NISSAN 350Z 2007 Owner´s Manual

COUPE MODELS1. Coat hook (P.2-38)
2. Seat belts (P.1-10)
3. Seats
— Manual seats adjustment (P.1-3)
— Power seats adjustment (P.1-3)
4. Passenger seat
— Tilt lever for passenger seat (seatback)
(P.1-7)
5. Power window switch (P.2-39)/Power door
lock switch (P.3-4)
6. Outside mirror remote control switch
(P.3-27)
7. Sun visor (P.3-25)
8. Interior light (P.2-41)
9. Sunglasses holder (P.2-32)
10. Inside mirror (P.3-26)
— Automatic anti-glare inside mirror*
(P.3-26)
— HomeLink
universal transceiver*
(P.2-43)
11. Front passenger air bag status light
(P.1-36)/Microphone (Bluetooth
Hands-
Free Phone System*) (P.4-31)
12. Rear parcel box (P.2-37)
13. Rear parcel box or Navigation system*1
14. Rear floor box (P.2-35)
15. Power outlet (P.2-31)
16. Console box (P.2-35)
17. Parking brake
— Operation (P.5-15)
SSI0256
PASSENGER COMPARTMENT0-6
Illustrated table of contents


07.2.9/Z33-D/V5.0


— Parking/Parking on hills (P.5-19)
— Checking (P.8-20)
18. Selector lever or shift lever
— Automatic transmission (P.5-10)
— Manual transmission (P.5-13)
19. Cargo net (P.2-33)
*: if so equipped
*1: Refer to the separate Navigation System
Owner’s Manual.
Illustrated table of contents
0-7


07.2.9/Z33-D/V5.0


ROADSTER MODELS1. Seat belts (P.1-10)
2. Seats
— Power seats adjustment (P.1-4)
— Ventilated net seats* (P.1-6)
3. Passenger seat
— Power seatback tilt switch (P.1-7)
— Cancel switch (P.1-8)
4. Power window switch (P.2-39)/Power door
lock switch (P.3-4)
5. Outside mirror remote control switch
(P.3-27)
6. Soft top latch lever (P.3-16)
7. Safety switch for soft top latch lever (P.3-16)
8. Interior light (P.2-41)
9. Front passenger air bag status light (P.1-36)
10. Inside mirror (P.3-26)
— Automatic anti-glare inside mirror*
(P.3-26)
— HomeLink
universal transceiver*
(P.2-43)
11. Rear parcel box (P.2-37)
12. Rear parcel box or Navigation system*1
13. Rear floor box (P.2-35)
— Trunk lid cancel switch (P.3-11)
— Secondary trunk lid release (P.3-12)
14. Power outlet (P.2-31)
15. Console box (P.2-35)
16. Parking brake
— Operation (P.5-15)
— Parking/Parking on hills (P.5-19)
— Checking (P.8-20)
SSI0257
0-8
Illustrated table of contents


07.2.9/Z33-D/V5.0


17. Selector lever or shift lever
— Automatic transmission (P.5-10)
— Manual transmission (P.5-13)
18. Cargo net (P.2-33)
*: if so equipped
*1: Refer to the separate Navigation System
Owner’s Manual.
Illustrated table of contents
0-9


07.2.9/Z33-D/V5.0


1. Headlight/turn signal switch (P.2-24)
2. Instrument brightness control switch
(P.2-26)
3. Steering wheel switch for audio control*
(P.4-29) or switch for Bluetooth
Hands-
Free Phone System* (P.4-31)4. Driver supplemental air bag (P.1-28)/Horn
(P.2-27)
5. Meters/gauges (P.2-3)
6. Cruise control main/set switch* (P.5-16)
7. Trip computer mode/setting switch (P.2-8)
8. Wiper/washer switch (P.2-21)9. Center ventilator (P.4-8)
10. Passenger supplemental air bag (P.1-28)
11. Side ventilators (P.4-8)
12. Soft top operating switch (for Roadster
models) (P.3-13)
13. VDC (Vehicle dynamic control) OFF switch*
(P.2-29) or TCS (Traction control system)
OFF switch* (P.2-29)
14. Fuel-filler door opener switch (P.3-23)
15. Hood lock release handle (P.3-8)
16. Fuse box (P.8-23)
17. Tilting steering wheel lock lever (P.3-25)
18. Ignition switch (P.5-6)
19. Navigation system display (P.4-2)*1 or In-
strument pocket (P.2-32)
20. Audio system (P.4-12)/Clock (P.2-30)
21. Rear window and outside mirror defroster
switch (P.2-23)
22. Hazard warning flasher switch (P.2-27)
23. Cup holder (P.2-33)
24. Heated seat switch* (P.2-28)
25. Heater/air conditioner control (P.4-9)
26. Power outlet (P.2-30)
*: if so equipped
*1: Refer to the separate Navigation System
Owner’s Manual.
SIC3266
INSTRUMENT PANEL0-10
Illustrated table of contents


07.2.9/Z33-D/V5.0


1. Warning/Indicator lights (P.2-11)
2. Turn signal/hazard indicator lights (P.2-26)
3. Tachometer (P.2-5)
4. Speedometer (P.2-4)5. Instrument brightness control switch
(P.2-26)
6. Fuel gauge (P.2-6)
7. Engine coolant temperature gauge (P.2-5)8. Automatic transmission position indicator
(P.2-15, P.5-10) or Manual transmission up-
shift indicator (P.2-10, P.5-14)
9. Reset knobfor trip odometer (P.2-4)
10. Odometer (Total/Twin trip) (P.2-4)
11. Trip computer setting switch (P.2-8)
12. Trip computer mode switch (P.2-8)
13. Trip computer (P.2-8)
14. Engine oil pressure gauge (P.2-7)
15. Volt meter (P.2-8)
SIC3329
Combination meter
SIC1948A
Triple meter
METERS AND GAUGES
Illustrated table of contents
0-11


07.2.9/Z33-D/V5.0


1. Fuse/fusible link holder (P.8-21)
2. Battery (P.8-15)
3. Engine oil filler cap (P.8-9)
4. Brake fluid reservoir (P.8-13)
5. Clutch fluid reservoir (M/T models) (P.8-13)
6. Window washer fluid reservoir (P.8-14)
7. Power steering fluid reservoir (P.8-12)
8. Air cleaner (P.8-18)
9. Radiator filler cap (P.8-8)
10. Engine drive belts (P.8-16)
11. Engine coolant reservoir (P.8-8)
12. Engine oil dipstick (P.8-9)
Do not tamper with the strut tower bar
adjustment
A. The strut tower bar has
been adjusted to the most suitable posi-
tion at the factory.
SDI2050
ENGINE COMPARTMENT0-12
Illustrated table of contents


07.2.9/Z33-D/V5.0


1 Safety — Seats, seat belts and supple-
mental restraint systemSeats ........................................................................................ 1-2
Front manual seat adjustment
(for Coupe models) ........................................................ 1-3
Front power seat adjustment
(for Coupe models — if so equipped) ...................... 1-3
Front power seat adjustment
(for Roadster models) .................................................... 1-4
Seat lifter (for driver’s seat) ......................................... 1-6
Tilting and reclining passenger’s seat from driver’s
seat ..................................................................................... 1-7
Head restraint adjustment ............................................ 1-9
Active head restraint (except for ventilated net
seats) ................................................................................ 1-10
Seat belts ............................................................................. 1-10
Precautions on seat belt usage ................................ 1-10
Child safety .................................................................... 1-12
Pregnant women .......................................................... 1-13
Injured persons ............................................................. 1-14Three-point type seat belt with retractor ............... 1-14
Seat belt extenders ...................................................... 1-16
Seat belt maintenance ................................................ 1-16
Child restraints ................................................................... 1-17
Precautions on child restraints ................................. 1-17
Child restraint installation on front passenger
seat (Coupe models only) .......................................... 1-20
Top tether strap child restraint
(Coupe models only) ................................................... 1-24
Booster seats ....................................................................... 1-25
Precautions on booster seats .................................... 1-25
Booster seat installation on front passenger
seat.................................................................................... 1-27
Supplemental restraint system ....................................... 1-28
Precautions on supplemental restraint system ..... 1-28
Supplemental air bag warning labels ...................... 1-42
Supplemental air bag warning light ......................... 1-43


07.2.9/Z33-D/V5.0


WARNING

Do not ride in a moving vehicle when
the seatback is reclined. This can be
dangerous. The shoulder belt will not
be against your body. In an accident,
you could be thrown into it and re-
ceive neck or other serious injuries.
You could also slide under the lap
belt and receive serious internal
injuries.
For the most effective protection
when the vehicle is in motion, the
seat should be upright. Always sit
well back in the seat with both feet
on the floor and adjust the seat belt
properly. See “Precautions on seat
belt usage” later in this section.

After adjustment, gently rock in the
seat to make sure it is securely
locked.

Do not leave children unattended in-side the vehicle. They could unknow-
ingly activate switches or controls.
Unattended children could become
involved in serious accidents.
SSS0133
SEATS1-2
Safety — Seats, seat belts and supplemental restraint system


07.2.9/Z33-D/V5.0


FRONT MANUAL SEAT
ADJUSTMENT (for Coupe models)1
Forward and backward
Pull the lever up while you slide the seat forward
or backward to the desired position. Release the
lever to lock the seat in position.
When sliding the passenger’s seat backward,
be careful not to crush items in the seatback
pocket against the rear floor box.
2
Reclining
To recline the seatback, pull the lever up and
lean back. To bring the seatback forward again,
pull the lever and move your body forward. The
seatback will move forward.
The reclining feature allows adjustment of the
seatback for occupants of different sizes for
added comfort and to help obtain proper seat
belt fit. See “Precautions on seat belt usage”
later in this section. The seatback may also be
reclined to allow occupants to rest when the
vehicle is parked.
FRONT POWER SEAT
ADJUSTMENT (for Coupe models —
if so equipped)
Operating tips
The seat motor has an auto-reset overload
protection circuit. If the motor stops during
operation, wait 30 seconds, then reactivate
the switch.

Do not operate the power support seat
for a long period of time when the engine is
off. This will discharge the battery.
SSS0394
Safety — Seats, seat belts and supplemental restraint system
1-3


07.2.9/Z33-D/V5.0
