Page 31 of 297
systems should be seated and restrained by the
seat belts which are provided. The seat belt may
not fit properly if the child is less than 4 feet 9
inches (142.5 cm) tall and weighs between 40
lbs (18 kg) and 80 lbs (36 kg). A booster seat
should be used to obtain proper seat belt fit.
NISSAN recommends that a child be placed in a
commercially available booster seat if the shoul-
der belt in the child’s seating position fits close
to the face or neck or if the lap portion of the seat
belt goes across the abdomen. The booster seat
should raise the child so that the shoulder belt is
properly positioned across the top, middle por-
tion of the shoulder and the lap belt is low on the
hips. A booster seat can only be used in seating
positions that have a three-point type seat belt.
The booster seat should fit the vehicle seat and
have a label certifying that it complies with
Federal Motor Vehicle Safety Standards or Ca-
nadian Motor Vehicle Safety Standards. Once
the child has grown so the shoulder belt is no
longer on or near the face and neck, use the
shoulder belt without the booster seat.PREGNANT WOMENNISSAN recommends that pregnant women use
seat belts. The seat belt should be worn snug,
and always position the lap belt as low as
possible around the hips, not the waist. Place
the shoulder belt over your shoulder and acrossyour chest. Never run the lap/shoulder belt over
your abdominal area. Contact your doctor for
specific recommendations.
INJURED PERSONSNISSAN recommends that injured persons use
seat belts, depending on the injury. Check with
your doctor for specific recommendations.THREE-POINT TYPE SEAT BELT
WITH RETRACTOR
WARNING
Every person who drives or rides in
this vehicle should use a seat belt at
all times.
Do not ride in a moving vehicle when
the seatback is reclined. This can be
dangerous. The shoulder belt will not
be against your body. In an accident,
you could be thrown into it and re-
ceive neck or other serious injuries.
You could also slide under the lap
belt and receive serious internal
injuries.For the most effective protection
when the vehicle is in motion, the
seat should be upright. Always sit
well back in the seat and adjust the
seat belt properly.
1-14
Safety — Seats, seat belts and supplemental restraint system
05.10.18/Z33-D/V5.0
Page 32 of 297
Fastening the seat belts1. Adjust the seat. See “Seats” earlier in this
section.
2. Slowly pull the seat belt out of the retractor
and insert the tongue into the buckle until it
clicks.
The retractor is designed to lock during
a sudden stop or on impact. A slow
pulling motion will permit the belt to
move, and allow you some freedom of
movement in the seat.
If the seat belt cannot be pulled from its
fully retracted position, firmly pull thebelt and release it. Then smoothly pull
the belt out of the retractor.
3. Position the lap belt portionlow and snug
on the hipsas shown.
4. Pull the shoulder belt portion toward the
retractor to take up extra slack. Be sure the
shoulder belt is routed over your shoulder
and across your chest.
The front passenger seat belt has a locking
mechanism for child restraint installation. It is
referred to as the automatic locking mode. (Also
remember, if you need to install a child restraint,
first obtain an air bag ON/OFF switch and turn
the passenger air bag OFF.)When the locking mechanism is activated the
seat belt cannot be extended again until the seat
belt tongue is detached from the buckle and fully
retracted. For additional information, see “Child
restraints” later in this section.
The automatic locking mode should be
used only for child restraint installation.
During normal seat belt use by a passen-
ger, the locking mode should not be acti-
vated. If it is activated it may cause uncom-
fortable seat belt tension.
WARNING
When fastening the seat belts, be cer-
tain that the seatbacks are completely
secured in the latched position. If they
are not completely secured, passengers
may be injured in an accident or sudden
stop.
SSS0292A
SSS0290A
Safety — Seats, seat belts and supplemental restraint system
1-15
05.10.18/Z33-D/V5.0
Page 33 of 297
Unfastening the seat beltsTo unfasten the belt, push the button on the
buckle. The seat belt will automatically retract.Checking seat belt operationYour seat belt retractors are designed to lock
belt movement using two separate methods:
when the belt is pulled quickly from the
retractor.
when the vehicle slows down rapidly.
You can check their operation as follows:
grasp the shoulder belt and pull quickly for-ward. The retractor should lock and restrict
further belt movement.
If the retractor does not lock during this check or
if you have any questions about belt operation,
see a NISSAN dealer.
Shoulder belt armThe shoulder belt arm should be adjusted to the
position best for you. (See “Precautions on seat
belt usage” earlier in this section.)
To adjust, pull the shoulder belt arm. Pulling the
arm forward will allow an easy access to the belt.SEAT BELT EXTENDERSIf, because of body size or driving position, it is
not possible to properly fit the lap-shoulder belt
and fasten it, an extender is available. The ex-
tender adds approximately 8 in (200 mm) of
length and may be used for either the driver or
passenger seating position. See a NISSAN
SSS0326
SSS0588
1-16
Safety — Seats, seat belts and supplemental restraint system
05.10.18/Z33-D/V5.0
Page 34 of 297
dealer for assistance if the extender is required.
WARNING
Only NISSAN seat belt extenders,
made by the same company which
made the original equipment seat
belts, should be used with NISSAN
seat belts.
Persons who can use the standard
seat belt should not use an extender.
Such unnecessary use could result in
serious personal injury in the event
of an accident.
Never use seat belt extenders to in-
stall child restraints. If the child re-
straint is not secured properly, the
child could be seriously injured in a
collision or a sudden stop. (Also re-
member never to use a child restraint
unless an air bag ON/OFF switch has
been installed and is being used
properly.)
SEAT BELT MAINTENANCETo clean the seat belt webbings,apply a
mild soap solution or any solution recom-
mended for cleaning upholstery or carpets.
Then brush the webbing, wipe it with a cloth
and allow it to dry in the shade. Do not allow
the seat belts to retract until they are com-
pletely dry.
If dirt builds up in the shoulder belt guide of
the seat belt anchors, the seat belts may
retract slowly. Wipe the shoulder belt guide
with a clean, dry cloth.
Periodically check to see that the seat
belt and the metal componentssuch as
buckles, tongues, retractors, flexible wires
and anchors work properly. If loose parts,
deterioration, cuts or other damage on the
webbing is found, the entire belt assembly
should be replaced.
PRECAUTIONS ON CHILD
RESTRAINTS
WARNING
The information in this section is pro-
vided only for those owners who have
received permission to install an air bag
ON/OFF switch and the switch has been
installed. See “Obtaining an air bag
ON/OFF switch” earlier in this manual.
Never let children 12 or under ride in this
vehicle unless an air bag ON/OFF
switch is installed and it is being prop-
erly used.
WARNING
Infants and small children should al-
ways be placed in an appropriate
child restraint while riding in the ve-
hicle. Failure to use a child restraint
can result in serious injury or death.
Infants and small children should
never be carried on your lap. It is notCHILD RESTRAINTS
Safety — Seats, seat belts and supplemental restraint system
1-17
05.10.18/Z33-D/V5.0
Page 35 of 297
possible for even the strongest adult
to resist the forces of a severe acci-
dent. The child could be crushed be-
tween the adult and parts of the ve-
hicle. Also, do not put the same seat
belt around both your child and your-
self.
Never install a child restraint in the
front seat unless an air bag ON/OFF
switch has been installed and the air
bag has been turned OFF. An inflat-
ing supplemental air bag could seri-
ously injure or kill your child.
An improperly installed child re-
straint could lead to serious injury or
death in an accident.
CAUTION
For Roadster models, when installing a
child restraint, be sure to turn off the
automatic passenger seatback tilt func-
tion with the seatback tilt cancel switch
(located on the back of the passengerseatback). Otherwise, the child restraint
may be damaged. See “Tilting and re-
clining passenger’s seat from driver’s
seat” earlier in this section for detailed
information.
In general, child restraints are designed to be
installed with the lap portion of a lap/shoulder
seat belt.
The proper restraint depends on the child’s size.
Generally, infants (up to about 1 year and less
than 20 lb(9 kg)) should be placed in rear facing
child restraints. Front facing child restraints are
available for children who outgrow rear facing
child restraints.
Child restraints for infants and children of various
sizes are offered by several manufacturers.
When selecting any child restraint, keep the
following points in mind:
choose only a restraint with a label certifying
that it complies with Federal Motor Vehicle
Safety Standard 213 or Canadian Motor
Vehicle Safety Standard 213.
check the child restraint in your vehicle to be
sure it is compatible with the vehicle’s seat
and seat belt system.
if the child restraint is compatible with yourvehicle, place your child in the child restraint
and check the various adjustments to be sure
the child restraint is compatible with your
child. Choose a child restraint that is de-
signed for your child’s height and weight.
Always follow all recommended procedures.
All US states and Canadian provinces re-
quire that infants and small children be
restrained in approved child restraints at
all times while the vehicle is being oper-
ated.
WARNING
Improper use of a child restraint can
increase the risk or severity of injury
for both the child and other occu-
pants of the vehicle.
Follow all of the child restraint manu-
facturer’s instructions for installation
and use. When purchasing a child
restraint, be sure to select one which
will fit your child and vehicle. It may
not be possible to properly install
some types of child restraints in your
vehicle.
1-18
Safety — Seats, seat belts and supplemental restraint system
05.10.18/Z33-D/V5.0
Page 36 of 297
If the child restraint is not anchored
properly, the risk of a child being
injured in a collision or a sudden stop
greatly increases.
Adjustable seatbacks should be po-
sitioned to fit the child restraint, but
as upright as possible.
After attaching the child restraint,
test it before you place the child in it.
Push it from side to side. Try to tug it
forward and check to see if the belt
holds the restraint in place. If the
restraint is not secure, tighten the
belt as necessary. You may need to
try a different child restraint. Not all
child restraints fit in all types of ve-
hicles.
If you install a front facing child re-
straint in the front seat, see “Child
restraint installation on front passen-
ger seat” later in this section.
When your child restraint is not in
use, keep it secured with a seat belt
to prevent it from being thrownaround in case of a sudden stop or
accident.
CAUTION
Remember that a child restraint left in a
closed vehicle can become very hot.
Check the seating surface and buckles
before placing your child in the child
restraint.
Safety — Seats, seat belts and supplemental restraint system
1-19
05.10.18/Z33-D/V5.0
Page 37 of 297
CHILD RESTRAINT INSTALLATION
ON FRONT PASSENGER SEAT
WARNING
Never install a child restraint in the
front passenger seat unless an air
bag ON/OFF switch has been in-
stalled and the air bag has been
turned OFF. Supplemental front air
bags inflate with great force. A child
restraint could be struck by thesupplemental front air bag in a crash
and could seriously injure or kill your
child.
The three-point seat belt in your ve-
hicle is equipped with an automatic
locking mode retractor which must
be used when installing a child re-
straint.
Failure to use the retractor’s locking
mode will result in the child restraint
not being properly secured. The re-straint could tip over or otherwise be
unsecured and cause injury to the
child in a sudden stop or collision.
CAUTION
Turn off the automatic passenger seat-
back tilt function by turning the seat-
back tilt cancel switch to the CANCEL
position. (Roadster models)
SSS0261
1-20
Safety — Seats, seat belts and supplemental restraint system
05.10.18/Z33-D/V5.0
Page 38 of 297
Front facingIf you must install a child restraint in the front
seat, follow these steps:
1. Turn the air bag ON/OFF switch to the OFF
position.
Turn the seatback tilt cancel switch to the
CANCEL position. (Roadster models only)
2. Position the child restraint on the front pas-
senger seat.Move the seat to the rear-
most position.Adjust the head restraint to
its highest position (if so equipped). The
direction of the child restraint depends on the
type of the child restraint and the size of thechild. Always follow the restraint manufactur-
er’s instructions.
The back of the child restraint should be
secured against the vehicle seatback. If nec-
essary, adjust or remove the head restraint to
obtain the correct child restraint fit. See
“Head restraint adjustment” earlier in this
section. If the head restraint is removed, store
it in a secure place. Be sure to install the
head restraint when the child restraint is
removed. If the seating position does not
have an adjustable head restraint and it is
interfering with the proper child restraint fit,
try a different child restraint.
3. Route the seat belt tongue through the child
restraint and insert it into the buckle until you
hear and feel the latch engage. Be sure to
follow the child restraint manufacturer’s in-
structions for belt routing.
SSS0301C
Front facing — step 2
SSS0253D
Front facing — step 3
Safety — Seats, seat belts and supplemental restraint system
1-21
05.10.18/Z33-D/V5.0
Page 39 of 297
4. Pull on the shoulder belt until all of the belt is
fully extended. At this time, the belt retractor
is in the automatic locking mode (child re-
straint mode). It reverts back to emergency
locking mode when the belt is fully retracted.5. Allow the belt to retract. Pull up the belt to
remove any slack in the belt.6. Before placing the child in the child restraint,
use force to push the child restraint from side
to side, and tug it forward to make sure that it
is securely held in place. It should not move
more than 1 in (25 mm). If it does move more
than 1 in (25 mm), pull again on the shoulder
belt to further tighten the child restraint. If
unable to properly secure the restraint, try a
different child restraint. Not all child restraints
fit in all types of vehicles.
7. Check that the retractor is in the automatic
locking mode by trying to pull more belt out of
the retractor. If you cannot pull any more belt
webbing out of the retractor, the belt is in the
automatic locking mode.
SSS0254D
Front facing — step 4
SSS0331D
Front facing — step 5
SSS0302B
Front facing — step 6
1-22
Safety — Seats, seat belts and supplemental restraint system
05.10.18/Z33-D/V5.0
Page 40 of 297
8. Check to make sure that the child restraint is
properly secured prior to each use. If the lap
belt is not locked, repeat steps 4 through 7.
After the child restraint is removed and the seat
belt is allowed to wind back into the retractor,
the automatic locking mode (child restraint
mode) is canceled.
Rear facingWhen you install a child restraint in the front
seat, follow these steps:
1. Turn the air bag ON/OFF switch to the OFF
position.
Turn the seatback tilt cancel switch to the
CANCEL position. (Roadster models only)
2. Position the child restraint on the front pas-
senger seat. Move the seat to the rearmost
position. The direction of the child restraint
depends on the type of the child restraint and
the size of the child. Always follow the re-
straint manufacturer’s instructions.3. Route the seat belt tongue through the child
restraint and insert it into the buckle until you
hear and feel the latch engage.
Be sure to follow the child restraint manufac-
turer’s instructions for belt routing.
SSS0211A
Rear facing — step 2
SSS0212A
Rear facing — step 3
Safety — Seats, seat belts and supplemental restraint system
1-23
05.10.18/Z33-D/V5.0
