Driving range button
— Audio control
— Bluetooth
®Hands-Free Phone System control
6. Steering wheel
— Electric power steering system (P.5-21) — Horn (P.2-46)
— Driver’s supplemental air bag (P.1-36)
7. Wiper and washer switch (P.2-38)
8. Steering-wheel-mounted controls (right side)
— Cruise control switches (P.5-17)
9. Fuse box cover (P.8-16)
10. Vehicle Dynamic Control (VDC) OFF switch (P.2-48)
11. Headlight aiming control (P.2-44)
12. Approaching Vehicle Sound for Pedestrians (VSP) OFF switch (P.EV-27)
13. Immediate charge switch (P.CH-24)
14. Heated steering wheel switch* (P.2-45)
15. Tilting steering wheel lever (P.3-19)
16. Heated seat switch* (P.2-47)
17. Selector lever (P.5-12)
18. Electric parking brake (P.5-15)
*: if so equipped
COCKPIT
EMERGENCY SHUT-OFF SYSTEM
The emergency shut-off system is activated and
the high-voltage system automatically turns off in
the following conditions:
- Front and side collisions in which the air bags
are deployed.
- Certain rear collisions.
- Certain EV (Electric Vehicle) system malfunc-
tions
For the above collisions and certain other EV
(Electric Vehicle) system malfunctions, the
READY to drive indicator light will turn off. See
“Warning/indicator lights and audible remin-
ders” in the “2. Instruments and controls”
section.
The emergency shut-off activates for the above
collisions to minimize risk of an event that could
cause injury or an accident. If the emergency
shut-off system activates, the EV system may
not be switched to READY to drive position,
contact a NISSAN certified LEAF dealer. Even if
the power switch is switched to READY to drive
position, the system may shut-off suddenly.
Therefore, drive cautiously to the nearest
NISSAN certified LEAF dealer or contact a
NISSAN certified LEAF dealer as soon as
possible.WARNING
.Pay special attention to pedes-
trians. Because there is no engine
noise, pedestrians may not know
the vehicle is approaching, moving
or about to move, and may step into
the path of vehicle travel.
. When leaving the vehicle, be sure to
turn off the EV (Electric Vehicle)
system.
. Be sure to push the P (Park) posi-
tion switch on the selector lever and
apply the parking brake when park-
ing because the vehicle can move
when the READY to drive indicator
light is ON. When the READY to
drive indicator light is ON, do not
leave your vehicle in a shift position
other than the P (Park) position.
. Keep the brake pedal depressed
until you are ready to drive. When
the vehicle is in the D (drive) posi-
tion or ECO or R (reverse) position,
if you release the brake pedal and
do not depress accelerator, the
vehicle will creep and may start
abruptly. This may cause serious injury or death.
NOTE:
. The vehicle cannot run with a dis-
charged Li-ion battery. Repeated accel-
eration consumes more power from the
Li-ion battery than driving at a steady
speed.
. This vehicle is equipped with a regen-
erative brake system. The primary pur-
pose of regenerative brake system is to
provide some power to recharge the Li-
ion battery and extend driving range. A
secondary benefit is “engine braking”
that operates based on Li-ion battery
conditions.
. In the D (Drive) position, when the
accelerator pedal is released, the re-
generative brake system provides
some deceleration.
. When you put the shift selector in the
ECO position and take your foot off the
accelerator pedal, more regenerative
brake is applied than in the D (Drive)
position.
. Less deceleration is provided by the
regenerative brake system when the Li-
EV OverviewEV-9
EV (Electric Vehicle)
CHARACTERISTICS
ion battery is fully charged. Regenera-
tive brake is automatically reduced
when the Li-ion battery is fully charged
to prevent the Li-ion battery from
becoming overcharged. Regenerating
brake is also automatically reduced
when the battery temperature is high/
low (indicated by the red/blue zones
on the Li-ion battery temperature
gauge) to prevent Li-ion battery da-
mage.
. The brake pedal should be used to
slow or stop the vehicle depending on
traffic or road conditions. The vehicle
brakes are not affected by regenerative
brake system operation.
NOISE AND VIBRATION
You might experience the following noise or
vibration as a normal characteristic of this
vehicle.
.Traction motor noise from motor compart-
ment.
. Noise and vibration when releasing and
applying the electric parking brake.
. Water pump and radiator fan noise while
charging. .
Compressor and radiator fan noise when the
A/C-Heater Timer (Climate Ctrl. Timer) or
remote climate control is used.
. Relay operation noise and vibration at start-
up and shut-down of the EV (Electric
Vehicle) system (power switch placed in
the ON and OFF position) .
. Approaching Vehicle Sound for Pedestrians
(VSP) .
WARNING
The EV (Electric Vehicle) system uses a
high voltage current. Failure to follow
the proper handling instructions may
cause serious injury or death. Be sure
to read the “CH. Charging” section and
follow the procedures and guidelines
described.
LIFE WITH AN EV (scene guide)
