Charging
Precautions on charging .................................................... CH-2
Types of charge and how to charge the
Li-ion battery ......................................................................... CH-5How to normal charge .................................................. CH-9
How to trickle charge ................................................ CH-11
How to quick charge (if so equipped) .................. CH-16
Charging methods ............................................................ CH-19 Charging timer ............................................................. CH-19 Charging related remote function ......................... CH-25
Charging related indicator lights .................................. CH-26 Charging status indicator lights ............................ CH-26
EVSE (Electric Vehicle Supply Equipment)
control box indicator light ....................................... CH-29
Charging troubleshooting guide ................................... CH-30
WARNING
.If you use any medical electric
devices, such as an implantable
cardiac pacemaker or an implanta-
ble cardiovascular defibrillator,
check with the electric medical de-
vice manufacturer concerning the
effects that charging may have on
implanted devices before starting
the charge operation. Charging
may affect the operation.
. If you have an implantable cardiac
pacemaker or an implantable cardi-
ovascular defibrillator, while the Li-
ion battery is charging:
— Do not stay inside the vehicle.
— Do not go inside the vehicle, for
example to remove or place an
item in the passenger compart-
ment.
— Do not open the rear hatch, for example to remove or place an
item in the cargo area.
Charging may affect the operation
of electric medical device and result
in serious personal injury or death. .
Make sure there is no water or
foreign materials in the charge port,
charge connector or electrical plug,
and that they are not damaged or
affected by rust or corrosion. If any
of these conditions are noticeable,
do not charge the Li-ion battery.
This may result in a short circuit or
electric shock and could cause a fire
which may result in serious perso-
nal injury or death.
. To avoid serious personal injury or
death when the Li-ion battery is
charging, be aware of the following
precautions.
— Do not touch the metal contacts
of the charge port, charge con-
nector or electrical plug.
— Do not touch the vehicle and charger when there is lightning.
A lightning strike may back feed
into the charger causing da-
mage and possible personal in-
jury or death.
. Make sure the charge connector is
removed from the charge port be-
fore starting your vehicle. If the
charge connector is only partially engaged and the connector latch is
unlocked, it is possible to place the
EV (Electric Vehicle) in the READY
to drive position.
. Do not plug in or unplug the plug
with wet hands and do not stand in
water, liquid or snow. This may
cause an electric shock which may
result in serious personal injury or
death.
. Do not disassemble or modify the
charge port or the EVSE (Electric
Vehicle Supply Equipment) . This
may cause a fire.
. If you notice an unusual odor or
smoke coming from the vehicle,
stop charging immediately.
. Be careful not to allow your hands,
hair, jewelry or clothing to come into
contact with, or get caught in, the
traction motor cooling fan. The cool-
ing fan can start at any time during
charging.
PRECAUTIONS ON CHARGING
