trunk NISSAN ALTIMA HYBRID 2007 L32A / 4.G First Responders Guide

- 8-
Hybrid SystemLocations and Descriptions
ComponentLocationDescription
1. ElectricAir
Conditioning
Compressor
Engine compartment, front
passenger side
Electric motor driven compressor supplied with 245 volts
DC.
2. Electric Power
Steering
Engine compartment, on
steering rack
A 42 volt DC assist motor is used for the electric power
steering (EPS) system.
3. EPS DC/DC
Converter
Trunk area, mounted to top
of high voltage battery
Converts 245 volts DC (high voltage) to 42 volts DC (low
voltage) for the EPS.
4. High Voltage
Battery
Trunk area, mounted to
cross member and behind
rear seat
245 volt DC Nickel Metal Hydride (Ni-MH) battery
consisting of34 low voltage (7.2 volt) modules connected
in series.
5. DC/DC
Converter
Trunk area, under front left
cover of the high voltage
battery
Converts 245 volts DC (high voltage) to 12 volts DC (low
voltage) for charging the 12 volt battery.
6. Service
Disconnect
Trunk area, on the
passenger side of the high
voltage battery
Used to disable the high voltage system.
7. High Voltage
Harnesses

- 9-
Battery Information
The Altima Hybrid utilizes two batteries in order to supply both high and low voltage.
Low Voltage Battery
The Altima Hybrid contains a lead-acid 12 volt DC low voltage battery.
The low voltage battery is located in the passenger rear quarter panel
well of the trunk and is concealed by atrim cover. The negative (-) 12
volt battery cable can be accessed through an access panel in the
trim cover.
The12 volt batterypowers the vehicle’s 12 volt electrical system,
similar to a conventional vehicle. As with conventional vehicles, the 12
volt battery is grounded to the metal chassis of the vehicle. However,
the 12 volt battery is charged by the high voltage battery through the
DC/DC converter.
High VoltageBattery
The Altima Hybrid contains aNi-MH245 volt DC high voltagebattery.
The high voltage batteryisenclosed in a metal case, which is isolated
from high voltage, and is securely mounted in the trunk area behind
the rear seat and is concealed by a trim cover. The service disconnect
can be accessedthrough an access panel in the trim cover.
The 245 volt battery powers the vehicle’s high voltage electrical
system. The high voltagebattery consists of34 low voltage (7.2 volt)
Ni-MH battery modules connected in series to produce approximately
245 volts DC. EachNi-MH battery module is sealed in a non-spillable
plastic case.The electrolyte used in theNi-MH battery module is an alkalinemixtureof potassiumand sodium
hydroxide. The electrolyte is absorbed into the battery cell plates and forms a gelthat should not normally leak,
even in a collision.In the unlikely eventthatthe high voltage batteryis overcharged, the modules vent gases
directly outside the vehiclethrough a venthose.
An air vent is located on the rear parcel shelftocool thehigh voltage
battery.If the vent is covered, the battery will overheat, resultingin
reduced output performance ofthe hybrid system.
The high voltage batterysupplies power to the following:

- 16-
NOTE:
Repositioningthe power seats and operating the power trunk release must be done prior to12 volt battery
disconnection.
Extrication
1. Immobilize the vehicle
a.Move the shift lever to the P (Park) position.
b.Shut the vehicle OFF by pressing the push-button ignition
switch.
c.Chock the wheels.
d.Set the parking brake.
2. Remove the Intelligent Key (1) from the key port (located on the lower
LH corner of the instrument panel). Keep it at least 3.3 feet (1 meter)
away from the vehicle.
3. Stabilize the vehicle
a.Crib at four points directly under the front and rear pillars. Do
not place cribbing under the high voltage harness, exhaust
system or fuel system.

- 17-
4. Open the trunk using one of the following methods:
