NISSAN LEAF 2011 Owners Manual

.Do not hang items on the selector
lever. This may cause an accident
due to a sudden start.
. Do not shift to the ECO position
abruptly on slippery roads. This may
cause a loss of control.
NOTE:
If the accelerator pedal is depressed when
the vehicle is in the D (Drive) or ECO
position and the driver’s seat belt is
securely fastened, the parking brake will
be released automatically. See “Electric
parking brake” later in this section.

NOTE:
The vehicle automatically applies the P
(Park) position when the power switch is in
the OFF position.

NOTE:
.While the electric parking brake is
applied or released, an operating
sound is heard from the lower side of
the rear seat. However, this is not a
malfunction.
. When the electric parking brake is
frequently applied and released in a
short period of time, the electric park-
ing brake may not operate in order to
prevent the electric parking brake sys-
tem from overheating. If this occurs,
operate the electric parking brake
again after approximately 1 minute.
. The electric parking brake can be
released with the power switch in the
ON or READY to drive position.
. If the electric parking brake must be
applied while driving in an emergency,
pull up and hold the electric parking
brake switch. When you release the
parking brake switch, the parking
brake will be released.
. While pulling up on the electric parking
brake switch, the electric parking brake
is applied and a chime sounds. The
electric parking brake indicator light in
the meter and parking brake switch operation indicator illuminate. This
does not indicate a malfunction. The
electric parking brake indicator light
and parking switch operation indicator
turn off when the electric parking brake
switch is released.
. Pull up on the electric parking brake
switch twice so that the maximum
electric parking brake force can be
applied to the vehicle.
. When operating the electric parking
brake switch with the power switch in
the ON position, the electric parking
brake indicator light in the meter and
the electric parking brake switch op-
eration indicator turn on.
. Do not start driving while the parking
brake is applied. Doing so may cause
the parking brake to overheat or re-
duce its effectiveness, which could
result in an accident.
. When pulling the electric parking brake
switch with the power switch in the
OFF or ACC position, the electric park-
ing brake switch operation indicator
will continue to illuminate for a short
period of time.

.The original tires have built-in
tread wear indicators. When
wear indicators are visible, the
tire(s) should be replaced.
.Tires degrade with age and use.
Have tires, over 6 years old
checked by a qualified techni-
cian, because some tire damage
may not be obvious. Replace the
tires as necessary to prevent tire
failure and possible personal
injury.
.For additional information re-
garding tires, refer to “Important
Tire Safety Information” (US) or
“Tire Safety Information” (Cana-
da) in the Warranty Information
Booklet.
Replacing wheels and tires
When replacing a tire, use the same size, tread
design, speed rating and load carrying capacity
as originally equipped. See “Specifications” in
the “9. Technical and consumer information”
section for recommended types and sizes of
tires and wheels.

9 Technical and consumer information
Capacities and recommended lubricants .......................... 9-2Air conditioning system refrigerant and
lubricant recommendations .............................................. 9-3
Specifications ............................................................................ 9-4 Charging system ................................................................ 9-4
Motor ..................................................................................... 9-5
Wheels and tires ................................................................ 9-5
Dimensions and weights .................................................. 9-5
When traveling or registering your vehicle in
another country ......................................................................... 9-6
Vehicle identification ................................................................ 9-6 Vehicle Identification Number (VIN) plate .................... 9-6
Vehicle identification number (chassis number) ........ 9-6
Traction motor serial number .......................................... 9-7
F.M.V.S.S./C.M.V.S.S certification label ....................... 9-7
Emission control information label ................................. 9-7
Tire and Loading Information label ................................ 9-8
Air conditioner specification label .................................. 9-8 Installing front license plate .................................................. 9-9
Vehicle loading information ................................................ 9-10 Terms ................................................................................ 9-10
Vehicle load capacity ................................................... 9-11
Securing the load ......................................................... 9-12
Loading tips .................................................................... 9-13
Measurement of weights ............................................. 9-13
Towing a trailer ...................................................................... 9-13
Flat towing .............................................................................. 9-14
Uniform tire quality grading ................................................ 9-14
Treadwear ....................................................................... 9-14
Traction AA, A, B and C ............................................. 9-14
Temperature A, B and C ............................................. 9-14
Reporting safety defects .................................................... 9-15
Telematics overview ............................................................. 9-16
Event Data Recorder (EDR) .............................................. 9-18
Owner’s Manual/Service Manual order information .... 9-19
