 Side-view camera (if so equipped) P.5-147 Fuel tank filler P.3-3
Power window P.5-51
Front turn-s
ignal lights
P.5-208, 9-34, 9-38
Front turn signal lights P.5-208, 9-34, 9-38
Headlights, low beam P.5-199, 9-34, 9-36 Parking lights P.5-199, 9-34, 9-38 Daytime running lights P.5-199, 9-34, 9-38
Headlights, low beam P.5-199, 9-34, 9-36 Parking lights P.5-199, 9-34, 9-38 Daytime running lights P.5-199, 9-34, 9-38
Headlights, high beam P.5-199, 9-34, 9-37
Headlights, high beam P.5-199, 9-34, 9-37
Halogen headlights type LED headlights type
Front side-marker lights P.5-199, 9-34, 9-37
Front side-marker lights P.5-199, 9-34, 9-37
Sensor (if so equipped) [for Fo
rward Collision Mitigation System
(FCM), Lane Departure Warning System (LDW) and Automatic high beam system] P. 5-118, 5-137, 5-203 Rain sensor (if so equipped) P.5-210 Front-view camera (if so equipped) P.5-147BK0278200US.book 7 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

Outside (Rear)
Overview 1-8
1
N00100602841
Outside (Rear)
Keyless entry system (if so equipped) P.5-7, 5-31 F.A.S.T.-key (Free-hand Advanced Se
curity Transmitter) (if so equipped)
P.5-15 Locking and unlocking P.5-36
Tires P.9-16 Tire pressure monitoring system P.5-140Tire inflation pressures P.9-20Changing tires P.8-11 Tire rotation P.9-22 Tire chains P.9-23Size of tires and wheels P.11-7
Stop lights P.5-199, 9-34, 9-40
Rear turn signal lights P.5-208, 9-34, 9-40
Spare tire (if so equipped) P.8-12
Back-up lights P.9-34, 9-40
License plate lights P.5-199, 9-34, 9-41 Rear-view camera (if so equipped) P.5-145, 5-147 Rear window wiper P.5-214
High-mounted stop light P.9-34
Antenna
Liftgate (if so equipped) P.5-40 Power liftgate (if so equipped) P.5-42
Rear side-marker lights P.5-199, 9-34
Tail lights P.5-199, 9-34, 9-40
Roof spoiler (if so equipped)
BK0278200US.book 8 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

BK0278200US.book 9 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

2-1
2
If this warning light comes on or
flashes while you’re driving...
Quick index
N00200702377
If this warning light comes on
or flashes while you’re driving...
NOTE
For information regarding warni
ng displays in the multi-informa
tion display, refer to “Multi-i
nformation display” on page 5-157
.
 These warning lights will co
me on for a few seconds for a bulb check when the i
gnition switch is
first turned to “ON” or the op
eration mode is put in ON.
Wa rn in g l ig h t s
Do this
Ref. Page
Charging system warning light
 Park your vehicle in a safe
place and stop the engine.
Contact your Mitsubishi Motors dealer or a re
pair facility of your choice for assis-
tance.
P. 5-197
or
Brake warning light
 If this light comes on while driving, check to see that the parking brake is fully released.  If this light stays on after
releasing the parking brake,
immediately stop and check
the brake fluid level.  If the brake fluid level is correct, there
may be a system malfunction. Avoid hard
braking and high speed, and contact an au
thorized Mitsubishi Mo
tors dealer or a
repair facility of your
choice for assistance.
P. 5-196
Electric parking brake warning light
(if so equipped)
 If the warning light comes on during driving,
there is the possibility that the parking
brake cannot be operated or re
leased. Immediately stop the
vehicle in a
safe place,
and contact an authorized Mitsubishi Motors
dealer or a repair facility of your
choice for assistance.
P. 5-196
BK0278200US.book 1 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

If this warning light comes on or flashes while you’re driving... 2-2 Quick index
2
or
Engine malfunction indicator (“SERVICE ENGINE SOON” or
“Check engine light”)
 Although your vehicle will usually be dr
ivable and not need towing, have the
engine system checked at an authorized Mi
tsubishi Motors dealer
or a repair facility
of your choice as soon as possible. If the
vehicle is not drivab
le, contact emergency
roadside assistance at 1-888-648-7820 (for
vehicles sold in U.S.A.) or 1-888-576-
4878 (for vehicles sold in Canada), an aut
horized Mitsubishi Moto
rs dealer, or local
towing company for assistance.
P. 5-197
Anti-lock braking system warning
light
 When this light comes on, the anti-lock
braking system is not functioning and only
the ordinary braking system is functioning.  Park your vehicle in a safe
place and stop the engine.
Test the system as described on page 5-98.  If the light does not go out after the test,
or if it comes on again, we recommend that
you have the system checked at an authoriz
ed Mitsubishi Motors dealer or a repair
facility of your choi
ce as soon as possible.
P. 5-98
SRS warning light
 Immediately have the airbag and the pre-te
nsioner seat belt sy
stem checked at an
authorized Mitsubishi Motors dealer.
P. 4-41
and
ASC indicator and ASC OFF indicator
 Park your vehicle in a safe
place and stop the engine.
Restart the engine and check wh
ether the indicator goes out.
 If the indicator does not go out, or if it
comes on again, have your vehicle inspected
by an authorized Mitsubishi Motors dealer or
a repair facility of
your choice as soon
as possible. When this indicator comes on, the active
stability control is
not functioning and
normal operation of the vehi
cle will not be affected.
P. 5-102
Warning lights
Do this
Ref. Page
BK0278200US.book 2 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

If this warning light comes on or
flashes while you’re driving...
Quick index 2-3
2
ASC indicator
 Park your vehicle in a safe
place and stop the engine.
Restart the engine and check
whether the indicator goes out.
 If the indicator does not go out, or if it co
mes on again, have your vehicle inspected
by an authorized Mitsubishi Motors dealer or
a repair facility of your choice as soon
as possible. When this indicator comes on, the hill start assist is not functioning. Start off carefully on a steep uphill slope.
P. 5-96
Tire pressure monitoring system warn-
ing light
 If the warning light comes on, you should st
op and adjust the tires to the proper
inflation pressure as
soon as possible.
(See “Tire inflation pr
essures” on page 9-20.)
Once adjustments have been
made, the warning light will go off after a few minutes
of driving.  If the warning light blinks for approxima
tely 1 minute and th
en remains continu-
ously illuminated, the system
is not operating properly. If
the system returns to nor-
mal, the warning light will
go off. If the warning light does not go off, have the
vehicle inspected at an author
ized Mitsubishi Motors dealer.
P. 5-140
LED headlight warning light
 If the warning light comes on, there may
be a malfunction in
the LED headlight
unit. Have the vehicle inspected at an authoriz
ed Mitsubishi Motors dealer or a repair
facility of your choice.
P. 5-202
Wa rn in g l ig h t s
Do this
Ref. Page
BK0278200US.book 3 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

If this problem occurs... 2-4 Quick index
2
N00200902135
If this problem occurs...
Problem
Do this
Ref. Page
Unable to turn the key. (except for vehicles equipped with the F.A.S.T.-key)
Will not turn from “LOCK” to “ACC”.
(Vehicles with steering lock system)
Turn the key while turning the st
eering wheel in either direction.
P. 5-68
Will not turn from “ACC” to “OFF” or “LOCK”. Check the position of the selector lever. The key cannot be removed unle
ss the selector lever is set
to the “P” (PARK) position.
On vehicles with steering lock system, push
the key in at the “ACC” position and keep it
depressed until it is turned to the “LOCK” position.
P. 5-67
The engine does not start when the engine swit
ch is pressed.
(for vehicles equipped with the F. A . S . T. - k e y )
Make sure the F.A.S.T.-key is in the vehicle. Make sure the selector lever is in the “P” (PAR
K) position, and then pr
ess the engine switch
while depressing the brake pedal.
P. 5-26
BK0278200US.book 4 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

If this problem occurs...
Quick index 2-5
2
The engine does not start and the operation mode cannot be changed to OFF. (for vehicles equipped with the F.A.S.T.-key)
1. Move the selector lever to the “P” (PARK)
position, and then cha
nge the operation mode
to OFF.2. One of the other causes could be low battery voltage. If this occurs, the keyless entry system, the
F.A.S.T.-key operation
and the steering wheel
lock (if so equipped) will also not operate
. Contact an authorized Mitsubishi Motors
dealer.
P. 5-20
The F.A.S.T.-key does not oper- ate.(for vehicles equipped with the F. A . S . T. - k e y )
Insert the F.A.S.T.-key into the key slot of the instrument panel, and then start the engine or change the operation mode. Use the emergency
key to lock and unlock the driver’s door.
P. 5-28, 5-29
Cannot shift the selector lever from the “P” (PARK) position.
Shift the selector lever while pressing the brake pedal. Check that the ignition switch or
the operation mode is in ON.
P. 5-70, 5-77
The windows are fogged up.
Push the defogger switch to change to the “ ” position.
P. 7-9
The engine does not start. The lights do not come on. The lights are dim. The horn does not honk.The horn sound is weak.
Have the battery checked. Rech
arge or replace as needed.
P. 8-2, 9-14
Problem
Do this
Ref. Page
BK0278200US.book 5 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

If this problem occurs... 2-6 Quick index
2
Problem
Do this
Ref. Page
The information screen in the multi information display will be interrupted and the engine coolant temperature warning display will appear. Also “ ” will blink. Steam comes out of the engine compartment.
The engine is overheated. Carefully stop the vehicle in a safe place.
P. 8-4
If your vehicle becomes stuck in sand, mud or snow
1. Slowly press down on the accelerator pedal to
get your vehicle moving again. For an all-
wheel drive vehicle, set the drive mode-sel
ector to the “4WD AUTO” or “4WD LOCK”
position (Electronica
lly controlled 4WD), “SNOW” or
“GRAVEL” positi
on (S-AWC) and
then slowly press down on the accelera
tor pedal to get your vehicle moving.
2. If there is nothing to stop your tires from sli
pping, rock your vehicle out of the stuck posi-
tion.
P. 8-19
WA R N I N G When attempting to rock your vehi
cle out of a stuck position, be su
re that no one is near the ve
hicle. The rocking motion may c
ause the vehicle to
suddenly lurch forward or backward, possibly injuring bystanders.
and
BK0278200US.book 6 ページ ２０１９年４月１０日　水曜日　午前１０時５９分

If this problem occurs...
Quick index 2-7
2
 Avoid revving the engine or spin
ning the wheels. Prolonged efforts to free a st
uck vehicle may result in
overheating and transa
xle failure.
If the vehicle remains stuck after several rocking attempts, have a towing service pull the vehicle out.
Problem
Do this
Ref. Page
The brakes are not functioning properly after crossing a puddle or stream.
Dry out the brakes by driving slowly
while lightly pressing the brake pedal.
P. 5-90, 6-5
The automatic transaxle makes no gear change when accelerat- ing. The initial movement of the vehicle is slow
when the vehicle
starts moving. (for vehicles with automatic transaxle)
There may be a problem in the automatic transaxle. Have the system inspected by your authorized Mitsub
ishi Motors dealer or
a repair facility of
your choice.
P. 5-75
The continuously variable trans- mission (CVT) makes no shift change when accelerating. The initial movement of the vehicle is slow when the vehicle starts moving.(for vehicles with CVT)
There may be a problem in the CVT. If the or warning lights on the multi-informat
ion display will not turn off, or if they
come on frequently, please have the vehicle chec
ked at your nearest Mits
ubishi Motors dealer.
P. 5-82
A tire is punctured.
1. Park the vehicle in a safe place where the surface is flat and level. 2. On vehicles equipped with the
tire repair kit, repair the flat tire with tire repair kit.
On vehicles equipped with the spare tire, replace the flat tire with the spare tire. 3. If your vehicle is not equippe
d with the tire repair kit or
spare tire, contact emergency
roadside assistance at 1-888-648-7820 (for ve
hicles sold in U.S.A.) or 1-888-576-4878
(for vehicles sold in Canada),
an authorized Mitsubishi Mo
tors dealer, or local towing
company for assistance.
P. 8 - 6 , 8 - 1 1
WA R N I N G
BK0278200US.book 7 ページ ２０１９年４月１０日　水曜日　午前１０時５９分
