STEERING WHEEL
PS-7
C
D
E
F
H
I
J
K
L
MA
B
PS
Revision: 2006 November2007 350Z
STEERING WHEELPFP:48430
On-Vehicle Inspection and ServiceNGS0000A
CHECKING CONDITION OF INSTALLATION
Check installation condition of steering gear assembly, front sus-
pension, axle and steering column.
Check if movement exists when steering wheel is moved up and
down, to the left and right and to the axial direction.
Check if the mounting bolts for steering gear assembly are loose
or not. Refer to PS-17, "
POWER STEERING GEAR AND LINK-
AGE" .
CHECKING STEERING WHEEL PLAY
1. Set tires to the straight ahead, start engine, then turn steering wheel to the left and right lightly, and mea-
sure steering wheel movement on the outer circumference when steering wheel is turned up to the point
where tires start moving.
CHECKING NEUTRAL POSITION ON STEERING WHEEL
Check neutral position on steering wheel after confirming that front wheel alignment is correct. Refer to
PS-35, "
SERVICE DATA AND SPECIFICATIONS (SDS)" .
1. Set the vehicle to the straight ahead-direction, check if steering wheel is in the neutral position.
2. If it is not in the neutral position, remove steering wheel and reinstall it correctly.
3. If the neutral position cannot adjust in the two teeth of steering gear assembly, loosen tie-rod lock nuts of
steering outer sockets, then adjust tie-rods by the same amount in the opposite direction.
CHECKING STEERING WHEEL TURNING FORCE
1. Park vehicle on a level and dry surface, set parking brake.
2. Start engine.
3. Bring power steering fluid up to adequate operating temperature. [Make sure temperature of fluid is
approximately 50 to 80°C (122 to 176°F).]
4. Check steering wheel turning force when steering wheel has
been turned 540° from neutral position.
NOTE:
Multiply the distance (L) from the hook of spring scale to the
center of steering wheel by the measurement value with a spring
scale.
5. If steering wheel turning force is out of the specification, check
rack sliding force and relief hydraulic pressure of oil pump.
Regarding relief hydraulic pressure of oil pump, refer to PS-28,
"CHECKING RELIEF OIL PRESSURE" .
a. Disconnect lower joint and steering knuckle from steering gear assembly. Refer to PS-17, "
Removal and
Installation" , FA X - 4 , "Removal and Installation" .
b. Start and run engine at idle to make sure steering fluid has reached normal operating temperature.End play of the axle direction for steering wheel:
0 mm (0 in)
SGIA0348E
Steering wheel play on the outer circumference : 0 - 35 mm (0 - 1.38 in)
Steering wheel turning
force: 7.45 N·m (0.76 kg-m, 66 in-lb)
SGIA1136E
Page 9 of 36
STEERING WHEEL
PS-9
C
D
E
F
H
I
J
K
L
MA
B
PS
Revision: 2006 November2007 350Z
Removal and InstallationNGS0000B
REMOVAL
NOTE:
When reconnecting spiral cable, fix cable with a tape so that fixing case and rotating part keep aligned. This
will omit neutral position alignment procedure during spiral cable installation.
1. Set vehicle to the straight-ahead position.
2. Remove driver air bag module. Refer to SRS-40, "
Removal and Installation" .
3. Remove steering wheel lock nut after steering is locked.
4. Remove steering wheel with the steering wheel puller A.
INSTALLATION
Installation is the reverse order of removal. For tightening torque, refer to PS-10, "Removal and Installation" .
NOTE:
Check the spiral cable neutral position after replacing or rotating spiral cable. Refer to SRS-42, "
Removal and
Installation" . Tool number A: ST27180001 (J-25726-A)
SGIA1323E
Page 18 of 36
PS-18
POWER STEERING GEAR AND LINKAGE
Revision: 2006 November2007 350Z
8. Loosen bolt on upper yoke of lower joint and remove bolt on
lower yoke of joint, then slide lower joint into lower shaft. Sepa-
rate steering gear assembly from lower shaft.
9. Tack bolt on upper yoke of lower joint, fix lower joint to lower
shaft.
10. Remove the fixing bolt and remove steering gear assembly, rack
mounting bracket and insulator from vehicle.
INSTALLATION
Refer to PS-17, "Removal and Installation" for tightening torque. Install in the reverse order of removal.
NOTE:
Refer to component parts location and do not reuse non-reusable parts.
After removing/installing or replacing steering components, check wheel alignment. Refer to FSU-6,
"Wheel Alignment Inspection" .
When steering wheel is set in the straight ahead direction, con-
firm slit of lower joint fits with the projection on rear cover cap,
furthermore marking position on steering gear assembly nearly
fits with the projection on rear cover cap.
After installation, bleed air from piping. Refer to PS-6, "Air
Bleeding Hydraulic System" .
SGIA0367E
SGIA0348E
SGIA1753E
