NISSAN MAXIMA 1996 A32 / 4.G User Guide

orwarning lightSeat belt warning lightEngine oil pressure warning light
Turn signal/hazard indicator lightLow washer fluid warning lightCRUISE indicator light
High beam indicator light (blue)orAnti-lock brake warning lightAir bag warning light
Charge warning lightOverdrive off indicator light
Door open warning lightMalfunction indicator light (MIL)
Checking bulbs
Apply the parking brake and turn the ignition
key to ªONº without starting the engine. The
following lights will come on:
,or,,
The following lights come on briefly and then
go off:
or,,
If any light fails to come on, it may indicate a
burned-out bulb or an open circuit in the elec-
trical system. Have the system repaired
promptly.
Engine oil pressure warning
light
This light warns of low engine oil pressure. If
the light flickers or comes on during normal
driving, pull off the road in a safe area, stop the
engineimmediatelyand call a NISSAN dealer
or other authorized repair shop.Running the
engine with the oil pressure warning light
on could cause serious damage to the
engine.
The oil pressure warning light is not de-
signed to indicate a low oil level. Use the
dipstick to check the oil level.See ªEngine
oilº in the ªDo-it-yourself operationsº section.Running the engine with the oil pressure
warning light on could cause serious
damage to the engine.
Charge warning light
If the light comes on while the engine is
running, it may indicate that there is something
wrong with the charging system. Turn the
engine off and check the alternator belt. If the
belt is loose, broken, missing or if the light
remains on, see your NISSAN dealer immedi-
ately.
WARNING/INDICATOR LIGHT
AND BUZZER
1-6
Z01.2.1/A32-DX

Do not continue driving if the belt is
loose, broken or missing.
Door open warning light
This light comes on when any of the doors are
not closed securely while the ignition key is
ªONº.
Seat belt warning light and
buzzer
The light and buzzer remind you to fasten seat
belts. The light illuminates whenever the igni-
tion key is turned to ªONº, and will remain
illuminated until the driver's seat belt is fas-
tened. At the same time, the buzzer will sound
for about six seconds unless the driver's seat
belt is securely fastened.
Refer to ªSeat beltsº in the ªPre-driving checks
and adjustmentsº section for precautions on
seat belt usage.
Air bag warning light
When the ignition key is in the ªONº or
ªSTARTº position, the air bag light will illumi-
nate for about 7 seconds and then turn off.This means the system is operational.
If any of the following conditions occur, the air
bag needs servicing and your vehicle must be
taken to your nearest authorized NISSAN
dealer.
1. The air bag light does not come on for 7
seconds and then go off as described
above.
2. The air bag light flashes intermittently or
remains on.
3. The air bag light does not come on at all.
Unless checked and repaired, the Supplemen-
tal Restraint System may not function properly.
For additional details on the Air Bag System,
see Section 2.
Low washer fluid warning
light
This light comes on when the washer tank fluid
is at a low level. Add washer fluid as neces-
sary. See the ªDo-it-yourself operationsº sec-
tion.
orBrake warning light
This light functions for both the parking brake
and the foot brake systems.Parking brake indicator
The light comes on when the parking brake is
applied.
Low brake fluid warning
The light warns of a low brake fluid level. If the
light comes on while the engine is running with
the parking brake not applied, stop the vehicle
and perform the following:
1. Check the brake fluid level. Add brake fluid
as necessary. See ªBrake and clutch fluidº
in the ªDo-it-yourself operationsº section.
If the level is below the MINIMUM mark
on the brake fluid reservoir, do not drive
until the brake system has been
checked at a NISSAN dealer.
2. If the brake fluid level is correct:
Have the warning system checked by a
NISSAN dealer.
IEven if you judge it to be safe, have
your vehicle towed because driving it
1-7
Z01.2.1/A32-DX

could be dangerous.
IPressing the brake pedal with the
engine stopped could increase your
stopping distance and require greater
pedal effort as well as pedal travel.
orAnti-lock brake
warning light
If the light comes on while the engine is
running, it may indicate there is something
wrong with the anti-lock portion of the brake
system. Have the system checked by your
NISSAN dealer. However if the light illumi-
nates while starting the engine, it does not
indicate a system malfunction.
If an abnormality occurs in the system, the
anti-lock function will cease but the ordinary
brakes will continue to operate normally.
If the light comes on while you are driving,
contact your NISSAN dealer for repair.
Overdrive off indicator light
This light comes on when the overdrive switch
is pushed to the ªOFFº position.
However when the ignition key is in the ªONº or
ªSTARTº position and the overdrive switch is
not in the ªOFF
º position, the light willilluminate for about 2 seconds and then turn
off. This means the system is operational.
Turn signal/hazard indicator
lights
The light flashes when the turn signal switch
lever or hazard switch is turned on.
High beam indicator light
(Blue)
This light comes on when the headlight high
beam is on and goes out when the low beam is
selected.
Cruise indicator light
The light comes on while the vehicle speed is
controlled by the cruise control system. If the
light flickers while the engine is running, it may
indicate there is something wrong with the
cruise control system. Have the system
checked by your NISSAN dealer.
Key reminder buzzer
The buzzer will sound if the driver side door is
opened while the key is left in the ignition
switch (ignition switch is turned off). Remove
the key and take it with you when leaving the
vehicle.
Light reminder buzzer
A buzzer will sound when the driver side door
is opened if the light switch is turned on
(ignition switch is turned off).
Turn the light switch off when you leave the
vehicle.
Brake pad wear warning
The disc brake pads have audible wear warn-
ings. When a brake pad requires replacement,
it will make a high pitched scraping sound
when the vehicle is in motion whether or not
the brake pedal is depressed. Have the brakes
checked as soon as possible if the warning
sound is heard.
1-8
Z01.2.1/A32-DX

Malfunction indicator light
(MIL)
If the MIL comes on or blinks while the
engine is running, it may indicate a poten-
tial emission control problem.
IContinued operation without having
the emission control system checked
and repaired as necessary could lead
to poor driveability, reduced fuel
economy, and possible damage to
the emission control system which
may affect your warranty coverage.
IAlthough the vehicle is still driveable,
see your nearest NISSAN dealer as
soon as possible. To avoid system
damage, do not drive at speeds
above 45 MPH (72 km/h). If possible,
avoid hard acceleration or
deceleration.
If the fuel filler cap is not tightened prop-
erly, the MIL may come on. Check and
securely tighten the fuel filler cap, and have
your vehicle checked as noted above.
The theft warning system provides visual and
audio alarm signals if parts of the vehicle are
disturbed.
How to activate the theft warning
system
1. Remove the key from the ignition switch.
2. Close all windows. Close and lock all doors,
hood and trunk lid. The doors can be locked
either with or without the key.
The system can be activated even if the
windows are open.
IC0005
THEFT WARNING
1-9
Z01.2.1/A32-DX

3. Confirm that the indicator light comes on.
The light will glow for about 30 seconds and
then blink. The system is now activated. If,
during this 30 second time period, the door
is unlocked by the key or multi-remote
controller, or the ignition key is turned to
ªACCº, the system will not activate.
IIf the key is turned quickly when
locking the door, the system may not
activate. Furthermore, if the key is
turned excessively to the unlock po-
sition, the system may be deactivated
when the key is removed. If the indi-
cator light fails to glow for 30 sec-
onds, unlock the door once and lock
it again.
IEven when the driver and/or passen-
gers are in the vehicle, the systemwill activate with all doors, hood,
trunk lid and back door locked and
ignition key off. Turn the ignition key
to ªACCº to turn the system off.
Theft warning system operation
The warning system will give the following
alarm:
IThe headlights blink and the horn sounds
intermittently. In addition, the starter motor
will not operate.
IThe alarm automatically turns off after 2 to
3 minutes; however, the alarm will reacti-
vate if the vehicle is tampered with again.
The alarm can be shut off by unlocking a
door or trunk lid with the key.
The alarm is activated by:
IUnlocking the door or opening the trunk lid
without using the key or multi-remote con-
troller. (Even if the door is opened by re-
leasing the door inside lock knob or the
trunk lid is opened by operating the opener
lever/button, the alarm is activated.)
IOpening the hood.
IPushing in or pulling out of the key cylinder
on the door or trunk lid.
SIC0175
1-10
Z01.2.1/A32-DX

How to stop alarm
The alarm will stop only by unlocking a door or
trunk lid with the key or multi-remote controller.
The alarm will not stop if the ignition switch is
turned to ªACCº.
If the system does not operate as de-
scribed above, have it checked by your
NISSAN dealer.
The windshield wiper and washer operates
when the ignition key is in the ªACCº or ªONº
position.
Push the lever down to operate the wiper.
Intermittent operation can be adjusted from 3
to 21 seconds by turning the knob.
(Type B only)
Pull the lever toward you to operate the
washer. Then the wiper will also operate sev-
eral times.
IDo not operate the washer continu-
ously for more than 30 seconds.
IDo not operate the washer if the res-
ervoir tank is dry.
In freezing temperatures the washer so-
lution may freeze on the windshield and
obscure your vision. Warm windshield
SIC0176
WINDSHIELD WIPER AND
WASHER SWITCH
1-11
Z01.2.1/A32-DX

with the defroster before you wash the
windshield.
To defog the rear window glass and outside
mirrors, start the engine and push the switch
on. (The indicator light will come on.) Push the
switch again to turn the defogger off.
It will automatically turn off in approximately 15
minutes.
When cleaning the inner side of the
window, be careful not to scratch or
damage the electrical conductors.
SIC0177
REAR WINDOW AND OUTSIDE
MIRROR DEFOGGER SWITCH
1-12
Z01.2.1/A32-DX

Lighting
Turn the switch to the ªº position:
The front clearance, side marker, tail, license
plate and instrument lights will come on.Turn the switch to the ª
º position:
Headlights will come on and all the other lights
remain on.
To select the high beam, push the lever for-
ward. Pull it back to select the low beam.
Daytime light system
(For Canada)
Even if the headlight control switch is off, the
headlights' high beams will illuminate after
starting the engine. The headlights will be a
little dimmer than they are with the headlight
switch in the ª
º position.
If the parking brake is applied before the
engine is started, the daytime lights will not be
illuminated. The daytime lights will illuminate
once the parking brake is released. Thereafter,
the daytime lights will not turn off when using
the parking brake at stop signals, etc.
When the daytime light system is active,
tail lights on your vehicle will not be on.
It is necessary at dusk to turn on your
headlights. Failure to do so could cause
an accident injuring yourself and others.
Passing signal
Pulling the lever toward you will turn on the
headlight high beam.
SIC0188
HEADLIGHT AND TURN SIGNAL
SWITCH
1-13
Z01.2.1/A32-DX

Turn signal
Move the lever up or down to signal the turning
direction. When the turn is completed, the turn
signals cancel automatically.
Lane change signal
To indicate a lane change, move the lever up
or down to the point where lights begin flash-
ing.
The cornering light provides additional illumi-
nation toward the turning direction. The light
will come on when the turn signal lever is
moved to the right or left with the headlights
on.The instrument brightness control operates
when the light switch is in the ª
ºor
ªº position.
Turn the control to adjust the brightness of
instrument panel lights (except clock) and
power window switch lights.
When the control is turned to the right until a
click sound is heard, the light intensity will be
at maximum. When the control is turned to the
left until a click sound is heard, the light will be
turned off.
IC1030IC1284MA
CORNERING LIGHT
INSTRUMENT BRIGHTNESS
CONTROL
1-14
Z01.2.1/A32-DX

To turn the fog lights on, turn the headlight
switch to the ªº position, then turn the
switch to the ªº position. To turn them off,
turn the switch to the ªOFFº position.
The headlights must be on for the fog lights to
operate.Push the switch on to warn other drivers when
you must stop or park under emergency con-
ditions. All turn signal lights will flash.
IWhen stalled or stopped on the road-
way under emergency conditions,
move the vehicle well off the road.
IDo not use the switch while moving
on the highway unless unusual cir-
cumstances force you to drive so
slowly that your vehicle might be-
come a hazard to other traffic.ISome state laws may prohibit the use
of the hazard warning flasher switch
while driving.
ITurn signals do not work when the
switch is operating.
The flasher can be actuated with the ignition
switch either off or on.
IC1292SIC0178
FRONT FOG LIGHT SWITCH
HAZARD WARNING FLASHER
SWITCH
1-15
Z01.2.1/A32-DX
