ENGINE COMPARTMENT
WARNING
Never use a fuse of a higher or lower
amperage rating than that specified
on the fuse box cover. This could
damage the electrical system or
electronic control units or cause a
fire.
If any electrical equipment does not
operate, check for an open fuse.
1. Be sure the ignition switch is pushed to the OFF or LOCK position and theFUSES

headlights are turned off.
2. Open the engine hood and remove the cover on the battery and the fuse/
fusible link holder.
3. Remove the fuse/fusible link holder cover.
4. Remove the fuse with the fuse puller that is located in the engine compart-
ment fuse box.
, replace it with a
new fuses
. Spare fuses are stored in
the passenger compartment fuse box.
6. If a new fuse also opens, have the electrical system checked and re-
paired. It is recommended you contact
a GT-R certified NISSAN dealer.
Fusible linksIf any electrical equipment does not
operate and fuses are in good condition,
check the fusible links. If any of these
fusible links are melted, replace only with
genuine NISSAN parts.
WARNING
Never use a fuse of a higher or lower
amperage rating than that specified
on the fuse box cover. This could
damage the electrical system or
electronic control units or cause a
fire.
If any electrical equipment does not
operate, check for an open fuse.
1. Be sure the ignition switch is pushed to the OFF or LOCK position and the
Do-it-yourself
8-23

However, the brake pads can be sepa-
rately replaced only when a GT-R certified
technician judges that the brake disc
rotors are reusable, based on a measured
weight and a check for scratches and
cracks.EXHAUST MUFFLER AND TRUNK
CARPETThe GT-R exhaust system is designed to
provide the maximum vehicle perfor-
mance and to protect the vehicle from
high exhaust gas temperatures.
If non-genuine GT-R exhaust system
parts are used it is possible that the
muffler or other exhaust system parts will
deform and cause damage to the under-
body. Non-genuine GT-R exhaust system
parts can also affect vehicle performance
and possibly lead to turbocharger, engine
or power train related parts including
transmission, damage.
Also, do not remove the trunk carpet from
the vehicle for any reason. The carpet
insulates the vehicle interior from the
heat of the muffler and from the noise
of the transmission.
TITANIUM MUFFLER AND TRUNK
CARPET (if so equipped)
NOTICE
Never allow polishes with com-
pounds, because there is a possibi-
lity that the titanium muffler finisher
coloring will be changed.
GT-R Overview
GTR-7

Cool downThe information and specifications in
this section apply only when engaging
in performance driving.
Cool down the vehicle to help extend the
life of the vehicle if coolant temperatures
are extremely high. Drive the vehicle at 37
to 50 MPH (60 to 80 km/h), in 5th or 6th
gear for 2 to 3 miles (3 to 5 km) and then
stop the engine.Refueling precautions
WARNING
Do not attempt to top off the fuel
tank after the fuel pump nozzle
shuts off automatically. Continued
refueling may cause fuel overflow,
resulting in fuel spray and possibly a
fire. The fuel tank is full at the first
automatic shutoff.
To maximize vehicle performance, the
fuel tank is located as low as possible to
lower the vehicle center of gravity. The
tank is also divided into two parts. This
fuel tank design causes higher pressures
inside the tank than other vehicles so fuel
spillage is possible by trying to top off the fuel tank after automatic shutoff.
The fuel tank pressure is higher when the
vehicle is hot, especially if the tank is more
than half full. If the cap is opened when
the vehicle is hot, it may cause fuel spray
and there may be a hissing noise. Open
the cap slowly, releasing the pressure
from the tank gradually. Also, if the
vehicle is refueled when the vehicle is
hot, the fuel pump may automatically
shut off before the tank is full. This does
not indicate that there is a malfunction.
Refuel slowly or refuel after the vehicle
has cooled.
INSPECTION AND ADJUSTMENTS
BEFORE DRIVINGThe information and specifications in
this section apply only when engaging
in performance driving.Fluids.
Check the engine, transmission, differ-
ential and under vehicle surfaces for
oil and coolant leaks.
. Check the fluid levels and adjust as
necessary using the specified fluid as
described under the conditions listed
in this section.(
“Recommended
fluids and maintenance interval” page GTR-20) If you do not drive under the
conditions listed, refer to the “9. Main-
tenance and schedules” section of this
manual.

to be 0.39 in (10
mm) (1/8 gal (0.5 liters))
below the H
mark on the engine oil dipstick. (
range is 1.18 in (30 mm).) Before
checking the oil level, run the engine
until it reaches operating temperature
and wait at least 5 minutes after
turning off the engine. Make sure the
oil level always remains above the L
mark.
When the vehicle is delivered, the
engine oil is set to

Check the coolant level in the pressurized
coolant reservoir. Adjust the level so that
the fluid is between the MAX and MIN
markings. For the coolant, use genuine
NISSAN Long Life coolant or equivalent.
(On delivery of new vehicle, the reservoir
is filled to the MIN level. Be sure to
replenish approximately 3/8 US quart
(0.3 to 0.4 liter) of coolant.)
NOTICE
Do not overfill the coolant. This may
increase the pressure in the cooling
system and cause coolant leaks.
To maximize vehicle performance, the
coolant mixture ratio should be a combi-
nation of 30% coolant antifreeze and 70%
demineralized or distilled water for max-
imum cooling system performance re-
gardless of ambient temperatures.
If ambient temperatures are anticipated
below 5°F (−15°C), make sure a proper
mixture ratio of 50% antifreeze and 50%
demineralized or distilled water mix is
used.Engine and powertrainThe information and specifications in
this section apply only when engaging in performance driving.
.
Check the engine, transmission, differ-
ential and under the vehicle for oil and
coolant leaks.
. Inspect the areas surrounding of the
catalytic converter for heat deteriora-
tion.
. Always perform the transmission
setting. After that, adjust the clutch
clearance so that the clearance is less
than the clearance used for daily
driving. Your GT-R certified NISSAN
dealer has the necessary information
and equipment to set the clutch
clearance to the correct specification.
The clearance used for daily driving
increases clutch heat generated dur-
ing Performance Driving. This leads to
an increase in temperature of the
transmission oil. In addition, a more
direct shifting feel can be obtained by
reducing the clutch clearance for
Performance Driving. The clutch clear-
ance should be reset to the daily
driving specification after Perfor-
mance Driving. It is recommended
you see a GT-R certified NISSAN dealer
for information.
NOTICE
Failure to have the clutch properly
adjusted before performance driving
may cause the transmission oil tem-
perature to increase which may
cause transmission damage.
. Inspect and confirm the clearance
between the exhaust finisher and rear
bumper is more than 0.24 in (6 mm)
(up/down) and more than 0.20 in (5
mm) (left/right).
. Inspect the dust boot of the drive
shaft universal joint for cracks or
damage.Suspension and wheel alignmentThe information and specifications in
this section apply only when engaging
in performance driving.
.Check the steering and suspension
system and other links for loose and/
or damaged parts.
. Measure and adjust the wheel align-
ment. (
“Wheel alignment” page
GTR-10) It is recommended you con-
tact a GT-R certified NISSAN dealer to
adjust the wheel alignment to the
recommended setting for high perfor-

in this section for 48 hours after tires
are installed on the wheels. The tire
may slip on the wheel if the vehicle is
driven in these conditions before 48
hours have passed. If the tire slips on
the wheel, the wheel/tire assembly
will be out of balance and will require
rebalancing.
BrakesThe information and specifications in
this section apply only when engaging
in performance driving.
.Check for the heat deterioration of the
brakes and parts around the brakes.
. It is recommended that you remove
air from the brake system after any of
the following:
— When engaging in high perfor-
mance driving for the first time
after purchasing a new vehicle.
— After replacing the brake fluid.
— When engaging in high perfor- mance driving for a sustained per-
iod of time. It is recommended that
bleeding the brake be performed
when the brake calipers are hot
(about 212°F (100°C)). Brake pad break-in procedure:
NISSAN recommends that a special brake
pad break-in procedure be performed
before engaging in performance driving.
It is recommended you contact a GT-R
certified NISSAN dealer for details.
INSPECTION AND ADJUSTMENTS
AFTER DRIVINGThe information and specifications in
this section apply only when engaging
in performance driving.
NOTICE
At the completion of performance
driving, all fluid and other adjust-
ments should be returned to the
normal fluid specifications as shown
in the “8. Do-it-yourself” section of
this manual.FluidsThe information and specifications in
this section apply only when engaging
in performance driving.
.
Check the engine, transmission, differ-
ential and under the vehicle for oil and
coolant leaks. .
Check the fluid levels and adjust as
necessary using the specified fluid as
described under the conditions listed
in this section. (
“Recommended
fluids and maintenance interval” page
GTR-20) If you do not drive under the
conditions listed, refer to the “9. Main-
tenance and schedules” section of this
manual.
. When changing fluids, be sure to use
the specified fluids as described in this
Owner’s manual. (“Capacities and
recommended fluids/lubricants” page
10-2)
GT-R Overview
GTR-19

to
position before the vehicle stops, you may not be able
to shift gear or it may take longer to shift gear. Make sure to depress the brake pedal and check that the vehicle has
stopped before shifting.
Multiple-disc wet
clutch
.
When stopping the vehicle with the shift lever in the
orposition. Move the shift lever after turning off the system check
display. Also, it is normal to hear clicking noises during the transmission systems check.
Changing modes
.
The higher shift speeds in the
position may result in shift shock and jerkiness when starting or shifting.
.
The quickest shifting in the R mode with the transmission in the
position is available when the engine speed is high.
However, the transmission may shift more slowly when the engine speed is low.
Mechanical Limited Slip
Differential (LSD) If the vehicle accelerates from a stop with the steering wheel turned half a turn in cold temperatures, the inner wheel tire
may slip and some noise or vibration may be heard. This phenomenon occurs because the viscosity of the differential oil
becomes thicker and the Limited Slip Differential (LSD) operates with increasing load. When the steering wheel is returned
to the straight ahead position or the differential oil warms up, the noise and vibration decrease.

position. Operate the shift lever after
the system check indicator turns off.
. The shift lever cannot be moved if
the shift lever button is pushed
while the system check is being performed, even after the system
check is finished. Release the button
and push it again to operate the
shift lever.
. During winter or at other times when
the temperature is extremely low,
changes in the hydraulic response
characteristics may increase the
amount of time that is required for
the system check. During the system
check, a thudding operating noise
may occur or the engine speed may
decrease, however this does not
indicate that there is a malfunction.
Instruments and controls
2-15

to change the time. Push and
hold the switch to increase the number
every 1 hour. A maximum of 6 hours can
be set.
NOTE:
The default setting is OFF.
Low outside temperature warning:
This alert informs the driver when the
outside air temperature is lower than 37°F
(3°C).
On the ICY screen, push the NEXT switch
to turn this warning ON/OFF.
NOTE:
The default setting is ON.
MaintenanceThis function can be used to set the
various maintenance intervals and to
check the engine oil level. The reminders
shown below are used to notify the driver
of the maintenance intervals.
NOTE:
Because these are displayed based on
the mileage driven, they do not indicate
the actual conditions of the vehicle. Use
these functions only as a reference.
Input the maintenance distance using the
following items:
. On each setting screen, push the
Instruments and controls
2-21
