Page 111 of 341
of the sunroof opening while the ve-
hicle is in motion or while the sun-
roof is closing.
CAUTION
Remove water drops, snow, ice or
sand from the sunroof before open-
ing.
Do not place any heavy object on the
sunroof or surrounding area.If the sunroof does not closeHave a NISSAN dealer check and repair the
sunroof.
CEILING LIGHTThe ceiling light has a three-position switch.
When the switch is in the ON position
1, the
light will illuminate.
When the switch is in the OFF position
2, the
light will turn off.
When the switch is in the DOOR position3,
the light will illuminate when a door is opened.
The light will stay on for about 30 seconds when:
The doors are unlocked by the remote key-
less entry system, a key, power door lock
switch or using the Intelligent Key systemwhile all doors are closed.
The driver’s door is opened and then closed
while the key is removed from the ignition
switch or the ignition switch is turned to the
LOCK position (Intelligent Key system).
The key is removed from the ignition switch or
the ignition switch is turned to the LOCK
position (Intelligent Key system) while all
doors are closed.
The ceiling light will turn off while the 30 second
timer is activated, when:
The driver’s door is locked by the remote
keyless entry system, a key or the power door
lock switch.
The ignition switch is turned ON.
When the ceiling light switch or map light
switch or rear personal light switch is in the
ONposition, the ceiling, map, rear and
vanity mirror lights will automatically turn
off 30 minutes after the ignition switch has
been turned to the ACC or OFF position. To
turn on the light again, turn the ignition
switch to the ONposition.
After the above procedure, the ceiling, map, rear
personal and vanity mirror lights will automati-
cally turn off 30 minutes after the latest operation
SIC2063
INTERIOR LIGHTS
2-40
Instruments and controls
05.8.26/Z50-D/V5.0
Page 112 of 341
of the following with the ignition switch in the
ACC or OFF position:
Opening or closing any door
Locking or unlocking with the remote keyless
entry system, a key, the lock-unlock switch or
the ignition switch is turned to the LOCK
position (Intelligent Key system).
Inserting or removing a key from the ignition
switch
These lights will turn on again when any of the
above operations is performed after the lights
have turned off automatically. (The lights will turn
off 30 minutes after the latest operation of the
above as well.)
CAUTION
Turn off the ceiling, map, rear and
vanity mirror lights when you leave
the vehicle.
Do not use for extended periods of
time with the engine stopped. This
could result in a discharged battery.
MAP LIGHTTo turn on the light, push the plastic surface
A
of the light. Push it again to turn off the light.
REAR PERSONAL LIGHTThe rear personal light has a three-position
switch. (
A: DOOR,
B: OFF,
C: ON)
When the switch is in the DOOR position
A,
the light will illuminate when a door is opened.
When the ceiling light or the map light
switch or rear personal light switch is in the
ONposition
C, the ceiling, map, rear per-
sonal and vanity mirror lights will auto-
matically turn off 30 minutes after the ig-
nition switch has been turned to the OFF
position
B. To turn on the light again, turn
the ignition switch to the ONposition.
SIC2068
Front
SIC2069
Rear
Instruments and controls
2-41
05.8.26/Z50-D/V5.0
Page 113 of 341
CAUTION
Turn off the ceiling, map, rear and
vanity mirror lights when you leave
the vehicle.
Do not use for extended periods of
time with the engine stopped. This
could result in a discharged battery.
LUGGAGE LIGHTWhen the switch is in the ON position
A, the
light illuminates while the lift gate is opened.
When the lift gate is closed, the light will turn off.
When the switch is in the OFF position
B, the
light will turn off.The light on the vanity mirror will turn on when
the cover on the vanity mirror is opened.
When the ceiling light or the map light
switch or rear personal light switch is in the
ONposition, the ceiling, map, rear per-
sonal and vanity mirror lights will auto-
matically turn off 30 minutes after the ig-
nition switch has been turned to the OFF
position. To turn on the light again, turn the
ignition switch to the ONposition.
SIC2131
SIC2064
VANITY MIRROR LIGHT (if so
equipped)
2-42
Instruments and controls
05.8.26/Z50-D/V5.0
Page 114 of 341
The HomeLink
Universal Transceiver provides a
convenient way to consolidate the functions of
up to three individual hand-held transmitters into
one built-in device.
HomeLink
Universal Transceiver:
Will operate most Radio Frequency (RF)
devices such as garage doors, gates, home
and office lighting, entry door locks and se-
curity systems.
Is powered by your vehicle’s battery. No
separate batteries are required. If the vehi-
cle’s battery is discharged or is discon-
nected, HomeLink
will retain all program-
ming.
Once the HomeLinkUniversal Transceiver
is programmed, retain the original trans-
mitter for future programming procedures
(Example: new vehicle purchases). Upon
sale of the vehicle, the programmed
HomeLink
Universal Transceiver buttons
should be erased for security purposes.
For additional information, refer to “Pro-
gramming HomeLink
” later in this sec-
tion.
WARNING
Do not use the HomeLink
Universal
Transceiver with any garage door
opener that lacks safety stop and
reverse features as required by fed-
eral safety standards. (These stan-
dards became effective for opener
models manufactured after April 1,
1982). A garage door opener which
cannot detect an object in the path of
a closing garage door and then auto-
matically stop and reverse, does not
meet current federal safety stan-
dards. Using a garage door opener
without these features increases the
risk of serious injury or death.
During programming procedure, your
garage door or security gate may
open or close. Make sure that people
and objects are clear of the garage
door, gate, etc. that you are program-
ming.
Your vehicle’s engine should be
turned off while programming theHomeLink
Universal Transceiver.
HomeLink
UNIVERSAL
TRANSCEIVER (if so equipped)
Instruments and controls
2-43
05.8.26/Z50-D/V5.0
Page 115 of 341
PROGRAMMING HomeLinkTo program your HomeLink
Transceiver to op-
erate a garage door, gate, or entry door opener,
home or office lighting, you need to be at the
same location as the device. Note: Garage door
openers (manufactured after 1996) have “rolling
code protection”. To program a garage door
opener equipped with “rolling code protection”;
you will need to use a ladder to get up to the
garage door opener motor to be able to access
the “smart or learn” program button.
1. To begin, push and hold the 2 outer
HomeLink
buttons (to clear the memory)
until the indicator light
A
blinks (after 20
seconds). Release both buttons.
2. Position the end of the hand-held transmitter
1-3 inches away from the HomeLink
sur-
face.3. Using both hands, simultaneously push and
hold both the HomeLink
button you want to
program and the hand-held transmitter but-
ton.
DO NOT release the buttons until step 4 has
been completed.
4. Hold down both buttons until the indicator
light on the HomeLinkflashes, changing
from a “slow blink” to a “rapid blink”. This
could take up to 90 seconds. When the
indicator light blinks rapidly, both buttons
may be released. The rapidly flashing light
indicates successful programming. To acti-
vate the garage door or other programmed
device, push and hold the programmed
SIC3040
SIC3041
2-44
Instruments and controls
05.8.26/Z50-D/V5.0
Page 116 of 341
HomeLink
button - releasing when the de-
vice begins to activate.
5. If the indicator light on the HomeLink
blinks
rapidly for two seconds and then turns solid,
HomeLink
has picked up a “rolling code”
garage door opener signal. You will need to
proceed with the next steps to train the
HomeLinkto complete the programming
which may require a ladder and another
person for convenience.
6. Push and release the training button located
on the garage door opener’s motor to acti-
vate the “training mode”. This button is usu-
ally located near the antenna wire that hangs
down from the motor. If the wire originates
from under a light lens, you will need to
remove the lens to access the training button.
NOTE:
Once you have pushed and released the
training button on the garage door open-
er’s motor and the “training light” is lit, you
have 30 seconds in which to perform step
7. Use the help of a second person for
convenience to assist when performing
this step.
7. Quickly within 30 seconds of pushing and
releasing the garage door opener training
button, firmly push and release theHomeLink
button you have just pro-
grammed. Push and release the HomeLink
button up to three times to complete the
training.
8. Your HomeLink
button should now be pro-
grammed. (To program the remaining
HomeLink
buttons for additional door or
gate openers, follow steps 2 through 8 only.)
NOTE:
Do not repeat step one unless you want to
“clear” all previously programmed
HomeLinkbuttons).
If you have any questions or are having difficulty
programming your HomeLink
buttons, please
refer to the HomeLinkwebsite at:
www.homelink.com or call 1-800-355-3515.
PROGRAMMING HomeLink
FOR
CANADIAN CUSTOMERS
Prior to 1992, D.O.C. regulations required hand-
held transmitters to stop transmitting after 2
seconds. To program your hand-held transmitter
to HomeLink
, continue to push and hold the
HomeLinkbutton (note steps 2 through 4
under “Programming HomeLink
”) while you
push and re-push (“cycle”) your hand-held
transmitter every 2 seconds until the indicatorlight flashes rapidly (indicating successful pro-
gramming).
NOTE:
If programming a garage door opener, etc.,
it is advised to unplug the device during
the “cycling” process to prevent possible
damage to the garage door opener compo-
nents.
OPERATING THE HomeLinkUNIVERSAL TRANSCEIVERThe HomeLink
Universal Transceiver (once
programmed) may now be used to activate the
garage door, etc. To operate, simply push the
appropriate programmed HomeLink
Universal
Transceiver button. The red indicator light will
illuminate while the signal is being transmitted.
PROGRAMMING TROUBLE
DIAGNOSISIf the HomeLink
does not quickly learn the
hand-held transmitter information:
replace the hand-held transmitter batteries
with new batteries.
position the hand-held transmitter with its
battery area facing away from the HomeLink
surface.
Instruments and controls
2-45
05.8.26/Z50-D/V5.0
Page 117 of 341
push and hold both the HomeLink
and
hand-held transmitter buttons without inter-
ruption.
position the hand-held transmitter 2 to 5
inches (50 to 127 mm) away from the
HomeLink
surface. Hold the transmitter in
that position for up to 15 seconds. If
HomeLinkis not programmed within that
time, try holding the transmitter in another
position - keeping the indicator light in view at
all times.
If you continue to have programming difficulties,
please contact the NISSAN Consumer Affairs
Department. The phone numbers are located in
the Foreword of this Owner’s Manual.
CLEARING THE PROGRAMMED
INFORMATIONIndividual buttons cannot be cleared, however to
clear all programming, push and hold the two
outside buttons and release when the indicator
light begins to flash (approximately 20 seconds).REPROGRAMMING A SINGLE
HomeLink
BUTTON
To reprogram a HomeLink
Universal Trans-
ceiver button, complete the following.
1. Push and hold the desired HomeLink
but-ton.Do notrelease the button until step 4
has been completed.
2. When the indicator light begins to flash
slowly (after 20 seconds), position the hand-
held transmitter 2 to 5 inches (50 to 127 mm)
away from the HomeLink
surface.
3. Push and hold the hand-held transmitter but-
ton.
4. The HomeLink
indicator light will flash, first
slowly and then rapidly. When the indicator
light begins to flash rapidly, release both
buttons.
The HomeLinkUniversal Transceiver button
has now been reprogrammed. The new device
can be activated by pushing the HomeLink
button that was just programmed. This proce-
dure will not affect any other programmed
HomeLink
buttons.
IF YOUR VEHICLE IS STOLENIf your vehicle is stolen, you should change the
codes of any non-rolling code device that has
been programmed into HomeLink
. Consult the
Owner’s Manual of each device or call the
manufacturer or dealer of those devices for
additional information.
When your vehicle is recovered, you will
need to reprogram the HomeLink
Univer-sal Transceiver with your new transmitter
information.
FCC Notice:
This device complies with FCC rules part
15. Operation is subject to the following
two conditions: (1) This device may not
cause harmful interference and (2) This
device must accept any interference that
may be received, including interference
that may cause undesired operation.
The transmitter has been tested and com-
plies with FCC and DOC/MDC rules.
Changes or modifications not expressly
approved by the party responsible for com-
pliance could void the user’s authority to
operate the equipment.
DOC: ISTC 1763K1313
FCC I.D.: CB2V67690
2-46
Instruments and controls
05.8.26/Z50-D/V5.0
Page 118 of 341
MEMO
Instruments and controls
2-47
05.8.26/Z50-D/V5.0
Page 119 of 341
MEMO2-48
Instruments and controls
05.8.26/Z50-D/V5.0
Page 120 of 341
3 Pre-driving checks and adjustmentsKeys ........................................................................................... 3-2
NISSAN Vehicle Immobilizer System (NVIS)
keys ...................................................................................... 3-2
Doors......................................................................................... 3-3
Locking with key ............................................................... 3-3
Locking with inside lock knob...................................... 3-4
Locking with power door lock switch ......................... 3-4
Child safety rear door lock ............................................ 3-5
Remote keyless entry system (models without
Intelligent Key system) .......................................................... 3-5
How to use remote keyless entry system.................. 3-6
Intelligent Key system (if so equipped) ............................ 3-9
Door locks/unlocks precaution ................................. 3-11
Intelligent Key operation .............................................. 3-12
Operating the engine.................................................... 3-13
Intelligent Key operating range ................................. 3-15
Warning signals ............................................................. 3-17
Trouble-shooting guide ................................................ 3-19
Operation with intelligent remote keyless entry
system .............................................................................. 3-20Operation with the mechanical key and valet
key ..................................................................................... 3-23
Hood ....................................................................................... 3-24
Lift gate .................................................................................. 3-24
Fuel-filler door ...................................................................... 3-26
Open the fuel-filler door .............................................. 3-26
Fuel-filler cap .................................................................. 3-27
Steering wheel ..................................................................... 3-28
Tilt operation ................................................................... 3-28
Pedal position adjustment (if so equipped).................. 3-29
Sun visors.............................................................................. 3-30
Mirrors .................................................................................... 3-30
Inside mirror .................................................................... 3-30
Automatic anti-glare inside mirror (if so
equipped)......................................................................... 3-31
Outside mirrors .............................................................. 3-32
Automatic drive positioner (if so equipped) ................. 3-33
Entry/exit function .......................................................... 3-33
Memory storage ............................................................. 3-33
System operation ........................................................... 3-34
05.8.26/Z50-D/V5.0
