OUTSIDE MIRRORS
WARNING
Objects viewed in the outside mirror on
the passenger side are closer than they
appear. Be careful when moving to the
right. Using only this mirror could cause
an accident. Use the inside mirror or
glance over your shoulder to properly
judge distances to other objects.
The outside mirror switch, located in front of theselector lever, will operate only when the ignition
switch is in the ACC or ON position.
Move the switch to right
A
or left
B
to select
the right or left outside mirror, then adjust the
mirror to the desired position by pushing the
button
C.
Foldable outside mirrorsFold the outside mirror by pushing it toward the
rear of the vehicle.
SPA1449A
SPA1829
3-32
Pre-driving checks and adjustments
05.8.26/Z50-D/V5.0
Page 152 of 341
The automatic drive positioner system has two
features:
Entry/exit function
Memory storageENTRY/EXIT FUNCTIONThis system is designed so that the driver’s seat
and outside mirror will automatically move when
the selector lever is in the P (Park) position. This
allows the driver to get into and out of the
driver’s seat more easily.
The driver’s seat will slide backward:
The driver’s seat will slide backward when the
driver’s door is opened with the ignition switch
(knob) in the LOCK position.
The driver’s seat will return to the previous
position:
When the key is inserted into the ignition
switch after closing the driver’s door, or when
the driver’s door is closed after inserting the
key into the ignition switch.
When the ignition switch is pushed with the
driver’s door closed. (Intelligent Key
equipped model)
When the key or ignition switch is turned to
the ON position.The entry/exit feature can be canceled. See “4.
Display screen, heater, air conditioner and audio
systems” section of this manual.
The entry/exit function can be activated or can-
celled by pressing and holding the SET switch
for more than 10 seconds while the ignition key
is in the LOCK position. The indicator light will
blink once when the function is cancelled, and
the indicator light will blink twice when the
function is activated. If the battery cable is
disconnected, or if the fuse opens, the entry/exit
function will be cancelled. In such a case, after
connecting the battery or replacing with a new
fuse, open and close the driver’s door more than
two times with the ignition key or ignition switch
in the LOCK position to activate the entry/exit
function.
MEMORY STORAGETwo positions for the driver’s seat, pedals (Brake
and Accelerator) and outside mirrors can be
stored in the automatic drive positioner memory.
Follow these procedures to use the memory
system.
1. Set the selector lever to the P (Park) position.
2. Adjust the driver’s seat, pedals (Brake and
Accelerator) and outside mirrors to the de-
sired positions by manually operating each
adjusting switch. For additional information,
see “Seats” in the “1. Safety — seats, seat
belts and supplemental restraint system”
SPA2185
AUTOMATIC DRIVE POSITIONER
(if so equipped)
Pre-driving checks and adjustments
3-33
05.8.26/Z50-D/V5.0
Page 153 of 341
section and “Pedal position adjustment” and
“Outside mirrors” earlier in this section.
3. Turn the ignition ON.
4. Push the SET switch and, within 5 seconds,
push the memory switch (1 or 2) fully for at
least 1 second.
The indicator light for the pushed memory
switch will come on and stay on for approxi-
mately 5 seconds after pushing the switch.
After the indicator light goes off, the selected
positions are stored in the selected memory
(1 or 2).
If memory is stored in the same memory switch,
the previous memory will be deleted.
Linking a remote keyless entry to a
stored memory positionA remote keyless entry can be linked to a stored
memory position with the following procedure.
1. Follow the steps for storing a memory posi-
tion.
2. While the indicator light for the memory
switch being set is illuminated for 5 seconds,
push the unlock button on the remote keyless
entry. The indicator light will blink. After the
indicator light goes off, the remote keyless
entry is linked to that memory setting.With the key removed from the ignition switch,
push the unlock button on the keyfob. The
driver’s seat, pedals (Brake and Accelerator)
and outside mirrors will move to the memorized
position.
Confirming memory storageTurn the ignition switch to the ON position
and push the SET switch. If the main memory
has not been stored, the indicator light will
come on for approximately 0.5 seconds.
When the memory has stored the position,
the indicator light will stay on for approxi-
mately 5 seconds.Selecting the memorized position1. Set the sift selector lever to the P (Park)
position.
2. Turn the ignition ON.
3. Push the memory switch (1 or 2) fully for at
least 1 second.
The driver’s seat, pedals (Brake and Accel-
erator) and outside mirrors will move to the
memorized position with the indicator light
flashing, and then the light will stay on for
approximately 5 seconds.SYSTEM OPERATIONThe automatic drive positioner system will notwork or will stop operating under the following
conditions:
when the vehicle speed is above 4 MPH (7
km/h).
when any two or more of the memory
switches and the SET switch is simulta-
neously pushed while the automatic drive
positioner is operating.
when the adjusting switch for the driver’s
seat, pedals and outside mirror are operated
while the automatic drive positioner is oper-
ating.
when the memory switch (1 or 2) and the
SET switch is not pushed for at least 1
second.
when the seat has been already moved to the
memorized position.
when no seat position is stored in the
memory switch.
when the engine is started while moving the
automatic drive positioner.
when the shift selector lever is moved from
the P position to any other position (However,
it will not be cancelled if the switch is pushed
while the seat is returning to the previous
positions (entry/exit function).).
3-34
Pre-driving checks and adjustments
05.8.26/Z50-D/V5.0
Page 154 of 341
MEMO
Pre-driving checks and adjustments
3-35
05.8.26/Z50-D/V5.0
Page 155 of 341
MEMO3-36
Pre-driving checks and adjustments
05.8.26/Z50-D/V5.0
Page 156 of 341
4 Display screen, heater, air conditioner and
audio systemsSafety note .............................................................................. 4-2
Control panel buttons — without navigation system .... 4-2
How to use joystick and “ENTER” button ................. 4-3
How to use “BACK” button .......................................... 4-3
How to use “TRIP” button ............................................. 4-3
How to use “FUEL ECON” button .............................. 4-3
Clock ................................................................................... 4-4
How to use “E/M” button .............................................. 4-4
How to use “MAINT” (Maintenance) button ............. 4-4
Maintenance notice ......................................................... 4-5
How to use “SETTING” button .................................... 4-6
“DAY/NIGHT” button.................................................... 4-10
Control panel buttons — with navigation system ....... 4-11
How to use joystick and “ENTER” button .............. 4-11
How to use “BACK” button........................................ 4-11
Setting up the start-up screen................................... 4-12
How to use the “TRIP” button ................................... 4-12
Maintenance notice ....................................................... 4-14
How to use the “SETTING” button .......................... 4-15
“DAY/NIGHT” button.................................................... 4-19
Rear view monitor (if so equipped) ................................ 4-19
How to read the displayed lines................................ 4-20Rear view monitor setting............................................ 4-20
Operating tips................................................................. 4-20
Ventilators .............................................................................. 4-21
Heater and air conditioner (Automatic) ......................... 4-23
Automatic operation ...................................................... 4-24
Manual operation ........................................................... 4-25
Operating tips................................................................. 4-25
In-cabin microfilter ......................................................... 4-26
Servicing air conditioner .................................................... 4-26
Audio system ........................................................................ 4-27
FM radio reception ........................................................ 4-27
AM radio reception ....................................................... 4-28
Satellite radio reception ............................................... 4-28
Audio operation precautions....................................... 4-28
FM-AM-SAT radio with CD player .......................... 4-33
FM-AM-SAT radio with cassette player and CD
changer ............................................................................ 4-37
CD care and cleaning .................................................. 4-42
Steering switch for audio control (if so
equipped)......................................................................... 4-43
Antenna ............................................................................ 4-44
Car phone or CB radio .................................................... 4-44
05.8.26/Z50-D/V5.0
Page 157 of 341
WARNING
