HEADLAMP Ð Daytime Light System Ð
Wiring Diagram Ð DTRL Ð (Cont'd)
EL-3045

Wiring Diagram Ð TAIL/L Ð/Type A
Rear combination lamps are not located on rear bumper.
TEL752M
PARKING, LICENSE AND TAIL LAMPS
EL-3046

TEL212M
PARKING, LICENSE AND TAIL LAMPS
Wiring Diagram Ð TAIL/L Ð/Type A (Cont'd)
EL-3047

Wiring Diagram Ð TAIL/L Ð/Type B
LHD MODELS FOR EUROPERear combination lamps are located on rear bumper.
TEL658M
PARKING, LICENSE AND TAIL LAMPS
EL-3048

TEL213M
PARKING, LICENSE AND TAIL LAMPS
Wiring Diagram Ð TAIL/L Ð/Type B (Cont'd)
EL-3049

Wiring Diagram Ð TAIL/L Ð/Type C
RHD MODELS FOR EUROPERear combination lamps are located on rear bumper.
TEL753M
PARKING, LICENSE AND TAIL LAMPS
EL-3050

TEL394M
PARKING, LICENSE AND TAIL LAMPS
Wiring Diagram Ð TAIL/L Ð/Type C (Cont'd)
EL-3051

Wiring Diagram Ð F/FOG Ð/For Israel
TEL754M
FRONT FOG LAMP
EL-3052

Wiring Diagram Ð F/FOG Ð/RHD Models for
Europe
TEL755M
FRONT FOG LAMP
EL-3053

Wiring Diagram Ð F/FOG Ð/LHD Models for
Europe
TEL813M
FRONT FOG LAMP
EL-3054
