fuses NISSAN MAXIMA 1997 A32 / 4.G Owners Manual

7 Do-it-yourself operations
Maintenance precautions .......................................... 7-2
Engine cooling system .............................................. 7-5
Engine oil .................................................................. 7-7
Automatic transmission fluid ................................... 7-10
Power steering fluid ................................................ 7-11
Brake and clutch fluid ............................................. 7-12
Window washer fluid ............................................... 7-12
Battery ..................................................................... 7-13
Drive belts ............................................................... 7-15
Spark plug replacement .......................................... 7-15
Air cleaner filter ....................................................... 7-17
Wiper blades ........................................................... 7-18
Parking brake .......................................................... 7-19
Brake pedal ............................................................. 7-20
Brake booster .......................................................... 7-21
Clutch pedal ............................................................ 7-21
Fuses....................................................................... 7-21
Fusible links ............................................................ 7-23
Light bulbs ............................................................... 7-23
Wheels and tires ..................................................... 7-30
Z01.2.1/A32-DX

Check the brake booster function as follows:
1. With the engine off, press and release the
brake pedal several times. When brake
pedal movement (distance of travel) re-
mains the same from one pedal application
to the next, continue on to the next step.
2. While depressing the brake pedal, start the
engine. The pedal height should drop a
little.
3. With the brake pedal depressed, stop the
engine. Keeping the pedal depressed for
about 30 seconds, the pedal height should
not change.
4. Run the engine for one minute without
depressing the brake pedal, then turn it off.
Depress the brake pedal several times. The
pedal travel distance will decrease gradu-
ally with each depression as the vacuum is
released from the booster.
If the brakes do not operate properly, see your
NISSAN dealer.Press the pedal by hand and be sure the free
travel is within the limits shown above. If free
travel is too little or too much, see your NIS-
SAN dealer.
Engine compartment
Never use a fuse of higher amperage
rating than that specified on the fuse
box cover. This could damage the elec-
trical system or cause a fire.
If any electrical equipment does not operate,
check for an open fuse.
1. Be sure the ignition key and headlight
switch are ªOFFº.
DI1021MCSDI0126
BRAKE BOOSTER CLUTCH PEDAL FUSES
7-21
Z01.2.1/A32-DX

If any electrical equipment does not operate
and fuses are in good condition, check the
fusible links. If any of these fusible links are
melted, replace only with genuine NISSAN
parts.
HEADLIGHTS
The headlight is a semi-sealed beam type
which uses a replaceable headlight (halogen)
bulb. A bulb can be replaced from inside the
engine compartment without removing the
headlight assembly.
High pressure halogen gas is sealed
inside the halogen bulb. The bulb may
break if the glass envelope is scratched
or the bulb is dropped.
Hold the plastic base when handling the
bulb. Never touch the glass envelope.
Removing the headlight bulb
1. Disconnect the battery negative cable.
2. Disconnect the electrical connector from
the rear end of the bulb.
3. Turn the bulb retaining ring counterclock-
wise until it is free from the headlight reflec-
tor, then remove it.
4. Remove the headlight bulb. Do not shake
or rotate the bulb when removing it.
SDI0128
SDI0129
FUSIBLE LINKS LIGHT BULBS
7-23
Z01.2.1/A32-DX

Precautions when starting and driving ........ 4-2
E
Economy hints ................................................ 4-15
Emission control information label .................. 9-11
Emission control system warranty .................. 9-19
Engine ............................................................... 9-8
Before starting the engine ........................... 4-6
Changing engine coolant ............................ 7-6
Changing engine oil .................................... 7-8
Checking engine coolant level .................... 7-5
Checking engine oil level ............................ 7-7
Engine coolant temperature gauge ............. 1-4
Engine cooling system ................................ 7-5
Engine oil..................................................... 7-7
Engine oil and oil filter
recommendation .......................................... 9-4
Engine serial number ................................ 9-11
Starting the engine ...................................... 4-6
Exhaust gas (Carbon monoxide) ...................... 4-2
Explanation of maintenance items.................. 8-10
F
Flat tire .............................................................. 5-2
Fluid
Automatic transmission fluid ..................... 7-10
Brake and clutch fluid................................ 7-12
Power steering fluid................................... 7-11
Window washer fluid ................................. 7-12
FM/AM radio with cassette player .................. 3-12
FM-AM radio with cassette player .................. 3-16FM-AM radio with cassette player and
compact disc player ........................................ 3-22
F.M.V.S.S. certification label........................... 9-11
Foldable outside mirrors ................................. 2-39
Front fog light switch (If so equipped) ............ 1-15
Front personal light ......................................... 1-23
Fuel
Capacities and recommended
fuel/lubricants .............................................. 9-2
Fuel filler cap ............................................. 2-10
Fuel filler lid lock ....................................... 2-10
Fuel gauge .................................................. 1-5
Fuel recommendation.................................. 9-2
Fuses .............................................................. 7-21
Fusible links .................................................... 7-23
G
Gauge
Engine coolant temperature gauge ............. 1-4
Fuel gauge .................................................. 1-5
Meters and gauges ..................................... 1-3
General maintenance ....................................... 8-3
Glove box lock .................................................. 2-8
H
Hazard warning flasher switch........................ 1-16
Head restraint ................................................. 2-15
Headlight and turn signal switch..................... 1-14
Headlights ....................................................... 7-23
Heated seats (If so equipped) ........................ 1-16
Heater operation ............................................... 3-4Hood release .................................................... 2-8
I
If your vehicle is ever stolen ........................... 1-26
If your vehicle overheats .................................. 5-9
Ignition switch ................................................... 4-4
Injured persons ............................................... 2-26
Inside mirror .................................................... 2-40
Installing license plate .................................... 9-12
Instrument brightness control ......................... 1-15
Integrated HomeLink
transmitter
(If so equipped).......................................... 1-24
Interior light ..................................................... 1-22
J
Jump starting ........................................... 5-7, 7-14
K
Key .................................................................... 2-2
L
License plate
Installing license plate ............................... 9-12
Light
Front fog light switch (If so
equipped)................................................... 1-15
Front personal light ................................... 1-23
Headlight and turn signal switch ............... 1-14
Headlights.................................................. 7-23
Interior light................................................ 1-22
10-2
Z01.2.1/A32-DX
