The front seat(s) are warmed by built-in heaters.
The switches located on the instrument panel
can be operated independently of each other.
1. Start the engine.
The battery could run down if the heater is
operated while the engine is not running.
2. Push the
(Low) or
(High) po-
sition of the switch, as desired, depending on
the temperature. The indicator light in the
switch will illuminate.
The heater is controlled by a thermostat,
automatically turning the heater on and off.The indicator light will remain on as long as
the switch is on.
3. When the vehicle’s interior is warmed or
before you leave the vehicle, be sure to turn
the switch off.
CAUTION

The battery could run down if the
seat heater is operated while the en-
gine is not running.

Do not use the seat heater for ex-
tended periods or when no one is
using the seat.

Do not put anything on the seat
which insulates heat, such as a blan-
ket, cushion, seat cover, etc. Other-
wise, the seat may become over-
heated.

Do not place anything hard or heavy
on the seat or pierce it with a pin or
similar object. This may result in
damage to the heater.

Any liquid spilled on the heating seatshould be removed immediately with
a dry cloth.

When cleaning the seat, never use
gasoline, thinner, or any similar ma-
terials.

If any abnormalities are found or the
heating seat does not operate, turn
the switch off and have the system
checked by your NISSAN dealer.
SIC1463
HEATED SEATS (if so equipped)2-26
Instruments and controls


03.1.28/R50-D/V5


The vehicle should be driven with the Vehicle
Dynamic Control System (VDC) on for most
driving conditions.
When the vehicle is stuck in mud or snow, the
VDC system reduces the engine output to re-
duce wheel spin. The engine RPM will be re-
duced even if the accelerator is depressed to the
floor. If maximum engine power is needed to free
a stuck vehicle, turn the VDC system off.
To cancel the Vehicle Dynamic Control System
(VDC), push the VDC OFF switch to turn off the
system. The
indicator will come on.
Push the VDC OFF switch again or restart the
engine to turn ON the system. See “Vehicledynamic control system (VDC)” in the “5. Start-
ing and driving” section.
The digital clock displays time when the ignition
key is in ACC or ON.
If the power supply is disconnected, the clock
will not indicate the correct time. Readjust the
time.
ADJUSTING THE TIMEPush theHbutton to adjust the hour.
Push theMbutton to adjust the minute.
SIC1881
SPA1159
VEHICLE DYNAMIC CONTROL
(VDC) OFF SWITCH (if so
equipped)CLOCK
Instruments and controls
2-27


03.1.28/R50-D/V5


The power outlet is for powering electrical ac-
cessories such as cellular telephones.
CAUTION

Use caution as the outlet and plug
may be hot during or immediately
after use.

This power outlet is not designed for
use with a cigarette lighter unit.

Do not use with accessories that ex-
ceed a 12 volt, 120W (10A) power
draw. Do not use double adapters or
more than one electrical accessory.

Use only one power outlet at a time.

Use this power outlet with the engine
running. (If the engine is stopped,
this could result in a discharged bat-
tery.)

Avoid using when the air conditioner,
headlights or rear window defogger
is on.

Before inserting or disconnecting a
plug, be sure to turn off the powerswitch of electrical accessory being
used or the ACC power of the vehicle.

Push the plug in as far as it will go. If
good contact is not made, the plug
may overheat or the internal tem-
perature fuse may blow.

When not in use, be sure to close the
cap. Do not allow water to contact
the socket.
SIC1574
POWER OUTLET (if so equipped)2-28
Instruments and controls


03.1.28/R50-D/V5


The cigarette lighter element is an accessory. A
genuine NISSAN cigarette lighter unit can be
purchased from your local NISSAN dealer.
The cigarette lighter operates when the ignition
switch is in ACC or ON.
Push the lighter in all the way. When the lighter
is heated, it will spring out.
Return the lighter to its original position after
use.
WARNING
The cigarette lighter should not be used
while driving so full attention may be
given to vehicle operation.
CAUTION
The cigarette lighter socket is a power
source for the cigarette lighter element
only. The use of the cigarette lighter
socket as a power source for any other
accessory is not recommended.
TRAY
WARNING
The storage tray should not be used
while driving so full attention may be
given to vehicle operation.
Do not place valuable items in the tray.
SIC2017
SIC1449
CIGARETTE LIGHTER AND
ASHTRAY (if so equipped)STORAGE
Instruments and controls
2-29


03.1.28/R50-D/V5


COIN BOX (if so equipped)To open the box, lightly push it once and draw it
out.
Do not use the box as an ashtray.
Do not place valuable items in the box.
SUNGLASSES HOLDERThe sunglasses holder can be opened by push-
ing the button.
WARNING
The sunglasses holder should not be
used while driving so full attention may
be given to vehicle operation.
CAUTION

Do not use for anything other than
glasses.

Do not leave glasses in the sun-
glasses holder while parking in direct
sunlight. The heat may damage the
glasses.
SIC1735
SIC0557
2-30
Instruments and controls


03.1.28/R50-D/V5


CUP HOLDERS
WARNING
The cup holders should not be used
while driving so full attention may be
given to vehicle operation.
CAUTION

Avoid abrupt starting and brakingwhen the cup holder is being used to
prevent spilling the drink. If the liquid
is hot, it can scald you or your pas-
senger.

Use only soft cups in the cup holder.
Hard objects can injure you in an
accident.
The cup holders have an insert that can be
removed for larger cups.
SIC1585A
SIC0553C
Instruments and controls
2-31


03.1.28/R50-D/V5


To open, pull the cup holder.
To close, fully push the cup holder.
GLOVE BOXWhen locking or unlocking the glove box, use
the master key.
The glove box may be opened by the handle.
WARNING
Keep glove box lid closed while driving
to help prevent injury in an accident or
during a sudden stop.
SIC1450
SIC1941
SIC1942
2-32
Instruments and controls


03.1.28/R50-D/V5


CONSOLE BOX
WARNING

The center console box should not be
used while driving so full attention
may be given to vehicle operation.

Keep the center console box lid
closed while driving to prevent injury
in an accident or sudden stop.
Do not place valuable items in the center
console box.
WARNING
Keep luggage side console box lids
closed securely while driving to prevent
injury in an accident or sudden stop.
Do not place valuable items in the luggage
side console box.
SIC0598
Instruments and controls
2-33


03.1.28/R50-D/V5


CAUTION

Make sure the luggage board closes
securely.
Do not drive with the board removed.

Properly secure all cargo to help pre-
vent it from sliding or shifting. Do not
place cargo higher than the seat-
backs. In a sudden stop or collision,
unsecured cargo could cause per-
sonal injury.

Never allow anyone to ride in the
luggage area or on the rear seat
when it is in the fold-down position.

It is extremely dangerous to ride in a
cargo area inside of a vehicle. In a
collision, people riding in these areas
are more likely to be seriously in-
jured or killed.

Do not allow people to ride in any
area of your vehicle that is not
equipped with seats and seat belts.
LUGGAGE HOOKSThe luggage hooks can be used to secure cargo
with ropes or other types of straps.
WARNING

Properly secure all cargo to help pre-
vent it from sliding or shifting. Do not
place cargo higher than the seat-
backs. In a sudden stop or collision,
unsecured cargo could cause per-
sonal injury.

Use the suitable ropes and hooks to
secure cargo.

Never allow anyone to ride in the
luggage area. It is extremely danger-
ous to ride in a cargo area inside of a
vehicle. In a collision, people riding in
these areas are more likely to be
seriously injured or killed.

Do not allow people to ride in any
area of your vehicle that is not
equipped with seats and seat belts.

Be sure everyone in your vehicle is in
a seat and using a seat belt properly.
SPA0346A
2-34
Instruments and controls


03.1.28/R50-D/V5


Side finisher
When hooking on ropes, do not apply a
load of more than 22 lb (98 N) to a single
hook.

Do not use the luggage net between the
A and B hooks.
Floor hooks
SPA0408A
SPA0365
