NISSAN QUEST 1998 V40 / 1.G Owners Manual

Due to legal requirements in some states
and Canadian Provinces, your vehicle may
be required to be in the ready condition for
an Inspection/Maintenance (I/M) test of the
emission control system.
The vehicle is set to the ready condition
when it is driven through certain driving pat-
terns. Usually, the ready condition can be
obtained by ordinary usage of the vehicle.
If a powertrain system component is repaired
or the battery is disconnected, the vehicle
may be reset to a not ready condition. Before
taking the I/M test, drive the vehicle through
the following pattern to set the vehicle to the
ready condition. If you cannot or do not want
to perform the driving pattern, an authorized
NISSAN dealer can conduct it for you.
WARNING
Always drive the vehicle in a safe man-
ner according to traffic conditions and
obey all traffic laws.
1. Start the engine when the engine coolant
temperature gauge needle points to C.
Allow the engine to idle until the gauge
needle points between the C and H (nor-
mal operating temperature).2. Accelerate the vehicle to 55 MPH (88
km/h), then quickly release the accelera-
tor pedal completely and keep it released
for at least 6 seconds.
3. Quickly depress the accelerator pedal for
a moment, then drive the vehicle at a
speed of 53 to 60 MPH (86 to 96 km/h)
for at least 5 minutes.
4. Stop the vehicle.
5. Accelerate the vehicle to 35 mph (55
km/h) and maintain the speed for 20
seconds.
6. Repeat steps four through five at least
three times.
7. Accelerate the vehicle to 55 mph (88
km/h) and maintain the speed for at least
3 minutes.
8. Stop the vehicle and turn the engine off.
9. Repeat steps one through eight at least
one more time.
If step one through seven are interrupted,
repeat the preceding step. Any safe driving
mode is acceptable between steps. Do not
stop the engine until step seven is com-
pleted.
READINESS FOR
INSPECTION/MAINTENANCE
(I/M) TEST
10-20Technical and consumer information
ZX

A Genuine NISSAN Service Manual is the best
source of service and repair information for
your vehicle. Filled with wiring diagrams, illus-
trations and step-by-step diagnostic and ad-
justment procedures, this manual is the same
one used by the factory trained technicians
working at an authorized NISSAN dealership.
Also available are Genuine NISSAN Owner's
Manuals.
For current pricing and availability of a Genu-
ine NISSAN Service Manual or Genuine NIS-
SAN Owner's Manual, contact:
In the USA:
See an authorized NISSAN dealer or contact:
Dyment Distribution Services
20770 Westwood Dr.
Strongsville OH 44136
In a hurry? Call 1-800-247-5321 and charge
your purchase to Visa/Master Card.
In Canada:
To purchase a copy of a Genuine NISSAN
Service Manual or Owner's Manual please
contact your nearest NISSAN Dealer. For the
phone number and location of a NISSAN
Dealer in your area call the NISSAN Satisfac-
tion Center at 1-800-387-0122 and a bilingual
NISSAN representative will assist you.
Also available are Genuine NISSAN Service
and Owner's Manuals for older NISSAN mod-
els.
Technical and consumer information10-21
ZX

MEMO
10-22Technical and consumer information
ZX

11 Index
A
After an accident........................................ 6-11
Air bag (See supplemental restraint
system) ...................................................... 1-18
Air bag warning light .................................. 1-23
Air cleaner housing filter ............................ 8-13
Air conditioner
Air conditioner operation ............... 4-20, 4-5
Air conditioner service .......................... 4-14
Air conditioner specification label ....... 10-11
Air conditioner system refrigerant and
lubrication recommendations ................ 10-6
Heater and air conditioner (automatic)
(if so equipped)..................................... 4-10
Heater and air conditioner (manual)....... 4-3
Rear seat heater and air conditioner ... 4-13
Air flow charts .............................................. 4-7
Alarm system (See theft warning) ............. 2-10
Anchor point locations ............................... 1-53
Antenna
Manual .................................................. 4-20
Power.................................................... 4-20
Anti-lock brake system (ABS).................... 5-15
Anti-lock brake warning light ....................... 2-8
Armrests....................................................... 1-6
Ashtray (See cigarette lighter and
ashtray) ...................................................... 2-16Audio system
AM-FM radio with cassette player ........ 4-14
Compact disc (CD) player .................... 4-21
Autolamp switch......................................... 2-14
Automatic
Automatic power window switch .......... 2-21
Automatic transmission fluid (ATF) ........ 8-8
Driving with automatic transmission ....... 5-5
B
Battery........................................................ 8-11
Before starting the engine ........................... 5-5
Brake
Anti-lock brake system (ABS) .............. 5-15
Brake booster ....................................... 8-18
Brake fluid ................................... 10-2, 8-10
Brake light (See stop light) ................... 8-22
Brake pedal .......................................... 8-17
Brake system ........................................ 5-14
Brake warning light ................................. 2-7
Brake wear indicators ............................. 2-9
Parking brake check ............................. 8-16
Parking brake operation ......................... 5-9
Self-adjusting brakes ............................ 8-17
Break-in schedule ...................................... 5-11
Bulb check/instrument panel ....................... 2-6
Bulb replacement ....................................... 8-22C
Capacities and recommended fuel/
lubricants.................................................... 10-2
Cargo net ................................................... 3-14
Cargo (See vehicle loading
information) .............................................. 10-12
Cassette player (See audio system) ......... 4-14
CB radio or car phone ............................... 4-25
Check engine indicator light
(See malfunction indicator light) .................. 2-9
Child restraint with top tether strap ........... 1-49
Child restraints ........................................... 1-39
Child safety sliding door lock....................... 3-5
Cigarette lighter (accessory)
and ashtray ................................................ 2-16
Cleaning exterior and interior ...................... 7-2
Clock .......................................................... 2-23
Coin tray .................................................... 2-18
Cold weather driving .................................. 5-16
Compact disc (CD) player ......................... 4-21
Controls
Audio controls ....................................... 4-14
Audio controls (rear) ............................. 4-24
Audio controls (steering wheel) ............ 4-23
Heater and air conditioner controls
(automatic) ............................................ 4-10
Heater and air conditioner controls
(manual).................................................. 4-3
ZX

Rear seat heater and air conditioner
controls ................................................. 4-13
Coolant
Capacities and recommended fuel/
lubricants .............................................. 10-2
Changing engine coolant........................ 8-5
Checking engine coolant level ............... 8-4
Engine coolant temperature gauge ........ 2-4
Cornering light ........................................... 2-15
Corrosion protection .................................... 7-4
Cruise control............................................... 5-9
Cup holder ................................................. 2-19
D
Daytime running light system
(Canada only) ............................................ 2-13
Defogger switch
Rear window defogger switch .............. 2-13
Dimensions and weights............................ 10-8
Door ajar warning light ................................ 2-7
Door locks .................................................... 3-2
Drive belts .................................................. 8-12
Driving
Cold weather driving............................. 5-16
Driving with automatic transmission ....... 5-5
Precautions when starting and driving ... 5-2
E
Economy - fuel........................................... 5-12Emission control information label........... 10-10
Emission control system warranty ........... 10-19
Engine
Before starting the engine ...................... 5-5
Capacities and recommended fuel/
lubricants .............................................. 10-2
Changing engine coolant........................ 8-5
Changing engine oil................................ 8-6
Changing engine oil filter........................ 8-7
Checking engine coolant level ............... 8-4
Checking engine oil level ....................... 8-5
Engine compartment check locations .... 8-3
Engine coolant temperature gauge ........ 2-4
Engine cooling system ........................... 8-4
Engine oil ................................................ 8-5
Engine oil and oil filter
recommendation ................................... 10-4
Engine oil pressure warning light ........... 2-6
Engine oil viscosity ............................... 10-5
Engine serial number ........................... 10-9
Starting the engine ................................. 5-8
Exhaust gas (Carbon monoxide) ................. 5-2
F
Five passenger seating ............................. 1-66
Five passenger seating with cargo room .. 1-66
Flashers (See hazard warning flasher
switch) ........................................................ 2-16
Flat tire ......................................................... 6-2
Flexible seating ............................................ 1-8
Floor mat positioning ........................ 1-65, 1-68Floor mat positioning aid ........................... 1-68
Fluid
Automatic transmission fluid (ATF) ........ 8-8
Brake fluid ................................... 10-2, 8-10
Capacities and recommended fuel/
lubricants .............................................. 10-2
Engine coolant ........................................ 8-4
Engine oil ................................................ 8-5
Power steering fluid ...................... 10-2, 8-9
Window washer fluid ............................ 8-10
F.M.V.S.S. certification label ................... 10-10
Fuel
Capacities and recommended fuel/
lubricants .............................................. 10-2
Fuel economy ....................................... 5-12
Fuel filler lid and cap ............................ 3-16
Fuel filler lid lock opener lever ............. 3-16
Fuel gauge.............................................. 2-5
Fuel octane rating................................. 10-3
Fuel recommendation ........................... 10-2
Fuses ......................................................... 8-18
G
Gauge
Engine coolant temperature gauge ........ 2-4
Fuel gauge.............................................. 2-5
Odometer ................................................ 2-4
Speedometer .......................................... 2-4
Tachometer............................................. 2-4
Trip odometer ......................................... 2-4
General maintenance .................................. 9-2
11-2
ZX

H
Hazard warning flasher switch .................. 2-16
Head restraints ............................................ 1-6
Headlight control switch............................. 2-13
Headlights .................................................. 8-20
Heater
Heater and air conditioner (automatic)
(if so equipped)..................................... 4-10
Heater and air conditioner (manual)....... 4-3
Rear seat heater and air conditioner ... 4-13
Hood release ............................................. 3-11
I
Ignition switch .............................................. 5-4
Important vehicle information label.......... 10-10
Increasing fuel economy............................ 5-12
Indicator lights and chimes (See warning/
indicator lights and chimes) ......................... 2-6
Inertial fuel shut off switch ......................... 6-11
Inside mirror ............................................... 3-18
Instrument brightness control .................... 2-15
Integrated child safety seats...................... 1-57
Interior lights .............................................. 2-24
J
Jump starting ...................................... 6-8, 8-12K
Key ............................................................... 3-2
Keyless entry system (See multi-remote
control system) ............................................ 3-8
L
Labels
Air conditioner specification label ....... 10-11
Emission control information label...... 10-10
Engine serial number ........................... 10-9
F.M.V.S.S. certification label .............. 10-10
Vehicle identification number (VIN) ...... 10-9
Vehicle identification number (VIN)
plate ...................................................... 10-9
Warning labels (for SRS) ..................... 1-23
License plate
Installing the license plate .................. 10-11
Light
Air bag warning light............................. 1-23
Brake light (See stop light) ................... 8-22
Bulb check/instrument panel .................. 2-6
Bulb replacement.................................. 8-22
Cornering light ...................................... 2-15
Headlight control switch ....................... 2-13
Headlights ............................................. 8-20
Interior lights ......................................... 2-24
Light bulbs ............................................ 8-20
Luggage compartment lights ................ 2-24
Spotlights (See map light) .................... 2-25Warning/indicator lights and chimes ...... 2-6
Lock
Child safety sliding door lock ................. 3-5
Door locks............................................... 3-2
Fuel filler lid lock opener lever ............. 3-16
Power door lock...................................... 3-6
Rear door lock ...................................... 3-12
Luggage compartment lights ..................... 2-24
Luggage rack ............................................. 3-15
Luggage (See vehicle loading
information ............................................... 10-12
M
Maintenance
General maintenance ............................. 9-2
Inside the vehicle.................................... 9-3
Maintenance precautions ....................... 8-2
Outside the vehicle ................................. 9-2
Periodic maintenance schedules ............ 9-5
Seat belt maintenance.......................... 1-38
Under the hood and vehicle ................... 9-4
Malfunction indicator light ............................ 2-9
Manual antenna ......................................... 4-20
Manual front seat adjustment ...................... 1-3
Manual rear windows................................. 2-22
Map light .................................................... 2-25
Mirror
Inside mirror.......................................... 3-18
Outside mirror control ........................... 3-17
Outside mirrors ..................................... 3-18
Vanity mirror ......................................... 3-19
11-3
ZX

Multi-remote control system ........................ 3-8
O
Odometer ..................................................... 2-4
Oil
Capacities and recommended fuel/
lubricants .............................................. 10-2
Changing engine oil................................ 8-6
Changing engine oil filter........................ 8-7
Checking engine oil level ....................... 8-5
Engine oil ................................................ 8-5
Engine oil and oil filter
recommendation ................................... 10-4
Engine oil viscosity ............................... 10-5
Outside mirror control ................................ 3-17
Outside mirrors .......................................... 3-18
Overdrive switch .......................................... 5-7
Overheat
If your vehicle overheats ...................... 6-10
Owner's manual order form ..................... 10-21
P
Parking
Parking brake check ............................. 8-16
Parking brake operation ......................... 5-9
Parking/parking on hills ........................ 5-13
Periodic maintenance schedules ................. 9-5
Personal reading light ................................ 2-25Power
Power antenna ..................................... 4-20
Power door lock...................................... 3-6
Power rear windows ............................. 2-23
Power steering fluid ...................... 10-2, 8-9
Power support front seat ........................ 1-4
Power windows..................................... 2-20
Precautions
Maintenance precautions ....................... 8-2
Precautions on seat belt usage............ 1-25
Precautions when starting and driving ... 5-2
Push starting .............................................. 6-10
R
Radio
AM-FM radio with cassette player ........ 4-14
CB radio or car phone .......................... 4-25
Readiness for inspection maintenance
(I/M) test................................................... 10-20
Rear door ................................................... 3-12
Rear door lock ........................................... 3-12
Rear power point ....................................... 2-17
Rear seat heater and air conditioner......... 4-13
Rear window defogger switch ................... 2-13
Rear window wiper and washer switches . 2-12
Refrigerant recommendation ..................... 10-6
Registering your vehicle in another
country ....................................................... 10-9
Remote keyless entry system (See
multi-remote control system) ....................... 3-8Removing and installing the second row
bench seat ................................................... 1-8
Reporting safety defects (USA) ............... 10-19
S
Safety
Child safety sliding door lock ................. 3-5
Reporting safety defects (USA) .......... 10-19
Seat belt
2-point type without retractor................ 1-36
3-point type with retractor ........... 1-28, 1-31
Precautions on seat belt usage............ 1-25
Seat belt extenders .............................. 1-38
Seat belt maintenance.......................... 1-38
Seat belts.............................................. 1-25
Seat belt warning light ................................. 2-7
Seat positions ............................................ 1-69
Seating arrangements ............................... 1-64
Seats
Five passenger seating ........................ 1-66
Five passenger seating with cargo
room...................................................... 1-66
Flexible seating....................................... 1-8
Integrated child safety seats ................ 1-57
Manual front seat adjustment ................. 1-3
Power support front seat ........................ 1-4
Seat positions ....................................... 1-69
Second row bench seat........................ 1-69
Second row bucket seats ..................... 1-72
Seven passenger seating ..................... 1-65
Sliding three-passenger seat................ 1-14
11-4
ZX

Three-passenger bench seat in fully
forward position .................................... 1-67
Three-passenger bench seat in storage
position ................................................. 1-65
Seats/floor mats ......................................... 1-64
Self-adjusting brakes ................................. 8-17
Service manual order form ...................... 10-21
Seven passenger seating .......................... 1-65
Shifting
Automatic transmission .......................... 5-6
Sliding three-passenger seat ..................... 1-14
Spark plug replacement............................. 8-12
Speedometer ............................................... 2-4
Spotlights (See map light) ......................... 2-25
SRS warning label ..................................... 1-23
Starting
Before starting the engine ...................... 5-5
Jump starting................................. 6-8, 8-12
Precautions when starting and driving ... 5-2
Push starting......................................... 6-10
Starting the engine ................................. 5-8
Steering
Power steering fluid ...................... 10-2, 8-9
Tilting steering wheel............................ 3-17
Stop light .................................................... 8-22
Storage
Coin tray ............................................... 2-18
Compact disc storage........................... 2-18
Under seat storage tray.......................... 1-7
Sun shade.................................................. 2-22
Sunroof ...................................................... 2-22Supplemental restraint system
Information and warning labels ............ 1-23
Switch
Autolamp switch ................................... 2-14
Automatic power window switch .......... 2-21
Hazard warning flasher switch ............. 2-16
Headlight control switch ....................... 2-13
Ignition switch ......................................... 5-4
Overdrive switch ..................................... 5-7
Rear window defogger switch .............. 2-13
Rear window wiper and washer
switches ................................................ 2-12
Turn signal switch................................. 2-15
Windshield wiper and washer switch ... 2-11
T
Tabletop seats ............................................. 1-7
Tachometer .................................................. 2-4
Theft warning ............................................. 2-10
Three way catalyst....................................... 5-2
Three-passenger bench seat..................... 1-34
Three-passenger bench seat in fully
forward position ......................................... 1-67
Three-passenger bench seat in storage
position....................................................... 1-65
Tilting steering wheel ................................. 3-17
Timing belt ................................................. 10-7
Timing chain .............................................. 10-7
Tire
Flat tire.................................................... 6-2
Spare tire .............................................. 8-30Tire chains ............................................ 8-28
Tire placard......................................... 10-11
Tire pressure ........................................ 8-26
Tire rotation .......................................... 8-28
Tool kit .................................................... 6-2
Types of tires ........................................ 8-27
Uniform tire quality grading ................ 10-18
Wheels and tires ......................... 10-8, 8-26
Wheel/tire size ...................................... 10-8
Towing
Tow truck towing .................................. 6-12
Towing load/specification chart .......... 10-14
Trailer towing ...................................... 10-13
Transmission
Automatic transmission fluid (ATF) ........ 8-8
Driving with automatic transmission ....... 5-5
Travel (See registering your vehicle in
another country)......................................... 10-9
Trip odometer .............................................. 2-4
Turn signal switch ...................................... 2-15
U
Under seat storage tray ............................... 1-7
Uniform tire quality grading ..................... 10-18
V
Vanity mirror .............................................. 3-19
Vehicle dimensions and weights ............... 10-8
Vehicle identification .................................. 10-9
11-5
ZX

Vehicle identification number (VIN) ........... 10-9
Vehicle identification number (VIN) plate .. 10-9
Vehicle loading information ..................... 10-12
Vehicle recovery ........................................ 6-14
Ventilators .................................................... 4-2
W
Warning
Air bag warning light............................. 1-23
Hazard warning flasher switch ............. 2-16
Theft warning ........................................ 2-10
Warning labels (for SRS) ..................... 1-23
Warning/indicator lights and chimes ...... 2-6
Weights (See dimensions and weights) .... 10-8
Wheels and tires .............................. 10-8, 8-26
Wheel/tire size ........................................... 10-8
When traveling or registering your vehicle
in another country ...................................... 10-9
Window washer fluid.................................. 8-10
Windows
Locking passengers' windows .............. 2-21
Manual rear windows ........................... 2-22
Power rear windows ............................. 2-23
Power windows..................................... 2-20
Windshield wiper and washer switch ........ 2-11
Wiper
Rear window wiper and washer
switches ................................................ 2-12
Windshield wiper and washer switch ... 2-11
Wiper blades......................................... 8-15
11-6
ZX

Recommended fuel:
Unleaded gasoline, at least 87 AKI number
(RON 91).
For further details such as gasohol, see
``Fuel recommendation'' in the ``Technical
and consumer information'' section.
Recommended engine oil:
cAPI SG or SH and Energy Conserving II
cAPI Certification Mark
cSAE 5W-30 viscosity oil is preferred for
all ambient temperatures
See ``Engine oil and oil filter recommenda-
tion'' in the ``Technical and consumer infor-
mation'' section.
Cold tire pressure:
See tire placard affixed to the glove com-
partment lid.
Recommended new vehicle
break-in procedure:
During the first 1,000 miles (1,600 km) of
vehicle use, follow the recommendations
outlined in the ªBreak-in schedule'' informa-
tion found in the ªStarting and Drivingº sec-
tion of this Owner's Manual. Follow these
recommendations for the future reliability
and economy of your new vehicle. Failure to
follow these recommendations may result in
vehicle damage or shortened engine life.
AGS1009
GAS STATION INFORMATION QUICK REFERENCE
ZX
