tow NISSAN 350Z 2005 Z33 Navigation Manual

SWITCHING BETWEEN Birdview
TM
and PLANVIEW DISPLAYSThe Birdview
TM
mode displays the view from
above, looking down toward the direction the
vehicle is traveling. This combines the detailed
display close to the vehicle and the long dis-
tance view in one screen.
To change between the Birdview
TM
and Plan-
view, proceed as follows:
1. Press the SETTING button.
INV1690
INV1691
INI0036
11-4
How do I adjust the display?


04.7.6/Z33-N


3. The [DISPLAY SETTINGS] screen will be
displayed.
Select the
Setting Display Duration key.
INFO:
When you finish setting the display duration
time, the display will return to the previous
display automatically.The display uses liquid crystal and should be
handled with care.
WARNING
Never disassemble the display. It has
some areas with extreme high voltage.
Touching it may result in serious per-
sonal injury.CHARACTERISTICS OF LIQUID
CRYSTAL DISPLAY
If the temperature inside the vehicle is espe-
cially low, the display will stay relatively dim or
the movement of the images may be slow.
These conditions are normal; when the tem-
perature rises, the display will function nor-
mally.

You may notice darker or brighter dots in
parts of the display; this is inherent in monitor
displays and is not a malfunction.

You may also notice a remnant of the previ-
ous display image on the screen. This after-
image is inherent in displays and is not
abnormal.INFO:
The screen may become distorted by strong
magnetic fields.
MAINTENANCE OF THE DISPLAY
CAUTION

To clean the display, never use a
rough cloth, alcohol, benzine, thin-
ner, any kind of solvent, or paper
towel with chemical cleaning agent.
They will scratch or deteriorate the
panel.

Do not splash any liquid such as
water or car fragrance on the display.
Contact with liquid will cause the
system to malfunction.
If you need to clean the display screen, use a dry
soft cloth. If additional cleaning is necessary, use
a small amount of neutral detergent with a soft
cloth. Never soak the exterior with water or
detergent.
INV1744
HOW TO HANDLE THE DISPLAY
11-28
How do I adjust the display?


04.7.6/Z33-N
