NISSAN TEANA 2003 Service Manual

EXHAUST SYSTEM
EX-3
C
D
E
F
G
H
I
J
K
L
MA
EX

Refer to GI-10, "Components" for symbol marks in the figure.
VQ23DE and VQ35DE
REMOVAL
Disconnect each joint and mounting.
INSTALLATION
Note the following, and install in the reverse order of removal.

If exhaust front tube stud bolts were removed, and install them and tighten to the specified torque below.
CAUTION:

Always replace exhaust tube gaskets with new ones when reassembling.

If heat insulator is badly deformed, repair or replace it. If deposits such as mud pile up on the heat
insulator, remove them.
7. Ground cable 8. Main muffler mounting rubber 9. Main muffler mounting bracket
10. Main muffler (RH) 11. Ring gasket 12. Center muffler mounting rubber
13. Center muffler 14. Center muffler mounting bracket 15. Main muffler mounting rubber
16. Main muffler mounting bracket 17. Main muffler (LH)
PBIC2812E
1. Gasket 2. Exhaust front tube 3. Ring gasket
4. Exhaust front tube mounting bracket 5. Exhaust front tube mounting rubber 6. Center muffler
7. Ground cable 8. Main muffler mounting rubber 9. Main muffler mounting bracket
10. Main muffler (RH) 11. Ring gasket 12. Center muffler mounting rubber
13. Center muffler mounting bracket 14. Main muffler mounting rubber 15. Main muffler mounting bracket
16. Main muffler (LH)
: 14.7 N·m (1.5 kg-m, 11 ft-lb)

EX-4
EXHAUST SYSTEM


When installing heat insulator avoid large gaps or interference between heat insulator and each
exhaust pipe.

Remove deposits from the sealing surface of each connection. Connect them securely to avoid
gas leakage.

Temporarily tighten mounting nuts and bolts on the exhaust manifold side, and mounting bolts
and nuts on the vehicle side. Check each part for unusual interference, and then tighten them to
the specified torque.

When installing each mounting rubber, avoid twisting or unusual extension in up/down and right/
left directions.
Seal Bearing (QR20DE)
1. Securely insert seal bearing into exhaust manifold and three
way catalyst assembly side in the direction as shown in the fig-
ure.
CAUTION:
Be careful not to damage seal bearing surface when install-
ing.
2. With spring large diameter side facing to exhaust front tube
flange, tighten mounting nut.
3. Make sure that stud bolt does not interfere with flange of
exhaust front tube.
INSPECTION AFTER INSTALLATION

Make sure that clearance between tail tube and rear bumper is even.

With engine running, check exhaust tube joints for gas leakage and unusual noises.

Make sure that mounting brackets and mounting rubbers are installed properly and free from undue
stress. Improper installation could result in excessive noise and vibration.
PBIC2432E

FAX-1
FRONT AXLE
D DRIVELINE/AXLE
CONTENTS
C
E
F
G
H
I
J
K
L
M
SECTION FA X
A
B
FA X

FRONT AXLE
PRECAUTIONS .......................................................... 2
Caution ..................................................................... 2
PREPARATION ........................................................... 3
Special Service Tools ............................................... 3
NOISE, VIBRATION AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 4
NVH Troubleshooting Chart ..................................... 4
FRONT WHEEL HUB AND KNUCKLE ...................... 5
On-Vehicle Inspection .............................................. 5
WHEEL BEARING INSPECTION ......................... 5
Removal and Installation .......................................... 5
COMPONENT ....................................................... 5
REMOVAL ............................................................. 5
INSPECTION AFTER REMOVAL ......................... 6
INSTALLATION ..................................................... 7
FRONT DRIVE SHAFT ............................................... 8
On-Vehicle Inspection .............................................. 8
DRIVE SHAFT BOOT REPLACEMENT ............... 8
Removal and Installation (LH) ................................. 11
COMPONENT ...................................................... 11
REMOVAL ............................................................ 11
INSPECTION AFTER REMOVAL ....................... 12
INSTALLATION ................................................... 12
Removal and Installation (RH) ............................... 13
COMPONENT ..................................................... 13
REMOVAL ........................................................... 13
INSPECTION AFTER REMOVAL ....................... 14
INSTALLATION ................................................... 14Disassembly and Assembly (Models With VQ23DE:
LH) .......................................................................... 15
COMPONENT ..................................................... 15
DISASSEMBLY ................................................... 15
INSPECTION AFTER DISASSEMBLY ................ 16
ASSEMBLY ......................................................... 17
Disassembly and Assembly (Models With VQ35DE
and QR20DE: LH) .................................................. 19
COMPONENT ..................................................... 19
DISASSEMBLY ................................................... 19
INSPECTION AFTER DISASSEMBLY ................ 20
ASSEMBLY ......................................................... 20
Disassembly and Assembly (Models With VQ23DE:
RH) ......................................................................... 22
COMPONENT ..................................................... 22
DISASSEMBLY ................................................... 22
INSPECTION AFTER DISASSEMBLY ................ 24
ASSEMBLY ......................................................... 25
Disassembly and Assembly (Models With VQ35DE
and QR20DE: RH) .................................................. 28
COMPONENT ..................................................... 28
DISASSEMBLY ................................................... 28
INSPECTION AFTER DISASSEMBLY ................ 30
ASSEMBLY ......................................................... 30
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 34
Wheel Bearing ........................................................ 34
Drive Shaft .............................................................. 34
Dynamic Damper .................................................... 34

FAX-2
PRECAUTIONS

PRECAUTIONSPFP:00001
CautionBDS0007G
Observe the following precautions when disassembling and assembling drive shaft.

Joint sub-assembly does not disassemble because it is non-overhaul parts.

Perform work in a location which is as dust-free as possible.

Before disassembling and assembling, clean the outside of parts.

Prevention of entry of foreign objects must be taken into account during disassembly of the service loca-
tion.

Disassembled parts must be carefully reassembled in the correct order. If work is interrupted, a clean
cover must be placed over parts.

Paper shop cloths must be used. Fabric shop cloths must not be used because of danger of lint adhering
to parts.

Disassembled parts (except for rubber parts) should be cleaned with kerosene which shall be removed by
blowing with air or wiping with paper shop cloths.

PREPARATION
FAX-3
C
E
F
G
H
I
J
K
L
MA
B
FA X

PREPARATIONPFP:00002
Special Service Tools BDS0007H
Tool number
Tool nameDescription
HT72520000
Ball joint remover
a: 33 mm (1.30 in)
b: 50 mm (1.97 in)
r: 11.5 mm (0.453 in)Removing steering outer socket
KV40107300
Boot band crimping toolInstalling boot band
KV40107500
Drive shaft attachmentRemoving drive shaft
KV38105500
Protector
a: 32 mm (1.26 in) dia.Installing drive shaft
ST17130000
Drift
a: 32 mm (1.26 in) dia.
b: 60 mm (2.36 in) dia.Removing support bearing
ST35271000
Drift
a: 72 mm (2.83 in) dia.
b: 63 mm (2.48 in) dia.Installing support bearing
ST33252000
Drift
a: 82 mm(3.23 in) dia.
b: 60 mm (2.36 in) dia.Installing support bearing
NT546
ZZA1229D
ZZA1230D
ZZA0835D
ZZA0836D
ZZA0837D
ZZA0838D

FAX-4
NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTINGPFP:00003
NVH Troubleshooting ChartBDS0007J
Use chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
×: ApplicableReference page
—
FAX-16
FA X -2 0
FAX-24
FAX-30
—
FAX-5—
FAX-5
NVH in FAX and FSU sections
Refer to Front axle in this chart.
NVH in WT section
NVH in WT section
Refer to DRIVE SHAFT in this chart.
NVH in BR section
NVH in PS section
Possible cause and Suspected parts
Excessive joint angle
Joint sliding resistance
Imbalance
Improper installation, looseness
Parts interference
Wheel bearing damage
FRONT AXLE AND FRONT SUSPENSION
FRONT AXLE
TIRES
ROAD WHEELS
DRIVE SHAFT
BRAKES
STEERING
SymptomDRIVE
SHAFTNoise×× ××××× ××
Shake× × ××××× ××
FRONT
AXLENoise×××× ×××××
Shake×××× ×××××
Vibration×××× × × ×
Shimmy×××××××
Judder× × ×× ××
Poor quality ride or handling×××××

FRONT WHEEL HUB AND KNUCKLE
FAX-5
C
E
F
G
H
I
J
K
L
MA
B
FA X

FRONT WHEEL HUB AND KNUCKLEPFP:40202
On-Vehicle Inspection BDS0007K
Make sure that the mounting conditions (looseness, backlash) of each component and component conditions
(wear, damage) are normal.
WHEEL BEARING INSPECTION

Move wheel hub and bearing assembly in the axial direction by hand. Make sure there is no looseness of
wheel bearing.

Rotate wheel hub and make sure that is no unusual noise or other irregular conditions. If there is any of
irregular conditions, replace wheel hub and bearing assembly
Removal and InstallationBDS0007L
COMPONENT
REMOVAL
1. Remove tires from vehicle.
2. Remove wheel sensor from steering knuckle. Refer to BRC-33, "
WHEEL SENSORS" .
CAUTION:
Do not pull on wheel sensor harness.
3. Remove torque member fixing bolts. Hang torque member in a place where it will not interfere with work.
Refer to BR-26, "
FRONT DISC BRAKE" .
NOTE:
Do not depress brake pedal while brake caliper is removed.
4. Put matching mark on disc rotor and wheel hub and bearing
assembly, then remove disc rotor.
5. Remove cotter pin, then loosen hub lock nut.
6. Remove wheel hub and bearing assembly mounting bolts.Axial end play : 0.05 mm (0.002 in) or less
1. Cotter pin 2. Disc rotor 3. Wheel hub and bearing assembly
4. Splash guard 5. Steering knuckle 6. Stopper bolt
SDIA1756E
SDIA2608E

FAX-6
FRONT WHEEL HUB AND KNUCKLE

7. Separate wheel hub and bearing assembly from drive shaft by
lightly tapping the end with a hammer (suitable tool) and a wood
block, and then remove hub lock nut. Remove wheel hub and
bearing assembly.
CAUTION:

Do not place drive shaft joint at an extreme angle. Also be
careful not to overextend slide joint.

Do not allow drive shaft to hang down without support for
housing (or joint sub-assembly), shaft and the other
parts.
NOTE:
Use a puller (suitable tool) if wheel hub and bearing assembly
and drive shaft cannot be separated even after performing the above procedure.
8. Remove splash guard from steering knuckle.
9. Remove cotter pin of steering outer socket and steering knuckle,
and then loosen nut. Refer to PS-17, "
COMPONENTS" .
10. Remove steering outer socket from steering knuckle so as not to
damage ball joint boot using the ball joint remover [SST].
CAUTION:
Temporarily tighten the nut to prevent damage to threads
and to prevent ball joint remover [SST] from suddenly com-
ing off.
11. Remove nut and bolt, and then remove steering knuckle from
transverse link.
12. Remove fixing nuts and bolts, and then remove steering knuckle
from strut assembly. Refer to FSU-7, "
Components" .
13. Remove stopper bolt from steering knuckle.
INSPECTION AFTER REMOVAL
Check components for deformation, cracks, and other damage. Replace if there are.
Ball Joint Inspection
Check boots of transverse link and steering outer socket ball joint for breakage, axial play, and torque. Refer to
FSU-14, "
INSPECTION AFTER REMOVAL" , “TRANSVERSE LINK”, PS-23, "INSPECTION AFTER DISAS-
SEMBLY" , “STEERING GEAR AND LINKAGE”.
SDIA1821E
SDIA2637E
SGIA0725E
SEIA0411J

FRONT WHEEL HUB AND KNUCKLE
FAX-7
C
E
F
G
H
I
J
K
L
MA
B
FA X

INSTALLATION

Installation is the reverse order of the removal. For tightening torque, refer to FAX-5, "COMPONENT" .
NOTE:
Do not reuse non-reusable parts.

When installing transverse link ball joint, fix bolt to avoid rotation, and then tighten the nut.

Perform the final tightening of each of parts under unladen conditions, which were removed when remov-
ing wheel hub and bearing assembly and steering knuckle. Check the wheel alignment. Refer to FSU-5,
"Wheel Alignment Inspection" .

Adjust neutral position of steering angle sensor after checking the wheel alignment for the models with
VDC. Refer to BRC-40, "
Adjustment of Steering Angle Sensor Neutral Position" .

Check wheel sensor harness for proper connection. Refer to BRC-33, "WHEEL SENSORS" .

Assembly disc rotor and wheel hub and bearing assembly by
aligning each matching mark as shown in the figure when install-
ing disc rotor.
NOTE:
Refer to BR-26, "
FRONT DISC BRAKE" for assembly when
removing disc rotor without matching mark.
SDIA2608E

FAX-8
FRONT DRIVE SHAFT

FRONT DRIVE SHAFTPFP:39100
On-Vehicle InspectionBDS0007M

Check drive shaft mounting point and joint for looseness and other damage.

Check boot for cracks and other damage.
CAUTION:
Replace entire drive shaft assembly when noise or vibration occur from drive shaft.
DRIVE SHAFT BOOT REPLACEMENT
1. Remove tires from vehicle.
2. Remove wheel sensor from steering knuckle. Refer to BRC-33, "
WHEEL SENSORS" .
CAUTION:
Do not pull on wheel sensor harness.
3. Remove torque member fixing bolts. Hang torque member in a place where it will not interfere with work.
Refer to BR-26, "
FRONT DISC BRAKE" .
NOTE:
Do not depress brake pedal while brake caliper is removed.
4. Remove disc rotor. Refer to FA X - 5 , "
Removal and Installation" .
5. Remove cotter pin, then loosen hub lock nut.
6. Separate wheel hub and bearing assembly from drive shaft by
lightly tapping the end with hammer (suitable tool) and a wood
block, and then remove hub lock nut.
CAUTION:

Do not place drive shaft joint at an extreme angle. Also be
careful not to overextend slide joint.

Do not allow drive shaft to hang down without support for
housing (or joint sub-assembly), shaft and the other
parts.
NOTE:
Use a puller (suitable tool) if wheel hub and drive shaft cannot
be separated even after performing the above procedure.
7. Remove fixing nuts and bolts, and then remove steering knuckle
from strut assembly. Refer to FSU-7, "
Components" .
8. Remove drive shaft from wheel hub and bearing assembly.
9. Remove boot bands, and then remove boot from joint sub-
assembly.
10. Screw a drive shaft puller (suitable tool) into joint sub-assembly
screw part to a length of 30 mm (1.18 in) or more. Support drive
shaft with one hand and pull out joint sub-assembly with a slid-
ing hammer (suitable tool) from shaft.
CAUTION:

Align a sliding hammer and drive shaft and remove them
by pulling firmly and uniformly.

If joint sub-assembly cannot be pulled out, try after
removing drive shaft from vehicle.
SDIA1821E
SEIA0411J
SDIA0881J
