NISSAN LATIO 2007 Service Repair Manual

TROUBLE DIAGNOSIS
STC-15
[EPS]
C
D
E
F
H
I
J
K
L
MA
B
STC
Revision: June 20062007 Versa
Symptom ChartUGS0008I
If EPS warning lamp turns ON, perform self-diagnosis. Refer to STC-13, "SELF-DIAG RESULTS MODE" .
Symptom Condition Check item Reference page
EPS warning lamp does not turn ON when
ignition switch to “ON”.
(EPS warning lamp check)Ignition switch: ONCAN communication line
STC-26
Combination meter
EPS warning lamp does not turn OFF for
several seconds after starting the engineEngine runningCAN communication line
STC-27
Power supply and ground for
EPS control unit
Torque sensor
EPS motor
Vehicle speed signal
Engine status signal
Combination meter
Steering wheel turning force is heavy or light,
while driving

While driving

Steering wheel turningCAN communication line
STC-29
Vehicle speed signal
Engine status signal
EPS motor
Steering wheel turning force
(Mechanical malfunction)
Unbalance steering wheel turning force and
return between right and left, while driving

While driving

Steering wheel turningWheel alignment
STC-31Steering wheel turning force
(Mechanical malfunction)
Unbalance steering wheel turning force,
while driving (Torque variation)

While driving

Steering wheel turningSteering column intermediate
shaft installation condition
STC-32Steering wheel turning force
(Mechanical malfunction)

STC-16
[EPS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: June 20062007 Versa
TROUBLE DIAGNOSIS FOR SYSTEMPFP:00000
DTC C1601 BATTERY VOLTUGS0008J
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
EPS CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.Monitor item (Unit) Content Condition Display value
MOTOR VOL (V) Power supply voltage for EPS control unit Ignition switch: ON Battery voltage
Terminal Wire color Item Condition Data (Approx.)
10 O Power supplyIgnition switch: ON Battery voltage
Ignition switch: OFF 0 V
17 R Power supply (Memory back-up)Ignition switch: ON Battery voltage
Ignition switch: OFF Battery voltage
18 B Ground Always 0 V

TROUBLE DIAGNOSIS FOR SYSTEM
STC-17
[EPS]
C
D
E
F
H
I
J
K
L
MA
B
STC
Revision: June 20062007 Versa
DIAGNOSTIC PROCEDURE
1. CHECK EPS CONTROL UNIT POWER SUPPLY CIRCUIT
1. Turn ignition switch “OFF”.
2. Disconnect EPS control unit harness connector.
3. Turn ignition switch “ON”. (Do not start engine.)
4. Check voltage between EPS control unit harness connector (A)
terminals and ground.
5. Turn ignition switch “OFF”.
6. Check voltage between EPS control unit harness connector (A)
terminals and ground.
7. Connect EPS control unit harness connector.
OK or NG
OK >> GO TO 2.
NG >> Check the following. If any items are damaged, repair or
replace damaged parts.

60 A fusible link (No. m , located in the fuse and fusible link block). Refer to PG-4, "POWER
SUPPLY ROUTING CIRCUIT" .

10 A fuses (No. 2, located in the fuse block). Refer to PG-4, "POWER SUPPLY ROUTING CIR-
CUIT" .

Harness for short or open between battery and EPS control unit harness connector M54 termi-
nal 17.

Harness for short or open between ignition switch and EPS control unit harness connector M53
terminal 10.
2. CHECK EPS CONTROL UNIT GROUND CIRCUIT
1. Turn ignition switch “OFF”.
2. Disconnect EPS control unit harness connector.
3. Check continuity between EPS control unit harness connector
(A) terminal and ground.
Also check harness for short to power.
4. Connect EPS control unit harness connector.
OK or NG
OK >> GO TO 3.
NG >> Repair open circuit or short to ground or short to power
in harness or connectors.
Connector Terminal Voltage
M53 10 – Ground Battery voltage
M54 17 – Ground Battery voltage
SGIA1626E
Connector Terminal Voltage
M53 10 – Ground Approx. 0 V
M54 17 – Ground Battery voltage
SGIA1627E
Connector Terminal Continuity
M54 18 Yes
SGIA1628E

STC-18
[EPS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: June 20062007 Versa
3. CHECK DTC
Start engine.
Does EPS warning lamp turn OFF?
YES >>INSPECTION END
NO >> Perform self-diagnosis, repair or replace damaged parts. Refer to STC-13, "
SELF-DIAG
RESULTS MODE" .

TROUBLE DIAGNOSIS FOR SYSTEM
STC-19
[EPS]
C
D
E
F
H
I
J
K
L
MA
B
STC
Revision: June 20062007 Versa
DTC C1604 TORQUE SENSORUGS0008K
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
*: In the front of the value, “L” is displayed at steering left and “R” is displayed at steering right.
EPS CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.
DIAGNOSTIC PROCEDURE
1. CHECK TORQUE SENSOR SIGNAL
With CONSULT-II
1. Start engine.
2. Select “DATA MONITOR” mode for “EPS” with CONSULT-II.
3. Check the value of “TORQUE SENSOR”. Refer to STC-11, "
SPECIFICATIONS WITH CONSULT-II" .
Without CONSULT-II
1. Start engine.
2. Check voltage between EPS control unit harness connector M53 terminals 4, 5, 6, 7 and ground. Refer to
STC-12, "
SPECIFICATIONS BETWEEN EPS CONTROL UNIT TERMINALS" .
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
Monitor item (Unit) Content Condition Display value
TORQUE SENSOR (Nm) Steering wheel turning force Engine runningSteering wheel: Not steering
(There is no steering force)0.00 Nm
Steering wheel: Steering0 – 8.19 Nm*
(The value is changed
according to steering
left or right)
TerminalWire
color Item Condition Data (Approx.)
4 V Torque sensor sub Engine runningSteering wheel: Not steering
(There is no steering force)2.5 V
Steering wheel: Steering1.7 V – 3.3 V
(The value is
changed accord-
ing to steering
left or right)
5 BR Torque sensor power supplyIgnition switch: ON 8 V
Ignition switch: OFF 0 V
6 G Torque sensor main Engine runningSteering wheel: Not steering
(There is no steering force)2.5 V
Steering wheel: Steering1.7 V – 3.3 V
(The value is
changed accord-
ing to steering
left or right)
7 R Torque sensor ground Always 0 V

STC-20
[EPS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: June 20062007 Versa
2. CHECK HARNESS AND CONNECTOR
1. Turn ignition switch “OFF”.
2. Disconnect EPS control unit harness connector and torque sensor harness connector.
3. Check continuity between EPS control unit harness connector
(A) M53 terminals 4, 5, 6, 7 and torque sensor harness connec-
tor (B) M63 terminals 1, 2, 3, 4.
Also check harness for short to ground and short to power.
4. Connect EPS control unit harness connector and torque sensor harness connector.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace damaged parts.
3. CHECK EPS CONTROL UNIT
Check EPS control unit input/output signal. Refer to STC-11, "
EPS Control Unit Input/Output Signal Reference
Values" .
OK or NG
OK >> GO TO 4.
NG >> Check EPS control unit pin terminals for damage or loose connection with harness connector. If
any items are damaged, repair or replace damaged parts.
4. CHECK DTC
Perform the self-diagnosis, after driving the vehicle for a while.
OK or NG
OK >>INSPECTION END
NG >> Torque sensor is malfunctioning. Replace steering column assembly. Refer to PS-9, "
Removal
and Installation" .
Terminal Continuity
4 – 3
Ye s 5 – 2
6 – 1
7 – 4
SGIA1629E

TROUBLE DIAGNOSIS FOR SYSTEM
STC-21
[EPS]
C
D
E
F
H
I
J
K
L
MA
B
STC
Revision: June 20062007 Versa
DTC C1606 EPS MOTORUGS0008L
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
* : Almost in accordance with the value of “MOTOR SIG”. It is not a malfunction though these values are not accorded when steering
quickly.
EPS CONTROL UNIT TERMINALS AND REFERENCE VALUE
Data are reference value and are measured between each terminal and ground.
CAUTION:
When using a circuit tester to measure voltage for inspection, be sure not to extend forcibly any connector terminals.
DIAGNOSTIC PROCEDURE
1. CHECK EPS MOTOR SIGNAL
With CONSULT-II
1. Start engine.
2. Select “DATA MONITOR” mode for “EPS” with CONSULT-II.
3. Check the values of “MOTOR SIG” and “MOTOR CURRENT”. Refer to STC-11, "
SPECIFICATIONS
WITH CONSULT-II" .
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2. CHECK EPS MOTOR
1. Turn ignition switch “OFF”.
2. Disconnect EPS control unit harness connector.
3. Check resistance between EPS control unit harness connector
(A) terminals.
4. Connect EPS control unit harness connector.
OK or NG
OK >> GO TO 3.
NG >> EPS motor is malfunctioning. Replace steering column
assembly. Refer to PS-9, "
Removal and Installation" .
Monitor item (Unit) Content Condition Display value
MOTOR SIG (A)Command current to
EPS motorEngine runningSteering wheel: Not steering
(There is no steering force)0.00 A
Steering wheel: Steering0 – 65.00 A
(The value is changed
according to steering left
or right)
MOTOR CURRENT (A)Consumption current of
EPS motorEngine runningSteering wheel: Not steering
(There is no steering force)0.00 A
Steering wheel: Steering0 – 65.00 A *
(The value is changed
according to steering left
or right)
Terminal Wire color Item Condition Data (Approx.)
19 — Motor (+) — —
20 — Motor (−)— —
Connector Terminal Resistance
M60 19 – 20 Approx. 0.1 Ω or less
SGIA1630E

STC-22
[EPS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: June 20062007 Versa
3. CHECK EPS CONTROL UNIT
Check EPS control unit input/output signal. Refer to STC-11, "
EPS Control Unit Input/Output Signal Reference
Values" .
OK or NG
OK >> GO TO 4.
NG >> Check EPS control unit pin terminals for damage or loose connection with harness connector. If
any items are damaged, repair or replace damaged parts.
4. CHECK DTC
Perform the self-diagnosis, after driving the vehicle for a while.
OK or NG
OK >>INSPECTION END
NG >> GO TO 3.
DTC C1607 EEPROMUGS0008M
DIAGNOSTIC PROCEDURE
1. PERFORM SELF-DIAGNOSIS
With CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “SELF-DIAG RESULTS” mode for “EPS” with CONSULT-II.
3. Touch “ERASE”.
4. Turn ignition switch “OFF”, and wait at least 10 seconds.
5. Start engine.
6. Perform the self-diagnosis again.
Is the
“EEPROM [C1607]” displayed?
YES >> Replace EPS control unit. Refer to PS-9, "Removal and Installation" .
NO >>INSPECTION END
DTC C1608 CONTROL UNITUGS0008N
DIAGNOSTIC PROCEDURE
1. PERFORM SELF-DIAGNOSIS
With CONSULT-II
1. Turn ignition switch “ON”. (Do not start engine.)
2. Select “SELF-DIAG RESULTS” mode for “EPS” with CONSULT-II.
3. Touch “ERASE”.
4. Turn ignition switch “OFF”, and wait at least 10 seconds.
5. Start engine.
6. Perform the self-diagnosis again.
Is the
“CONTROL UNIT [C1608]” displayed?
YES >> Replace EPS control unit. Refer to PS-9, "Removal and Installation" .
NO >>INSPECTION END

TROUBLE DIAGNOSIS FOR SYSTEM
STC-23
[EPS]
C
D
E
F
H
I
J
K
L
MA
B
STC
Revision: June 20062007 Versa
DTC C1609 CAN VHCL SPEEDUGS0008O
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
* : It is not a malfunction, though it might not be corresponding just after ignition switch is turned ON.
DIAGNOSTIC PROCEDURE
1. CHECK DTC WITH COMBINATION METER
Perform self-diagnosis with combination meter. Refer to DI-14, "
SELF-DIAGNOSTIC RESULTS" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system.
NO-1 >> With ABS: GO TO 2.
NO-2 >> Without ABS: GO TO 3.
2. CHECK DTC WITH ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
Perform self-diagnosis with ABS actuator and electric unit (control unit). Refer to BRC-20, "
SELF-DIAGNO-
SIS" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system.
NO >> GO TO 4.
3. CHECK DTC WITH TRANSMISSON CONTROL MODULE (TCM)
Perform self-diagnosis with TCM. Refer to AT-82, "
SELF-DIAGNOSTIC RESULT MODE" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system.
NO >> GO TO 4.
4. CHECK EPS CONTROL UNIT
Check EPS control unit input/output signal. Refer to STC-11, "
EPS Control Unit Input/Output Signal Reference
Va lu e s" .
OK or NG
OK >> GO TO 5.
NG >> Check EPS control unit pin terminals for damage or loose connection with harness connector. If
any items are damaged, repair or replace damaged parts.
5. CHECK DTC
Perform the self-diagnosis, after driving the vehicle for a while.
OK or NG
OK >>INSPECTION END
NG >> Perform self-diagnosis with ABS actuator and electric unit (control unit) and combination meter.
Refer to BRC-20, "
SELF-DIAGNOSIS" , DI-14, "SELF-DIAGNOSTIC RESULTS" .
Monitor item (Unit) Content Condition Display value
VEHICLE SPEED (km/h) or (mph) Vehicle speedVehicle stopped 0 km/h (0 mph)
While drivingApproximately equal to the indication on
speedometer (Inside of ±10%)

STC-24
[EPS]
TROUBLE DIAGNOSIS FOR SYSTEM
Revision: June 20062007 Versa
DTC C1610 CAN ENG RPMUGS0008P
CONSULT-II REFERENCE VALUE IN DATA MONITOR MODE
Data are reference value.
DIAGNOSTIC PROCEDURE
1. CHECK DTC WITH ECM
Perform self-diagnosis with ECM. Refer to EC-116, "
SELF-DIAG RESULTS MODE" .
Is any malfunction detected by self-diagnosis?
YES >> Check the malfunctioning system.
NO >> GO TO 2.
2. CHECK EPS CONTROL UNIT
Check EPS control unit input/output signal. Refer to STC-11, "
EPS Control Unit Input/Output Signal Reference
Values" .
OK or NG
OK >> GO TO 3.
NG >> Check EPS control unit pin terminals for damage or loose connection with harness connector. If
any items are damaged, repair or replace damaged parts.
3. CHECK DTC
Perform the self-diagnosis, after driving a vehicle for a while.
OK or NG
OK >>INSPECTION END
NG >> Perform self-diagnosis with ECM again. Refer EC-116, "
SELF-DIAG RESULTS MODE" .
DTC U1000 CAN COMM CIRCUITUGS0008Q
DIAGNOSTIC PROCEDURE
1. CHECK CAN COMMUNICATION CIRCUIT
With CONSULT-II
1. Turn ignition switch “ON” and start engine.
2. Select “SELF-DIAG RESULTS” mode for “EPS” with CONSULT-II.
3. Perform the self-diagnosis.
Is the
“CAN COMM CIRCUIT [U1000]” displayed?
YES >> Print out CONSULT-II screen and go to LAN-47, "CAN
System Specification Chart" .
NO >>INSPECTION END
Monitor item (Unit) Content Condition Display value
ENGINE STATUS (RUN/STOP) Engine statusEngine stopped (Engine speed: Less than 400 rpm) STOP
Engine running (Engine speed: 400 rpm or more) RUN
SDIA1850E
