NISSAN LEAF 2011 Owners Manual

When opening the charge port lid:
1. Pull the charge port lid opener handlelocated below the instrument panel. The
charge port lid will then spring up slightly.

.Pay particular attention when using
the normal charge port as the
charge port lid can be closed even
when the normal charge port cap is
open.
. Close the quick charge port cap
before closing the charging lid. The
quick charge port cap can be da-
maged if it is open when closing the
charge port lid.

Automatic anti-glare type
The inside mirror is designed so that it
automatically changes reflection based on the
intensity of the headlights of the vehicle behind.
The anti-glare system automatically turns on
when the power switch is moved to the ON
position.
When the system is turned on, the indicator light
*Awill illuminate and excessive glare from the
headlights of the vehicle behind you will be
reduced.
Type A: Push the

Passenger side power window
switch
The passenger’s side power window switch will
open or close only the corresponding window.
To open or close the window, push down or pull
up the switch and hold it.

If the windows do not close auto-
matically
If the power window automatic function (closing
only) does not operate properly, perform the
following procedure to initialize the power
window system.
1. Place the power switch in the ON position.
2. Close the door.
3. Open the window completely by operatingthe power window switch.
4. Pull the power window switch and hold it to close the window, and then hold the switch
more than 3 seconds after the window is
closed completely.
5. Release the power window switch. Operate the window by the automatic function to
confirm the initialization is complete.
If the power window automatic function does
not operate properly after performing the pro-
cedure above, have your vehicle checked by a
NISSAN certified LEAF dealer.

— remains on for about 15 seconds.
. doors are unlocked by pushing the UN-
LOCK
