Page 311 of 341
ENGINEModelVQ35DE
Type Gasoline, 4-cycle
Cylinder arrangement 6-cylinder, V-slanted at 60°
Bore x Stroke in (mm) 3.760 x 3.205 (95.5 x 81.4)
Displacement cu in (cm
3) 213.45 (3,498)
Firing order 1-2-3-4-5-6*
Idle speed rpm
See the emission control label on the
underside of the hood. Ignition timing (B.T.D.C.) degree/rpm
CO percentage at idle speed [No air] %
Spark plugStandard PLFR5A-11
Service option PLFR4A-11 (Hot), PLFR6A-11 (Cold)
Spark plug gap (Normal) in (mm) 0.043 (1.1)
Camshaft operation Timing chain
The spark ignition system of this vehicle
meets all requirements of the Canadian
Interference-Causing Equipment Regula-
tions.
TI1009-A
SPECIFICATIONS9-8
Technical and consumer information
05.8.26/Z50-D/V5.0
Page 312 of 341
WHEELS AND TIRESRoad wheelType Size Offset in (mm)
Aluminum 18 x 7-1/2JJ 1.38 (35)
TireConventional P235/65R18 104T
SpareT165/90D18 107M
Conventional*
Pressure (cold)Conventional 33 PSI (230 kPa)
Spare (T-type) 60 PSI (420 kPa)
*: For Canada
DIMENSIONS AND WEIGHTSOverall length in (mm) 187.6 (4,767)
Overall width in (mm) 74.0 (1,880)
Overall height without roof rack rail in (mm) 66.5 (1,689)
Overall height with roof rack rail in (mm) 67.3 (1,709)
Front tread in (mm) 64.2 (1,630)
Rear tread in (mm) 64.2 (1,630)
Wheelbase in (mm) 111.2 (2,825)
Gross vehicle weight rating lb(kg)
See the F.M.V.S.S. certifica-
tion label on the driver’s side
lock pillar. Gross axle weight rating
Front lb(kg)
Rear lb(kg)
Technical and consumer information
9-9
05.8.26/Z50-D/V5.0
Page 313 of 341
When planning to travel in another country,
you should first find out if the fuel available is
suitable for your vehicle’s engine.
Using fuel with too low an octane rating may
cause engine damage. All gasoline vehicles
must be operated with unleaded engine gaso-
line. Therefore, avoid taking your vehicle to areas
where appropriate fuel is not available.
When transferring the registration of your
vehicle to another country, state, province
or district,it may be necessary to modify the
vehicle to meet local laws and regulations.
The laws and regulations for motor vehicle emis-
sion control and safety standards vary according
to the country, state, province or district; there-
fore, vehicle specifications may differ.
When any vehicle is to be taken into an-
other country, state, province or district
and registered, its modifications, transpor-
tation, and registration are the responsibil-
ity of the user. NISSAN is not responsible
for any inconvenience that may result.
VEHICLE IDENTIFICATION NUMBER
(VIN) PLATEThe vehicle identification number plate is at-
tached as shown. This number is the identifica-
tion for your vehicle and is used in the vehicle
registration.
VEHICLE IDENTIFICATION NUMBER
(Chassis number)The number is stamped under the passenger’s
seat as shown.
STI0334
STI0374
WHENTRAVELING OR
REGISTERING YOUR VEHICLE IN
ANOTHER COUNTRYVEHICLE IDENTIFICATION9-10
Technical and consumer information
05.8.26/Z50-D/V5.0
Page 314 of 341
ENGINE SERIAL NUMBERThe number is stamped on the engine as shown.
F.M.V.S.S. CERTIFICATION LABELThe Federal Motor Vehicle Safety Standards
(F.M.V.S.S.) certification label is affixed as
shown. This label contains valuable vehicle in-
formation, such as: Gross Vehicle Weight Rat-
ings (GVWR), Gross Axle Weight Rating
(GAWR), month and year of manufacture, Ve-
hicle Identification Number, (VIN), etc. Review it
carefully.
EMISSION CONTROL
INFORMATION LABELThe emission control information label is at-
tached as shown.
STI0047
STI0336
STI0337
Technical and consumer information
9-11
05.8.26/Z50-D/V5.0
Page 315 of 341
TIRE AND LOADING INFORMATION
LABELThe cold tire pressure is shown on the Tire and
Loading Information label affixed to the driver’s
door center pillar.
AIR CONDITIONER SPECIFICATION
LABELThe air conditioner specification label is affixed
inside of the hood as shown.
STI0373
STI0339
9-12
Technical and consumer information
05.8.26/Z50-D/V5.0
Page 316 of 341
Use the following steps to mount the license
plate:
Before mounting the license plate, confirm that
the following parts are enclosed in the vinyl bag.
License plate bracket
Screw x 2
Bolt grommet x 2
Bolt x 2
1. Temporarily place the license plate bracket
and mark the pilot hole points using holes
A.
2. Remove the license plate bracket.
3. Carefully drill two pilot holes using a 0.39 in
(10 mm) drill bit at the marked locations.(Be
sure that the drill only goes through the
fascia, or damage to the nut may occur.)
4. Insert grommets into the hole on the fascia.
5. Install the license plate bracket with bolts.
6. Install the license plate with screws
C.
STI0459
INSTALLING FRONT LICENSE
PLATE
Technical and consumer information
9-13
05.8.26/Z50-D/V5.0
Page 317 of 341
WARNING
It is extremely dangerous to
ride in a cargo area inside a
vehicle. In a collision, people
riding in these areas are more
likely to be seriously injured or
killed.
Do not allow people to ride in
any area of your vehicle that is
not equipped with seats and
seat belts.
Be sure everyone in your ve-
hicle is in a seat and using a
seat belt properly.TERMSIt is important to familiarize yourself with
the following terms before loading your
vehicle:
CurbWeight (actual weight of your
vehicle) - vehicle weight including:
standard and optional equipment, flu-ids, emergency tools, and spare tire
assembly. This weightdoes notin-
clude passengers and cargo.
GVW (Gross Vehicle Weight) - curb
weight plus the combined weight of
passengers and cargo.
GVWR (Gross Vehicle Weight Rat-
ing) - maximum total combined weight
of the unloaded vehicle, passengers,
luggage, hitch, trailer tongue load and
any other optional equipment. This in-
formation is located on the F.M.V.S.S.
label.
GAWR (Gross Axle Weight Rating) -
maximum weight (load) limit specified
for the front or rear axle. This informa-
tion is located on the F.M.V.S.S. label.
GCWR (Gross Combined Weight
Rating) - maximum total weight rating
of the vehicle, passengers, cargo, and
trailer.
Vehicle Capacity Weight, Load limit,
Total load capacity - maximum totalweight limit specified of the load (pas-
sengers and cargo) for the vehicle.
This is the maximum combined weight
of occupants and cargo that can be
loaded into the vehicle. If the vehicle is
used to tow a trailer, the trailer tongue
weight must be included as part of the
cargo load. This information is located
on the Tire and Loading Information
label.
Cargo capacity - permissible weight of
cargo, the subtracted weight of occu-
pants from the load limit.
VEHICLE LOAD CAPACITYDo not exceed the load limit of your
vehicle shown as “The combined weight
of occupants and cargo” on the Tire and
Loading Information label. Do not exceed
the number of occupants shown as
“Seating Capacity” on the Tire and Load-
ing Information label.
To get “the combined weight of occu-
pants and cargo”, add the weight of all
occupants, then add the total luggage
VEHICLE LOADING
INFORMATION9-14
Technical and consumer information
05.8.26/Z50-D/V5.0
Page 318 of 341
weight. Examples are shown below.
STI0445
Technical and consumer information
9-15
05.8.26/Z50-D/V5.0
Page 319 of 341
Steps for determining correct load
limit1. Locate the statement “The combined
weight of occupants and cargo should
never exceed XXX kg or XXX lbs” on
your vehicle’s placard.
2. Determine the combined weight of the
driver and passengers that will be
riding in your vehicle.
3. Subtract the combined weight of the
driver and passengers from XXX kg or
XXX lbs.
4. The resulting figure equals the avail-
able amount of cargo and luggage
load capacity. For example, if the XXX
amount equals 1400 lbs. and there will
be five 150 lb. passengers in your
vehicle, the amount of available cargo
and luggage load capacity is 650 lbs.
(1400 − 750 (5 x 150) = 650 lbs.) or
(640 − 340 (5 x 70) = 300 kg.)
5. Determine the combined weight of
luggage and cargo being loaded onthe vehicle. That weight may not safely
exceed the available cargo and lug-
gage load capacity calculated in Step
4.
6. If your vehicle will be towing a trailer,
load from your trailer will be trans-
ferred to your vehicle. Consult this
manual to determine how this reduces
the available cargo and luggage load
capacity of your vehicle.
Before driving a loaded vehicle, confirm
that you do not exceed the Gross Vehicle
Weight Rating (GVWR) or the Gross
Axle Weight Rating (GAWR) for your
vehicle. See “Measurement of Weights”
later in this section.
Also check tires for proper inflation pres-
sures. See the Tire and Loading Informa-
tion label.
LOADING TIPSThere are tie down hooks located in the
cargo area. The tie down hooks can be
used to secure cargo with ropes or other
types of straps.
The GVW must not exceed GVWR or
GAWR as specified on the F.M.V.S.S.
certification label.
Do not load the front and rear axle to
the GAWR. Doing so will exceed the
GVWR.
STI0343
9-16
Technical and consumer information
05.8.26/Z50-D/V5.0
Page 320 of 341
WARNING
Properly secure all cargo with
ropes or straps to help prevent
it from sliding or shifting. Do
not place cargo higher than the
seatbacks. In a sudden stop or
collision, unsecured cargo
could cause personal injury.
Do not load your vehicle any
heavier than the GVWR or the
maximum front and rear
GAWRs. If you do, parts of your
vehicle can break, tire damage
could occur, or it can change
the way your vehicle handles.
This could result in loss of con-
trol and cause personal injury.
Overloading not only can
shorten the life of your vehicle
and the tire, but can also cause
unsafe vehicle handling and
longer braking distances. Thismay cause a premature tire fail-
ure which could result in a seri-
ous accident and personal in-
jury. Failures caused by
overloading are not covered by
the vehicle’s warranty.
PAYLOAD WEIGHT CAPACITYThe payload weight capacity is the maxi-
mum total weight of passengers, optional
equipment (air conditioning, trailer hitch,
etc.) and cargo that your vehicle is de-
signed to carry.
Before driving a loaded vehicle, confirm
that you do not exceed the Gross Vehicle
Weight Rating (GVWR) or the Gross
Axle Weight Rating (GAWR) for your
vehicle. See “Vehicle loading informa-
tion” earlier in this section for details.
Also check tires for proper inflation pres-
sures. See the tire and loading informa-
tion label affixed to the driver’s door
center pillar.
Payload Weight Capacity Unit: lb(kg)
VQ35DE
2WD AWD
US1,050
(475)1,055
(480)
Canada1,070
(485)1,070
(485)MEASUREMENT OF WEIGHTSSecure loose items to prevent weight
shifts that could affect the balance of
your vehicle. When the vehicle is loaded,
drive to a scale and weigh the front and
the rear wheels separately to determine
axle loads. Individual axle loads should
not exceed either of the gross axle weight
ratings (GAWR). The total of the axle
loads should not exceed the gross ve-
hicle weight rating (GVWR). These rat-
ings are given on the vehicle certification
label. If weight ratings are exceeded,
move or remove items to bring all weights
below the ratings.Technical and consumer information
9-17
05.8.26/Z50-D/V5.0
