NISSAN LEAF 2012 Owners Manual

1 Safety—Seats, seat belts and supple-mental restraint system
Seats ........................................................................................... 1-2
Front seats ........................................................................... 1-3
Rear seats ........................................................................... 1-4
Head restraints ................................................................... 1-4
Adjustable headrests ......................................................... 1-7
Seat belts ................................................................................ 1-10
Precautions on seat belt usage ................................... 1-10
Pregnant women ............................................................. 1-12
Injured persons ................................................................ 1-12
Three-point type seat belt with retractor .................. 1-12
Seat belt extenders ......................................................... 1-16
Seat belt maintenance ................................................... 1-16
Child safety ............................................................................. 1-17
Infants ................................................................................. 1-17
Small children ................................................................... 1-18
Larger children ................................................................. 1-18
Child restraints ....................................................................... 1-19 Precautions on child restraints .................................... 1-19
Lower Anchors and Tethers for CHildren System
(LATCH) ........................................................................... 1-20
Rear-facing child restraint installation using latch ... 1-23 Rear-facing child restraint installation using the
seat belts ......................................................................... 1-25
Forward-facing child restraint installation
using latch ...................................................................... 1-27
Forward-facing child restraint installation using the
seat belts ......................................................................... 1-29
Installing top tether strap ............................................ 1-32
Booster seats ........................................................................ 1-33 Precautions on booster seats .................................... 1-33
Booster seat installation .............................................. 1-34
Supplemental restraint system .......................................... 1-36 Precautions on supplemental restraint system ...... 1-36
NISSAN Advanced Air Bag System
(front seats) .................................................................... 1-42
Front seat-mounted side-impact supplemental
air bag and roof-mounted curtain side-impact
supplemental air bag systems ................................... 1-47
Seat belts with pretensioners (front seats) ............ 1-49
Supplemental air bag warning labels ...................... 1-50
Supplemental air bag warning light ......................... 1-50
Repair and replacement procedure ......................... 1-51

REAR SEATS
Folding
Before folding the rear seats:
.Secure the seat belts on the seat belt hooks
located on the side wall. See “Seat belt
hooks ” later in this section.
To fold down the seatback, pull the release
knob.
To return the seatback to the seating position, lift
up each seatback and push it to the upright
position until it is latched.

has been removed. If the head restraint
was removed, reinstall and properly
adjust the head restraint before an
occupant uses the seating position.
Failure to follow these instructions
can reduce the effectiveness of the
head restraints. This may increase the
risk of serious injury or death in a
collision.

Removal
Use the following procedure to remove the
adjustable head restraints.
1. Pull the head restraint up to the highestposition.
2. Push and hold the lock knob.
3. Remove the head restraint from the seat.
4. Store the head restraint properly in a secure place so it is not loose in the vehicle.
5. Reinstall and properly adjust the head restraint before an occupant uses the
seating position.
