CAUTION

Do not store the main sun visor be-
fore storing the extension sun visor.

Do not pull the extension sun visor
forcedly downward.
1. To block out glare from the front, swing down
the main sun visor
1.
2. To block glare from the side, remove the main
sun visor from the center mount and swing it
to the side
2.
3. Draw out the extension sun visor
3from the
main sun visor
4
to block further glare.
INSIDE MIRRORWhile holding the inside rearview mirror, adjust
the mirror angles until the desired position is
achieved.
The adjusting lever
1
can be operated when
the glare from the headlights of the vehicle
behind you obstructs your vision at night.
WARNING
Use the night position only when neces-
sary, because it reduces rear view clar-
SPA2176
SPA1756
SUNVISORS MIRRORS3-30
Pre-driving checks and adjustments


05.8.26/Z50-D/V5.0


OUTSIDE MIRRORS
WARNING
Objects viewed in the outside mirror on
the passenger side are closer than they
appear. Be careful when moving to the
right. Using only this mirror could cause
an accident. Use the inside mirror or
glance over your shoulder to properly
judge distances to other objects.
The outside mirror switch, located in front of theselector lever, will operate only when the ignition
switch is in the ACC or ON position.
Move the switch to right
A
or left
B
to select
the right or left outside mirror, then adjust the
mirror to the desired position by pushing the
button
C.
Foldable outside mirrorsFold the outside mirror by pushing it toward the
rear of the vehicle.
SPA1449A
SPA1829
3-32
Pre-driving checks and adjustments


05.8.26/Z50-D/V5.0


New vehicle break-in ................................................ 5-23
NISSAN advanced air bag system ....................... 1-45
NISSAN Vehicle Immobilizer System ................... 2-18
NISSAN Vehicle Immobilizer System
Engine start .............................................. 5-10, 5-12
O
Odometer ....................................................................... 2-4
Oil
Capacities and recommended fuel/
lubricants ................................................................. 9-2
Changing engine oil ........................................... 8-10
Checking engine oil level .................................... 8-9
Engine oil................................................................. 8-9
Engine oil viscosity ............................................... 9-5
Outside mirrors .......................................................... 3-32
Overheat, If your vehicle overheats ...................... 6-11
Owner’s Manual/Service Manual order
information................................................................... 9-27
P
Parking
Brake break-in ..................................................... 5-30
Brake check ......................................................... 8-20
Parking brake operation .................................... 5-21
Parking on hills .................................................... 5-29
Pedal position adjustment....................................... 3-29
Phone, Car phone or CB radio ............................. 4-44
Power
Front seat adjustment .......................................... 1-4
Power door lock .................................................... 3-3Power outlet ......................................................... 2-30
Power steering fluid ........................................... 8-12
Power steering system ...................................... 5-30
Power windows................................................... 2-36
P position selecting warning light ......................... 2-13
Pre-tensioner seat belt system .............................. 1-52
Precautions
Audio operation ................................................... 4-28
Braking precautions ........................................... 5-30
Child restraints .................................................... 1-21
Cruise control ...................................................... 5-21
Driving safety .......................................................... 5-6
Maintenance ........................................................... 8-5
On-pavement and offroad driving ..................... 5-6
Seat belt usage ................................................... 1-10
Supplemental restraint system ........................ 1-39
When starting and driving .................................. 5-2
Push starting .............................................................. 6-10
R
Radio, Car phone or CB radio .............................. 4-44
Readiness for inspection/maintenance (I/M)
test (US only) ............................................................. 9-26
Rear center seat belt................................................ 1-17
Rear door lock, Child safety rear door lock.......... 3-5
Rear personal light .................................................... 2-41
Rear power point....................................................... 2-30
Rear seat adjustment .................................................. 1-5
Rear view monitor ..................................................... 4-19
Rear window and outside mirror defroster
switch ........................................................................... 2-22
Rear window wiper and washer switch .............. 2-21
Recorders, Event data ............................................. 9-27Registering your vehicle in another country ....... 9-10
Remote keyless entry
System, Except Intelligent Key system ............ 3-5
System, For Intelligent Key system ................ 3-20
Reporting safety defects (US only) ...................... 9-25
S
Safety
Child seat belts ................................................... 1-12
Reporting safety defects (US only)................ 9-25
Towing safety....................................................... 9-20
Safety chain ................................................................ 9-21
Seat adjustment
Front manual seat adjustment............................ 1-3
Front power seat adjustment ............................. 1-4
Rear seat adjustment ........................................... 1-5
Seat belt(s)
Child safety .......................................................... 1-12
Infants .................................................................... 1-13
Injured persons.................................................... 1-13
Larger children .................................................... 1-13
Pre-tensioner seat belt system ....................... 1-52
Precautions on seat belt usage ...................... 1-10
Pregnant women ................................................. 1-13
Rear center seat belt ......................................... 1-17
Seat belt cleaning ................................................. 7-5
Seat belt extenders ............................................ 1-20
Seat belt hook ..................................................... 1-17
Seat belt maintenance ...................................... 1-20
Seat belt warning light and chime ................. 2-13
Seat belts ............................................................. 1-10
Shoulder belt height adjustment..................... 1-16
Small children ...................................................... 1-13
