NISSAN LATIO 2007 Service Repair Manual

SERVICE DATA AND SPECIFICATIONS (SDS)
MT-49
D
E
F
G
H
I
J
K
L
MA
B
MT
Revision: June 20062007 Versa
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsUCS006KD
Engine typeMR18DE
Transaxle modelRS6F94R
Number of speeds6
Synchromesh typeWarner
Shift pattern
Gear ratio 1st3.727
2nd2.105
3rd1.452
4th1.171
5th0.971
6th0.811
Reverse 3.687
Final gear 3.933
Number of teeth Input gear 1st 11
2nd 19
3rd 31
4th 35
5th 35
6th 37
Reverse 11
Main gear 1st 41
2nd 40
3rd 45
4th 41
5th 34
6th 30
Reverse 42
Reverse idler gear Input/Output 28/29
Final gear Final gear/Pinion 59/15
Side gear/Pinion
mate gear21/18
Oil capacity
(US pt, Imp pt)Approx. 2.0 (4-1/4, 3-1/2)
Remarks Reverse synchronizer Installed
Triple-cone synchronizer 1st and 2nd
PCIB1769E

MT-50
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: June 20062007 Versa

MTC-1
MANUAL AIR CONDITIONER
J AIR CONDITIONER
CONTENTS
C
D
E
F
G
H
I
K
L
M
SECTION MTC
A
B
MTC
Revision: June 20062007 Versa PRECAUTIONS .......................................................... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 4
Precautions for Procedures without Cowl Top Cover ..... 4
Precautions for Working with HFC-134a (R-134a) ..... 4
General Refrigerant Precautions .............................. 5
Oil Precautions ......................................................... 5
Precautions for Refrigerant Connection ................... 5
FEATURES OF NEW TYPE REFRIGERANT
CONNECTION ...................................................... 5
O-RING AND REFRIGERANT CONNECTION ..... 6
Precautions for Servicing Compressor ..................... 8
Precautions for Service Equipment .......................... 9
RECOVERY/RECYCLING EQUIPMENT .............. 9
ELECTRONIC LEAK DETECTOR ........................ 9
VACUUM PUMP ................................................... 9
MANIFOLD GAUGE SET ...................................... 9
SERVICE HOSES ................................................. 9
SERVICE COUPLERS ........................................ 10
REFRIGERANT WEIGHT SCALE ...................... 10
CHARGING CYLINDER ...................................... 10
Precautions for Leak Detection Dye ....................... 10
IDENTIFICATION LABEL FOR VEHICLE ........... 10
PREPARATION ......................................................... 12
Special Service Tools ............................................. 12
HFC-134a (R-134a) Service Tools and Equipment ... 12
Commercial Service Tools ...................................... 15
REFRIGERATION SYSTEM ..................................... 16
Refrigerant Cycle ................................................... 16
REFRIGERANT FLOW ....................................... 16
FREEZE PROTECTION ..................................... 16
Refrigerant System Protection ............................... 16
REFRIGERANT PRESSURE SENSOR ............. 16
PRESSURE RELIEF VALVE ............................... 16
Component Layout ................................................. 17OIL ............................................................................. 18
Maintenance of Oil Quantity in Compressor ........... 18
OIL ....................................................................... 18
OIL RETURN OPERATION ................................. 18
OIL ADJUSTING PROCEDURE FOR COMPO-
NENTS REPLACEMENT EXCEPT COMPRES-
SOR ..................................................................... 19
OIL ADJUSTING PROCEDURE FOR COM-
PRESSOR REPLACEMENT ............................... 19
AIR CONDITIONER CONTROL ............................... 21
Control Operation ................................................... 21
BLOWER CONTROL DIAL ................................. 21
TEMPERATURE CONTROL DIAL ...................... 21
MODE DOOR CONTROL DIAL .......................... 21
INTAKE DOOR LEVER ....................................... 21
REAR WINDOW DEFOGGER SWITCH ............. 21
A/C SWITCH (IF EQUIPPED) ............................. 21
Discharge Air Flow ................................................. 22
System Description ................................................. 23
SWITCHES AND THEIR CONTROL FUNCTION ... 23
CAN Communication System Description .............. 23
TROUBLE DIAGNOSIS ............................................ 24
CONSULT-II Function (BCM) ................................. 24
CONSULT-II START PROCEDURE .................... 24
DATA MONITOR ................................................. 24
How to Perform Trouble Diagnosis for Quick and
Accurate Repair ...................................................... 24
WORK FLOW ...................................................... 24
SYMPTOM TABLE .............................................. 24
Component Parts and Harness Connector Location ... 25
ENGINE COMPARTMENT .................................. 25
PASSENGER COMPARTMENT ......................... 26
Schematic ............................................................... 27
Wiring Diagram — Heater — .................................. 28
WITHOUT A/C ..................................................... 28
Wiring Diagram — A/C,M — ................................... 29
Operational Check .................................................. 33
CHECKING BLOWER ......................................... 33
CHECKING DISCHARGE AIR ............................ 33
CHECKING RECIRCULATION ........................... 33

MTC-2Revision: June 20062007 Versa CHECKING TEMPERATURE DECREASE ......... 33
CHECKING TEMPERATURE INCREASE .......... 33
CHECKING A/C SWITCH (IF EQUIPPED) ......... 33
CHECKING DEFROST A/C SWITCH (IF
EQUIPPED) ......................................................... 33
Mode Door .............................................................. 34
INSPECTION FLOW ........................................... 34
Air Mix Door ............................................................ 35
INSPECTION FLOW ........................................... 35
Intake Door ............................................................. 36
INSPECTION FLOW ........................................... 36
Blower Motor Circuit ............................................... 37
INSPECTION FLOW ........................................... 37
DIAGNOSTIC PROCEDURE FOR BLOWER
MOTOR ............................................................... 38
Magnet Clutch Circuit (If Equipped) ........................ 41
INSPECTION FLOW ........................................... 41
SYSTEM DESCRIPTION .................................... 42
DIAGNOSTIC PROCEDURE FOR MAGNET
CLUTCH .............................................................. 42
Insufficient Cooling ................................................. 50
INSPECTION FLOW ........................................... 50
PERFORMANCE TEST DIAGNOSIS ................. 52
PERFORMANCE CHART ................................... 54
TROUBLE DIAGNOSIS FOR UNUSUAL PRES-
SURE ................................................................... 55
Insufficient Heating ................................................. 58
INSPECTION FLOW ........................................... 58
Noise ...................................................................... 60
INSPECTION FLOW ........................................... 60
CONTROLLER .......................................................... 61
Removal and Installation ........................................ 61
REMOVAL ........................................................... 61
INSTALLATION .................................................... 61
Disassembly and Assembly .................................... 62
THERMO CONTROL AMPLIFIER ............................ 63
Removal and Installation ........................................ 63
REMOVAL ........................................................... 63
INSTALLATION .................................................... 63
A/C UNIT ASSEMBLY .............................................. 64
Removal and Installation ........................................ 64
REMOVAL ........................................................... 64
INSTALLATION .................................................... 65
Disassembly and Assembly .................................... 66
BLOWER MOTOR .................................................... 68
Removal and Installation ........................................ 68
REMOVAL ........................................................... 68
INSTALLATION .................................................... 68
INTAKE DOOR .......................................................... 69
Intake Door Cable Adjustment ................................ 69
AIR MIX DOOR ......................................................... 70
Air Mix Door Cable Adjustment .............................. 70
MODE DOOR ............................................................ 71
Mode Door Cable Adjustment ................................ 71
BLOWER FAN RESISTOR ....................................... 72
Removal and Installation ........................................ 72
REMOVAL ........................................................... 72
INSTALLATION .................................................... 72HEATER CORE .........................................................73
Removal and Installation .........................................73
REMOVAL ............................................................73
INSTALLATION ....................................................73
AIR CONDITIONER FILTER .....................................74
Removal and Installation .........................................74
FUNCTION ..........................................................74
REPLACEMENT TIMING ....................................74
REPLACEMENT PROCEDURES ........................74
DUCTS AND GRILLES .............................................75
Removal and Installation .........................................75
CENTER VENTILATOR GRILLES .......................76
SIDE VENTILATOR GRILLES (LH/RH) ...............76
DEFROSTER NOZZLE AND SIDE
DEFROSTER DUCTS (LH/RH) ...........................77
SIDE VENTILATOR DUCTS ................................77
CENTER VENTILATOR DUCTS .........................78
SIDE FOOT DUCTS ............................................78
FLOOR DUCTS ...................................................78
REFRIGERANT LINES .............................................80
HFC-134a (R-134a) Service Procedure ..................80
SETTING OF SERVICE TOOLS AND EQUIP-
MENT ...................................................................80
Components ............................................................82
Removal and Installation of Compressor ................84
REMOVAL ............................................................84
INSPECTION FOR CLUTCH DISC TO PULLEY
CLEARANCE .......................................................85
INSTALLATION ....................................................85
Removal and Installation of Low-pressure Flexible
Hose ........................................................................85
REMOVAL ............................................................85
INSTALLATION ....................................................86
Removal and Installation of High-pressure Flexible
Hose ........................................................................86
REMOVAL ............................................................86
INSTALLATION ....................................................87
Removal and Installation of High-pressure Pipe .....87
REMOVAL ............................................................87
INSTALLATION ....................................................87
Removal and Installation of Refrigerant Pressure
Sensor .....................................................................88
REMOVAL ............................................................88
INSTALLATION ....................................................88
Removal and Installation of Condenser ..................88
REMOVAL ............................................................88
INSTALLATION ....................................................88
Removal and Installation of Liquid Tank .................89
REMOVAL ............................................................89
INSTALLATION ....................................................89
Removal and Installation of Evaporator ..................90
REMOVAL ............................................................90
INSTALLATION ....................................................90
Removal and Installation of Expansion Valve .........91
REMOVAL ............................................................91
INSTALLATION ....................................................91
Checking for Refrigerant Leaks ..............................92
Checking System for Leaks Using the Fluorescent
Leak Detector ..........................................................92

MTC-3
C
D
E
F
G
H
I
K
L
MA
B
MTC
Revision: June 20062007 Versa Dye Injection .......................................................... 92
Electronic Refrigerant Leak Detector ..................... 93
PRECAUTIONS FOR HANDLING LEAK
DETECTOR ........................................................ 93
CHECKING PROCEDURE ................................. 94
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 96Compressor ............................................................ 96
Oil ........................................................................... 96
Refrigerant .............................................................. 96
Engine Idling Speed ............................................... 96
Belt Tension ............................................................ 96

MTC-4
PRECAUTIONS
Revision: June 20062007 Versa
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EJS005HO
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WAR NIN G:

To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.

Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.

Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Procedures without Cowl Top CoverEJS0056V
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
Precautions for Working with HFC-134a (R-134a)EJS0056W
WAR NIN G:

CFC-12 (R-12) refrigerant and HFC-134a (R-134a) refrigerant are not compatible. These refrigerants
must never be mixed, even in the smallest amounts. If the refrigerants are mixed a compressor
malfunction is likely to occur.

Use only specified oil for the HFC-134a (R-134a) A/C system and HFC-134a (R-134a) components.
If oil other than that specified is used, compressor malfunction is likely to occur.

The specified HFC-134a (R-134a) oil rapidly absorbs moisture from the atmosphere. The following
handling precautions must be observed:
–When removing refrigerant components from a vehicle, immediately cap (seal) the component to
minimize the entry of moisture from the atmosphere.
–When installing refrigerant components to a vehicle, do not remove the caps (unseal) until just
before connecting the components. Connect all refrigerant loop components as quickly as possi-
ble to minimize the entry of moisture into system.
–Only use the specified oil from a sealed container. Immediately reseal containers of oil. Without
proper sealing, oil will become moisture saturated and should not be used.
–Avoid breathing A/C refrigerant and oil vapor or mist. Exposure may irritate eyes, nose and throat.
Use only approved recovery/recycling equipment to discharge HFC-134a (R-134a) refrigerant. If
accidental system discharge occurs, ventilate work area before resuming service. Additional
health and safety information may be obtained from refrigerant and oil manufacturers.
–Do not allow oil (NISSAN A/C System Oil) to come in contact with styrofoam parts. Damage may
result.
PIIB3706J

PRECAUTIONS
MTC-5
C
D
E
F
G
H
I
K
L
MA
B
MTC
Revision: June 20062007 Versa
General Refrigerant PrecautionsEJS0056X
WA RN ING:

Avoid breathing A/C refrigerant and oil vapor or mist. Exposure may irritate eyes, nose and throat.
Use only approved recovery/recycling equipment to discharge HFC-134a (R-134a) refrigerant. If
accidental system discharge occurs, ventilate work area before resuming service. Additional
health and safety information may be obtained from refrigerant and oil manufacturers.

Do not release refrigerant into the air. Use approved recovery/recycling equipment to capture the
refrigerant every time an air conditioning system is discharged.

Always wear eye and hand protection (goggles and gloves) when working with any refrigerant or
air conditioning system.

Do not store or heat refrigerant containers above 52°C (126° F).

Do not heat a refrigerant container with an open flame; if container warming is required, place the
bottom of the container in a warm pail of water.

Do not intentionally drop, puncture, or incinerate refrigerant containers.

Keep refrigerant away from open flames: poisonous gas will be produced if refrigerant burns.

Refrigerant will displace oxygen, therefore be certain to work in well ventilated areas to prevent
suffocation.

Do not pressure test or leak test HFC-134a (R-134a) service equipment and/or vehicle air condi-
tioning systems with compressed air during repair. Some mixtures of air and HFC-134a (R-134a)
have been shown to be combustible at elevated pressures. These mixtures, if ignited, may cause
injury or property damage. Additional health and safety information may be obtained from refriger-
ant manufacturers.
Oil PrecautionsEJS0056Y

Use only specified oil for the HFC-134a (R-134a) A/C system and HFC-134a (R-134a) components. If oil
other than that specified is used, compressor malfunction is likely to occur.

The specified HFC-134a (R-134a) oil rapidly absorbs moisture from the atmosphere. The following han-
dling precautions must be observed:
–When removing refrigerant components from a vehicle, immediately cap (seal) the component to minimize
the entry of moisture from the atmosphere.
–When installing refrigerant components to a vehicle, do not remove the caps (unseal) until just before con-
necting the components. Connect all refrigerant loop components as quickly as possible to minimize the
entry of moisture into system.
–Only use the specified oil from a sealed container. Immediately reseal containers of oil. Without proper
sealing, oil will become moisture saturated and should not be used.

Avoid breathing A/C refrigerant and oil vapor or mist. Exposure may irritate eyes, nose and throat.
Use only approved recovery/recycling equipment to discharge HFC-134a (R-134a) refrigerant. If acciden-
tal system discharge occurs, ventilate work area before resuming service. Additional health and safety
information may be obtained from refrigerant and oil manufacturers.

Do not allow oil (NISSAN A/C System Oil) to come in contact with styrofoam parts. Damage may result.
Precautions for Refrigerant ConnectionEJS0056Z
A new type refrigerant connection has been introduced to all refrigerant lines except the following location.

Expansion valve to evaporator

Refrigerant pressure sensor to condenser
FEATURES OF NEW TYPE REFRIGERANT CONNECTION

The O-ring has been relocated. It has also been provided with a groove for proper installation. This elimi-
nates the chance of the O-ring being caught in, or damaged by, the mating part. The sealing direction of
the O-ring is now set vertically in relation to the contacting surface of the mating part to improve sealing
characteristics.

MTC-6
PRECAUTIONS
Revision: June 20062007 Versa

The reaction force of the O-ring will not occur in the direction that causes the joint to pull out, thereby facil-
itating piping connections.
O-RING AND REFRIGERANT CONNECTION
Ty p e 1
SHA8 15 E
SJIA0697E

PRECAUTIONS
MTC-7
C
D
E
F
G
H
I
K
L
MA
B
MTC
Revision: June 20062007 Versa
Ty p e 2
CAUTION:
The new and former refrigerant connections use different O-ring configurations. Do not confuse O-
rings since they are not interchangeable. If a wrong O-ring is installed, refrigerant will leak at, or
around, the connection.
O-Ring Part Numbers and Specifications
WA RN ING:
Make sure all refrigerant is discharged into the recycling equipment and the pressure in the system is
less than atmospheric pressure. Then gradually loosen the discharge side hose fitting and remove it.
CAUTION:
When replacing or cleaning refrigerant cycle components, observe the following.

When the compressor is removed, store it in the same position as it is when mounted on the vehi-
cle. Doing so will cause oil to enter the low-pressure chamber.

When connecting tubes, always use a torque wrench and a back-up wrench.
SJIA1327E
Connection type Piping connection point Part number QTY O-ring size
NewCondenser to high-pressure flexible hose 92472 N8210 1 12
Condenser to high-pressure pipe 92471 N8210 1 8
Low-pressure flexible hose to expansion valve 92473 N8210 1 16
High-pressure pipe to expansion valve 92471 N8210 1 8
Compressor to low-pressure flexible hose 92474 N8210 1 19
Compressor to high-pressure flexible hose 92472 N8210 1 12
Liquid tank to condenser pipeInlet
92471 N82101
8
Outlet 1
FormerRefrigerant pressure sensor to condenser J2476 89956 1 10
Expansion valve to evaporatorInlet 92471 N8200 2 12
Outlet 92473 N8200 2 16

MTC-8
PRECAUTIONS
Revision: June 20062007 Versa

After disconnecting tubes, immediately plug all openings to prevent entry of dirt and moisture.

When installing an air conditioner in the vehicle, connect the pipes as the final stage of the opera-
tion. Do not remove the seal caps of pipes and other components until just before required for
connection.

Allow components stored in cool areas to warm to working area temperature before removing seal
caps. This prevents condensation from forming inside A/C components.

Thoroughly remove moisture from the refrigeration system before charging the refrigerant.

Always replace used O-rings.

When connecting tube, apply oil to circle of the O-rings as shown. Be careful not to apply oil to
threaded portion.

O-ring must be closely attached to dented portion of tube.

When replacing the O-ring, be careful not to damage O-ring and tube.

Connect tube until you hear it click, then tighten the nut or bolt by hand until snug. Make sure that
the O-ring is installed to tube correctly.

After connecting line, perform leak test and make sure that there is no leakage from connections.
When the refrigerant leaking point is found, disconnect that line and replace the O-ring. Then
tighten connections of seal seat to the specified torque.
Precautions for Servicing CompressorEJS00570

Plug all openings to prevent moisture and foreign matter from entering.

When the compressor is removed, store it in the same position as it is when mounted on the car.

When replacing or repairing compressor, follow “Maintenance of Oil Quantity in Compressor”
exactly. Refer to MTC-18, "
Maintenance of Oil Quantity in Compressor" .

Keep friction surfaces between clutch and pulley clean. If the surface is contaminated, with oil,
wipe it off by using a clean waste cloth moistened with thinner.

After compressor service operation, turn the compressor shaft by hand more than five turns in
both directions. This will equally distribute oil inside the compressor. After the compressor is
installed, let the engine idle and operate the compressor for one hour.

After replacing the compressor magnet clutch, apply voltage to the new one and check for usual
operation.TYPE 1 Compressor (CR-10) : NISSAN A/C System Oil Type R
TYPE 2 Compressor (CSV511) : NISSAN A/C System Oil Type S
RHA861F
