NOTE:
Do not keep the starter motor en-
gaged for more than 10 seconds. If
the engine does not start right away,
push the ignition switch to the OFF
position and wait 10 seconds before
trying again.
7. After starting your engine, carefully disconnect the negative cable and
then the positive cable (
?
?“Removing the cowl top cover”
page 8-5) Do not attempt to start the engine by
pushing.
NOTICE
Your NISSAN cannot be push-started
or tow-started. Attempting to do so
may cause transmission damage.
WARNING
.
Do not continue to drive if your
vehicle overheats. Doing so could
cause engine damage or a vehicle
fire.
. To avoid the danger of being
scalded, never remove the radia-
tor filler cap and the coolant
reservoir cap while the engine is
still hot. When the cap is removed,
pressurized hot water will spurt
out, possibly causing serious in-
jury.
. Do not open the hood if steam is
coming out.
If your vehicle is overheating (indicated by
an extremely high temperature gauge
reading), or if you feel a lack of engine
power, detect unusual noise, etc., take the
following steps:
1. Move the vehicle safely off the road, apply the parking brake and move the
shift lever to the
position.
Do not stop the engine.
2. Turn off the air conditioner. Open all the windows, move the temperature
control to maximum hot and fan
PUSH STARTING IF YOUR VEHICLE OVERHEATS

to
position before the vehicle stops, you may not be able
to shift gear or it may take longer to shift gear. Make sure to depress the brake pedal and check that the vehicle has
stopped before shifting.
Multiple-disc wet
clutch
.
When stopping the vehicle with the shift lever in the
orposition. Move the shift lever after turning off the system check
display. Also, it is normal to hear clicking noises during the transmission systems check.
Changing modes
.
The higher shift speeds in the
position may result in shift shock and jerkiness when starting or shifting.
.
The quickest shifting in the R mode with the transmission in the
position is available when the engine speed is high.
However, the transmission may shift more slowly when the engine speed is low.
Mechanical Limited Slip
Differential (LSD) If the vehicle accelerates from a stop with the steering wheel turned half a turn in cold temperatures, the inner wheel tire
may slip and some noise or vibration may be heard. This phenomenon occurs because the viscosity of the differential oil
becomes thicker and the Limited Slip Differential (LSD) operates with increasing load. When the steering wheel is returned
to the straight ahead position or the differential oil warms up, the noise and vibration decrease.

NOTICE
When the vehicle is stopped on a hill,
do not hold the vehicle in place by
depressing the accelerator pedal.
Doing so may cause the clutch to
overheat and result in transmission
damage. Use the brakes to prevent
the vehicle from moving.
The hill start assist system automatically
keeps the brakes applied to help prevent
the vehicle from rolling backwards in the
time it takes the driver to release the
brake pedal and apply the accelerator
when the vehicle is stopped on a hill.
Hill start assist will operate automatically
under the following conditions:
. The shift lever is moved to a forward
or reverse position.
. The vehicle is stopped completely on a
hill by applying the brake.
The maximum holding time is 2 seconds.
After 2 seconds the vehicle will begin to
roll back and hill start assist will stop operating completely.
Hill start assist will not operate when the
shift lever is moved to the
or
position
or on a flat and level road.
NOTE:
This system does not function when the
Vehicle Dynamic Control VDC) system
warning appears on the vehicle infor-
mation display located in the tach-
ometer. (
“Vehicle Dynamic Control
(VDC) system warning” page 2-40)Starting and driving
5-39
HILL START ASSIST SYSTEM

is started.
If any malfunction occurs in the AWD
system while the engine is running, the
warning light will come on.
The warning light may blink rapidly
(about twice per second) while trying to
free a stuck vehicle due to high AWD
clutch temperature. The driving mode
may change to two-wheel drive. If the
warning light blinks rapidly during opera-
tion, stop the vehicle with the engine
idling in a safe place immediately. Then if
the light goes off after a while, you can
continue driving.
A large difference between the diameters
of front and rear wheels will make the
warning light blink slowly (about once per
two seconds). Pull off the road in a safe
area, and idle the engine. Check that all
tire sizes are the same, tire pressure is
correct and tires are not worn and winter
tires are not installed on the front or rear
wheels only.
If the warning light is blinking after the
above operation, it is recommended you
have your vehicle checked by a GT-R
certified NISSAN dealer as soon as possi-
ble.
If non-genuine GT-R tires are used, the
warning light may illuminate. (

to
position before the vehicle stops, you may not be able
to shift gear or it may take longer to shift gear. Make sure to depress the brake pedal and check that the vehicle has
stopped before shifting.
Multiple-disc wet
clutch
.
When stopping the vehicle with the shift lever in the
orposition. Move the shift lever after turning off the system check
display. Also, it is normal to hear clicking noises during the transmission systems check.
Changing modes
.
The higher shift speeds in the
position may result in shift shock and jerkiness when starting or shifting.
.
The quickest shifting in the R mode with the transmission in the
position is available when the engine speed is high.
However, the transmission may shift more slowly when the engine speed is low.
Mechanical Limited Slip
Differential (LSD) If the vehicle accelerates from a stop with the steering wheel turned half a turn in cold temperatures, the inner wheel tire
may slip and some noise or vibration may be heard. This phenomenon occurs because the viscosity of the differential oil
becomes thicker and the Limited Slip Differential (LSD) operates with increasing load. When the steering wheel is returned
to the straight ahead position or the differential oil warms up, the noise and vibration decrease.

Intelligent Key warning light
After the ignition switch is pushed to the
ON position, this light comes on for about
2 seconds and then turns off.
This light warns of a malfunction with the
electrical steering lock system or the
Intelligent Key system.
If the light comes on while the engine is
stopped, it may be impossible to free the
steering lock or to start the engine. If the
light comes on while the engine is run-
ning, you can drive the vehicle. However
in these cases, it is recommended you
contact a GT-R certified NISSAN dealer for
repair as soon as possible.
“Tire
Pressure Monitoring System (TPMS)”
page 5-4) (
“Tire Pressure Monitor-
ing System (TPMS)” page 6-3)
Run-flat tire warning:
“Run-flat tires” page 8-36)
TPMS malfunction:
If the TPMS is not functioning properly,
the low tire pressure warning light will
flash for approximately 1 minute when the
ignition switch is pushed to the ON
position. The light will remain on after
the 1 minute. It is recommended you have
the system checked by a GT-R certified
NISSAN dealer. (
“Tire Pressure Mon-
itoring System (TPMS)” page 5-4)
(
“Tire pressure” page 8-30)

dually stop the vehicle.
6. Turn on the hazard warning flashers and contact a roadside emergency
service to change the tire.
DRINKING ALCOHOL/DRUGS AND
DRIVING
WARNING
Never drive under the influence of
alcohol or drugs. Alcohol in the
bloodstream reduces coordination,
delays reaction time and impairs
judgement. Driving after drinking
alcohol increases the likelihood of
being involved in an accident injuring
yourself and others. Additionally, if
you are injured in an accident, alco-
hol can increase the severity of the
injury.
NISSAN is committed to safe driving.
However, you must choose not to drive
under the influence of alcohol. Every year
thousands of people are injured or killed
in alcohol-related accidents. Although the
local laws vary on what is considered to
be legally intoxicated, the fact is that
alcohol affects all people differently and
most people underestimate the effects of alcohol.
Remember, drinking and driving don’t
mix! And that is true for drugs, too (over-
the-counter, prescription, and illegal
drugs). Don’t drive if your ability to oper-
ate your vehicle is impaired by alcohol,
drugs, or some other physical condition.
ALL-WHEEL DRIVE (AWD) DRIVING
SAFETY PRECAUTIONS
WARNING
.
Do not drive beyond the perfor-
mance capability of the tires,
even with AWD engaged. Acceler-
ating quickly, sharp steering
maneuvers or sudden braking
may cause loss of control.
. Always use the specified tires on
all four wheels. Install tire chains
on the rear wheels when driving
on slippery roads and drive care-
fully.
. This vehicle is not designed for
offroad (rough road) use. Do not
drive on sandy or muddy roads
that tires may get stuck in.
. Do not attempt to raise two
wheels off the ground and shift the transmission to any
position with the engine run-
ning. Doing so may result in
drivetrain damage or unexpected
vehicle movement which could
result in serious vehicle damage
or personal injury.
. Do not attempt to test an AWD
equipped vehicle on a 2-wheel
dynamometer, (such as the dy-
namometers used by some
states for emissions testing), or
similar equipment even if the
other two wheels are raised off
the ground. Make sure you inform
test facility personnel that your
vehicle is equipped with AWD
before it is placed on a dynam-
ometer. Using the wrong test
equipment may result in drive-
train damage or unexpected ve-
hicle movement which could
result in serious vehicle damage
or personal injury.
. When a wheel is off the ground
due to an unlevel surface, do not
spin the wheel excessively.
Starting and driving
5-9

position, and to
4,000 rpm when the engine oil or
coolant temperature is low or higher
than normal.
. If the ignition switch is pushed
before the shift lever is moved to
the
position, the ignition switch
will not change to the OFF position.
If this occurs, the SHIFT
warning
display appears on the vehicle in-
formation display. When stopping
the engine, be sure to move the shift
lever to the
position and then
push the ignition switch. Failure to
do so may result in discharge of the
battery. (“Shift “P” warning”
page 2-46)
. If the shift lever was in the
position when the engine was
stopped, then be sure to move the
shift lever to the
position before
starting the engine the next time. If the engine is started with the shift
lever in the
position, then it may
not be possible to drive the vehicle
even when the shift lever is moved
to the
position. If this
occurs, the SHIFTwarning appears
on the vehicle information display.
(
“Shift “P” warning” page 2-46)
CAUTION
If the engine was stopped soon
when the engine is hot, the cooling
fan may operate for approximately 2
minutes after the engine was
stopped to cool the components in
the engine compartment. When the
cooling fan is operating, be sure that
hands or other items do not get
caught in it.
DUAL CLUTCH TRANSMISSIONThe GT-R dual clutch transmission is a
newly-developed system that uses an
electronically controlled multiple-disc
wet clutch attached to the highly efficient
manual transmission. This transmission
has two driving modes.
.
position
and operate the paddle shifter to shift
down to 1st gear similar to a manual
transmission vehicle.
The GT-R dual clutch transmission was
developed specifically to maximize vehi-
cle performance and driving enjoyment.
The GT-R transmission components were
designed using different engineering
standards than typical passenger car
transmissions. Because of this, the GT-R
has different operating characteristics,
and various rattle noises may be heard
during some driving conditions because
Starting and driving
5-15
DRIVING THE VEHICLE

of the following items:
.Gear clearances
. Ultralight flywheel
. Dry sump lubrication
These noises do not indicate that there is
a malfunction.
or
position to the
or
or
position while the vehicle is mov-
ing forward and
or
toposition before the vehicle stops,
you may not be able to shift gear
or it may take longer to shift gear.
Make sure to depress the brake
pedal and check that the vehicle
has stopped before shifting.
CAUTION
. Because the vehicle includes a
dual clutch transmission that
automatically controls the clutch
and shifting operation of the
manual transmission, whenever
the shift lever is in a position
other than
or
, the vehicle will
begin to move slowly, in the same
way as when the clutch in a
manual transmission vehicle is
partially engaged. Keep the brake
pedal firmly depressed when the vehicle is stopped. In some cir-
cumstances the vehicle may not
start moving on its own, however
this does not indicate that there
is a malfunction.
NOTICE
.
To avoid possible damage to your
vehicle; when stopping the vehi-
cle on an uphill grade, do not hold
the vehicle in place by depressing
the accelerator pedal. Doing so
may cause the clutch to overheat
and result in transmission da-
mage. Use the brakes to prevent
the vehicle from moving.
. The GT-R dual clutch transmis-
sion is provided with a dry sump
lubrication system that improves
efficiency and ensures reliability
under high g-force conditions.
When oil viscosity is high at low
temperatures, it takes longer for
all components to be sufficiently
lubricated. Thus, when the trans-
mission temperature is low (ap-
proximately 104°F (40°C), do not
accelerate rapidly or run the en-
gine faster than 4,000 rpm.

position to the
,
,or
to any other
position.
The shift lever cannot be moved out of
the
position and into any other position
with the ignition switch other in the LOCK,
OFF or ACC position.
When accelerating from a stopKeep the foot brake pedal depressed and
push the shift lever button to shift into a
driving gear as following:
Starting and driving
5-21
