1. DVD entertainment system
(if so equipped) (P. 4-43)
2. Sunroof (if so equipped) (P. 2-47)
3. Map lights (P. 2-50)
4. Sun visors (P. 3-13)
5. HomeLinkT(P. 2-51)
6. Glove box (P. 2-36)
7. Seats (P. 1-2)
8. Armrest (P. 1-8)
9. Luggage storage (P. 2-40)
See the page number indicated in paren-
theses for operating details.
WII0050
PASSENGER COMPARTMENT
Illustrated table of contents0-5
ZREVIEW COPYÐ2005 Pathfinder(pat)
Owners ManualÐUSA_English(nna)
07/22/04Ðdebbie0
X
Page 12 of 336
1. Ventilators (P. 4-12)
2. Headlight/fog light (if so equipped)/
turn signal switch (P. 2-25)
3. Steering wheel switch for audio control
(if so equipped) (P. 4-42)
4. Driver supplemental air bag/horn
(P. 1-42, P. 2-30)
5. Meters, gauges and warning/indicator
lights (P. 2-3, 2-12)
6. Cruise control main/set switches
(P. 5-14)
7. Windshield wiper/washer switch and
rear window wiper/washer switch
(P. 2-23, P. 2-24)
8. Storage (P. 2-34)
9. Audio system controls (P. 4-24)
10. Front passenger supplemental air bag
(P. 1-42)
11. Glove box (P. 2-36)
12. Power outlet (P. 2-32)
13. Heated seat switch (if so equipped)
(P. 2-30)
14. Hill descent control (HDC) switch
(if so equipped) (P. 2-31)
15. Shift selector lever (P. 5-9)
16. Vehicle dynamic control (VDC) off
switch (P. 2-31)
LIC0758
INSTRUMENT PANEL
0-6Illustrated table of contents
ZREVIEW COPYÐ2005 Pathfinder(pat)
Owners ManualÐUSA_English(nna)
07/22/04Ðdebbie0
X
Page 13 of 336
17. 4WD shift switch (if so equipped)
(P. 5-17)
18. Climate controls (P. 4-13, 4-21)
19. Passenger air bag status light (P. 1-51)
20. Hazard lights (P. 2-29)
21. Ignition switch (P. 5-7)
22. Tilt steering wheel control (P. 3-12)
23. Pedal position adjustment switch
(P. 3-12)
24. Outside mirror controls (P. 3-15)
25. Navigation system and controls*
(if so equipped) (P. 4-2)
*: Refer to the separate Navigation System Own-
er’s Manual (if so equipped) .
See the page number indicated in paren-
theses for operating details.
Illustrated table of contents0-7
ZREVIEW COPYÐ2005 Pathfinder(pat)
Owners ManualÐUSA_English(nna)
07/22/04Ðdebbie0
X
Page 14 of 336
1. Windshield washer fluid reservoir
(P. 8-12)
2. Battery (P. 8-13)
3. Fuse/fusible link box (P. 8-22)
4. Engine oil filler cap (P. 8-8)
5. Engine oil dipstick (P. 8-8)
6. Brake fluid reservoir (P. 8-12)
7. Air cleaner (P. 8-16)
8. Radiator cap (P. 8-7)
9. Power steering fluid reservoir (P. 8-11)
10. Engine coolant reservoir (P. 8-7)
See the page number indicated in paren-
theses for operating details.
LDI0435
ENGINE COMPARTMENT CHECK
LOCATIONS
0-8Illustrated table of contents
ZREVIEW COPYÐ2005 Pathfinder(pat)
Owners ManualÐUSA_English(nna)
07/22/04Ðdebbie0
X
Page 15 of 336
Warning
lightName Page
or
Anti-lock brake
warning light2-13
Automatic
transmission oil
temperature
warning light
(
model)2-13
Automatic
transmission
park warning
light (
model)2-13
or
Brake warning
light2-14
Warning
lightName Page
Charge warning
light2-14
Door open
warning light2-14
Engine oil pres-
sure warning
light2-14
4WD warning
light (
model)2-15
Low fuel warn-
ing light2-15
Low tire pres-
sure warning
light2-15
Warning
lightName Page
Low windshield
washer fluid
warning light2-16
Seat belt warn-
ing light and
chime2-16
Supplemental
air bag warning
light2-17
WARNING/INDICATOR LIGHTS
Illustrated table of contents0-9
ZREVIEW COPYÐ2005 Pathfinder(pat)
Owners ManualÐUSA_English(nna)
07/22/04Ðdebbie0
X
Page 16 of 336
Indicator
lightName Page
Automatic
transmission
position indica-
tor light2-17
Cruise main
switch indicator
light2-17
Cruise set
switch indicator
light2-17
4WD shift indi-
cator light
(
model)2-17
Front passenger
air bag status
light2-18
Indicator
lightName Page
High beam in-
dicator light
(Blue)2-18
Hill Descent
Control (HDC)
indicator light
(if so equipped)2-31
Malfunction
indicator lamp
(MIL)2-18
Overdrive off
indicator light
(automatic
transmission
only)2-19
Security indica-
tor light (NVIS)2-19
Indicator
lightName Page
Slip indicator
light2-19
Transfer 4LO
position indica-
tor light
(
model)2-19
Turn
signal/hazard
indicator lights2-20
Vehicle dy-
namic control
off indicator
light2-20
0-10
Illustrated table of contents
ZREVIEW COPYÐ2005 Pathfinder(pat)
Owners ManualÐUSA_English(nna)
07/23/04Ðskoniecz
X
Page 17 of 336
1 Safety—Seats, seat belts and
supplemental restraint system
Seats............................................1-2
Front manual seat adjustment
(if so equipped)................................1-2
Front power seat adjustment
(if so equipped)................................1-4
2nd row bench seat adjustment..................1-5
Head restraint adjustment.......................1-7
Active head restraint (front seats).................1-7
Armrest.......................................1-8
Flexible seating.................................1-8
Seat belts.......................................1-12
Precautions on seat belt usage..................1-12
Child safety...................................1-14
Pregnant women..............................1-16
Injured persons................................1-16
Three-point type seat belt with retractor..........1-16
Seat belt extenders............................1-19
Seat belt maintenance.........................1-19Child restraints...................................1-20
Precautions on child restraints..................1-20
Child restraint installation on 2nd row bench
seats.........................................1-22
Child restraint installation on 3rd row bench
seat..........................................1-27
LATCH (Lower Anchors and Tethers for
CHildren) system..............................1-32
Top tether strap child restraint..................1-33
Child restraint installation on front passenger
seat..........................................1-34
Booster seats....................................1-37
Precautions on booster seats...................1-37
Supplemental restraint system.....................1-42
Precautions on supplemental restraint
system.......................................1-42
Supplemental air bag warning labels.............1-56
Supplemental air bag warning light..............1-57
ZREVIEW COPYÐ2005 Pathfinder(pat)
Owners ManualÐUSA_English(nna)
07/22/04Ðdebbie0
X
Page 18 of 336
WARNING
cDo not ride in a moving vehicle when
the seatback is reclined. This can be
dangerous. The shoulder belt will not
be against your body. In an accident,
you could be thrown into it and receive
neck or other serious injuries. You
could also slide under the lap belt and
receive serious internal injuries.cFor the most effective protection when
the vehicle is in motion, the seat should
be upright. Always sit well back in the
seat and adjust the seat properly. See
“Precautions on Seat Belt Usage” later
in this section.
FRONT MANUAL SEAT
ADJUSTMENT (if so equipped)
WARNING
cDo not adjust the driver’s seat while
driving so full attention may be given to
vehicle operation. The seat may move
suddenly and could cause loss of con-
trol of the vehicle.
cAfter adjustment, gently rock in the seat
to make sure it is securely locked.
ARS1152
SEATS
1-2Safety—Seats, seat belts and supplemental restraint system
ZREVIEW COPYÐ2005 Pathfinder(pat)
Owners ManualÐUSA_English(nna)
07/22/04Ðdebbie0
X
Page 19 of 336
