AT-360
ASSEMBLY

CAUTION:

Always replace oil pan fitting bolts as they are self-sealing bolts.

Tighten four bolts in a crisscross pattern to prevent dislocation of gasket.
e. Install drain plug gasket on drain plug.
CAUTION:
Do not reuse drain plug gasket.
f. Tighten drain plug to the specified torque. Refer to AT- 2 4 6 , "
Components" .
22. Install PNP switch according to the following procedures.
a. Set manual shaft in “P” position.
b. Temporarily install PNP switch on manual shaft.
c. Move selector lever to “N” position.
d. Use a pin [3 mm (0.12 in) dia.] for this adjustment.
i. Insert the pin straight into the manual shaft adjustment hole.
ii. Rotate PNP switch until the pin can also be inserted straight into
hole in PNP switch.
e. Tighten PNP switch fitting bolts. Refer to AT- 2 4 6 , "
Components"
.
f. Remove pin from adjustment hole after adjusting PNP switch.
23. Install bracket on transaxle case.
24. Install O-ring on revolution sensor.
CAUTION:

Do not reuse O-ring.

Apply petroleum jelly to O-ring.
25. Install revolution sensor on transaxle case.
26. Install O-ring on turbine revolution sensor (power train revolution sensor).
CAUTION:

Do not reuse O-ring.

Apply petroleum jelly to O-ring.
27. Install turbine revolution sensor (power train revolution sensor) on transaxle case.
28. Install bracket on transaxle case.
29. Install torque converter according to the following procedures.
a. Pour ATF into torque converter.
CAUTION:

Approximately 1 liter (7/8 Imp qt) of fluid is required for a
new torque converter.

When reusing old torque converter, add the same amount
of fluid as was drained.
SCIA3154E
SCIA4930E
SAT428DA
