ACCELERATOR CONTROL SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTIONACC
A
ACC
ACCELERATOR CONTROL SYSTEM
ACCELERATOR CONTROL SYSTEM ...................... 2Components ............................................................. 2
Removal and Installation .......................................... 2
REMOVAL ............................................................. 2
INSTALLATION ..................................................... 2
INSPECTION AFTER INSTALLATION .................. 3

ACC-2
ACCELERATOR CONTROL SYSTEM
ACCELERATOR CONTROL SYSTEM
PFP:18005
ComponentsEBS01F6Q
Removal and InstallationEBS01E7D
REMOVAL
1. Disconnect accelerator pedal position sensor harness connec-
tor.
a. Pull the connector lock back to unlock the connector from the
accelerator pedal position sensor as shown in the figure.
b. Pull up on the connector to disconnect it from the accelerator
pedal position sensor as shown in the figure.
2. Loosen nuts, and remove accelerator pedal assembly.
CAUTION:
lDo not disassemble accelerator pedal assembly. Do not remove accelerator pedal position sen-
sor from accelerator pedal assembly.
lAvoid impact from dropping etc. during handling.
lBe careful to keep accelerator pedal assembly away from water.
lDo not adjust adjusting screw (painted white).
INSTALLATION
Installation is the reverse order of removal.
1. Accelerator pedal assembly
Vehicle front
PBIC3633E
LBIA0333E

ACCELERATOR CONTROL SYSTEM
ACC-3
C
D
E
F
G
H
I
J
K
L
MA
ACC
INSPECTION AFTER INSTALLATION
lMake sure that accelerator pedal moves smoothly within the whole operation range.
lMake sure that accelerator pedal securely returns to the original position.
lFor the electrical inspection of accelerator pedal position sensor, refer toEC-108, "DTC P0122, P0123
APP SENSOR",EC-142, "DTC P0222, P0223 APP SENSOR",EC-275, "DTC P2135 APP SENSOR".
