ec-49 NISSAN ALMERA N16 2003 Electronic Repair Manual

INDEX FOR DTC
EC-11
[QG (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
ECHO2S1 (B1) P0133 0133 2×EC-155
HO2S1 (B1) P0134 0134 2×EC-165
HO2S1 (B1) P1143 1143 2×EC-296
HO2S1 (B1) P1144 1144 2×EC-302
HO2S1 HTR (B1) P0031 0031 2×EC-122
HO2S1 HTR (B1) P0032 0032 2×EC-122
HO2S2 (B1) P0138 0138 2×EC-172
HO2S2 (B1) P0139 0139 2×EC-178
HO2S2 (B1) P1146 1146 2×EC-308
HO2S2 (B1) P1147 1147 2×EC-316
HO2S2 HTR (B1) P0037 0037 2×EC-128
HO2S2 HTR (B1) P0038 0038 2×EC-128
IAT SEN/CIRCUIT P0112 0112 2×EC-140
IAT SEN/CIRCUIT P0113 0113 2×EC-140
INT/V TIM CONT-B1 P0011 0011 2 –EC-119
INT/V TIM V/CIR-B1 P1111 1111 2×EC-272
KNOCK SEN/CIRC-B1 P0327 0327 2 –EC-230
KNOCK SEN/CIRC-B1 P0328 0328 2 –EC-230
L/PRESS SOL/CIRC P0745 0745 2×AT- 1 6 4
MAF SEN/CIRCUIT P0102 0102 1×EC-134
MAF SEN/CIRCUIT P0103 0103 1×EC-134
MULTI CYL MISFIRE P0300 0300 2×EC-225
NATS MALFUNCTION P1610 - P1615 1610 - 1615 2 –EC-49
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.No DTC
Flashing*4–
Flashing*4EC-50
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.P0000 0000––—
O/R CLTCH SOL/CIRC P1760 1760 2×AT- 1 8 7
PNP SW/CIRC P0705 0705 2×AT- 111
P-N POS SW/CIRCUIT P1706 1706 2×EC-356
PURG VOLUME CONT/V P0444 0444 2×EC-251
PW ST P SEN/CIRC P0550 0550 2 –EC-260
SENSOR POWER/CIRC P1229 1229 1×EC-352
SFT SOL A/CIRC P0750 0750 1×AT- 1 7 1
SFT SOL B/CIRC P0755 0755 1×AT- 1 7 6
TCC SOLENOID/CIRC P0740 0740 2×AT- 1 5 9
TP SEN 1/CIRC P0222 0222 1×EC-205
TP SEN 1/CIRC P0223 0223 1×EC-205
TP SEN 2/CIRC P1223 1223 1×EC-335
TP SEN 2/CIRC P1224 1224 1×EC-335
TP SENSOR P0221 0221 1×EC-199
TPV SEN/CIRC A/T P1705 1705 1×AT- 1 8 1
Items
(CONSULT-II screen terms)DTC*
1
TripMI lighting
upReference page
CONSULT-II
GST*
2ECM*3

EC-14
[QG (WITH EURO-OBD)]
INDEX FOR DTC
*1: 1st trip DTC No. is the same as DTC No.
*2: These numbers are prescribed by ISO 15031-5.
*3: In Diagnostic Test Mode II (Self-diagnostic results), these numbers are controlled by NISSAN.
*4: When engine is running.
*5: The trouble shooting for this DTC needs CONSULT-II.
*6: When the fail-safe operations for both self-diagnoses occur, the MI illuminates. P1217 1217 ENG OVER TEMP 1×EC-324
P1223 1223 TP SEN 2/CIRC 1×EC-335
P1224 1224 TP SEN 2/CIRC 1×EC-335
P1225 1225 CTP LEARNING 2 –EC-341
P1226 1226 CTP LEARNING 2 –EC-343
P1227 1227 APP SEN 2/CIRC 1×EC-345
P1228 1228 APP SEN 2/CIRC 1×EC-345
P1229 1229 SENSOR POWER/CIRC 1×EC-352
P1610 - P1615 1610 - 1615 NATS MALFUNCTION 2 –EC-49
P1705 1705 TPV SEN/CIRC A/T 1×AT-181
P1706 1706 P-N POS SW/CIRCUIT 2×EC-356
P1760 1760 O/R CLTCH SOL/CIRC 2×AT-187
P1805 1805 BRAKE SW/CIRCUIT 2 –EC-360
DTC*1
Items
(CONSULT-II screen terms)TripMI lighting
upReference page
CONSULT-II
GST*
2ECM*3

EC-38
[QG (WITH EURO-OBD)]
ON BOARD DIAGNOSTIC (OBD) SYSTEM
CMP SEN/CIRC-B1 P0340 0340 — —×EC-240
TW CATALYST SYS-B1 P0420 0420××
×*4EC-246
PURG VOLUME CONT/V P0444 0444 — —×EC-251
VEH SPEED SEN/CIRC P0500 0500 — —×EC-257
PW ST P SEN/CIRC P0550 0550 — —×EC-260
ECM P0605 0605 — —×EC-265
PNP SW/CIRC P0705 0705 — —×AT- 111
ATF TEMP SEN/CIRC P0710 0710 — —×AT- 11 7
VEH SPD SEN/CIRC AT*5P0720 0720 — —×AT- 1 2 3
ENGINE SPEED SIG P0725 0725 — —×AT- 1 2 9
A/T 1ST GR FNCTN P0731 0731 — —×AT- 1 3 3
A/T 2ND GR FNCTN P0732 0732 — —×AT- 1 3 9
A/T 3RD GR FNCTN P0733 0733 — —×AT- 1 4 5
A/T 4TH GR FNCTN P0734 0734 — —×AT- 1 5 1
TCC SOLENOID/CIRC P0740 0740 — —×AT- 1 5 9
L/PRESS SOL/CIRC P0745 0745 — —×AT- 1 6 4
SFT SOL A/CIRC P0750 0750 — — —AT- 1 7 1
SFT SOL B/CIRC P0755 0755 — — —AT- 1 7 6
ECM BACK UP/CIRC P1065 1065 — —×EC-268
INT/V TIM V/CIR-B1 P1111 1111 — —×EC-272
ETC ACTR P1121 1121 — —×EC-276
ETC FUNCTION/CIRC P1122 1122 — — —EC-278
ETC MOT PWR P1124 1124 — — —EC-285
ETC MOT PWR P1126 1126 — — —EC-285
ETC MOT P11281128———EC-291
HO2S1 (B1) P1143 1143××
×*4EC-296
HO2S1 (B1) P1144 1144××
×*4EC-302
HO2S2 (B1) P1146 1146××
×*4EC-308
HO2S2 (B1) P1147 1147××
×*4EC-316
ENG OVER TEMP P1217 1217 — — —EC-324
TP SEN 2/CIRC P1223 1223 — — —EC-335
TP SEN 2/CIRC P1224 1224 — — —EC-335
CTP LEARNING P1225 1225 — —×EC-341
CTP LEARNING P1226 1226 — —×EC-343
APP SEN 2/CIRC P1227 1227 — — —EC-345
APP SEN 2/CIRC P1228 1228 — — —EC-345
SENSOR POWER/CIRC P1229 1229 — — —EC-352
NATS MALFUNCTION P1610 - P1615 1610 - 1615 — —×EC-49
TPV SEN/CIRC A/T P1705 1705 — — —AT- 1 8 1
P-N POS SW/CIRCUIT P1706 1706 — —×EC-356
Items
(CONSULT-II screen terms)DTC*
1
SRT codeTest Value/
Test Limit
(GST only)1st trip DTC Reference page
CONSULT-II
GST*
2ECM

ON BOARD DIAGNOSTIC (OBD) SYSTEM
EC-49
[QG (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
2. Perform “SELF-DIAGNOSTIC PROCEDURE (Without CONSULT-II)” in AT section titled “TROUBLE
DIAGNOSIS”, “Self-diagnosis”. (The engine warm-up step can be skipped when performing the diagnosis
only to erase the DTC.)
3. Select Mode 4 with GST (Generic Scan Tool).
How to Erase DTC ( No Tools)
1. If the ignition switch stays “ON” after repair work, be sure to turn ignition switch OFF” once.
2. Wait at least 10 seconds and then turn it “ON” (engine stopped) again.
3. Change the diagnostic test mode from Mode II to Mode I by depressing the accelerator pedal. Refer to
EC-51, "
HOW TO SWITCH DIAGNOSTIC TEST MODE" .
●If the battery is disconnected, the emission-related diagnostic information will be lost after
approx. 24 hours.
●The following data are cleared when the ECM memory is erased.
–Diagnostic trouble codes
–1st trip diagnostic trouble codes
–Freeze frame data
–1st trip freeze frame data
–System readiness test (SRT) codes
–Test values
–Others
Actual work procedures are explained using a DTC as an example. Be careful so that not only the DTC, but all
of the data listed above, are cleared from the ECM memory during work procedures.
NATS (Nissan Anti-theft System)EBS00K3I
●If the security indicator lights up with the ignition switch in
the “ON” position or “NATS MALFUNCTION” is displayed
on “SELF-DIAG RESULTS” screen, perform self-diagnostic
results mode with CONSULT-II using NATS program card.
Refer to EL-386.
●Confirm no self-diagnostic results of NATS is displayed
before touching “ERASE” in “SELF-DIAG RESULTS” mode
with CONSULT-II.
●When replacing ECM, initialization of NATS system and reg-
istration of all NATS ignition key IDs must be carried out
with CONSULT-II using NATS program card.
Therefore, be sure to receive all keys from vehicle owner.
Regarding the procedures of NATS initialization and NATS ignition key ID registration, refer to
CONSULT-II operation manual, NATS.
Malfunction Indicator (MI)EBS00K3J
DESCRIPTION
The MI is located on the instrument panel.
1. The MI will light up when the ignition switch is turned ON without
the engine running. This is a bulb check.
●If the MI does not light up, refer to EL-129, or see EC-397 .
2. When the engine is started, the MI should go off.
If the MI remains on, the on board diagnostic system has
detected an engine system malfunction.
ON BOARD DIAGNOSTIC SYSTEM FUNCTION
The on board diagnostic system has the following four functions.
SEF515Y
SAT652J

TROUBLE DIAGNOSIS
EC-67
[QG (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
6.PERFORM IDLE AIR VOLUME LEARNING
Refer to EC-31, "
Idle Air Volume Learning" .
Ye s o r N o
Ye s > > G O T O 7 .
No >> 1. Follow the construction of “Idle Air Volume Learning”.
2. GO TO 4.
7.CHECK TARGET IDLE SPEED AGAIN
With CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Read idle speed in “DATA MONITOR” mode with CONSULT-II.
Without CONSULT-II
1. Start engine and warm it up to normal operating temperature.
2. Check idle speed.
OK or NG
OK >> GO TO 10.
NG >> GO TO 8.
8.DETECT MALFUNCTIONING PART
Check the following.
●Check camshaft position sensor (PHASE) and circuit. Refer to EC-240 .
●Check crankshaft position sensor (POS) and circuit. Refer to EC-234 .
OK or NG
OK >> GO TO 9.
NG >> 1. Repair or replace.
2. GO TO 4.
9.CHECK ECM FUNCTION
1. Substitute another known-good ECM to check ECM function. (ECM may be the cause of a incident, but
this is the rarely the case.)
2. Perform initialization of NATS system and registration of NATS ignition key IDs. Refer to EC-49, "
NATS
(Nissan Anti-theft System)" .
>> GO TO 4. Is″Idle Air Volume Learning″ carried out successfully?
M/T: 700 ± 50 rpm
A/T: 800 ± 50 rpm (in “P” or “N” position)
M/T: 700 ± 50 rpm
A/T: 800 ± 50 rpm (in “P” or “N” position)

TROUBLE DIAGNOSIS
EC-69
[QG (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
15.CHECK IGNITION TIMING AGAIN
1. Run engine at idle.
2. Check ignition timing with a timing light.
OK or NG
OK >>INSPECTION END
NG >> GO TO 16.
16.CHECK TIMING CHAIN INSTALLATION
Check timing chain installation. Refer to EM-47, "
TIMING CHAIN" .
OK or NG
OK >> GO TO 17.
NG >> 1. Repair the timing chain installation.
2. GO TO 4.
17.DETECT MALFUNCTIONING PART
Check the following.
●Check camshaft position sensor (PHASE) and circuit. Refer to EC-240 .
●Check crankshaft position sensor (POS) and circuit. Refer to EC-234 .
OK or NG
OK >> GO TO 18.
NG >> 1. Repair or replace.
2. GO TO 4.
18.CHECK ECM FUNCTION
1. Substitute another known-good ECM to check ECM function. (ECM may be the cause of a incident, but
this is the rarely the case.)
2. Perform initialization of NATS system and registration of NATS ignition key IDs. Refer to EC-49, "
NATS
(Nissan Anti-theft System)" .
>> GO TO 4. M/T: 8 ± 5° BTDC
A/T: 10 ± 5° BTDC (in “P” or “N” position)

TROUBLE DIAGNOSIS
EC-73
[QG (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
1 - 6: The numbers refer to the order of inspection.Cooling Radiator/Hose/Radiator filler cap
55555 55 25LC-12
Thermostat 5 LC-15
Water pumpLC-14
Water galleryLC-12
Cooling fan 5 LC-17
Coolant level (low)/Contaminated
coolantLC-17
NATS (Nissan Anti-Theft System) 1 1EC-49
or
EL-386 SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA

DTC P0605 ECM
EC-267
[QG (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
2.REPLACE ECM
1. Replace ECM.
2. Perform initialization of NATS system and registration of all NATS ignition key IDs. Refer to EC-49, "
NATS
(Nissan Anti-theft System)" .
3. Perform EC-31, "
Accelerator Pedal Released Position Learning" .
4. Perform EC-31, "
Throttle Valve Closed Position Learning" .
5. Perform EC-31, "
Idle Air Volume Learning" .
>>INSPECTION END

DTC P1065 ECM POWER SUPPLY
EC-271
[QG (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
4.PERFORM DTC CONFIRMATION PROCEDURE
With CONSULT-II
1. Turn ignition switch “ON”.
2. Select “SELF DIAG RESULTS” mode with CONSULT-II.
3. Touch “ERASE”.
4.Perform “DTC Confirmation Procedure”.
See EC-268
.
5. Is the 1st trip DTC P1065 displayed again?
With GST
1. Turn ignition switch “ON”.
2. Select MODE 4 with GST.
3. Touch “ERASE”.
4.Perform “DTC Confirmation Procedure”.
See EC-268
.
5. Is the 1st trip DTC P1065 displayed again?
Ye s o r N o
Ye s > > G O T O 5 .
No >>INSPECTION END
5.REPLACE ECM
1. Replace ECM.
2. Perform initialization of NATS system and registration of all NATS ignition key IDs. Refer to EC-49, "
NATS
(Nissan Anti-theft System)" .
3. Perform EC-31, "
Accelerator Pedal Released Position Learning" .
4. Perform EC-31, "
Throttle Valve Closed Position Learning" .
5. Perform EC-31, "
Idle Air Volume Learning" .
>>INSPECTION END

EC-406
[QG (WITHOUT EURO-OBD)]
INDEX FOR DTC
[QG (WITHOUT EURO-OBD)]INDEX FOR DTCPFP:00024
Alphabetical IndexEBS00KE0
Check if the vehicle is a model with Euro-OBD (E-OBD) system or not by the “Type approval number” on the
identification plate. Refer to GI-39.
NOTE:
If DTC U1000 or U1001 is displayed with other DTC, first perform the trouble diagnosis for DTC U1000,
U1001. Refer to EC-492, "
DTC U1000, U1001 CAN COMMUNICATION LINE" .
×: Applicable —: Not applicable
Items
(CONSULT-II screen terms)DTC
*1
TripMI lighting
upReference page
CONSULT-
II
*2ECM*3
APP SEN 1/CIRC P0227 0227 1×EC-543
APP SEN 1/CIRC P0228 0228 1×EC-543
APP SEN 2/CIRC P1227 1227 1×EC-617
APP SEN 2/CIRC P1228 1228 1×EC-617
APP SENSOR P0226 0226 1×EC-536
BRAKE SW/CIRCUIT P1805 1805 1×EC-628
CAN COMM CIRCUIT*5U1000 1000 1×EC-492
CAN COMM CIRCUIT*5U1001 1001 2 —EC-492
CKP SEN/CIRCUIT P0335 0335 2×EC-554
CMP SEN/CIRC-B1 P0340 0340 2×EC-561
CTP LEARNING P1225 1225 2 —EC-613
CTP LEARNING P1226 1226 2 —EC-615
ECM P0605 0605 1 or 2× or —EC-568
ECM BACK UP/CIRC P1065 1065 2×EC-571
ECT SEN/CIRCUIT P0117 0117 2×EC-501
ECT SEN/CIRCUIT P0118 0118 2×EC-501
ENG OVER TEMP P1217 1217 1×EC-596
ETC ACTR P1121 1121 1 or 2×EC-575
ETC FUNCTION/CIRC P1122 1122 1×EC-578
ETC MOT P1128 1128 1×EC-591
ETC MOT PWR P1124 1124 1×EC-585
ETC MOT PWR P1126 1126 1×EC-585
HO2S1 (B1) P0132 0132 2×EC-506
HO2S1 (B1) P0134 0134 2×EC-512
HO2S2 (B1) P0138 0138 2×EC-518
KNOCK SEN/CIRC-B1 P0327 0327 2 —EC-550
KNOCK SEN/CIRC-B1 P0328 0328 2 —EC-550
MAF SEN/CIRCUIT P0102 0102 1×EC-495
MAF SEN/CIRCUIT P0103 0103 1×EC-495
NATS MALFUNCTIONP1610 -
P16151610 - 1615 2 —EC-431
NO DTC IS DETECTED.
FURTHER TESTING
MAY BE REQUIRED.No DTC
Flashing*4—
Flashing*4EC-433
