Page 311 of 336

NISSAN FRONTIER 2006 D22 / 1.G Owners Manual Maximum Gross Vehicle Weight
(GVW)/maximum Gross Axle Weight
(GAW)
The GVW of the towing vehicle must not exceed
the Gross Vehicle Weight Rating (GVWR)
shown on the F.M.V.S.S./C.M.V.S.S. certification

Page 312 of 336

NISSAN FRONTIER 2006 D22 / 1.G Owners Manual cGross Combined Weight Rating (GCWR)
from “Towing Load/Specification9chart -
11,133 lb. (5050 kg) .
cMaximum Trailer towing capacity from “Tow-
ing Load/Specification9chart - 6,100 lb.
(2767 kg) .

Page 313 of 336

NISSAN FRONTIER 2006 D22 / 1.G Owners Manual TOWING LOAD/SPECIFICATION
King Cab 2WD (4 cyl) King Cab 2WD (6 cyl) King Cab 4WD (6 cyl) Crew Cab 2WD Crew Cab 4WD
Towing Capacity*1, *2 3,500 lb. (1,588 kg) 6,500 lb. (2,949 kg) 6,300 lb. (2,858 kg)

Page 314 of 336

NISSAN FRONTIER 2006 D22 / 1.G Owners Manual TOWING SAFETY
Trailer hitch
Your vehicle may be equipped with an optional
trailer tow package. The trailer tow package in-
cludes a receiver-type frame mounted hitch. This
hitch is rated for the maxim

Page 315 of 336

NISSAN FRONTIER 2006 D22 / 1.G Owners Manual Bumper towing
The genuine NISSAN step bumper has provi-
sions to install a trailer hitch ball and is designed
to tow trailers of a maximum weight of 3,500 lb
(1,588 kg) .
To install a trailer hitch ba

Page 316 of 336

NISSAN FRONTIER 2006 D22 / 1.G Owners Manual Class II hitch
Class II trailer hitch equipment (receiver, ball
mount and hitch ball) can be used to tow trailers
of a maximum weight of 3,500 lb (1,510 kg) .
The genuine NISSAN step bumper is conside

Page 317 of 336

NISSAN FRONTIER 2006 D22 / 1.G Owners Manual Trailer lights
CAUTION
When splicing into the vehicle electrical
system, a commercially available power-
type module/converter must be used to
provide power for all trailer lighting. This
unit uses th

Page 318 of 336

NISSAN FRONTIER 2006 D22 / 1.G Owners Manual cAlways drive your vehicle at a moderate
speed.
cWhen backing up, hold the bottom of the
steering wheel with one hand. Move your
hand in the direction in which you want the
trailer to go. Make small c

Page 319 of 336

NISSAN FRONTIER 2006 D22 / 1.G Owners Manual cCrosswinds and rough roads will adversely
affect vehicle/trailer handling, possibly caus-
ing vehicle sway. When being passed by
larger vehicles, be prepared for possible
changes in crosswinds that c

Page 320 of 336

NISSAN FRONTIER 2006 D22 / 1.G Owners Manual Automatic Transmission
To tow a vehicle equipped with an automatic
transmission, an appropriate vehicle dollyMUST
be placed under the towed vehicle’s drive
wheels.Alwaysfollow the dolly manufacturer
