were left ON. The fog lights will be turned
OFF by the Battery Saver function ap-
proximately 5 minutes after the last door
is closed.
cIf the ignition switch is turned to the ON
position after the fog lights were turned
OFF by the Battery Saver function, the
fog lights will immediately come back
ON.
Headlight switch in the AUTO position;
nighttime operation
cFog lights, marker and taillights come
ON.
cHeadlights come ON.
cDash readouts dim unless the dimmer
switch is on full bright.
cIf the ignition switch is in the OFF position
with the fog lights turned ON, the fog
lights will be turned OFF by the Twilight
Sentinel function approximately 45 sec-
onds after the last door is closed. When
any door is opened when the ignition
switch is in the OFF position, the Twilight
Sentinel function operates for approxi-
mately 5 minutes. After approximately 5minutes, the lights will turn OFF due to
the Battery Saver function.
cIf the ignition switch is turned to the ON
position after the fog lights were turned
OFF by the Twilight Sentinel function, the
fog lights and the headlights will come
ON together when the Auto Light Sensor
determines it is dark enough. The fog
lights will now operate independently of
the headlights only if the headlight switch
is turned OFF.
cWhen the high-beams are turned ON, the
fog lights will turn OFF. The fog lights will
come back ON when the high-beams are
turned OFF.
Headlights turned ON and OFF by the
driver (no AUTO headlight function); day
or nighttime operation
cSame operation as ``Headlight switch in
the AUTO position; daytime operation''
described above.
Some of the Battery Saver and Twilight
Sentinel functions can be turned ON
and OFF or adjusted. Please see your
NISSAN dealer if you have any ques-
tions.To turn the fog lights OFF, turn the switch to
the OFF position.
The fog lights automatically turn off when-
ever the high-beam headlight function is
selected.
2-22Instruments and controls
ZX

Push the switch on to warn other drivers
when you must stop or park under emer-
gency conditions. All turn signal lights flash.
WARNING
cIf stopping for an emergency, be
sure to move the vehicle well off the
road.cDo not use the switch while moving
on the highway unless unusual cir-
cumstances force you to drive so
slowly that your vehicle might be-
come a hazard to other traffic.
cTurn signals do not work when the
hazard warning flasher lights are on.
The flashers can be actuated with the igni-
tion switch either OFF or ON.
Some state laws may prohibit the use of
the hazard warning flasher switch while
driving.
To sound the horn, push the center pad
area of the steering wheel.
WARNING
Do not disassemble the horn. Doing so
could affect proper operation of the
supplemental front air bag system.
Tampering with the supplemental front
air bag system may result in serious
personal injury.
LIC0174WIC0119
HAZARD WARNING FLASHER
SWITCHHORN
Instruments and controls2-23
ZX

The front seats (if so equipped) are warmed
by built-in heaters. The switches are located
on the center console.
1. Start the engine.
2. Push the low or high position of the
switch, as desired, depending on the
temperature. The indicator light in the
switch will illuminate.
The heater is controlled by a thermostat,
automatically turning the heater on and
off. The indicator light will remain on as
long as the switch is on.3. When the seat is warmed or before you
leave the vehicle, be sure to turn the
switch off.
CAUTION
cDo not use the seat heater for ex-
tended periods or when no one is
using the seat.
cDo not put anything on the seat
which insulates heat, such as a blan-
ket, cushion, seat cover, etc. Other-
wise, the seat may become over-
heated.
cDo not place anything hard or heavy
on the seat or pierce it with a pin or
similar object. This may result in
damage to the heater.
cAny liquid spilled on the heated seat
should be removed immediately with
a dry cloth.
cWhen cleaning the seat, never use
benzine, thinner, or any similar ma-
terials.cIf any abnormalities are found or the
heated seat does not operate, turn
the switch off and have the system
checked by your NISSAN dealer.
cThe battery could run down if the
heater is operated while the engine
is not running.
LIC0136
HEATED SEATS (if so
equipped)
2-24Instruments and controls
ZX

To cancel the Traction Control System
(TCS), push the ªTCS OFFº switch to turn
off the system. The
indicator will
come on.
Push the ªTCS OFFº switch again or restart
the engine and the system will operate
normally. See ªTraction control systemº in
the ªStarting and drivingº section.The power outlet is for powering electrical
accessories such as cellular telephones.CAUTION
cTake care as the outlet and plug may
be hot during or immediately after
use.
cThis power outlet is not designed for
use with a cigarette lighter unit.
cDo not use with accessories that
exceed a 12 volt, 120W (10A) power
draw. Do not use double adapters or
more than one electrical accessory.
LIC0134LIC0142WIC0186
TRACTION CONTROL
SYSTEM (TCS) CANCEL
SWITCH (if so equipped)POWER OUTLET
Instruments and controls2-25
ZX

cUse this power outlet with the engine
running. (If the engine is stopped,
this could result in a discharged bat-
tery.)
cAvoid using when the air conditioner,
headlights or rear window defogger is
on.
cBefore inserting or disconnecting a
plug, be sure the electrical accessory
being used is turned off.
cPush the plug in as far as it will go. If
good contact is not made, the plug
may overheat or the internal tempera-
ture fuse may blow.
cWhen not in use, be sure to close the
cap. Do not allow water to contact the
socket.
SEATBACK POCKETS (if so
equipped)
The seatback pockets are located on the
back of the driver and passenger seats. The
pockets can be used to store maps.
SEATBACK SIDE POCKETS (if so
equipped)
A seatback side pocket is located on the
inboard side of the front passenger seat.
SUNGLASSES CASE
The sunglasses case can be opened by
pushing the button.
WARNING
The sunglasses case should not be
used while driving so full attention may
be given to vehicle operation.
LIC0016LIC0137
STORAGE
2-26Instruments and controls
ZX

CAUTION
cDo not use for anything other than
sunglasses.
cDo not leave sunglasses in the sun-
glasses case while parking in direct
sunlight. The heat may damage the
sunglasses.
CUP HOLDERS
To open the front cup holders, lift the con-
sole cover. To close, lower the console
cover.
The rubber insert may be removed for
cleaning.
The rear cupholders are located in the fold-
down armrest in the rear seat back.
WARNING
The cup holder should not be used
while driving so full attention may be
given to vehicle operation.
CAUTION
cAvoid abrupt starting and braking
when the cup holder is being used to
prevent spilling the drink. If the liq-
uid is hot, it can scald you or your
passenger.
WIC0138LIC0175
Instruments and controls2-27
ZX

cUse only soft cups in the cup holder.
Hard objects can injure you in an
accident.
GLOVE BOX
The glove box opens by pulling the handle.
When locking or unlocking the glove box,
use the master key. The valet key cannot be
used to lock or unlock the glove box.
WARNING
Keep glove box lid closed while driving
to help prevent injury in an accident or
a sudden stop.
CONSOLE BOX
WARNING
The center console box should not be
used while driving so full attention may
be given to vehicle operation.
CAUTION
cThis power socket is not designed
for use with a cigarette lighter unit.
cDo not use accessories that exceed
12 volt, 120W (10A) power draw. Do
not use double adapters or more
than one electrical accessory.
LIC0176
2-28Instruments and controls
ZX

Armrest
Push the button to elevate the armrest. To
return armrest to regular position, push arm-
rest rearward until locked.Upper half
Pull up on the lever to open the upper half of
the console box. The rubber mat may be
removed for cleaning.
The upper half of the console box may be
used for storage of cellular phones. An
access hole is provided at the bottom of the
upper half of the console box for phone cord
routing to the power socket.
To route a phone cord to the power socket:
1. open the upper half of the console box
2. remove the rubber mat, and then remove
the cutout area from the mat
3. remove the access hole cover
4. install the rubber mat
5. route the phone cord through the access
hole and plug into the power socket
Lower half
Pull up on the lever to open the lower half of
the console box. A power socket is located
inside the console box and there is storage
for compact discs.
COVERED STORAGE BOX
Push the bottom center of the lid to open.
WIC0189
LIC0181
Instruments and controls2-29
ZX

CARGO NET (if so equipped)
The cargo net helps keep packages in the
cargo area from moving around while the
vehicle is in motion.
To install the cargo net, attach the hooks to
the retainers.
To remove the cargo net, detach the hooks
from the cargo net retainers.
WIC0190
2-30Instruments and controls
ZX

WARNING
cProperly secure all cargo to help pre-
vent it from sliding or shifting.
cBe sure to secure hooks into the
retainers. The cargo restrained in the
net must not exceed 30 lbs. (13.6 kg)
or the net may not stay secured.POWER WINDOWS
WARNING
cMake sure that all passengers have
their hands, etc. inside the vehicle
while it is in motion and before clos-
ing the windows. Use the window
lock switch to prevent unexpected
use of the power windows.
cDo not leave children unattended in-
side the vehicle. They could un-
knowingly activate switches or con-
trols and become trapped in a
window. Unattended children could
become involved in serious acci-
dents.The power windows operate when the igni-
tion key is in the ON position, or for about 45
seconds after the ignition key is turned to
the OFF position. If the driver's or front
passenger's door is opened during this pe-
riod of about 45 seconds, power to the
windows is cancelled. To open a window,
press down on the switch. To close a win-
dow, pull up on the switch. To stop the
opening or closing function at any time,
simply release the switch.
The driver side control panel is equipped
with switches to open or close all of the
windows.
LIC0177
WINDOWS
