NISSAN NV200 2019 Owners Manual

LDI2222
LIGHTS

LDI2252LDI2255
8-26Do-it-yourself

LDI2254

LDI2223
8-28Do-it-yourself

Item Wattage (W) Bulb No.
Headlight assembly/daytime running lights
High/ Low 60/55 H13
Park/Turn 28/8 3457NAK
Map light 5 W5W
Cargo light 5 W5W
High-mounted stop light 16 W16W
Rear combination light
Stop/Tail 21/7 3047K
Backup (reversing) 16 W16W
Turn 27 3157AK
License plate light 5 W5W
* It is recommended that you visit a NISSAN dealer for replacement.
Always check with the Parts Department at a NISSAN dealer for the latest parts information.
Do-it-yourself8-29

LDI2507WDI0263
8-30Do-it-yourself

Indicates bulb installation
Use a cloth to protect the housing.Use a cloth to protect the housing.
