Press and release the HomeLink
button up
to three times to complete the training.
8. Your HomeLink
button should now be pro-
grammed.
To program the remaining HomeLink
buttons
for additional door or gate openers, follow steps
2-8 only.
NOTE:
Do not repeat step 1 unless you want to
“clear” all previously programmed
HomeLink
buttons.
If you have any questions or are having difficulty
programming your HomeLink
buttons, refer to
the HomeLink
website at: www.homelink.com
or call 1-800-355-3515.
PROGRAMMING HomeLink
FOR
CANADIAN CUSTOMERS
Prior to 1992, D.O.C. regulations required hand-
held transmitters to stop transmitting after 2
seconds. To program your hand-held transmitter
to HomeLink
, continue to press and hold the
HomeLinkbutton (note steps 2 through 4
under “Programming HomeLink
”) while you
press and re-press (“cycle”) your hand-held
transmitter every 2 seconds until the indicator
light flashes rapidly (indicating successful pro-
gramming).NOTE:
When programming a garage door opener,
etc., it is advised to unplug the device
during the “cycling” process to prevent
possible damage to the garage door
opener components.
OPERATING THE HomeLinkUNIVERSAL TRANSCEIVERThe HomeLink
Universal Transceiver (once
programmed) may now be used to activate the
garage door, etc. To operate, simply press the
appropriate programmed HomeLink
Universal
Transceiver button. The red indicator light will
illuminate while the signal is being transmitted.
PROGRAMMING TROUBLE
DIAGNOSISIf the HomeLink
does not quickly learn the
hand-held transmitter information:
replace the hand-held transmitter batteries
with new batteries.
position the hand-held transmitter with its
battery area facing away from the HomeLink
surface.
press and hold both the HomeLink
and
hand-held transmitter buttons without inter-
ruption.position the hand-held transmitter 2 to 5 in
(50 to 127 mm) away from the HomeLink
surface. Hold the transmitter in that position
for up to 15 seconds. If HomeLink
is not
programmed within that time, try holding the
transmitter in another position - keeping the
indicator light in view at all times.
If you continue to have programming difficulties,
please contact the NISSAN Consumer Affairs
Department. The phone numbers are located in
the Foreword of this Owner’s Manual.
CLEARING THE PROGRAMMED
INFORMATIONIndividual buttons cannot be cleared, however to
clear all programming, press and hold the two
outside buttons and release when the indicator
light begins to flash (approximately 20 seconds).
2-44
Instruments and controls
04.8.23/Z33-D/V5.0
Page 102 of 279
REPROGRAMMING A SINGLE
HomeLink
BUTTON
To reprogram a HomeLink
Universal Trans-
ceiver button, complete the following.
1. Press and hold the desired HomeLink
but-
ton.Do notrelease the button until step 4
has been completed.
2. When the indicator light begins to flash
slowly (after 20 seconds), position the hand-
held transmitter 2 to 5 in (50 to 127 mm)
away from the HomeLink
surface.
3. Press and hold the hand-held transmitter
button.
4. The HomeLink
indicator light will flash, first
slowly and then rapidly. When the indicator
light begins to flash rapidly, release both
buttons.
The HomeLinkUniversal Transceiver button
has now been reprogrammed. The new device
can be activated by pushing the HomeLink
button that was just programmed. This proce-
dure will not affect any other programmed
HomeLink
buttons.
IF YOUR VEHICLE IS STOLENIf your vehicle is stolen, you should change the
codes of any non-rolling code device that hasbeen programmed into HomeLink
. Consult the
Owner’s Manual of each device or call the
manufacturer or dealer of those devices for
additional information.
When your vehicle is recovered, you will
need to reprogram the HomeLink
Univer-
sal Transceiver with your new transmitter
information.
FCC Notice:
This device complies with FCC rules part
15. Operation is subject to the following
two conditions: (1) This device may not
cause harmful interference and (2) This
device must accept any interference that
may be received, including interference
that may cause undesired operation.
The transmitter has been tested and com-
plies with FCC and DOC/MDC rules.
Changes or modifications not expressly
approved by the party responsible for com-
pliance could void the user’s authority to
operate the device.
DOC: ISTC 1763K1313
FCC I.D.: CB2V67690
Instruments and controls
2-45
04.8.23/Z33-D/V5.0
Page 103 of 279
MEMO2-46
Instruments and controls
04.8.23/Z33-D/V5.0
Page 104 of 279
3 Pre-driving checks and adjustmentsKeys ......................................................................................... 3-2
Doors ....................................................................................... 3-2
Locking with key ............................................................. 3-3
Locking with inside lock knob..................................... 3-3
Locking with power door lock switch ....................... 3-4
Remote keyless entry system ............................................ 3-4
How to use remote keyless entry system.................. 3-5
Battery replacement ....................................................... 3-8
Hood ........................................................................................ 3-9
Rear hatch (Coupe models) .............................................. 3-9
Opener operation ......................................................... 3-10
Secondary rear hatch release .................................... 3-10
Trunk lid (Roadster models) ............................................ 3-11
Opener operation ......................................................... 3-11
Interior trunk lid release ............................................... 3-12
Secondary trunk lid release ........................................ 3-13
Fuel filler lid ......................................................................... 3-13Opener operation ......................................................... 3-13
Fuel filler cap ................................................................. 3-14
Steering wheel .................................................................... 3-15
Tilt operation .................................................................. 3-15
Extension sun visor (if so equipped) .............................. 3-16
Mirrors ................................................................................... 3-16
Inside mirror .................................................................... 3-16
Automatic anti-glare inside mirror
(if so equipped) ............................................................ 3-17
Outside mirrors ............................................................. 3-18
Soft top (Roadster models) .............................................. 3-19
Before operating the top ............................................. 3-19
When operating the top .............................................. 3-21
Opening the top ............................................................ 3-24
Closing the top .............................................................. 3-25
If the top does not open or close electrically ........ 3-25
Care of the soft top and the vehicle body.............. 3-28
04.8.23/Z33-D/V5.0
Page 105 of 279
1. Master keys*
2. Valet key*
3. Key number plate
(* With built-in transponder chip)
You can only drive your vehicle using the master
or valet keys which are registered to the NISSAN
Vehicle Immobilizer System (NVIS) components
in your vehicle. These keys have a transponder
chip in the key head.
The master key can be used for all the locks.
The valet key cannot be used for the rear floor
box lock. To protect belongings when you leave
a key with someone, give them the valet key only.Never leave these keys in the vehicle.
A key number plate is supplied with your keys.
Record the key number and keep it in a safe
place (such as your wallet), not in the vehicle.
NISSAN does not record any key numbers so it
is very important to keep track of your key
number plate.
A key number is only necessary when you have
lost all keys and do not have one to duplicate
from. If you still have a key, this key can be
duplicated by a NISSAN dealer.
NISSAN Vehicle Immobilizer System (NVIS)
KEY - Master and Valet keys:
As many as 5 keys can be used with one vehicle.
New keys must be registered to the NVIS com-
ponents in your vehicle by a NISSAN dealer. At
this time, you should bring all NVIS keys that you
have to a NISSAN dealer for registration. This is
because the registration process will erase all
memory of the NVIS components.
CAUTION
Do not allow the NVIS key, which con-
tains an electrical transponder, to come
in contact with salt water. This could
cause the system to malfunction.
WARNING
Always have the doors locked while
driving. Along with the use of seat
belts, this provides greater safety in
the event of an accident by helping to
prevent persons from being thrown
from the vehicle. This also helps keep
children and others from uninten-
tionally opening the doors, and will
help keep out intruders.
Before opening any door, always
look for and avoid oncoming traffic.
Do not leave children unattended in-
side the vehicle. They could unknow-
ingly activate switches or controls.
Unattended children could become
involved in serious accidents.
SPA1379D
KEYSDOORS3-2
Pre-driving checks and adjustments
04.8.23/Z33-D/V5.0
Page 106 of 279
LOCKING WITH KEYThe power door lock system allows you to lock
or unlock all doors including the rear hatch/trunk
lid simultaneously.
Turning the driver’s door key to the rear of the
vehicle
1
will lock all doors including the
rear hatch/trunk lid.
Turning the driver’s door key one time to the
front of the vehicle
2
will unlock the driver’s
door and rear hatch/trunk lid. From that po-
sition, returning the key to neutral (where the
key can only be removed and inserted) and
turning it to the front again within 5 secondswill unlock the passenger’s door.
Opening and closing windowsTurn the driver’s door key towards the front of
the vehicle (UNLOCK position) and hold for
about 1 second, all door windows will begin to
lower.
To close all door windows, turn the key to the
LOCK position and hold for about 1 second.
To stop opening or closing, turn the key to the
neutral position.
In the event of a hand in the way, or other
obstruction, the auto reverse function will acti-
vate.
LOCKING WITH INSIDE LOCK
KNOBPushing the door inside lock knobto the LOCK1
or UNLOCK
2
position will lock or unlock
the corresponding door. (The rear hatch/trunk lid
lock is linked with the driver side door lock.)
To individually lock the doors from the outside
(without a key), move the inside lock knobto the
LOCK position. Then close the door.
When locking the door without a key, be
sure not to leave the key inside the vehicle.
SPA1503A
SPA1504A
Pre-driving checks and adjustments
3-3
04.8.23/Z33-D/V5.0
Page 107 of 279
A
Driver’s side
B
Passenger’s side
LOCKING WITH POWER DOOR
LOCK SWITCHAll doors will be locked when the power door
lock switch is pushed to the LOCK position
1
with the driver’s or front passenger’s door open.
Then close the door and all doors will be locked.
When locking the door this way, be certain
not to leave the key inside the vehicle.
To unlock, push the power door lock switch to
the UNLOCK position
2.
Lockout protectionWhen the power door lock switch (driver or front
passenger) is moved to the LOCK position with
the key in the ignition and any door open, all
doors will lock and unlock automatically. This
helps to prevent the keys from being accidentally
locked inside the vehicle.It is possible to lock/unlock all doors (including
the rear hatch/trunk lid), release the rear
hatch/trunk lid and activate the panic alarm by
using the keyfobfrom outside the vehicle.
Before locking the doors, make sure the
key is not left in the vehicle.
The keyfobcan operate at a distance of approxi-
mately 33 ft (10 m) from the vehicle. (The
effective distance depends upon the conditions
around the vehicle.)
As many as 5 keyfobs can be used with one
vehicle. For information concerning the purchase
and use of additional keyfobs, contact a NISSAN
dealer.
The keyfobwill not function when:
the battery is discharged,
the distance between the vehicle and the
keyfobis over 33 ft (10 m).
The panic alarm and the rear hatch/trunk
lid release will not activate when the key is
in the ignition switch.
CAUTION
The following conditions or occurrences
will damage the keyfob.
SPA1505E
REMOTE KEYLESS ENTRY
SYSTEM
3-4
Pre-driving checks and adjustments
04.8.23/Z33-D/V5.0
Page 108 of 279
Do not allow the keyfob to become
wet.
Do not drop the keyfob.
Do not strike the keyfob sharply
against another object.
Do not place the keyfob for an ex-
tended period in an area where tem-
peratures exceed 140°F (60°C).
If a keyfob is lost or stolen, NISSAN
recommends erasing the ID code of that
keyfob. This will prevent the keyfob
from unauthorized use to unlock the
vehicle. For information regarding the
erasing procedure, please contact a
NISSAN dealer.
1LOCK button
2UNLOCK button
3HATCH/TRUNK button
4PANIC button
HOW TO USE REMOTE KEYLESS
ENTRY SYSTEM
Locking doors1. Remove the ignition key.*1 *2
2. Close all the doors.*3
3. Push the LOCK button
1
on the keyfob.4. All the doors will lock.
All of the doors will lock when the LOCK
button on the keyfob is pushed even
though a door remains open and/or the
ignition switch is in the ONposition.
5. The hazard indicator flashes twice and the
horn chirps once.
When the LOCK button is pushed with all
doors locked, the hazard indicator flashes
twice and the horn chirps once as a reminder
that the doors are already locked.
*1: Doors lock with the keyfobwhile a key is in
the ignition switch. However, the panic
alarm and the rear hatch/trunk lid release will
not activate when the key is in the ignition
switch.
*2: Doors lock with the keyfobwhile the ignition
switch is in the ON position. However, the
hazard indicator and horn will not function.
*3: Doors lock with the keyfobwhile any door is
open. However, the hazard indicator and
horn will not function.
Unlocking doors1. Push the UNLOCK button
2
on the keyfob
once.
SPA1918
Pre-driving checks and adjustments
3-5
04.8.23/Z33-D/V5.0
Page 109 of 279
The driver’s door and rear hatch/trunk lid
unlock.
The hazard indicator flashes once if all doors
are completely closed with the ignition switch
in any position except the ON position.
The interior light turns on and the light timer
activates for 30 seconds when the switch is
in the DOOR position with the ignition switch
in any position except the ON position.
2. Push the UNLOCK button on the keyfob
again within 5 seconds.
Passenger’s door unlocks.
The hazard indicator flashes once if all doors
are completely closed.
All doors will be locked automatically unless one
of the following operations is performed within 1
minute of pushing the UNLOCK button.
Any door or rear hatch/trunk lid is opened.
The ignition switch is turned to the ON
position.
The interior light can be turned off without
waiting for 30 seconds by turning the ignition
switch to the ON position or by locking the
doors with the keyfob.
Opening the windowsPush the UNLOCK button
2on the keyfoband
the driver’s door will unlock.
Continue to push the UNLOCK button for 3
seconds. All the door windows will start to be
lowered. Keep pushing the UNLOCK button
until the windows are fully open.
To stop lowering the windows, release the UN-
LOCK button. To start lowering the windows
again, push the UNLOCK button again for 3
more seconds.
Releasing the rear hatch/trunk lid1. Push the HATCH/TRUNK button
3
on the
keyfobfor longer than 0.5 seconds with the
key removed from the ignition switch.
2. The rear hatch (Coupe) or trunk lid (Road-
ster) opens.
Using the panic alarmIf you are near your vehicle and feel threatened,
you may activate the alarm to call attention by
pushing and holding the PANIC button
4
on
the keyfobforlonger than 0.5 seconds(with
the key removed from the ignition switch).
The theft warning alarm and headlights will stay
on for 30 seconds.The panic alarm stops when:
It has run for 30 seconds, or
The LOCK button
1or the UNLOCK button
2
is pushed, or
The PANIC button
4
or the
HATCH/TRUNK button
3
is pushed on the
keyfobfor longer than 0.5 seconds.
3-6
Pre-driving checks and adjustments
04.8.23/Z33-D/V5.0
Page 110 of 279
Setting hazard indicator and horn
modeThis vehicle is set in hazard indicator and horn
mode when you first receive the vehicle.
In hazard indicator and horn mode, when the
LOCK button is pushed, the hazard indicator
flashes twice and the horn chirps once. When
the UNLOCK button is pushed, the hazard indi-
cator flashes once.
If hazard indicator and horn mode is not neces-
sary, you can switch to hazard indicator only
mode by following the switching procedure.
In hazard indicator only mode, when the LOCKbutton is pushed, the hazard indicator flashes
twice. When the UNLOCK button is pushed,
neither the hazard indicator nor the horn oper-
ates.
(Switching procedure)
Push the LOCK and UNLOCK buttons on the
keyfobsimultaneously for more than 2 seconds
to switch from one mode to the other.
When pushing the buttons to set hazard indica-
tor only mode, the hazard indicator flashes 3
times.
When pushing the buttons to set hazard indica-
tor and horn mode, the hazard indicator flashesonce and the horn chirps once.
SPA1260
Pre-driving checks and adjustments
3-7
04.8.23/Z33-D/V5.0
