GUID-BBB6864C-5D35-4D32-83EC-7A21C24B6795Welcome to the growing family of new NISSAN
owners. This vehicle is delivered to you with
confidence. It was produced using the latest
techniques and strict quality control.
This manual was prepared to help you under-
stand the operation and maintenance of your
vehicle so that you may enjoy many miles of
driving pleasure. Please read through this
manual before operating your vehicle.
A separate Warranty Information Booklet
explains details about the warranties cov-
ering your vehicle. The NISSAN Service
and Maintenance Guide explains details
about maintaining and servicing your ve-
hicle. Additionally, a separate Customer
Care/Lemon Law Booklet (U.S. only) will
explain how to resolve any concerns you
may have with your vehicle, as well as
clarify your rights under your state's lemon
law.
In addition to factory installed options, your
vehicle may also be equipped with additional
accessories installed by NISSAN or by your
NISSAN dealer prior to delivery. It is important
that you familiarize yourself with all disclosures,
warnings, cautions and instructions concerning
proper use of such accessories prior to operat-
ing the vehicle and/or accessory. See a NISSAN
dealer for details concerning the particularaccessories with which your vehicle is
equipped.
Your NISSAN dealer knows your vehicle best.
When you require any service or have any
questions, we will be glad to assist you with the
extensive resources available to us.
READ FIRST Ð THEN DRIVE SAFELYGUID-3EE2C5B3-F285-42A0-BC62-E4250F14B6F9Before driving your vehicle, read your Owner's
Manual carefully. This will ensure familiarity with
controls and maintenance requirements, assist-
ing you in the safe operation of your vehicle.
WARNING
IMPORTANT SAFETY INFORMATION
REMINDERS!
Follow these important driving rules to
help ensure a safe and comfortable trip
for you and your passengers!
.
NEVER drive under the influence of
alcohol or drugs.
. ALWAYS observe posted speed lim-
its and never drive too fast for
conditions.
. ALWAYS give your full attention to
driving and avoid using vehicle
features or taking other actions that could distract you.
. ALWAYS use your seat belts and
appropriate child restraint systems.
Pre-teen children should be seated
in the rear seat.
. ALWAYS provide information about
the proper use of vehicle safety
features to all occupants of the
vehicle.
. ALWAYS review this Owner's Man-
ual for important safety information.
MODIFICATION OF YOUR VEHI-
CLE
This vehicle should not be modified.
Modification could affect its performance,
safety or durability, and may even violate
governmental regulations. In addition,
damage or performance problems result-
ing from modification may not be covered
under NISSAN warranties.
Foreword
& R Q G L W L R Q
Page 3 of 503
> ( G L W 0 R G H O 0 < 1 , 6 6 $ 1 4 8 ( 6 7 ( 2 0 ( ( 8 @
WHEN READING THE MANUALGUID-26389A99-6692-4D0B-97B2-F12F4CFB8CB3This manual includes information for all
features and equipment available on this
model. Features and equipment in your
vehicle may vary depending on model, trim
level, options selected, order, date of
production, region or availability. There-
fore, you may find information about
features or equipment that are not in-
cluded or installed on your vehicle.
All information, specifications and illustrations in
this manual are those in effect at the time of
printing. NISSAN reserves the right to change
specifications, performance, design or compo-
nent suppliers without notice and without
obligation. From time to time, NISSAN may
update or revise this manual to provide owners
with the most accurate information currently
available. Please carefully read and retain with
this manual all revision updates sent to you by
NISSAN to ensure you have access to accurate
and up-to-date information regarding your ve-
hicle. Current versions of vehicle Owner's
Manuals and any updates can also be found in
the Owner section of the NISSAN website at
https://owners.nissanusa.com/nowners/naviga-
tion/manualsGuide. If you have questions con-
cerning any information in your Owner's Manual,
contact NISSAN Consumer Affairs. See the
NISSAN CUSTOMER CARE PROGRAM pagein this Owner's Manual for contact information.IMPORTANT INFORMATION ABOUT
THIS MANUAL
GUID-B9D90C05-70E2-4BAB-AC22-B2C9211BEF84You will see various symbols in this manual. They
are used in the following ways:
WARNING
This is used to indicate the presence of
a hazard that could cause death or
serious personal injury. To avoid or
reduce the risk, the procedures must
be followed precisely.
CAUTION
This is used to indicate the presence of
a hazard that could cause minor or
moderate personal injury or damage to
your vehicle. To avoid or reduce the risk,
the procedures must be followed care-
fully.
SIC0697
If you see the symbol above, it means
ªDo not
do thisº orªDo not let this happenº .
NOS1274
If you see a symbol similar to those above in an
illustration, it means the arrow points to the front
of the vehicle.
NOS1275
Arrows in an illustration that are similar to those
above indicate movement or action.
NOS1276
Arrows in an illustration that are similar to those
& R Q G L W L R Q
Page 4 of 503
> ( G L W 0 R G H O 0 < 1 , 6 6 $ 1 4 8 ( 6 7 ( 2 0 ( ( 8 @
above call attention to an item in the illustration.
CALIFORNIA PROPOSITION 65
WARNING
GUID-6C4EBC4A-66AB-4839-A9FC-C3F79F7108BF
WARNING
Engine exhaust, some of its constitu-
ents, and certain vehicle components
contain or emit chemicals known to the
State of California to cause cancer and
birth defects or other reproductive
harm. In addition, certain fluids con-
tained in vehicles and certain products
of component wear contain or emit
chemicals known to the State of Cali-
fornia to cause cancer and birth defects
or other reproductive harm.
CALIFORNIA PERCHLORATE ADVI-
SORY
GUID-8DB94B75-33FC-4B79-AE4A-39E93704B9ACSome vehicle parts, such as lithium bat-
teries, may contain perchlorate material.
The following advisory is provided: ªPer-
chlorate Material - special handling may
apply, see www.dtsc.ca.gov/
hazardouswaste/perchlorate.º
Bluetooth
Page 5 of 503
> ( G L W 0 R G H O 0 < 1 , 6 6 $ 1 4 8 ( 6 7 ( 2 0 ( ( 8 @
GUID-5FD98714-5A88-4E0D-9460-A8E61DCF9CABNISSAN CARES ...
Both NISSAN and your NISSAN dealer are dedicated to serving all your automotive needs. Your satisfaction with your vehicle and your NISSAN dealer are
our primary concerns. Your NISSAN dealer is always available to assist you with all your automobile sales and service needs.
We appreciate your interest in NISSAN and thank you for buying a quality NISSAN vehicle.
However, if there is something that your
NISSAN dealer cannot assist you with or you
would like to provide NISSAN directly with
comments or questions, please contact the
NISSAN Consumer Affairs Department using
our toll-free number:For U.S. customers1-800-NISSAN-1
(1-800-647-7261)
For Canadian customers 1-800-387-0122
The Consumer Affairs Department will ask for
the following information:
. Your name, address, and telephone number
. Vehicle identification number (attached to
the top of the instrument panel on the
driver's side)
. Date of purchase
. Current odometer reading
. Your NISSAN dealer's name
. Your comments or questions
OR You can write to NISSAN with the information at:
For U.S. customersNissan North America, Inc.
Consumer Affairs Department
P.O. Box 685003
Franklin, TN 37068-5003
or via e-mail at:
[email protected]
For Canadian customers Nissan Canada Inc.
5290 Orbitor Drive
Mississauga, Ontario L4W 4Z5
or via e-mail at:
information.centre@nissancanada.
com If you prefer, visit us at:
www.nissanusa.com(for U.S. customers) or
www.nissan.ca(for Canadian customers)
We appreciate your interest in NISSAN and
thank you for buying a quality NISSAN vehicle.
NISSAN CUSTOMER CARE
PROGRAM
& R Q G L W L R Q
Page 6 of 503
Page 7 of 503
Illustrated table of contents0
Safety Ð Seats, seat belts and supplemental
restraint system1
Instruments and controls
Pre-driving checks and adjustments
Monitor, heater, air conditioner, audio, phone and
voice recognition systems
Starting and driving
In case of emergency
Appearance and care
Maintenance and do-it-yourself
Technical and consumer information
Index
2
3
4
5
6
7
8
9
10
Table of
Contents
> ( G L W 0 R G H O 0 < 1 , 6 6 $ 1 4 8 ( 6 7 ( 2 0 ( ( 8 @ & R Q G L W L R Q
Page 8 of 503
Page 9 of 503
> ( G L W 0 R G H O 0 < 1 , 6 6 $ 1 4 8 ( 6 7 ( 2 0 ( ( 8 @
0 Illustrated table of contents
Seats, seat belts and supplemental restraint
system (SRS)...
........................................................................\
..... 0-2
Exterior front ...
........................................................................\
....... 0-3
Exterior rear ...
........................................................................\
........ 0-4
Passenger compartment ...
......................................................... 0-5
Cockpit ...
........................................................................\
................ 0-6 Instrument panel
...
....................................................................... 0-7
Meters and gauges ...
.................................................................. 0-8
Engine compartment ...
............................................................... 0-9
VQ35DE engine ...
................................................................ 0-9
Warning and indicator lights ...
.............................................. 0-10
& R Q G L W L R Q
Page 10 of 503
> ( G L W 0 R G H O 0 < 1 , 6 6 $ 1 4 8 ( 6 7 ( 2 0 ( ( 8 @
0-2Illustrated table of contents
GUID-68248295-5813-4B86-A730-DE82FCE28570
SSI0820
1. Non-adjustable head restraints/headrests (Page1-10)
2. Child restraint anchor points (for top tether strap child restraint) (P.1-32)
3. Seat belt for 3rd row center seat (P.1-20)
4. Seat belts (P.1-15) 5. Roof-mounted curtain side-impact supplemental
air bags (P.1-49)
6. Adjustable head restraints (P.1-10) Ð Front-seat Active Head Restraints (P.1-14)
7. Supplemental front-impact air bags (P.1-49)
8. LATCH (Lower Anchors and Tethers for CHil- dren) system (P.1-29) 9. 3rd row seats (P.1-7)
Ð Child restraints (P.1-27)
10. Armrest (2nd row seat) (P.1-7)
11. 2nd row seats (P.1-6)
Ð Child restraints (P.1-27)
12. Front seat-mounted side-impact supplemental air bags (P.1-49)
13. Seat belt pretensioner (P.1-63)
14. Front seats (P.1-3) Ð Occupant classification sensors (weight
sensors) (P.1-55)
SEATS, SEAT BELTS AND
SUPPLEMENTAL RESTRAINT
SYSTEM (SRS)
