NISSAN ALTIMA HYBRID 2009 L32A / 4.G User Guide Press the INFO button on the control panel, and
then touch the “Energy / Fuel History” key on the
screen.The Energy / Fuel History can be displayed on the
navigation system monitor. The screen mus

Page 12 of 353

NISSAN ALTIMA HYBRID 2009 L32A / 4.G User Guide Place the ignition switch in the ON position.
Depress the brake pedal and push the ignition
switch when the transmission is in the P (Park)
position to start the Hybrid System.
The READY light illumin

Page 13 of 353

NISSAN ALTIMA HYBRID 2009 L32A / 4.G User Guide HIGH VOLTAGE COMPONENTS
WARNING
cThe Hybrid System uses high voltage up
to 650 V. The system can be hot while
and after starting. Be careful of both the
high voltage and the high temperature.
Obey the

Page 14 of 353

NISSAN ALTIMA HYBRID 2009 L32A / 4.G User Guide 1. Air conditioner compressor location
2. Electric power steering location
3. 42V DC/DC converter
4. High voltage battery and 12V DC/DC
converter
5. Service disconnect
6. High voltage harnesses
7. Tra

Page 15 of 353

NISSAN ALTIMA HYBRID 2009 L32A / 4.G User Guide cWhen you leave your vehicle, be sure to
turn off the Hybrid System.
cBe sure to put the transmission in the P
(Park) position because the vehicle can
move when the READY light is on even
if the engin

Page 16 of 353

NISSAN ALTIMA HYBRID 2009 L32A / 4.G User Guide An air vent is located on the rear parcel shelfsA
to cool the high voltage battery. If the vent is
covered, the battery will overheat resulting in
reduced output performance of the Hybrid Sys-
tem.
Yo

Page 17 of 353

NISSAN ALTIMA HYBRID 2009 L32A / 4.G User Guide CAUTION
Do not allow any liquid to get on or in the
air vent. It may cause a short circuit and
damage the high voltage battery.
LHV0008
HEV-12HEV Overview
ZREVIEW COPYÐ2009 Altima Hybrid Electric
(ah

Page 18 of 353

NISSAN ALTIMA HYBRID 2009 L32A / 4.G User Guide 0 Illustrated table of contents
Air bags, seat belts and child restraints..............0-2
Exterior front......................................0-3
Exterior rear.......................................0

Page 19 of 353

NISSAN ALTIMA HYBRID 2009 L32A / 4.G User Guide 1. Top tether strap anchor (P. 1-18)
2. Rear seat belts (P. 1-7)
3. Roof-mounted curtain side-impact
supplemental air bag (P. 1-34)
4. Front seat-mounted side-impact
supplemental air bag (P. 1-34)
5.

Page 20 of 353

NISSAN ALTIMA HYBRID 2009 L32A / 4.G User Guide 1. Power windows (P. 2-41)
2. Windshield (P. 8-17)
3. Windshield wiper and washer switch
(P. 2-28)
4. Engine hood (P. 3-18)
5. Tie down/towing hooks (if so equipped)
(P. 6-14)
6. Fog light switch (if
