WW-48
REAR WIPER AND WASHER SYSTEM
Revision: 2006 November2007 350Z
REMOVAL
1. Remove rear wiper arm. Refer to WW-46, "REMOVAL" .
2. Remove pivot cap.
3. Remove back door finisher lower. Refer to EI-48, "
BACK DOOR
FINISHER" .
4. Disconnect rear wiper motor connector.
5. Remove rear wiper motor mounting bolts and remove rear wiper
motor from the vehicle.
INSTALLATION
1. Install rear wiper motor to the vehicle.
2. Install pivot cap.
3. Connect rear wiper motor connector. Turn rear wiper switch ON to operate wiper motor, and then turn rear
wiper switch OFF (auto stop).
4. Install back door finisher lower. Refer to EI-48, "
BACK DOOR FINISHER" .
5. Install rear wiper arm and arm cap. Refer to WW-47, "
INSTALLATION" .
CAUTION:
Never drop the rear wiper motor nor cause it to interfere with other parts.
Washer Nozzle AdjustmentNKS0053C
Adjust spray position as shown in the figure.
Unit: mm (in)
Adjust washer nozzle with suitable tool as shown in the figure.
1. Cover wiper arm 2. Wiper blade 3. Wiper arm
4. Rear wiper motor 5. Pivot cap
PKIB1792E
Rear wiper motor mounting bolts : 4.5 N·m (0.46 kg-m, 40 in-lb)
Spray position h (height)
(width)SDiameter
(spray position range)
A 30 (1.18) 73 (2.87) 50 (1.97) 30
B 12 (0.47) 50 (1.97) 50 (1.97) 30
PKIB1788E
Adjustable range : ±10° (In any direction)
PKIA1910E
