NISSAN TEANA 2003 Service Manual

SERVICE DATA AND SPECIFICATIONS (SDS)
EM-263
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM

*3 Machining data
Valve Spring
*: Exhaust side valve spring for VQ23DE has a parallel setting.Engine VQ23DE VQ35DE
Position Intake Exhaust* Intake Exhaust
Free height47.15 mm
(1.8563 in)52.28 mm
(2.0583 in)52.31 mm
(2.0594 in)47.07 mm
(1.8531 in)
Installation height37.00 mm
(1.4567 in)37.00 mm
(1.4567 in)37.00 mm
(1.4567 in)37.00 mm
(1.4567 in)
Installation load166 - 188 N
(16.9 - 19.2 kg,
37 - 42 lb)153 - 173 N
(15.6 - 17.6 kg,
34 - 39 lb)153 - 173 N
(15.6 - 17.6 kg,
34 - 39 lb)166 - 188 N
(16.9 - 19.2 kg,
37 - 42 lb)
Height during valve open27.20 mm
(1.0709 in)29.25 mm
(1.1516 in)29.25 mm
(1.1516 in)27.20 mm
(1.0709 in)
Load with valve open373 - 421 N
(38.0 - 42.9 kg,
84 - 95 lb)276 - 312 N
(28.1 - 31.8 kg,
62 - 70 lb)276 - 312 N
(28.1 - 31.8 kg,
62 - 70 lb)373 - 421 N
(38.0 - 42.9 kg,
84 - 95 lb)
Squareness 2.1 mm (0.083 in) 2.3 mm (0.091 in) 2.3 mm (0.091 in) 2.1 mm (0.083 in)

EM-264
[VQ]
SERVICE DATA AND SPECIFICATIONS (SDS)

CYLINDER BLOCK
Unit: mm (in)
EngineVQ23DE VQ35DE
Surface distortionStandard 0.03 (0.0012)
Limit 0.1 (0.004)
Main bearing housing inner diameter Standard 63.993 - 64.017 (2.5194 - 2.5203)
Cylinder bore Inner diameterStandardGrade No. 185.000 - 85.010
(3.3465 - 3.3468)95.500 - 95.510
(3.7598 - 3.7602)
Grade No. 285.010 - 85.020
(3.3468 - 3.3472)95.510 - 95.520
(3.7602 - 3.7606)
Grade No. 385.020 - 85.030
(3.3472 - 3.3476)95.520 - 95.530
(3.7606 - 3.7610)
Wear limit 0.2 (0.008)
Out-of-round (Difference between “X” and “Y”)
Limit0.015 (0.0006)
Taper (Difference between “A” and “C”) 0.01 (0.0004)
Main bearing housing inner diameter (Without bearing)Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W
Grade No. X
Grade No. Y
Grade No. 4
Grade No. 763.993 - 63.994 (2.5194 - 2.5194)
63.994 - 63.995 (2.5194 - 2.5195)
63.995 - 63.996 (2.5195 - 2.5195)
63.996 - 63.997 (2.5195 - 2.5196)
63.997 - 63.998 (2.5196 - 2.5196)
63.998 - 63.999 (2.5196 - 2.5196)
63.999 - 64.000 (2.5196 - 2.5197)
64.000 - 64.001 (2.5197 - 2.5197)
64.001 - 64.002 (2.5197 - 2.5198)
64.002 - 64.003 (2.5198 - 2.5198)
64.003 - 64.004 (2.5198 - 2.5198)
64.004 - 64.005 (2.5198 - 2.5199)
64.005 - 64.006 (2.5199 - 2.5199)
64.006 - 64.007 (2.5199 - 2.5200)
64.007 - 64.008 (2.5200 - 2.5200)
64.008 - 64.009 (2.5200 - 2.5200)
64.009 - 64.010 (2.5200 - 2.5201)
64.010 - 64.011 (2.5201 - 2.5201)
64.011 - 64.012 (2.5201 - 2.5202)
64.012 - 64.013 (2.5202 - 2.5202)
64.013 - 64.014 (2.5202 - 2.5202)
64.014 - 64.015 (2.5202 - 2.5203)
64.015 - 64.016 (2.5203 - 2.5203)
64.016 - 64.017 (2.5203 - 2.5203)
Difference in inner diameter between cylinders Standard Less than 0.03 (0.0012)
PBIC0923E

SERVICE DATA AND SPECIFICATIONS (SDS)
EM-265
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM

PISTON, PISTON RING AND PISTON PIN
Available Piston
Unit: mm (in)
Piston Ring
Unit: mm (in) ItemsStandard Oversize (Service) [0.2 (0.008)]
VQ23DE VQ35DE VQ23DE VQ35DE
Piston skirt diameter “A”Grade No. 184.980 - 84.990
(3.3457 - 3.3461)95.480 - 95.490
(3.7590 - 3.7594)—
Grade No. 284.990 - 85.000
(3.3461 - 3.3465)95.490 - 95.500
(3.7594 - 3.7598)—
Grade No. 385.000 - 85.010
(3.3465 - 3.3468)95.500 - 95.510
(3.7598 - 3.7602)—
Service —85.180 - 85.210
(3.3535 - 3.3547)95.680 - 95.710
(3.7669 - 3.7681)
ItemsStandard Limit
VQ23DE VQ35DE VQ23DE VQ35DE
“a” dimension 45.4 (1.787) 41.0 (1.614) —
Piston pin hole diameterGrade No. 0 21.993 - 21.999 (0.8659 - 0.8661) —
Grade No. 1 21.999 - 22.005 (0.8661 - 0.8663) —
Piston to cylinder bore clearance 0.010 - 0.030 (0.0004 - 0.0012) 0.08 (0.0031)
SEM882E
ItemsStandard Limit
VQ23DE VQ35DE VQ23DE VQ35DE
Side clearanceTo p0.045 - 0.080
(0.0018 - 0.0031)0.045 - 0.080
(0.0018 - 0.0031)0.11 (0.0043)
2nd0.030 - 0.070
(0.0012 - 0.0028)0.030 - 0.070
(0.0012 - 0.0028)0.10 (0.004)
Oil ring0.045 - 0.125
(0.0018 - 0.0049)0.065 - 0.135
(0.0026 - 0.0053)—
End gapTo p0.20 - 0.30
(0.0079 - 0.0118)0.23 - 0.33
(0.0091 - 0.0130)0.54 (0.0213) 0.47 (0.0185)
2nd0.31 - 0.46
(0.0122 - 0.0181)0.33 - 0.48
(0.0130 - 0.0189)0.67 (0.0264) 0.59 (0.0232)
Oil (rail ring)0.20 - 0.60
(0.0079 - 0.0236)0.20 - 0.50
(0.0079 - 0.0197)0.95 (0.0374) 0.76 (0.0299)

EM-266
[VQ]
SERVICE DATA AND SPECIFICATIONS (SDS)

Piston Pin
Unit: mm (in)
CONNECTING ROD
Unit: mm (in)
*: After installing in connecting rodItems Standard Limit
Piston pin outer diameterGrade No. 0 21.989 - 21.995 (0.8657 - 0.8659) —
Grade No. 1 21.995 - 22.001 (0.8659 - 0.8662) —
Piston to piston pin oil clearance 0.002 - 0.006 (0.0001 - 0.0002) —
Connecting rod bushing oil clearance 0.005 - 0.017 (0.0002 - 0.0007) 0.03 (0.0012)
ItemsStandard
Limit
VQ23DE VQ35DE
Center distance149.75 - 149.85
(5.896 - 5.900)144.15 - 144.25
(5.6752 - 5.6791)—
Bend [per 100 (3.94)] — 0.15 (0.0059)
Torsion [per 100 (3.94)] — 0.3 (0.0118)
Connecting rod bushing inner
diameter*Grade No. 0 22.000 - 22.006 (0.8661 - 0.8664) —
Grade No. 1 22.006 - 22.012 (0.8664 - 0.8666) —
Connecting rod big end diameter (Without bearing)48.000 - 48.013
(1.8898 - 1.8903)55.000 - 55.013
(2.1654 - 2.1659)—
Side clearance 0.20 - 0.35 (0.008 - 0.0138) 0.4 (0.016)

SERVICE DATA AND SPECIFICATIONS (SDS)
EM-267
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM

CRANKSHAFT
Unit: mm (in)
*: Total indicator readingEngineVQ23DE VQ35DE
Main journal diameter “Dm” StandardGrade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W
Grade No. X
Grade No. Y
Grade No. 4
Grade No. 759.974 - 59.975 (2.3612 - 2.3612)
59.973 - 59.974 (2.3611 - 2.3612)
59.972 - 59.973 (2.3611 - 2.3611)
59.971 - 59.972 (2.3611 - 2.3611)
59.970 - 59.971 (2.3610 - 2.3611)
59.969 - 59.970 (2.3610 - 2.3610)
59.968 - 59.969 (2.3609 - 2.3610)
59.967 - 59.968 (2.3609 - 2.3609)
59.966 - 59.967 (2.3609 - 2.3609)
59.965 - 59.966 (2.3608 - 2.3609)
59.964 - 59.965 (2.3608 - 2.3608)
59.963 - 59.964 (2.3607 - 2.3608)
59.962 - 59.963 (2.3607 - 2.3607)
59.961 - 59.962 (2.3607 - 2.3607)
59.960 - 59.961 (2.3606 - 2.3607)
59.959 - 59.960 (2.3606 - 2.3606)
59.958 - 59.959 (2.3605 - 2.3606)
59.957 - 59.958 (2.3605 - 2.3605)
59.956 - 59.957 (2.3605 - 2.3605)
59.955 - 59.956 (2.3604 - 2.3605)
59.954 - 59.955 (2.3604 - 2.3604)
59.953 - 59.954 (2.3603 - 2.3604)
59.952 - 59.953 (2.3603 - 2.3603)
59.951 - 59.952 (2.3603 - 2.3603)
Pin journal diameter “Dp” StandardGrade No. 044.968 - 44.974
(1.7704 - 1.7706)51.968 - 51.974
(2.0460 - 2.0462)
Grade No. 144.962 - 44.968
(1.7702 - 1.7704)51.962 - 51.968
(2.0457 - 2.0460)
Grade No. 244.956 - 44.962
(1.7699 - 1.7702)51.956 - 51.962
(2.0455 - 2.0457)
Center distance “r”34.46 - 34.54
(1.3567 - 1.3598)40.66 - 40.74
(1.6008 - 1.6039)
Out-of-round (Difference between “X” and “Y”)
Limit0.002 (0.0001)
Taper (Difference between “A” and “B”) 0.002 (0.0001)
Crankshaft runout [TIR*]Standard Less than 0.05 (0.002)
Limit 0.1 (0.004)
Crankshaft end playStandard 0.10 - 0.25 (0.004 - 0.0098)
Limit 0.3 (0.02)
SEM645SBIA0535E

EM-268
[VQ]
SERVICE DATA AND SPECIFICATIONS (SDS)

MAIN BEARING
Undersize
Unit: mm (in)
Main Bearing Oil Clearance
Unit: mm (in)
*: Actual clearanceGrade number UPR/LWR Thickness mm (in) Width mm (in) Identification color Remarks
0 — 2.000 - 2.003 (0.0787 - 0.0789)
19.9 - 20.1
(0.783 - 0.791)Black
Grade is the same
for upper and lower
bearings. 1 — 2.003 - 2.006 (0.0789 - 0.0790) Brown
2 — 2.006 - 2.009 (0.0790 - 0.0791) Green
3 — 2.009 - 2.012 (0.0791 - 0.0792) Yellow
4 — 2.012 - 2.015 (0.0792 - 0.0793) Blue
5 — 2.015 - 2.018 (0.0793 - 0.0794) Pink
6 — 2.018 - 2.021 (0.0794 - 0.0796) Purple
7 — 2.021 - 2.024 (0.0796 - 0.0797) White
01UPP 2.003 - 2.006 (0.0789 - 0.0790) Brown
Grade is different
for upper and lower
bearings. LWR 2.000 - 2.003 (0.0787 - 0.0789) Black
12UPR 2.006 - 2.009 (0.0790 - 0.0791) Green
LWR 2.003 - 2.006 (0.0789 - 0.0790) Brown
23UPR 2.009 - 2.012 (0.0791 - 0.0792) Yellow
LWR 2.006 - 2.009 (0.0790 - 0.0791) Green
34UPR 2.012 - 2.015 (0.0792 - 0.0793) Blue
LWR 2.009 - 2.012 (0.0791 - 0.0792) Yellow
45UPR 2.015 - 2.018 (0.0793 - 0.0794) Pink
LWR 2.012 - 2.015 (0.0792 - 0.0793) Blue
56UPR 2.018 - 2.021 (0.0794 - 0.0796) Purple
LWR 2.015 - 2.018 (0.0793 - 0.0794) Pink
67UPR 2.021 - 2.024 (0.0796 - 0.0797) White
LWR 2.018 - 2.021 (0.0794 - 0.0796) Purple
PBIC2619E
Items Thickness Main journal diameter
0.25 (0.0098) 2.132 - 2.140 (0.0839 - 0.0843) Grind so that bearing clearance is the specified value.
Items Standard Limit
Main bearing oil clearance 0.035 - 0.045 (0.0014 - 0.0018)* 0.065 (0.0026)

SERVICE DATA AND SPECIFICATIONS (SDS)
EM-269
[VQ]
C
D
E
F
G
H
I
J
K
L
MA
EM

CONNECTING ROD BEARING
Undersize
Unit: mm (in)
Connecting Rod Bearing Oil Clearance
Unit: mm (in)
*: Actual clearanceGrade number Thickness mm (in) Identification color (mark)
0 1.500 - 1.503 (0.0591 - 0.0592) Black
1 1.503 - 1.506 (0.0592 - 0.0593) Brown
2 1.506 - 1.509 (0.0593 - 0.0594) Green
Items Thickness Crank pin journal diameter
0.25 (0.0098) 1.626 - 1.634 (0.0640 - 0.0643) Grind so that bearing clearance is the specified value.
Items Standard Limit
Connecting rod bearing oil clearance 0.034 - 0.059 (0.0013 - 0.0023)* 0.07 (0.0028)

EM-270
[VQ]
SERVICE DATA AND SPECIFICATIONS (SDS)

EX-1
EXHAUST SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION EX
A
EX

EXHAUST SYSTEM
EXHAUST SYSTEM ................................................... 2Checking Exhaust System ........................................ 2
Removal and Installation .......................................... 2
REMOVAL ............................................................. 3
INSTALLATION ..................................................... 3
INSPECTION AFTER INSTALLATION .................. 4

EX-2
EXHAUST SYSTEM

EXHAUST SYSTEMPFP:20100
Checking Exhaust SystemBBS005AK
Check exhaust pipes, muffler and mounting for improper attachment,
leaks, cracks, damage or deterioration.

If necessary, repair or replace damaged parts.
Removal and InstallationBBS005AL
WARNING:
Be careful not to cut your hand on heat insulator edge.
CAUTION:

Be sure to use genuine exhaust system parts or equivalents which are specially designed for heat
resistance, corrosion resistance, and shape.

Perform the operation with the exhaust system fully cooled down because the system will be hot
just after engine stops.
QR20DE
SMA211A
PBIC4688E
1. Gasket 2. Exhaust front tube 3. Spring
4. Seal bearing 5. Stud bolt 6. Exhaust front tube mounting rubber
